Page 2361 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual COAT HOOK
REMOVAL
(1) Using a trim stick C-4755 or equivalent, pry
down the release clip and remove the hook. (Fig. 9)
INSTALLATION
(1) Snap the coat hook into the sheet metal and
seat the base of the

Page 2362 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INSTALLATION
(1) Route the shoulder belt through the slot in the
trim.
(2) Position the trim and seat the attachment clips
fully.
(3) Install the seat belt anchor bolt and tighten to
40 N´m (30 ft. l

Page 2363 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual HEADLINER
REMOVAL
(1) Remove the a-pillar trim. (Refer to 23 - BODY/
INTERIOR/A-PILLAR TRIM - REMOVAL)
(2) Remove the upper b-pillar trim. (Refer to 23 -
BODY/INTERIOR/B-PILLAR UPPER TRIM -
REMOVAL)
(

Page 2364 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual (3) Using a trim stick C-4755 or equivalent,
remove the center seat belt trim bezel, if equipped.
(4) On quad cab models, remove the left lower
c-pillar trim panel. (Refer to 23 - BODY/INTERIOR/
C-PIL

Page 2365 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INSTALLATION
INSTALLATION
(1) Position the mirror base at the bracket and
slide it downward onto the support bracket (Fig. 18).
(2) Tighten the setscrew 1 N´m (15 in. lbs.) torque.
(3) If equipped, c

Page 2366 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INSTALLATION
(1) Snap the visor support into the sheet metal
and seat the release clip fully.
BODY VENT
REMOVAL
(1) Remove the cab back panel trim. (Refer to 23 -
BODY/INTERIOR/REAR CAB BACK PANEL TRI

Page 2367 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual INSTALLATION
(1) Install the load floor and install the bolts.
(2) Tighten the bolts to 40 N´m (30 ft. lbs.).
(3) Fold the load floor down and install the nuts.
(4) Tighten the nuts to 25 N´m (18 ft

Page 2368 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual PAINT
TABLE OF CONTENTS
page page
PAINT
SPECIFICATIONS - PAINT CODES..........73
PAINT CODE
DESCRIPTION.........................73
BASECOAT/CLEARCOAT FINISH
DESCRIPTION.........................73PAINT

Page 2369 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual CAUTION: Do not use abrasive chemicals or com-
pounds on painted surfaces. Damage to finish can
result.
Do not use harsh alkaline based cleaning solvents
on painted surfaces. Damage to finish or color

Page 2370 of 2627

DODGE RAM 1500 1998 2.G Workshop Manual SEATS
TABLE OF CONTENTS
page page
CENTER SEAT
REMOVAL.............................75
INSTALLATION.........................76
CENTER ARMREST / SEAT BACK
REMOVAL.............................76
INSTALLAT
