TOYOTA LAND CRUISER 1996 J80 Workshop Manual

BO385−01
−
BODY REAR WIPER AND WASHER
BO−31
1265
Author: Date:
1996 LAND CRUISER (RM451U)
REAR WIPER AND WASHER
REMOVAL
1. REMOVE PULL HANDLE AND PULL HANDLE BEZEL
2. REMOVE BACK DOOR TRIM
(a) Insert a screwdriver between the retainers and door trim
to pry it loose.
HINT:
Tape the screwdriver tip before use.
(b) Remove the back door trim.
3. REMOVE WIPER ARM, MOTOR AND REAR WIPER CONTROL RELAY
(a) Open the cap.
(b) Remove the nut and wiper arm.
(c) Remove the 5 bolts and motor, then disconnect the con- nector.
(d) Remove the bolts and rear wiper control relay,then dis- connect the connector.
4. ADJUST REAR WASHER NOZZLE
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO386−01
BO−32
−
BODY REAR WIPER AND WASHER
1996 LAND CRUISER (RM451U)
INSPECTION
INSPECT REAR WASHER NOZZLE
While operating the washer, check whether the point where the
washer fluid hits the back door glass and the upsurge area are
within the range indicated by the hatched line.
AApprox. 120 mm (4.72 in.)
BApprox. 120 mm (4.72 in.)
CApprox. 90 mm (3.54 in.)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO387−01
−
BODY REAR WIPER AND WASHER
BO−33
1996 LAND CRUISER (RM451U)
INSTALLATION
1. INSTALL WIPER CONTROL RELAY
2. INSTALL WIPER MOTOR
Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
3. INSTALL BACK DOOR TRIM
4. INSTALL PULL HANDLE BEZEL
5. INSTALL PULL HANDLE
6. INSTALL REAR WIPER ARM
(a) Install the wiper arm and operate the wipers once and turn
the wiper switch OFF.
(b) Adjust the installation positions of the wiper arm to the positions shown in the illustration.
A: Approx. 40 mm (1.57 in.)
(c) Tighten the nut. Torque: 5.4 N·m (55 kgf·cm, 48 in.·lbf)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48L−01
BO−34
−
BODY BODY OUTSIDE MOULDING
1268
Author: Date:
1996 LAND CRUISER (RM451U)
BODY OUTSIDE MOULDING
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48M−01
BO5153
−
BODY BODY OUTSIDE MOULDING
BO−35
1996 LAND CRUISER (RM451U)
REMOVAL
1. REMOVE ROOF DRIP MOULDING
Using SST, pull off the roof drip moulding from front ends.
SST 09806−30010
2. REMOVE FRONT DOOR BELT MOULDING (See page BO−9)
3. REMOVE REAR DOOR BELT MOULDING (See page
BO−15 )
4. REMOVE QUARTER BELT MOULDING
Pry out the clips from the edge of the panel, and remove the
moulding.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48N−01
BO−36
−
BODY BODY OUTSIDE MOULDING
1996 LAND CRUISER (RM451U)
INSTALLATION
1. INSTALL ROOF DRIP MOULDING
Attach the upper edge of the moulding to the body flange. Tap
on the moulding by hand.
2. INSTALL FRONT DOOR BELT MOULDING
3. INSTALL REAR DOOR BELT MOULDING
4. INSTALL QUARTER BELT MOULDING
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48O−01
Front Fender
Wheel Moulding
Quarter
Outside
Moulding
−
BODY WHEEL OPENING MOULDING
BO−37
1271
Author: Date:
1996 LAND CRUISER (RM451U)
WHEEL OPENING MOULDING
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48P−01
N14081
N14075
BO−38
−
BODY WHEEL OPENING MOULDING
1996 LAND CRUISER (RM451U)
REMOVAL
1. REMOVE FRONT FENDER WHEEL OPENING MOULDING
(a) Remove the charcoal canister.
(b) Remove the air cleaner case assembly.
(c) Remove the cool air intake duct.
(d) Remove the front wheel.
(e) Remove the front mudguard.
(f) Remove the front bumper extension.
(g) Remove the 4 nuts from engine room inside service hole.
(h) Remove the 2 screws.
(i) Remove the front wheel opening extension.
2. REAR DOOR SIDE: REMOVE REAR WHEEL OPENING MOULDING
Remove the 2 bolts and moulding.
3. REMOVE REAR WHEEL OPENING MOULDING
(a) Remove the mud guard, bumper extention and back door
scuff plate.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

N14076
N14077
N14078
N14079
N14440
−
BODY WHEEL OPENING MOULDING
BO−39
1996 LAND CRUISER (RM451U)
(b) Remove the quarter trim RH.
(c) Remove the quarter trim LH.
4. REMOVE QUARTER OUTSIDE MOULDING
(a) Remove the 2 nuts.
(b) Remove the screw.
(c) Using a screwdriver, pry out the rearwheel moulding.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

BO48Q−01
N14082
BO−40
−
BODY WHEEL OPENING MOULDING
1996 LAND CRUISER (RM451U)
INSTALLATION
1. INSTALL FRONT WHEEL OPENING MOULDING
(a) Install the front wheel opening moulding.
(b) Install the 4 nuts from the service hole of the engine room
inside.
(c) Install the 2 screws.
(d) Front bumper extension
(e) Front mudguard
(f) Front wheel
(g) Cool air intake duct
(h) Air cleaner case assembly
(i) Charcoal canister
2. INSTALL QUARTER OUTSIDE MOULDING
Install the quarter outside moulding with the 2 bolts.
3. INSTALL REAR WHEEL OPENING MOULDING
(a) Install the rear wheel opening moulding with the 2 nuts.
(b) Install the screw.
(c) Install the quarter trim LH.
(d) Install the quarter trim RH.
(e) Install the back door scuff plate.
(f) Install the rear bumper extension.
(g) Install the rear mudguard.
