SUBARU FORESTER 2004 Service Repair Manual

LUBRICATION
LU(H4DOTC 2.5)
Page
1. General Description ....................................................................................2

LU(H4DOTC 2.5)-2
LUBRICATION
General Description
1. General Description
A: SPECIFICATION
Specifications for 2.5 L model are included in
LU(H4SO) section. Description.>

FUJI HEAVY INDUSTRIES LTD. G8080GE4
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
ENGINE SECTION 3
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.FUEL INJECTION (FUEL SYSTEM) FU(H4DOTC 2.5)
EMISSION CONTROL
(AUX. EMISSION CONTROL DEVICE)EC(H4DOTC 2.5)
INTAKE (INDUCTION) IN(H4DOTC 2.5)
MECHANICAL ME(H4DOTC 2.5)
EXHAUST EX(H4DOTC 2.5)
COOLING CO(H4DOTC 2.5)
LUBRICATION LU(H4DOTC 2.5)
SPEED CONTROL SYSTEM SP(H4DOTC 2.5)
IGNITION IG(H4DOTC 2.5)
STARTING/CHARGING SYSTEM SC(H4DOTC 2.5)
ENGINE (DIAGNOSTIC) EN(H4DOTC 2.5)

SPEED CONTROL SYSTEM
SP(H4DOTC 2.5)
Page
1. General Description ....................................................................................2
2. Accelerator Pedal ........................................................................................4

SP(H4DOTC 2.5)-2
SPEED CONTROL SYSTEM
General Description
1. General Description
A: SPECIFICATION
B: COMPONENT
Accelerator pedalFree play At pedal pad 0 — 4 mm (0 — 0.16 in)
Stroke At pedal pad 52 — 57 mm (2.05 — 2.24 in)
(1) Accelerator pedal bracket (4) Accelerator pedalTightening torque: N·m (kgf-m, ft-lb)
(2) Accelerator pedal ASSY (5) Spring pinT: 18 (1.8, 13.0)
(3) Accelerator pedal spring (6) Accelerator stopper
(6)
(1)
(2)
(5)(3)
(4)
SP-00002
T
T
T
T
T

SP(H4DOTC 2.5)-3
SPEED CONTROL SYSTEM
General Description
C: CAUTION
 Wear work clothing, including a cap, protective
goggles, and protective shoes during operation.
 Remove contamination, including dirt and corro-
sion, before removal, installation or disassembly.
 Keep the disassembled parts in order and pro-
tect them from dust and dirt.
 Before removal, installation or disassembly, be
sure to clarify the failure. Avoid unnecessary re-
moval, installation, disassembly, and replacement.
 Be careful not to burn your hands, because each
part in the vehicle is hot after running.
 Be sure to tighten fasteners including bolts and
nuts to the specified torque.
 Place shop jacks or rigid racks at the specified
points.
 Before disconnecting electrical connectors of
sensors or units, be sure to disconnect the ground
cable from battery.

SP(H4DOTC 2.5)-4
SPEED CONTROL SYSTEM
Accelerator Pedal
2. Accelerator Pedal
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Disconnect the connector.
3) Remove the nuts which securing accelerator
pedal assembly.
B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
18 N·m (1.8 kgf-m, 13.0 ft-lb)
C: DISASSEMBLY
NOTE:
Accelerator pedal for 2.5 L model is a non-disas-
semble part.
SP-00011

FUJI HEAVY INDUSTRIES LTD. G8080GE4
2004 FORESTER SERVICE MANUAL QUICK REFERENCE INDEX
ENGINE SECTION 3
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.FUEL INJECTION (FUEL SYSTEM) FU(H4DOTC 2.5)
EMISSION CONTROL
(AUX. EMISSION CONTROL DEVICE)EC(H4DOTC 2.5)
INTAKE (INDUCTION) IN(H4DOTC 2.5)
MECHANICAL ME(H4DOTC 2.5)
EXHAUST EX(H4DOTC 2.5)
COOLING CO(H4DOTC 2.5)
LUBRICATION LU(H4DOTC 2.5)
SPEED CONTROL SYSTEM SP(H4DOTC 2.5)
IGNITION IG(H4DOTC 2.5)
STARTING/CHARGING SYSTEM SC(H4DOTC 2.5)
ENGINE (DIAGNOSTIC) EN(H4DOTC 2.5)

IGNITION
IG(H4DOTC 2.5)
Page
1. General Description ....................................................................................2

IG(H4DOTC 2.5)-2
IGNITION
General Description
1. General Description
A: SPECIFICATION
Specifications for 2.5 L model are included in
IG(H4DOTC) section. eral Description.>
