RENAULT KANGOO 2016 X61 / 2.G Service Manual
Manufacturer: RENAULT, Model Year: 2016, Model line: KANGOO, Model: RENAULT KANGOO 2016 X61 / 2.GPages: 173, PDF Size: 3.8 MB
Page 41 of 173
JauneNoirNoir texte
1.35
ENG_UD14057_2
Sécurité enfants : installation du siège enfant (X76 - Renault\
)
ENG_NU_854-2_X76LL_Renault_1
³ Check the status of the air bag
before fitting a child seat or allowing a
passenger to use the seat.
Child seat attached using the belt
U = Seat which allows a seat with “uni -
versal” approval to be attached using a
belt.
L = S
eat reserved for fitting a rear -
facing child seat available only from
our network, using a belt.
Using a child safety system
which is not approved for
this vehicle will not cor-
rectly protect the baby or
child. They risk serious or even fatal
injury.
R I S K O F D E AT H O R
SERIOUS INJURY: before
fitting a rear-facing child
seat on the front passen-
ger seat, check that the air bag has
been deactivated (refer to the infor-
mation on “Deactivating the front
passenger air bag” in Section 1).
CHILD SAFETY : Fitting a child seat (6/7)
Page 42 of 173
1.36
ENG_UD14057_2
Sécurité enfants : installation du siège enfant (X76 - Renault\
)
ENG_NU_854-2_X76LL_Renault_1
The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-
tions in force are respected.
(5) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat,
check that the air bag has been deactivated (refer to the information on “Deactivating the front passenger air bag” in
Section
1).
Type of child seat 5-seat version with 1/3-2/3 bench seat
Standard front
passenger seat Rear side seats
Rear centre seat
Carrycot fitted across the vehicle
Group 0 X
U (2)U (2)
Shell seat/rear-facing seat
Groups 0, 0+ and 1 L (1) (5)
U (3)U (3)
Forward-facing seat (1)
Group 1 X
U (4)U (4)
Booster seat (1)
Groups 2 and 3 X
U (4)U (4)
X =
Seat not suitable for fitting child seats.
U = Seat allowing a child seat with “Universal” approval to be attached by seat belt; check that it can be fitted correctly.
L = Reserved for fitting a rear-facing child seat available only from our network, using a belt.
(1) Only
a rear-facing child seat can be fitted in this seat: position the vehicle seat as far back as possible, and gently tilt the seat-
back (approximately 25°).
(2)
A
carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest
the door.
(3) Move
the front seat as far forward as possible to install a rear-facing child seat, then move back the seat or seats in front in
accordance with the child seat instructions.
(4) Forward-facing
child seat; position the seatback of the child seat in contact with the seatback of the vehicle seat. Adjust the
height of the headrest or remove it if necessary; do not push the seat in front of the child more than halfway back on its runners
and do not recline the seatback more than 25°.
CHILD SAFETY : Fitting a child seat (7/7)
Page 43 of 173
child safety............................................ (up to the end of the DU)
transporting children ............................. (up to the end of the DU)
child restraint/seat ................................ (up to the end of the DU)
child restraint/seat ................................ (up to the end of the DU)
air bag deactivating the front passenger air bags ........ (current page)
front passenger air bag deactivation ..................... (current page) 1.37
ENG_UD8776_1
Sécurité enfants : désactivation/Activation airbag passager (X\
76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
Deactivating/activating the front passenger air bag
CHILD SAFETY : deactivating/activating the front passenger air bag (1/2)
Deactivating the front
passenger air bags
(on equipped vehicles)
In order to be able to install a rear-
facing child seat on the front passen-
ger seat you must deactivate the front
passenger seat belt additional restraint
systems. To deactivate the air bags:
with the
vehicle stationary and the ignition off,
insert
the ignition key in lock 1 and turn
to the OFF position.
With the ignition on, you must check
t
hat warning light 2
ã is lit up on
the instrument panel.
This warning light remains continu-
ously lit to let you know that you can
fit a child seat.
DANGER
Since front passenger air
bag triggering and the po-
sition of a rear-facing child
seat are incompatible, it is not per-
mitted to fit such a seat in this posi-
tion unless the vehicle is fitted with
an air bag deactivation device. The
child may suffer very serious injuries
if the air bag inflates.
The label (on the dashboard) and
the markings (on the sun visor)
remind you of these instructions.
2
1
Page 44 of 173
air bagactivating the front passenger air bags ............ (current page)
1.38
ENG_UD8776_1
Sécurité enfants : désactivation/Activation airbag passager (X\
76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
CHILD SAFETY : deactivating/activating the front passenger air bag (2/2)
Activating the front
passenger air bags
You should reactivate the air bag as
soon as you remove the child seat from
the front passenger seat to ensure the
protection of the front passenger in the
event of an impact.
To reactivate the air bags: with the
vehicle stationary and the ignition off,
insert
the ignition key in lock 1 and turn
to the ON position.
With the ignition on, check that warning
light
2
ã is off. The front passenger
seat belt additional restraint systems
are activated.
The passenger air bag must
only be deactivated or acti-
vated when the vehicle is
stationary.
I f a n y o p e r a t i o n i s c a r r i e d
out with the ignition on, the
å
and
ø warning lights come on:
the passenger air bag is deacti-
vated.
Switch the ignition off then on again
to reset the air bag in accordance
with the lock position.
Operating faults
It is forbidden to fit a rear-facing child
seat to the front passenger seat if the
air bag activation/deactivation system
is faulty.
Allowing any other passenger to sit in
that seat is not recommended.
Contact your approved Dealer as soon
as possible.
2
1
Page 45 of 173
audible and visual signals..................... (up to the end of the DU)
hazard warning lights signal ................. (up to the end of the DU)
hazard warning lights signal ................. (up to the end of the DU) 1.39
ENG_UD7269_1
Avertisseurs sonores et lumineux (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
Audible and visual signals
Direction indicators
Move stalk 1 parallel to the steering
wheel and in the direction you are going
to turn it.
When driving on the motorway, the
steering wheel is not often turned
enough to return the stalk automatically
t
o 0 . There is an intermediate position
in which the stalk may be held when
changing lanes.
When the stalk is released, it automati-
cally returns to
0.
Horn
Press at one of the locations 2.
Headlight flasher
Pull stalk 1 towards you to flash the
headlights.
AUDIBLE AND vISUAL SIGNALS
1
2
3
0
1
éHazard warning lights
Press switch 3. This device si-
multaneously activates the four direc-
tion indicators and the side indicator
lights. It must only be used in an emer-
gency to warn other drivers that you
have had to stop in an area where stop-
ping is prohibited or unexpected, or that
you are obliged to drive under special
conditions.
Depending on the vehicle, the hazard
warning lights may come on automati-
cally under heavy deceleration. You can
switch them of
f by pressing switch 3.
Page 46 of 173
1.40
ENG_UD7262_1
Poste de conduite direction à gauche (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
Jaune NoirNoir texte
Driving position
DRIvING POSITION: LEFT -HAND DRIvE (1/2)
12345678910111213
2725242322212019181716151426
Page 47 of 173
JauneNoirNoir texte
1.41
ENG_UD7262_1
Poste de conduite direction à gauche (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
DRIvING POSITION: LEFT -HAND DRIvE (2/2)
The equipment fitted, described below, DEPENDS ON THE vERSION AND COUNTRY.
21 Hazard warning lights switch.
22 Ignition switch.
23 Fuse box.
24 Headlight adjustment control.
25 Door mirror adjustment control.
26 Bonnet release.
27 Rear screen demisting switch.
10 Storage compartment
11 Passenger air bag location.
12 Location for speaker
.
13 Side air vent.
14 Glove box.
15
Location for:
–
radio,
– storage compartment.
16
Controls for ventilation, heating
and de-icing.
17 Gear lever
.
18 Ashtray and cigar lighter
.
19 Handbrake.
20 Cup holder
.
1 Side air vent.
2
Location for speaker.
3
Stalk for:
–
direction indicator lights,
– exterior lights,
– front fog lights,
– rear fog lights.
4
Instrument panel.
5
– Horn.
– Location for driver’s air bag.
6
Radio remote control.
7
Steering column stalk for wind-
screen and rear screen wash/
wipe.
8
Demisting outlets for the wind-
screen.
9
Centre air vents.
Page 48 of 173
control instruments ............................... (up to the end of the DU)
lights: fog lights .......................................................... (current page)
lights: dipped beam headlights ................................... (current page)
lights: direction indicators ........................................... (current page)
lights: side lights ......................................................... (current page)
lights: main beam headlights ...................................... (current page)
indicators: instrument panel ............................. (up to the end of the DU)
instrument panel ................................... (up to the end of the DU)
warning lights........................................ (up to the end of the DU)
1.42
ENG_UD7264_1
Tableau de bord : témoins lumineux (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
Jaune NoirNoir texte
If no lights or sounds are ap-
parent, this indicates a fault
in the instrument panel. This
indicates that it is essential
to stop immediately (as soon as traf-
fic conditions allow). Ensure that the
vehicle is correctly immobilised and
contact an approved Dealer.
Instrument panel
INSTRUMENT PANEL: warning lights (1/4)
VHeated rear screen warning
light
gFront fog light tell-tale light
fRear fog light tell-tale
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT\
AND COUNTRY.
Instrument panel A
In some cases, the appearance of
a warning light is accompanied by
a message.
The
ø warning light means you
should drive very carefully to an
approved Dealer as soon as possi-
ble. You risk damaging your vehicle
If you keep driving after this warning
light has come on.
The û warning light
requires you to stop im-
mediately, for your own
safety, as soon as traffic conditions
allow. Switch off the engine and do
not restart it. Contact an approved
Dealer.
A
LLow fuel level warning light
This goes out as soon as the engine
starts. If it lights up or remains lit, fill up
with fuel as soon as possible. There is
only approximately 30 miles (50 km)
worth of fuel left after the warning light
first comes on.
åAir bag warning light
This lights up when the igni-
tion is switched on and goes out after
a few seconds. If it does not come on
when the ignition is switched on or if it
flashes, there is a fault in the system.
Contact your approved Dealer as soon
as possible.
Page 49 of 173
rear screendemisting ......................................................... (current page)
Jaune NoirNoir texte
1.43
ENG_UD7264_1
Tableau de bord : témoins lumineux (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
INSTRUMENT PANEL: warning lights (2/4)
6
Electronic fault and water
present in diesel fuel warn-
ing light (on petrol and diesel
versions) and preheating warning
light (on diesel versions)
Electronic fault warning light (on
petrol and diesel versions). If it comes
on while driving, it indicates an electri-
cal or electronic fault or that water is
present in the fuel. Contact your ap-
proved Dealer as soon as possible.
Preheating and water present in
diesel fuel warning light (on diesel
version).
This light should come on when the ig-
nition key is in position M; it indicates
that the heater plugs are in operation.
It goes out after preheating is sufficient
and the engine can be started.
ãFront passenger air bag de-
activated warning light
Refer to the information on “Child
safety” in Section 1.
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT\
AND COUNTRY.
A
oMain beam headlight tell-tale
light
mDipped beam headlight tell-
tale
cLeft-hand direction indicator
tell-tale light
bRight-hand direction indica-
tors tell-tale light .
ÔCoolant temperature warn-
ing light
If it comes on while you are driving,
stop and let the engine idle for a minute
or two. The temperature should drop. If
not, stop the engine. Let the engine cool
down, then check the coolant level.
Contact an approved Dealer if neces-
sary.
êEngine immobiliser system
warning light
Refer to section 1 on the engine immo-
biliser.
çSeat belt reminder light
It remains lit when the engineis started,
when the seat belt is not fas-tened, then
when the vehicle reaches a speed
of approximately 6 mph (10 km/h), it
flashes and a bleep sounds for approxi-
mately 90 seconds.
vDoor status warning light
If it lights up when the ignition
is switched on, it indicates that a door is
not properly closed.
Page 50 of 173
1.44
ENG_UD7264_1
Tableau de bord : témoins lumineux (X76 - Renault)
ENG_NU_854-2_X76LL_Renault_1
Jaune NoirNoir texte
INSTRUMENT PANEL: warning lights (3/4)
The presence and operation of the warning lights DEPEND ON THE EQUIPMENT\
AND COUNTRY.
A
DHandbrake “on” warning
light and brake circuit inci-
dent warning light
If it comes on during braking, it indicates
a low level in the circuits; it may be dan-
gerous to continue driving. Contact an
approved Dealer as soon as possible.
If it lights up at the same time as the
warning light
z it indicates that the
brake pads need replacing.
ÀOil pressure warning light
If it comes on while you are
driving, stop at once and switch off the
ignition. Check the oil level (refer to
section 4 “Engine oil level”). If the level
is normal, the light has come on for
another reason: contact an approved
Dealer as soon as possible.
zBrake pad wear warning
light
If the warning light comes on when you
brake, have your brake pads checked
as soon as possible.
xAnti-lock braking warning
light
This lights up when the ignition is
switched on and goes out after a few
seconds. If it does not go out after the
ignition is switched on, or lights up
when driving, there is a fault with the
ABS. Braking will then operate as on
a vehicle without ABS. Contact an ap-
proved Dealer as soon as possible.
ÄWarning light for monitoring
exhaust gas
It comes on when the ignition is switched
on and then goes out.
–
If it lights up continuously, consult an
approved Dealer as soon as possi-
ble;
–
If it flashes, reduce the engine speed
until the light stops flashing. Contact
your approved dealer as soon as
possible.
Refer to the information on “Special op-
erating conditions” in Section 2.
ÚBattery charge warning light
If it comes on when you are driving, it
indicates that the circuit is overcharged
or has discharged. Stop as soon as
traffic conditions allow and contact an
approved dealer.
î or Z LPG operating tell-
tale
Refer to the specific document for LPG
vehicles.
