20.Cylinder Block
A: REMOVAL
NOTE:
Before conducting this procedure, drain the engine
oil completely if applicable.
1) Remove the intake manifold. FU(H4DOTC)-14, REMOVAL, Intake Manifold.> or
Manifold.>
2) Remove the V-belt. REMOVAL, V-belt.>
3) Remove the crank pulley. ME(H4DOTC)-55, REMOVAL, Crank Pulley.>
4) Remove the timing belt cover. ME(H4DOTC)-57, REMOVAL, Timing Belt Cover.>
5) Remove the timing belt assembly. ME(H4DOTC)-58, REMOVAL, Timing Belt Assem-
bly.>
6) Remove the cam sprocket. ME(H4DOTC)-67, REMOVAL, Cam Sprocket.>
7) Remove the crank sprocket. ME(H4DOTC)-68, REMOVAL, Crank Sprocket.>
8) Remove the generator and A/C compressor with
their brackets.
9) Remove the cylinder head assembly. ME(H4DOTC)-76, REMOVAL, Cylinder Head As-
sembly.>
10) Remove the clutch disc and cover. (MT model)
er.>
11) Remove the flywheel. (MT model) 19, REMOVAL, Flywheel.>
12) Remove the drive plate. (AT model)
Using the ST, lock crankshaft.
ST 498497100 CRANKSHAFT STOPPER
13) Remove the oil separator cover.
14) Remove the water by-pass pipe for heater.
15) Remove the oil filter using ST.
ter.>16) Remove the oil cooler.
17) Removal of oil pan:
(1) Turn the cylinder block with #2 and #4 piston
sides facing upward.
(2) Remove the bolts which secure oil pan to
cylinder block.
(3) Insert an oil pan cutter blade between cylin-
der block-to-oil pan clearance, and then remove
the oil pan.
Do not use a screwdriver or similar tool in place
of oil pan cutter.
18) Remove the oil strainer stay.
19) Remove the oil strainer.
20) Remove the baffle plate.
21) Remove the water pipes.
22) Remove the water pump.
23) Remove the oil pump from cylinder block.
Use a flat-bladed screwdriver as shown in the fig-
ure when removing the oil pump.
ME-00136
ST
(A) Adapter (1)
(B) Adapter connector
(C) Adapter (2)
(D) Oil cooler
(E) Oil cooler connector
LU-00041
(A)
(B)
(C)
(D)
(E)

ME(H4DOTC)-84
MECHANICAL
Cylinder Block
NOTE:
Be careful not to scratch the mating surface of cyl-
inder block and oil pump.
ME-00138
(1) Service hole plug (3) Circlip (5) Service hole cover
(2) Gasket (4) Piston pin (6) O-ring
ME-00139
(3)
(4) (2)(1)
(3)
(4)
(5)
(6)
(2)(3)
(2)
(1)(3)(4)
(4)
(1)

ME(H4DOTC)-85
MECHANICAL
Cylinder Block
24) Remove the service hole cover and service
hole plugs using hexagon wrench [14 mm (0.55
in)].
25) Rotate the crankshaft to bring #1 and #2 pis-
tons to bottom dead center position, and then re-
move the piston circlip through service hole of #1
and #2 cylinders.
26) Draw out the piston pin from #1 and #2 pistons
using ST.
ST 499097600 PISTON PIN REMOVER (2.0
L model)
ST 499097700 PISTON PIN REMOVER (2.5
L model)
NOTE:
Be careful not to confuse the original combination
of piston, piston pin and cylinder.
27) Similarly remove the piston pins from #3 and #4
pistons.
28) Remove the bolts which connect the cylinder
block on the side of #2 and #4 cylinders.29) Back off the bolts which connect the cylinder
block on the side of #1 and #3 cylinders two or
three turns.
30) Set up the cylinder block so that #1 and #3 cyl-
inders are on the upper side, then remove the cyl-
inder block connecting bolts.
31) Separate the cylinder blocks (LH) and (RH).
ME-00140
ME-00141
ME-00142
ST

ME(H4DOTC)-86
MECHANICAL
Cylinder Block
NOTE:
When separating the cylinder block, do not allow
the connecting rod to fall and damage the cylinder
block.
32) Remove the rear oil seal.
33) Remove the crankshaft together with connect-
ing rod.
34) Remove the crankshaft bearings from cylinder
block using a hammer handle.
NOTE:
Do not confuse the combination of crankshaft bear-
ings. Press the bearing at the end opposite to lock-
ing lip.
35) Draw out each piston from cylinder block using
a wooden bar or hammer handle.
NOTE:
Do not confuse the combination of piston and cylin-
der.
(1) Cylinder block (3) Crankshaft (5) Piston
(2) Rear oil seal (4) Crankshaft bearing
ME-00143
(2)
(3)(4)
(4) (5)
(5) (1) (1)

ME(H4DOTC)-87
MECHANICAL
Cylinder Block
B: INSTALLATION
1. 2.0 L MODEL
1) Remove oil in the mating surface of bearing and
cylinder block before installation. Also apply a coat
of engine oil to crankshaft pins.
2) Position the crankshaft on #2 and #4 cylinder
block.
3) Apply liquid gasket to the mating surface of #1
and #3 cylinder block, and position it on #2 and #4
cylinder block.
Liquid gasket:
Part No. 004403007
THREE BOND 1215 or equivalentNOTE:
Do not allow liquid gasket to jut into O-ring grooves,
oil passages, bearing grooves, etc.
4) Apply a coat of engine oil to washers and bolt
threads.
(1) Crankshaft bearing (3) Cylinder block (4) Rear oil seal
(2) Crankshaft
ME-00144
( 1 )
( 1 )
( 2 )
( 3 )
( 3 )
( 4 )
ME-00145

ME(H4DOTC)-88
MECHANICAL
Cylinder Block
5) Tighten the 10 mm cylinder block connecting
bolts in alphabetical sequence shown in the figure.
(LH side)
Tightening torque:
15 N
⋅m (1.5 kgf-m, 10.8 ft-lb)
6) Tighten the 10 mm cylinder block connecting
bolts in alphabetical sequence shown in the figure.
(RH side)
Tightening torque:
15 N
⋅m (1.5 kgf-m, 10.8 ft-lb)
7) Further tighten the LH side bolts (A — D) to 90°
in alphabetical sequence.8) Further tighten the RH side bolts (E — J) to 90°
in alphabetical sequence.
9) Tighten the 8 mm and 6 mm cylinder block con-
necting bolts in alphabetical sequence shown in the
figure.
Tightening torque:
(A) — (G): 25 N
⋅m (2.5 kgf-m, 18.1 ft-lb)
(H): 6.4 N
⋅m (0.65 kgf-m, 4.7 ft-lb)
10) Install the rear oil seal using ST1 and ST2.
ST1 499597100 CRANKSHAFT OIL SEAL
GUIDE
ST2 499587200 CRANKSHAFT OIL SEAL IN-
STALLER
11) Position the top ring gap at (A) or (B) in the fig-
ure.
12) Position the second ring gap at 180° on the re-
verse side for the top ring gap.
ME-00398
(A)
(B)
(C) (D)
ME-00399
(E)(G)
(F)(I)
(J)
(H)
ME-00398
(A)
(B)
(C) (D)
(A) Rear oil seal
(B) Flywheel attaching bolt
ME-00399
(E)(G)
(F)(I)
(J)
(H)
ME-00147
(B)(C)
(D)
(E)
(F)
(G)
(H)
(A)
ME-00148
ST1
ST2
(B)
(A)

ME(H4DOTC)-89
MECHANICAL
Cylinder Block
13) Position the expander gap at (C) in the figure.
14) Position the lower rail gap at (D) in the figure.
15) Align lower rail spin stopper (F) with piston side
surface hole (E).16) Position the upper rail gap at (G) in the figure.
NOTE:
 Ensure ring gaps do not face the same direction.
 Ensure ring gaps are not within the piston skirt
area.
17) Install the circlip.
Install the circlips in piston holes located opposite
of service holes in cylinder block, when positioning
all pistons in the corresponding cylinders.
ME-00718
(A)(B)
180
ME-00719
(C)
ME-00720
(D)
25
ME-00152
ME-00721
(G)
0 20

ME(H4DOTC)-90
MECHANICAL
Cylinder Block
NOTE:
Use new circlips.
18) Installing the piston:
(1) Turn the cylinder block so that #1 and #2 cyl-
inders face upward.
(2) Using the ST1, turn the crankshaft so that
#1 and #2 connecting rods are set at bottom
dead center.
ST1 499987500 CRANKSHAFT SOCKET
(3) Apply a coat of engine oil to the pistons and
cylinders and insert pistons in their cylinders us-
ing ST2.ST2 398744300 PISTON GUIDE
NOTE:
Piston front mark faces towards the front of the en-
gine.
(A) Front side
ME-00154
#4 #3
#2 #1
(A)
(1) Piston (4) GasketTightening torque: N⋅m (kgf-m, ft-lb)
(2) Piston pin (5) Service hole plugT: 70 (7.1, 51.4)
(3) Circlip
ME-00155
(1) (1)
(2)
(2) (3)
(3) (4)
(4) (5)
(5)
T
ME-00157
ST2
ST1
