Checks
Coolant level
The coolant level should be closeto the "MA X" mark but should never exceed it.When the engine is warm, the
temperature of the coolant is regulated by the fan. This can operate with the ignition off.
On vehicles which are fitted with a par ticle
emission filter, the fan may operate after the vehicle has been switched off, even if the engine is cold.
In addition, as the cooling system is pressurised,
wait at least one hour after switching off
the engine before carrying out any work.
To avoid any risk of scalding, unscrew the cap
b
y two turns to allow the pressure to drop.
When the pressure has dropped, remove the
cap and top up the level.
Changing the coolant
The coolant does not have to be changed.
Fluid specifi cation
The coolant must conform to the
manufacturer's recommendations.


Fluid specifi cation

For optimum cleaning and to avoid freezing,
this fluid must not be topped up with or
replaced with plain water.
Screenwash and headlamp
wash fluid

In the case of vehicles fitted with
headlamp washers, the low fluid level is indicated by an audible signal anda message in the instrument panelscreen.
Top up the reser voir when you next stop the
vehicle.

220
!
Checks
Avoid prolonged contact of used oil or fluids with the skin. Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids intosewers or onto the ground. Take used oil to a PEUGEOT dealer or a qualified workshop (France) or to an authorised waste disposal site.








Used products
To p p i ng up
This additive must be topped up by a
PEUGEOT dealer or a qualified workshop
w
ithout delay.
Diesel additive level
(Diesel engine with particle
emission filter)
A low additive level is indicated by illumination
of the ser vice warning lamp, accompanied by an audible warning and a message in
the instrument panel screen.

9
221
!
Checks






Checks
12 V battery

The battery does not require any maintenance.
However, check that the terminals are clean
and correctly tightened, particularly in summer and winter.
When carrying out work on the battery, refer to the "Practical information" section for details of the precautions to be
taken before disconnecting the battery and following its reconnection.

Refer to the servicing booklet for
details of the replacement inter vals
for these components.
Dependin
g on the environment(e.g. dusty atmosphere) and the use of the
vehicle (e.g. city driving), replace them twiceas often if necessary (refer to the "Engines"section).
A clogged passenger compar tment filter mayhave an adverse effect on the per formanceof the air conditioning system and generate undesirable odours.
Air filter and passenger compartment filter

Replace the oil filter each time theengine oil is changed.
Refer to the servicing booklet for
details of the replacement inter val
for this component.
Oil filter The presence of this label, in particular with
the Stop & Star t system, indicates the use of a specific 12 V lead-acid battery with special
technology and specification, for which theinvolvement of a PEUGEOT dealer or a qualified workshop is required when replacing
or disconnecting the battery.Failure to obser ve this recommendation may
shor ten the life of the battery.
Unless other wise indicated, check these components in accordance with the ser vicing booklet and according to your engine.

Other wise, have them checked by a PEUGEOT dealer or a qualified workshop.





Before doing anything under the bonnet,switch off the ignition (Ready
lamp off) to avoid any risk of injury resulting fromautomatic operation of the engine.

222
i
Checks





6-speed electronic gear
control gearbox
The gearbox does not require any maintenance (no oil change).
Refer to the servicing booklet for
details of the checking interval for
this component.
Brake wear depends on the style
of driving, par ticularly in the case
of vehicles used in town, over shor t
distances. It may be necessary to have the condition of the brakes checked, evenbetween vehicle services.
Unless there is a leak in the circuit, a drop in
th
e brake fluid level indicates that the brakepads are worn.
Brake pads
Particle emission filter (Diesel)
The star t of saturation of the par ticle
filter is indicated by the temporary
illumination of this warning lamp
accompanied by a message in the
multi-function screen.
As soon as the traffic conditions permit,regenerate the filter by driving at a speed of at least 40 mph (60 km/h) until the warning lamp goes off.If the warning lamp stays on, thisindicates a low additive level.
On a new vehicle, the first par ticle filter regeneration operations may beaccompanied by a "burning" smell,which is perfectly normal.Following prolonged operation of thevehicle at very low speed or at idle,you may, in exceptional circumstances, notice the emission of water vapour atthe exhaust on acceleration. This does not affect the behaviour of the vehicle or the environment.

The 100 % electric mode is not
available during regeneration of thepar ticle emissions filter.

9
223
!
Checks
For information on checking brake
disc wear, contact a PEUGEOT
dealer or a qualified workshop.


Brake disc wear Electric parking brake

This system does not require anyroutine servicing. However, in the event of a problem, have the systemchecked by a PEUGEOT dealer or aqualified workshop.
For more information, see "Driving - Electric parking brake - § Operating faults".
Only use products recommended by PEUGEOT or products of equivalent quality and specification. In order to optimise the operationof units as impor tant as the braking system, PEUGEOT selects and offers very specific products.
To avoid damaging the electrical units, the use of a high pressure washer in the engine compar tment is strictly prohibited.

224
Technical data
ELECTRIC MOTOR AND BATTERY
Electric motor-
Te c h n o l ogy Synchronous with permanent magnets.
Max. power: EU standard
(kW) 27
Max. power speed
(rpm)

2 500

Max. torque: EU standard
(Nm)200

Max. torque speed (rpm)

1 250

Ef ficienc
y (%)
80 to 90

High voltage batteryNi-MH(Nickel Metal Hydride)

Volt age (V~)200

Energy capacity (kWh/Ah)

1.1/5.5

Ran
ge (miles (km))

1. 2 (2) (approximately)

Ran
ge varies according to the ambient climatic conditions, the driving style and conditions, the use of vehicle systems and ageing of the battery.

10
225
Technical data
ENGINE AND GEARBOX
Diesel engine2.0 litre HDi 163 hp
Gearbox

Electronic gear control (6-speed)
Model codes
8URHC8/P

Cubic capacity (cc)

1 997
Bore x stroke
(mm)
85 x 88

Max power: EU standard
(kW) 10 0
120

Max power engine speed (rpm) 3 750
Max torque: EU standard
(Nm)
340

Max torque engine speed (rpm)
2 000

F
uel Diesel

Catalytic converter

yes

Particle emission filter
yes
OIL CAPACITIES (in litres)

Engine (with filter replacement) 5

226
Technical data
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced by 10 % for
each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.
* The kerb wei
ght is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
WEIGHTS AND TOWED LOADS (in kg)
Diesel engines2.0 litre HDi 163 hp
Gearboxes

Electronic gear control
(6-speed)

Model codes8URHC8/P


- Unladen wei
ght1 770



- Kerb weight *

1 845


- Gross vehicle wei
ght (GV W)
2 325



- Gross train wei
ght (GT W)
on a 12% gradient 3 125


- Braked trailer
(within GTW limit) on a 10% or 12% gradient 800



- Braked trailer
**
(with load transfer with the GTW limit)
1 100


- Unbraked trailer
750



- Recommended nose weight
75

10
227
!
Technical data





Dimensions (in mm)
Be aware of the ground clearance of your vehicle: around 184 mm (with the vehicle in working order: driver only and the fuel tank full) in idealconditions.
This value will vary with vehicle load, the nature of the ground surface and the surroundings.
If the driver considers that the vehicle can traverse an obstacle, they assume entire responsibility for this.

228
i
!
Technical data























Identifi cation markings Various visible markings for the identification and tracing of your vehicle.
A.Vehicle Identification Number (VIN) under the bonnet.
This number is engraved on the bodyworknear the damper suppor t.


The tyre pressures must be checked when the tyres are cold, at least oncea month.


Low tyre pressures increase fuelconsumption.

B.Vehicle identification Number (VIN) on
the windscreen lower crossmember.This number is indicated on a self-adhesive label which is visible through the
windscreen.
C.Manufacturer's label. The VIN is indicated on a self-destroying
label affixed to the door aper ture, on the driver's side.
D.Tyre/paint label. This label is fitted to the door aperture or
middle pillar, on the driver's side. It bears the
following information:


- the tyre inflation pressures with and without
load,

- the wheel rim and tyre sizes,

- the brands o
f tyre recommended by the manufacturer,

- the inflation pressure of the spare wheel,

- the paint colour code.
The use of snow chains is onlyauthorised on the front wheels.
The selector must be in 4WD mode.
