TOYOTA SUPRA 2021 Accessories, Audio & Navigation (in English)

311-1. NAVIGATION
1
NAVIGATION
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
1"Navigation"
2 "Map"
3 "Map content"
 "Traffic icons": symbols for
traffic events are displayed.
 "Traffic flow": lines for traf-
fic flow are displayed.
Depending on the scale of the
map and the location of the traf-
fic obstruction, the symbols for
traffic events are displayed.
Depending on the scale of the
map, length and impact of a traf-
fic obstruction are displayed on
the map using colored lines.
 Black: road blocked.
 Red: congestion.
 Orange: stop-and-go traffic.
 Yellow: heavy traffic.
 Green: clear roads.
 Gray: general traffic bulletins,
for instance construction site.
The displayed information
depends on the particular traffic information service.
With dynamic destination guid-
ance, traffic bulletins are consid-
ered when calculating routes.
1
"Navigation"
2 "Settings"
3 "Route settings"
4 "Dynamic guidance"
5 Select desired setting:
 "With confirmation": a mes-
sage is displayed, whether
the route should be guided
around a traffic obstruction.
 "Automatic": the route is auto-
matically changed in the
event of traffic obstructions.
Traffic bulletins on the
map
Map view settings
Symbols in the map view
Information about traffic
flow in the map view
Dynamic destination guid-
ance
Concept
Settings

321-1. NAVIGATION
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e. g., due to the
selected options or country ver-
sions. This also applies to
safety-related functions and sys-
tems. When using these func-
tions and systems, the
applicable laws and regulations
must be observed.
Information regarding position
determination and navigation
data version can be called up.
1"Navigation"
2 "Settings"
3 "Position and software ver-
sion"
4 Select desired setting:
 "Enter position": the vehicle
position can be manually set
on the map in situations with-
out GPS reception or, for
instance immediately after
transport on a ferry. 
"Software version": informa-
tion about the current map
version.
 In the Professional navigation
system:"Help to improve the navigation
map": data such as speed or posi-
tion is stored in the vehicle in an
anonymized state and transmitted
to the manufacturer in order to
improve the digital map.
Navigation data is stored in the
vehicle and can be updated
from a USB device.
Current navigation data is avail-
able from your Toyota dealer or
in the Toyota Supra Connect
User Site.
Depending on the data volume,
the navigation data update may
take several hours. The status
of the update can be queried.
The navigation data is updated
during the trip to preserve the
vehicle battery.
1 Connect the USB device with
the new navigation data to a
USB port in the front.
2 Follow the instructions on the
Control Display.
Navigation data
Vehicle features and
options
Concept
Settings
Map update
General information
Update

331-1. NAVIGATION
1
NAVIGATION
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
3Remove the USB device
after the update.
1 Press the button.
2 "Saving navigation data in
the vehicle…(USB)"
Depending on the vehicle equip-
ment and country version, the
navigation data for the home
region is transmitted online to
the vehicle four times a year and
automatically installed and
updated. This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e. g., due to the
selected options or country ver-
sions. This also applies to
safety-related functions and sys-
tems. When using these func-
tions and systems, the
applicable laws and regulations
must be observed.
Why can the current position not
be displayed?

The vehicle is located in an
unrecognized region, is in a
poor reception area, or the
system is currently determin-
ing the position. Reception is
usually best when you have
an unobstructed view of the
sky.
Why does destination guidance
not accept a destination without
the street?
 No downtown can be deter-
mined for the entered
Viewing the status
Automatic map update
General information
Frequently asked
questions
Vehicle features and
options
Frequently asked ques-
tions

341-1. NAVIGATION
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
town/city. Input any street in
the selected town/city and
start destination guidance.
Why does destination guidance
not accept a destination?
 The destination data is not
contained in the navigation
data. Select a destination that
is as close as possible to the
original.
Why can letters not be selected
for destination input?
 The destination data is not
contained in the navigation
data. Select a destination that
is as close as possible to the
original.
Why are spoken instructions no
longer be output during destina-
tion guidance in front of inter-
sections?
 You have left the recom-
mended route and the system
requires a few seconds to cal-
culate a new route sugges-
tion.

35
2
2
ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
ENTERTAINMENT
.2-1. ENTERTAINMENTGeneral information ....... 36
Tone ............................... 38
Radio.............................. 40
Audio .............................. 50
Video .............................. 58

362-1. ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
2-1.ENTERTAINMENT
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e. g., due to the
selected options or country ver-
sions. This also applies to
safety-related functions and sys-
tems. When using these func-
tions and systems, the
applicable laws and regulations
must be observed.Audio recording playback is
stopped during muting.
Possible entertainment sources:
Radio, refer to page 40.
 Music collection, refer to page
50.
 USB audio, refer to page 53.
General infor mation
Vehicle features and
options
Control elements
Buttons and functions
ButtonFunction
Press: switches sound
output on/off.
Turn: adjusts the vol-
ume.
Change the entertain-
ment source.
Press once: changes
the station/track.
Press and hold: fast
forward/rewind the
track.
Programmable mem-
ory buttons.
Change waveband/sat-
ellite radio.
Sound output
Safety information
WARNING
●A high sound output volume can
damage your hearing. There is
a risk of injury. Do not adjust the
volume too high.
Volume and sound output
Turn the button to
adjust the volume.
 Press the button to
switch off the sound
output. Pressing the
button again restores
the previous volume
setting.
Entertainment sources
General information
ButtonFunction

372-1. ENTERTAINMENT
2
ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
USB video, refer to page 59.
 Bluetooth audio, refer to page
54.
 Screen Mirroring, refer to
page 59.
 Apple CarPlay, refer to page
85.
On the radio:
1 Press the button.
A list of all currently available enter-
tainment sources is displayed.
2 Press the button again
to select an entertainment
source.
Via Toyota Supra Command:
1 "Media/Radio"
A list of all possible entertainment
sources is displayed.
2Select the desired entertain-
ment source.
Via the button on the Controller:
1 Press the button.
The most recently selected enter-
tainment source is played.
2 Press the button again.
A list of all currently available enter-
tainment sources is displayed.
3Select the desired entertain-
ment source. It is possible to select which
entertainment sources are dis-
played in the selection list. The
entertainment source currently
being played cannot be
removed from the selection list.
1
"Media/Radio"
A list of all possible entertainment
sources is displayed.
2"Personalize menu"
3 Select the desired setting.
Changing the entertain-
ment source
Adjusting the selection list
of entertainment sources

382-1. ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e. g., due to the
selected options or country ver-
sions. This also applies to
safety-related functions and sys-
tems. When using these func-
tions and systems, the
applicable laws and regulations
must be observed.
The settings are stored in the
currently used driver profile.
1"Media/Radio"
2 "Tone"
3 Select desired setting:
 "Treble": treble adjustment.
 "Bass": depth adjustment.
 "Balance": left/right volume
distribution.
 "Fader": front/rear volume dis-
tribution.
4 To adjust: turn the Controller. 5
To store: press the Controller.
When surround is activated,
multi-channel playback is simu-
lated when a stereo audio track
is played.
1 "Media/Radio"
2 "Tone"
3 "Surround"
Depending on the vehicle equip-
ment, this function may not be
available.
Settings for individual audio fre-
quency ranges.
1 "Media/Radio"
2 "Tone"
3 "Equalizer"
The current bass and treble set-
tings, refer to page 38, are shown
on the left and right edge of the
equalizer display. These values can
also be adjusted in the equalizer.
The treble and bass sound settings
affect the settings for the audio fre-
quency ranges of the equalizer.
Select and adjust trebles,
basses, or an audio frequency
range.
To n e
Vehicle features and
options
General information
Treble, bass, balance, and
fader
Multi-channel playback,
surround
Concept
Switching on/off
Equalizer

392-1. ENTERTAINMENT
2
ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
1Turn the Controller to select
the audio frequency range to
be adjusted.
2 Press the Controller.
3 Turn the Controller to adjust
the audio frequency.
4 Press the Controller to store
the setting.
An automatic increase of the
volume can be set to compen-
sate for the increasing driving
noises at higher speeds.
1 "Media/Radio"
2 "Tone"
3 "Volume settings"
4 Select the desired setting.
 "Navigation": ratio of spoken
instructions volume to enter-
tainment volume.
 "Speed volume": ratio of
entertainment volume to
speed.
 "Parking Sens.": ratio of the
volume of the signal tone of
Parking Sensors to the enter-
tainment volume.
The basic setting ensures that the
signal tone is audible at any vol- ume.

"Gong": ratio of the volume of
the signal tone, for instance
for safety belt reminder, to the
entertainment volume.
The basic setting ensures that the
signal tone is audible at any vol-
ume.
"Microphone": sensitivity of
the microphone during a
phone call.
The setting is adju sted while calling
and is stored for the mobile phone
used.
 "Speakers": volume of the
loudspeakers during a phone
call.
Audio recording playback is
stopped during muting.
The setting is adju sted while calling
and is stored for the mobile phone
used.
5 To adjust: turn the Controller.
6 To store: press the Controller.
The tone settings are reset to
the factory settings.
1 "Media/Radio"
2 "Tone"
3 "Reset"
Volume equalization
Concept
Set automatic volume
increase
Reset the tone settings

402-1. ENTERTAINMENT
Supra Navigation System Owner’s Manual_U (from July ’20 Prod.)
This chapter describes all stan-
dard, country-specific and
optional features offered with
the series. It also describes fea-
tures and functions that are not
necessarily available in your
vehicle, e. g., due to the
selected options or country ver-
sions. This also applies to
safety-related functions and sys-
tems. When using these func-
tions and systems, the
applicable laws and regulations
must be observed.
The settings are stored in the
currently used driver profile.
Depending on the vehicle equip-
ment and country version, it may
not be possible to receive AM
stations.
RDS broadcasts additional infor-mation, such as the station
name, in the FM waveband.
It is recommended to switch on
RDS.
1
"Media/Radio"
2 "FM"
3 Press the button.
4 "RDS"
1 "Media/Radio"
2 "FM" or "AM"
The last station listened to will be
played and the station list dis-
played.
3 Select the desired station.
On the radio:
The previous or next station
from the list of stations is
played.
A symbol on the highlighted
channel indicates whether the
channel has already been
stored.
Radio
Vehicle features and
options
General information
AM/FM station
General information
Radio Data System RDS
Concept
Switching on/off
Selecting a station
Changing the station
Press the left or right
button.
Storing a station
General information
