LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 13
CONTINUED
Cut the + accessories feed (for at least 1 minute) then reactivate it.
Is the fault still present?
NO YES
End of fault finding.
In the event of an intermittent fault, contact the
Techline.
Contact the Techline.
AFTER REPAIRCarry out a complete check with the diagnostic tool.

86A-82
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 14The volume does not increase in accordance with the vehicle
speed
NOTESOnly check the customer complaint after performing a full check with the diagnostic
tool.
Ensure there are no present or stored faults.
Check the correction value of the speed-dependent volume in the "Audio" menu (accessed by pressing the SET
button), then select "menu", "audio" and "Main options": volume/speed.
Setting 0: no adjustment.
Setting 5: maximum adjustment.
Increase the adjustment value to 5.
Has the fault disappeared?
NO YES
Check the conformity of parameter PR010 Vehicle
speed.
Has the fault disappeared?
NO
Contact the Techline.
The recommended adjustment level is level 3.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP14

86A-83
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 15 No traffic information messages on the screen
NOTESOnly consult this customer complaint after a complete check with the diagnostic
tool.
Ensure there are no present or stored faults.
Place the vehicle in an open area for 5 minutes with the system switched on.
Traffic information (TMC) is transmitted via the radio's FM band.
Switch on the traffic information function (see handbook).
Press the "SET" button to display the settings menu. Select "Navigation" then "Traffic information (TMC)" then
"Select service".
Use automatic selection to find the optimum service with the clearest reception (see handbook).
Is the system set to automatic selection?
YES NO
No TMC service can be decoded in the
geographical area:
–Either the vehicle is in a reception dead spot,
–or the country in question does not offer a service
decodable by the system.
End of fault finding.
Activate traffic information automatic selection (see
handbook).
Carry out a road test.
Has the fault disappeared?
NO
No TMC service can be decoded in the
geographical area:
–Either the vehicle is in a reception dead spot,
–or the country in question does not offer a service
decodable by the system.
If the fault is still present, apply ALP 3 Poor
guidance/Poor positioning/GPS fault.
YES
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP15

86A-84
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 16 Screen display frozen
NOTESOnly check the customer complaint after performing a full check with the diagnostic
tool.
Ensure there are no present or stored faults.
Cut the + accessories feed (for at least 1 minute) then reactivate it.
Has the fault disappeared?
YES NO
End of fault finding.
In the event of an intermittent fault, contact the
Techline.
Contact the Techline.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP16

86A-85
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 17 The screen displays Connect a diagnostic tool
NOTESOnly consult this customer complaint after a complete check with the diagnostic
tool.
Ensure there are no present or stored faults.
The navigation computer configuration has not been carried out.
Configure the computer (see Configuration and programming).
Has the fault disappeared?
YES NO
End of fault finding.
Carry out a multiplex network test.
Are the tests correct?
YES NO
Contact the Techline.
Repair the defective
connections.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP17

86A-86
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 18 Telephone cannot be used with the Bluetooth function
NOTESOnly consult this customer complaint after a complete check with the diagnostic
tool.
Ensure there are no present or stored faults.
Check that Bluetooth mode is activated in the navigation and communication system.
Press the SET button and select the Telephone, Bluetooth option and Bluetooth connection menus.
Has the telephone been researched by Renault?
YES
Check that the telephone software on the telephone
is compatible with the vehicle's navigation and
communication system.
Consult the list of compatible phones on the
"RENAULT.net intranet" site.
Is the telephone software compatible with the
vehicle's navigation and communication
system?
YES
Activate the telephone's Bluetooth mode.
NOSuggest that the customer buy a telephone
approved by Renault.
List of compatible phones on the
"RENAULT.net intranet" site.
NOAsk the customer to contact the teleph one
vendor in order to install a software version
into the telephone that would be compatible
with the navigation and communication
system.
Refer to the phone's manual to activate its
Bluetooth mode.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP18

86A-87
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 18
CONTINUED 1
Match up the navigation and communication system
and the telephone.
Was the match successful?
YES
Check that the telephone does not require
confirmation before being connected to the
Bluetooth system.
If it does, respond that you wish to connect then
disable this function on the phone.
NO
Test the Bluetooth terminal on the
navigation computer.
Procedure for matching the communication
system and the telephone:
On the navigation and communication system:
–Press the SET button.
–Access the Telephone menu.
–Select the Bluetooth option line.
–Select the Save a Bluetooth telephone line.
On the telephone:
–Enter the menu to find a Bluetooth accessory.
–In the list of accessories found, select My CAR.
–Enter the PIN code given on the vehicle's
navigation display.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
B

86A-88
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 18
CONTINUED 2
Check that the telephone is at the top of the
matched phones list (icon opposite its name).
Is the telephone at the top of the list?
YES
Try to match another telephone to the vehicle's
navigation and communication system.
Was the match successful?
YES
The customer's telephone is definitely the reason
why it does not work with the navigation and
communication system.
NOPut the telephone at the top of the list of
telephones matched to the navigation and
communication system.
NOIf the fault has not been solved, contact
Techline.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
B

86A-89
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 19The person I am calling using the communication system cannot
hear me well or cannot hear me at all (in Bluetooth mode)
NOTESOnly consult this customer complaint after a complete check with the diagnostic
tool.
Ensure there are no present or stored faults.
Check that the telephone network availability is sufficient to make a call.
Make a call to a fixed line.
Is the fault still present?
YES
With the engine stopped, does the voice
recognition work for the words "phonebook"
and "dial"?
YES
NOThe fault is linked to the number the customer
is calling or to a localised lack of network
availability.
NOCheck the condition and connection of the
microphone connector.
Repair if necessary.
Check that the microphone part number is
correct. If not, replace the microphone.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
LPN_VC4_ALP19

86A-90
MR-372-J84-86A050$944.mif
V3
LPN RADIO
Vdiag No.: C4RADIO
Fault finding - Fault Finding Chart86A
ALP 19
CONTINUED
Check the condition and connection of the
connectors of the telephone support base plate, the
navigation computer and the radio. Carry out the
necessary repairs.
Match up another telephone and make a call.
Is the fault still present?
YES NO
If the fault is still
present, contact the
Techline.
The fault is probably
linked to the
telephone. Ask the
customer to carry out a
fault finding procedure
on the telephone.
Procedure for matching the communication
system and the telephone:
On the navigation and communication system:
–Press the SET button.
–Access the Telephone menu.
–Select the Bluetooth option line.
–Select the Save a Bluetooth telephone line.
On the telephone:
–Enter the menu to find a Bluetooth accessory.
–Bluetooth.
–In the list of accessories found, select My CAR.
–Enter the PIN code given on the vehicle's
navigation display.
AFTER REPAIRCarry out a complete check with the diagnostic tool.
