8W-50 FRONT LIGHTING
Component Page
Cargo Lamp No. 1.................... 8W-50-2
Cargo Lamp No. 2.................... 8W-50-2
Center Identification Lamp............. 8W-50-8
Central Timer Module C2.............. 8W-50-2
Daytime Running Lamp Module.... 8W-50-6, 9, 11,
12, 13
Fog Lamp Indicator............... 8W-50-10, 11
Fog Lamp Relay............. 8W-50-6, 10, 11, 12
Fuse 5 (JB)......................... 8W-50-3
Fuse 7 (JB)........................ 8W-50-12
Fuse 14 (JB)...................... 8W-50-6, 9
Fuse B (PDC)....................... 8W-50-4
Fuse C (PDC)....................... 8W-50-4
Fuse E (PDC)....................... 8W-50-5
Fuse F (PDC).................. 8W-50-10, 11, 3
Fuse G (PDC)................ 8W-50-10, 11, 12
G100........................... 8W-50-7, 12
G102........................... 8W-50-5, 13
G201.................. 8W-50-2, 4, 6, 9, 10, 11
G302.............................. 8W-50-8
Headlamp Beam Select Switch....... 8W-50-4, 6,
9, 10, 13
Headlamp Switch........... 8W-50-2, 3, 4, 10, 11
Ignition Switch...................... 8W-50-3
Instrument Cluster............ 8W-50-2, 6, 9, 13
Joint Connector No. 1............ 8W-50-4, 5, 13Component Page
Joint Connector No. 3................. 8W-50-7
Joint Connector No. 4.............. 8W-50-12, 7
Joint Connector No. 5........... 8W-50-3, 10, 11
Joint Connector No. 6............... 8W-50-2, 3
Joint Connector No. 8............... 8W-50-2, 3
Junction Block.......... 8W-50-2, 3, 6, 7, 8, 9, 12
Left Fog Lamp................... 8W-50-10, 11
Left Headlamp...................... 8W-50-5
Left Outboard Clearance Lamp.......... 8W-50-8
Left Outboard Headlamp............ 8W-50-4, 6
Left Outboard Identification Lamp....... 8W-50-8
Left Park/Turn Signal Lamp............ 8W-50-7
Overhead Console.................... 8W-50-2
Park Brake Switch.................. 8W-50-12
Power Distribution Center...... 8W-50-10, 11, 12,
3, 4, 5
Quad High Beam Relay............. 8W-50-13, 5
Right Fog Lamp................. 8W-50-10, 11
Right Headlamp..................... 8W-50-5
Right Outboard Clearance Lamp........ 8W-50-8
Right Outboard Headlamp........... 8W-50-4, 6
Right Outboard Identification Lamp...... 8W-50-8
Right Park/Turn Signal Lamp........... 8W-50-7
Security Relay...................... 8W-50-13
Trailer Tow Relay.................... 8W-50-7
BR/BE8W-50 FRONT LIGHTING 8W - 50 - 1
