TOYOTA RAV4 2020 Owners Manual (in English)

71110-1. For owners
10
For owners
AVERTISSEMENT
●Si les emplacements de stock-
age des coussins gonflables
SRS, tels que le tampon de
volant et les garnitures des
montants avant et arrière, sont
endommagés ou fissurés,
faites-les remplacer par votre
concessionnaire Toyota.
●Ne placez aucun objet, par
exemple un coussin, sur le
siège du passager avant. Cela
disperserait le poids du pas-
sager, ce qui empêcherait le
capteur de le détecter correcte-
ment. Cela pourrait empêcher le
déploiement des coussins gon-
flables SRS du passager avant
en cas de collision.
■Modification et mise au rebut
des composants du système
de coussins gonflables SRS
Ne mettez pas votre véhicule au
rebut et n’effectuez aucune des
modifications suivantes sans
d’abord consulter votre conces-
sionnaire Toyota. Les coussins
gonflables SRS pourraient
fonctionner de manière incor-
recte ou se déployer (gonfler)
accidentellement, ce qui serait
susceptible d’occasionner des
blessures graves, voire mortelles.
●Installation, retrait, démontage
et réparation des coussins gon-
flables SRS
●Réparations, modifications,
retrait ou remplacement du
volant, du tableau de bord, de la
planche de bord, des sièges ou
du capitonnage des sièges, des
montants avant, latéraux et
arrière, des brancards de pavil-
lon, des panneaux des portières
avant, des garnitures des
portières avant ou des haut-
parleurs des portières avant
●Modifications du panneau de la
portière avant (comme le per-
forer)
●Réparations ou modifications de
l’aile avant, du pare-chocs
avant ou du côté de l’habitacle
●Installation d’une protection de
calandre (barre safari, barre
kangourou, etc.), de lames de
déneigement, de treuils ou d’un
porte-bagages de toit
●Modifications du système de
suspension du véhicule
●Installation d’ap pareils électro-
niques tels qu’un émetteur-
récepteur radio ou un lecteur de
CD
●Modifications à votre véhicule
pour une personne aux capac-
ités physiques réduites

71210-1. For owners

713
Index
What to do if... (Trouble-shooting) .................. 714
Alphabetical Index ...... 717

714What to do if... (Troubleshooting)
1-1.What to do if... (Troubleshooting)What to do if... (Troubleshooting)
If you lose your keys or
mechanical keys, new genu-
ine keys or mechanical keys
can be made by your Toyota
dealer. ( P.653)
 Vehicles with smart key sys-
tem:
If you lose your electronic
keys, the risk of vehicle theft
increases significantly. Con-
tact your Toyota dealer imme-
diately. ( P.653)
 Is the key battery weak or
depleted? ( P.604)
 Vehicles with smart key sys-
tem:
Is the engine switch in ON?
When locking the doors, turn
the engine switch off.
( P.197) 
Vehicles with smart key sys-
tem:
Is the electronic key left inside
the vehicle?
When locking the doors,
make sure that you have the
electronic key on your person.
 The function may not operate
properly due to the condition
of the radio wave. ( P.105,
129)
 Is the child-protector lock set?
The rear door cannot be
opened from inside the vehi-
cle when the lock is set. Open
the rear door from outside
and then unlock the child-pro-
tector lock. ( P. 1 1 2 )
 Is the shift lever in P?
( P.193)
 Is the battery discharged?
( P.655)
 Did you press the engine
If you have a problem,
check the following before
contacting your Toyota
dealer.
The doors cannot be
locked, unlocked, opened
or closed
You lose your keys
The doors cannot be
locked or unlocked
The rear door cannot be
opened
If you think something is
wrong
The engine does not start
(vehicles without smart
key system)
The engine does not start
(vehicles with smart key
system)

715What to do if... (Troubleshooting)
switch while firmly depress-
ing the brake pedal?
(P.194)
 Is the shift lever in P?
( P.194)
 Is the electronic key any-
where detectable inside the
vehicle? ( P.128)
 Is the steering wheel
unlocked? ( P.195)
 Is the electronic key battery
weak or depleted?
In this case, the engine can
be started in a temporary way.
( P.654)
 Is the battery discharged?
( P.655)
 Is the engine switch in ON?
If you cannot release the shift
lever by depressing the brake
pedal with the engine switch
in ON ( P.200)
 Vehicles without smart key
system:
It is locked to prevent theft of
the vehicle if the key is
removed from the engine
switch. ( P.193)
 Vehicles with smart key sys- tem:
It is locked automatically to
prevent theft of the vehicle.
(
P.195)
 Is the window lock switch
pressed?
The power window except for
the one at the driver’s seat
cannot be operated if the win-
dow lock switch is pressed.
( P.158)
 The auto power off function
will be operated if the vehicle
is left in ACC or ON (the
engine is not running) for a
period of time. ( P.198)
 The seat belt reminder light is
flashing
Are the driver and the passengers
wearing the seat belts? ( 
P. 635)
The parking brake indicator is
on
Is the parking br ake released?
( 
P.203)
Depending on the situation,
other types of warning buzzer
The shift lever cannot be
shifted from P even if you
depress the brake pedal
The steering wheel can-
not be turned after the
engine is stopped
The windows do not open
or close by operating the
power window switches
The engine switch is
turned off automatically
(vehicles with smart key
system)
A warning buzzer sounds
during driving

716What to do if... (Troubleshooting)
may also sound. (P.628, 639)
 Did anyone inside the vehicle
open a door during setting the
alarm?
The sensor detects it and the
alarm sounds. ( P.73)
To stop the alarm, turn the engine
switch to ON or start the engine.
 Is the message displayed on
the multi-information display?
Check the message on the
multi-information display.
( P.639)
 When a warning light turns on
or a warning message is dis-
played, refer to P.628, 639.
 Stop the vehicle in a safe
place and replace the flat tire
with the spare tire. ( P.642)
Try the procedure for when
the vehicle becomes stuck in
mud, dirt, or snow. ( P.661)
An alarm is activated and
the horn sounds (if
equipped)
A warning buzzer sounds
when leaving the vehicle
A warning light turns on
or a warning message is
displayed
When a problem has
occurred
If you have a flat tire
The vehicle becomes
stuck

717Alphabetical Index
Alphabetical Index
A
A/C ................................... 510, 515Air conditioning filter ............. 599
Automatic air conditioning sys-tem ..................................... 515
Eco air conditioning mode .... 516
Front seat concentrated airflow mode (S-FLOW) ................. 519
Manual air conditioning system ........................................... 510
ABS (Anti-lock Brake System) ............................................... 360Function ............................... 360
Warning light ........................ 630
ACA (Active Cornering Assist) ............................................... 360
Active Cornering Assist (ACA) ............................................... 360
Airbags ...................................... 33 Airbag operating conditions.... 35
Airbag precautions for your child............................................. 38
Airbag warning light.............. 629
Correct driving posture ........... 27
Curtain shield airbag operating conditions ............................. 36
Curtain shield airbag precautions ............................................. 38
Front passenger occupant clas- sification system ................... 43
General airbag precautions .... 38
Locations of airbags ............... 33
Modification and disposal of air- bags ..................................... 41
Seat cushion airbag ............... 33
Side airbag operating conditions ............................................. 36
Side airbag precautions ......... 38
Side and curtain shield airbags operating conditions ............. 36
Side and curtain shield airbags precautions ...........................38
SRS airbag instructions for Canadian owners ...............704
SRS airbags ...........................33
SRS warning light .................629
Air conditioning filter .............599
Air conditioning system.510, 515 Air conditioning filter .............599
Automatic air conditioning sys-tem .....................................515
Eco air conditioning mode ....516
Front seat concent rated airflow
mode (S-FLOW) .................519
Manual air conditioning system ...........................................510
Alarm .........................................73 Alarm ......................................73
Warning buzzer ....................628
AM ............................................425
Anchor brackets .......................61
Android Auto ...........407, 410, 437
Android Auto button (Menu screen) ...................................377
Antenna (Smart key system) .128
Anti-lock brake system (ABS)360 Function................................360
Warning light.........................630
Apple CarPlay .........................434
Apple CarPlay
®/Android Auto
.......................................407, 410
Apple CarPlay button (Menu screen) ...................................377
Approach warning ..................256
Apps button (Menu screen) ...377
Armrest ......... ......................... ..547
Assist grips .............................547
Audio .......................................420 Operating information ...........446
Some basics .........................421
Turning the sys tem on and off
...........................................421
Audio button (Menu screen) ..377

718Alphabetical Index
Audio button (Setup screen) ... ........... 380, 444
AUDIO button.......................... 375
Audio buttons overview......... 375
Audio settings ........................ 444
Automatic air conditioning sys- tem ......................................... 515Air conditioning filter ............. 599
Eco air conditioning mode .... 516
Automatic High Beam ............ 212
Automatic light control system ............................................... 210
Automatic transmission ........ 199 S mode ................................. 201
Auxiliary boxes ....................... 530
Average fuel consumption ...... 99
Average fuel economy ............. 91
Average vehicle speed....... 93, 99
B
Back door ................................ 114 Hands Free Power Back Door........................................... 119
Power back door .................. 118
Wireless remote control ....... 118
Back-up lights Replacing light bulbs ............ 609
Wattage ................................ 670
Battery Checking .............................. 579
If the vehicle battery is dis-charged .............................. 655
Preparing and c hecking before
winter.................................. 367
Replacing ............................. 657
Warning light ........................ 628
Blind Spot Monitor (BSM) ...... 260 Blind Spot Monitor function .. 264
Rear Cross Traffic Alert function........................................... 267
Bluetooth
® button (Setup screen) ...................................380
Bluetooth
® details settings ...394
Bluetooth
® setup screen.......395
Connecting a Bluetooth
® device
...........................................395
Deleting a Bluetooth
® device397
Detailed settings screen .......399
Displaying the Bluetooth
® setup
screen.................................394
Editing the Bluetooth
® device
information..........................398
Registering a Bluetooth
® device
...........................................397
Bluetooth
® device information
...............................................398
Bluetooth
® hands-free system
...............................................465
Bluetooth
® phone message func-
tion .........................................476 Calling the message sender .479
Checking received messages ...........................................477
Displaying the message screen ...........................................476
Receiving a mess age ...........477
Replying to a message (dicta- tion reply)............................478
Replying to a message (quick reply) ..................................479
Bottle holders .........................530
Brake Brake Hold ............................206
Fluid......................................577
Parking brake .......................203
Warning light.........................628
Brake assist ............................360
Brake Hold...............................206
Break-in tips ............................170
Brightness control Instrument panel light

Alphabetical Index719
control ............................ 84, 88
BSM (Blind Spot Monitor) ...... 260 Blind Spot Monitor function .. 264
Rear Cross Traffic Alert function........................................... 267
C
Care Aluminum wheels ................. 558
Exterior ................................. 558
Interior .................................. 561
Seat belts ............................. 561
Cargo capacity ............... 175, 178
Cargo hooks ........................... 532
Chains ..................................... 369
Child-protectors .. ................... 112
Child restraint s ystem ............. 50
Fixed with a LATCH system ... 59
Fixed with a seat belt ............. 54
Front passenger occupant clas- sification system ................... 43
Points to remember ................ 50
Riding with children ................ 49
Types of child restraint system installation met hod ............... 52
Using an anchor bracket ........ 61
Child safety ............................... 49 Airbag precautions ................. 38
Back door precautions ......... 114
Battery precautions ...... 580, 658
Child restraint system............. 52
Heated steering wheel and seat
heater precautions ............. 522
How your child should wear the seat belt................................ 30
Moon roof precau tions ......... 160
Panoramic moon roof precau- tions.................................... 164
Power window lock switch.... 158
Power window precautions .. 157
Rear door child-protectors.... 112
Removed key battery precau- tions ....................................606
Seat belt extender precautions .............................................30
Seat belt precautions..............29
Seat heater precautions .......522
Cleaning ..........................558, 561 Aluminum wheels .................558
Exterior .................................558
Interior ..................................561
Radar sensor ........................224
Seat belts .............................561
Clock ....................................84, 88
Coat hooks ..............................548
Condenser ............. ..................577
Connected Service s ...............495
Console box ............................529
Consumption screen ................99
Coolant Checking ..............................576
Preparing and checking before winter ..................................367
Warning light.........................629
Cooling system .......................576 Engine overheating ..............659
Cruise control (Dynamic radar cruise control with full-speed
range).....................................250
Cup holders.............................529
Current fuel consumption........99
Current fuel economy ..............91
Curtain shield airbags ..............33
Customizable featu res ...........688
D
Daytime running light system209
Replacing light bulbs ............609
DCM .................496, 498, 499, 502
Deck board ..............................532
Defogger Outside rear view mirrors ........................ 511, 517
Rear window................. 511, 517

720Alphabetical Index
Windshield.................... 511, 517
Differential .............................. 669
Digital Rear-view Mirror ......... 145
Dimensions ............................. 664
Dinghy towing ........................ 191
Display BSM (Blind Spot Monitor)..... 261
Drive information .................... 93
Driving information ................. 91
Dynamic radar cruise control with full-speed range .......... 250
Fuel consumption information 99
Intuitive parking assist .......... 270
LTA (Lane-Tracing Assist) .... 242
Multi-information display ........ 89
RCTA .................................... 261
Warning messages............... 639
Do-it-yourself maintenance . 565, 569
Door lock Back door ............................. 114
Side doors ............................ 108
Smart key system................. 128
Wireless remote control ....... 104
Doors Automatic door locking and unlocking system................ 113
Back door ............................. 114
Door glasses ........................ 156
Door lock .............................. 108
Open door warning buzzer ... 112
Outside rear view mirrors ..... 154
Rear door child-protectors.... 112
Side doors ............................ 108
Downhill assist control system ............................................... 358
Drive information ..................... 93
Driver’s seat belt reminder light ............................................... 635
Driver’s seat position memory ............................................... 137Driving position memory....... 137 Memory recall function .........138
Drive-start control ..................170
Driving Break-in tips .........................170
Correct posture .......................27
Driving mode select switch ...351
Procedures ...........................169
Winter drive tips....................367
Driving information display .....91
Driving mode select switch ...351
Driving position memory .......137 Memory recall function .........138
Driving support system informa- tion display..............................93
Dynamic radar cruise control with full-speed rangeFunction................................250
Warning message.................639
Dynamic Torque Control AWD system ...................................361
Dynamic Torque Vectoring AWD system ...................................361
E
Eco drive mode .......................351
Eco Driving Indicator ...............92
Eco Driving Indicator Light......92
EDR (Event data recorder) .......10
Elapsed time .............................93
Electric Power Steering (EPS) Function................................360
Warning light.........................630
Electronic key Battery-saving function .........129
If the electronic key does not operate properly .................653
Replacing the battery ...........604
Electronic sunshade ..............162 Jam protection function ........163
Operation..............................162
Emergency, in case of If a warning buzzer sounds ..628
