SUBARU FORESTER 2004 Service Repair Manual

EX(H4DOTC)-15
EXHAUST
Rear Exhaust Pipe
3) Install the rear exhaust pipe to center exhaust
pipe.
Tightening torque:
18 N·m (1.8 kgf-m, 13.0 ft-lb)
4) Lower the vehicle.
5) Connect the battery ground cable to battery.
C: INSPECTION
1) Make sure there are no exhaust leaks from con-
nections and welds.
2) Make sure there are no holes or rusting.
3) Make sure the cushion rubber is not worn or
cracked.
EX-00045
FU-00009

EX(H4DOTC)-16
EXHAUST
Muffler
6. Muffler
A: REMOVAL
1) Separate the muffler from rear exhaust pipe.
CAUTION:
Be careful, the exhaust pipe is hot.
2) Remove the cushions rubber, and detach the
muffler.
CAUTION:
Be careful not to drop the muffler during remov-
al.
NOTE:
To facilitate removal, apply a coat of SUBARU
CRC to the mating area of cushions rubber in ad-
vance.
SUBARU CRC (Part No. 004301003)
B: INSTALLATION
Install in the reverse order of removal.
NOTE:
Replace the gasket and nuts with new ones.
Tightening torque:
48 N·m (4.9 kgf-m, 35.4 ft-lb)
C: INSPECTION
1) Make sure there are no exhaust leaks from con-
nections and welds.
2) Make sure there are no holes or rusting.
3) Make sure the cushions rubber is not worn or
cracked.
EX-00020
EX-00022
EX-00020

FUJI HEAVY INDUSTRIES LTD. G8080GE3
