Fuel INFINITI QX56 2011 Factory Service Manual

HIGH PRESSURE FUEL PUMP AND FUEL HOSEEM-43
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
M A
EM
NP
O
HIGH PRESSURE FUEL
PUMP AND FUEL HOSE
Exploded ViewINFOID:0000000006289553
CAUTION:
Never remove or disassemble parts unless instructed as shown in the figure.
Removal and InstallationINFOID:0000000006289554
REMOVAL
WARNING:
 Be sure to read EM-4, "
Precaution for Handling High Pressure Fuel System" when working on the
high pressure fuel system.
 Put a “CAUTION: FLAMMABLE” sign in the workshop.
 Be sure to work in a well ventila ted area and furnish workshop with a CO
2 fire extinguisher.
 Never smoke while servicing fuel system. Keep op en flames and sparks away from the work area.
 To avoid the danger of being scalded, never drain engine coolant when engine is hot.
1. Release fuel pressure. Refer to EC-153, "
Work Procedure".
2. Remove intake manifold. Refer to EM-30, "
Removal and Installation".
3. Disconnect harness connector from high pressure fuel pump.
1. High pressure fuel pump insulator 2. High pressure fuel pump 3. O-ring
4. Lifter 5. Fuel pump connector protector 6. Copper washer
7. Fuel feed hose 8. Copper washer 9. Low fuel pressure sensor
10. Bracket 11. Fuel feed tube (pump side)
A. From fuel tank
: Engine front
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA4596GB
Revision: 2010 May2011 QX56

EM-44
< REMOVAL AND INSTALLATION >
HIGH PRESSURE FUEL PUMP AND FUEL HOSE
4. Remove fuel feed tube (pump side) (1).
5. Disconnect fuel hose (2) from high pressure fuel pump.
6. Remove high pressure fuel pump and lifter.CAUTION:
After removing lifter, replace lifter with a new one.
7. Disconnect quick connector (A) with the following procedure.
a. Remove quick connector cap from quick connector connection.
b. With the sleeve side of quick connector release facing quick connector, install quick connector release
onto fuel tube.
c. Insert quick connector release into quick connector until sleeve contacts and goes no further. Hold quick connector release on
that position.
CAUTION:
Inserting quick connector re lease hard will not disconnect
quick connector. Hold qui ck connector release where it
contacts and goes no further.
d. Draw and pull out quick connector straight from fuel tube. CAUTION:
 Pull quick connector holding (A) position as shown in thefigure.
 Never pull with lateral force applied. O-ring inside quick
connector may be damaged.
 Prepare container and cloth befo rehand because fuel will leak out.
 Avoid fire and sparks.
 Keep parts away from heat source. Especially, be careful when welding is performed around
them.
 Never expose parts to battery electrolyte or other acids.
 Never bend or twist connection between quick c onnector and fuel feed hose (with damper) dur-
ing installation/removal.
JPBIA3479ZZ
JPBIA3493ZZ
KBIA0702E
Revision: 2010 May2011 QX56

HIGH PRESSURE FUEL PUMP AND FUEL HOSEEM-45
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
M A
EM
NP
O
 To keep clean the connecting portion and to avoid dam-
age and foreign materials, cover them completely with
plastic bags, etc. or a similar item.
8. Disconnect harness connector from low fuel pressure sensor.
9. Remove fuel hose assembly.
10. Remove fuel pressure sensor. CAUTION:
 Never allow water and foreign mate rials enter into the connector.
 Never reuse the dropped sensor.
 Carefully handle sensor avoiding shocks.
 Use hex head support installation fo r removal and installation of sensor.
 The contact surface of gasket must not have any stain or scoring by dust etc.
INSTALLATION
1. Install O-ring to high pressure fuel pump. When handi ng new O-ring, paying attention to the following cau-
tion items:
CAUTION:
 Handle O-ring with bare hands. Never wear gloves.
 Lubricate O-ring with new engine oil.
 Never clean O-ring with solvent.
 Check that O-ring and its mating pa rt are free of foreign material.
 When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched wh ile it was being attached, never insert it quickly
into fuel tube.
 Insert new O-ring straight into fu el rail. Never decenter or twist it.
2. Install fuel pressure sensor.
3. Install fuel hose assembly.  Temporarily tighten mounting bolt (A) as shown in the figure.
4. Install high pressure fuel pump to front cover. CAUTION:
After removing lifter, replace lifter with a new one.
5. Connect fuel feed hose to high pressure fuel pump. NOTE:
 Never allow the machined edge of the high pr essure fuel pump to contact with gasket.
 The gasket contact area must be free of dust and scratches.
PBIC2205E
: Engine front
JPBIA4250ZZ
Revision: 2010 May2011 QX56

EM-46
< REMOVAL AND INSTALLATION >
HIGH PRESSURE FUEL PUMP AND FUEL HOSE
 Check that rotation stopper (A) of fuel feed hose contact highpressure fuel pump.
6. Tighten mounting bolts that are temporarily tightened in step 3.
7. Connect harness connector to high pressure fuel pump.
8. Install fuel pump connector protector.
9. Connect harness connector to low fuel pressure sensor.
10. Note the following, and connect quick connector to install fuel feed hose.
a. Check the connection for foreign material and damage.
b. Align center to insert quick connector straightly into fuel tube. NOTE:
The figure shows engine side as an example.
 Insert fuel tube into quick connector until the top spool on fueltube is inserted completely and the second level spool is posi-
tioned slightly below quick connector bottom end.
CAUTION:
 Hold “A” position in the figure when inserting fuel tube
into quick connector.
 Carefully align center to avoid inclined insertion to pre-
vent damage to O-ring inside quick connector.
 Insert until you hear a “c lick” sound and actually feel
the engagement.
 To avoid misidentification of engagement with a similar sound , be sure to perform the next
step.
c. Before clamping fuel feed hose with hose clamps, pull quick connector hard by hand holding “A” position.
Check it is completely engaged (connected) so that it does not come out from fuel feed tube.
d. Install quick connector cap to quick connector connection.  Install so that the arrow mark on the side faces up.
CAUTION:
 Check that quick connector and fuel tube are securely fitinto quick connector cap installation groove.
 If quick connector cap canno t be installed smoothly,
quick connector may have not been installed correctly.
Check connection again.
11. Install in the reverse order of removal.
InspectionINFOID:0000000006289555
INSPECTION AFTER INSTALLATION
Check for Fuel Leakage
1. Turn ignition switch “ON” (with the engine stopped). With fuel pressure applied to fuel piping, check that
there is no fuel leakage at connection points.
NOTE:
Use mirrors for checking at points out of clear sight.
2. Start the engine. With engine speed increased, check again that there is no fuel leakage at connection
points.
JSBIA0364ZZ
KBIA0272E
PBIC2348E
Revision: 2010 May2011 QX56

HIGH PRESSURE FUEL PUMP AND FUEL HOSEEM-47
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
M A
EM
NP
O
CAUTION:
Never touch the engine immediately after it is
stopped because the engine is extremely hot.
Revision: 2010 May2011 QX56

EM-48
< REMOVAL AND INSTALLATION >
FUEL INJECTOR AND FUEL TUBE
FUEL INJECTOR AND FUEL TUBE
Exploded ViewINFOID:0000000006289556
CAUTION:
 Never remove or disassemble parts unless instructed as shown in the figure.
 Be sure to follow the tightening instruction to avoid fuel leakage.
1. Fuel tube insulator (bank 2) 2. Fuel tube insulator (center) 3. Fuel tube insulator (bank 1)
4. High pressure fuel pump 5. Fuel feed tube (pump side) 6. Fuel feed tube (bank side)
7. Fuel rail (bank 2) 8. Injector holder 9. O-ring (blue)
10. Backup ring 11. Fuel injector 12. Seal ring
13. Insulator 14. Fuel rail (bank 1) 15. Gasket
16. Fuel rail pressure sensor
A.Comply with the installation proce-
dure when tightening. Refer to
EM-
49, "Removal and Installation".
Refer to GI-4, "
Components" for symbols in the figure.
JPBIA3506GB
Revision: 2010 May2011 QX56

FUEL INJECTOR AND FUEL TUBEEM-49
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
M A
EM
NP
O
Removal and InstallationINFOID:0000000006289557
REMOVAL
WARNING:
 Be sure to read
EM-4, "
Precaution for Handling High Pressure Fuel System" when working on the
high pressure fuel system.
 Put a “CAUTION: FLAMMABLE” sign in the workshop.
 Be sure to work in a well ventila ted area and furnish workshop with a CO
2 fire extinguisher.
 Never smoke while servicing fuel system. Keep op en flames and sparks away from the work area.
 To avoid the danger of being scalded, never drain engine coolant when engine is hot.
1. Release fuel pressure. Refer to EC-153, "
Work Procedure".
2. Remove intake manifold. Refer to EM-30, "
Removal and Installation".
3. Remove fuel feed tube (pump side) and fuel feed tube (bank side). CAUTION:
Never reuse fuel feed tube.
4. Remove fuel rail (bank 1) and fuel rail (bank 2).
5. Disconnect harness connector from fuel injectors.
6. Remove fuel injector from cylinder head as per the following: CAUTION:
 Be careful with remaining fuel th at may go out from fuel tube.
 Be careful not to damage in jector nozzles during removal.
 Never bump or drop fuel injector.
 Never disassemble fuel injector.
a. Remove injector holder.
b. Install an injector remover [SST: KV10119600 (—)] (A) to the injector connector side so that cutout (B) of injector remover
faces the injector connector side.
 Hook pawl portion (B) of injector remover [SST: KV10119600(—)] (A) to groove portion (C) of injector.
JSBIA0342ZZ
JSBIA0343ZZ
Revision: 2010 May2011 QX56

EM-50
< REMOVAL AND INSTALLATION >
FUEL INJECTOR AND FUEL TUBE
c. Press down body portion (A) of injector remover [SST:KV10119600 (—)] until it contacts cylinder head.
d. Tighten injector remover [SST: KV10119600 (—)] clockwise and remove injector from cylinder head.
e. Cut Teflon seal (1) while pinching it. Be careful not to damage injector.
f. Remove insulator from mounting ho le of fuel injector of cylinder
head.
INSTALLATION
1. Install seal ring to fuel injector as per the following: CAUTION:
 Handle seal ring with bare hands. Never wear gloves.
 Never apply engine oil to seal ring.
 Never clean seal ring with solvent.
JPBIA3747ZZ
JPBIA3748ZZ
JSBIA0346ZZ
Revision: 2010 May2011 QX56

FUEL INJECTOR AND FUEL TUBEEM-51
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
K L
M A
EM
NP
O
a. Install an injector seal drift set [SST: KV101197S0 (—)] (A) to
fuel injector (1).
b. Set seal ring (1) to injector seal drift set [SST: KV101197S0 (—)]
(A).
c. Straightly insert seal ring (1), which is set in step 2, to fuel injec- tor as shown in the figure and install.
CAUTION:
Be careful that seal ring do es not exceed the groove portion
of fuel injector.
d. Insert injector seal drift set [SST: KV101197S0 (—)] (A) to injec- tor and rotate clockwise and counterclockwise by 90 ° while
pressing seal ring to fit it.
NOTE:
Compress seal ring, because this operation is for rectifying
stretch of seal ring caused by installation and for preventing
sticking when inserting injector into cylinder head.
2. Install O-ring and backup ring to fuel injector. When handing new O-ring and backup ring, paying attention to the following caution items:
CAUTION:
 Handle O-ring with bare hands. Never wear gloves.
 Lubricate O-ring with new engine oil.
 Never clean O-ring with solvent.
 Check that O-ring and its mating pa rt are free of foreign material.
 When installing O-ring, be careful not to scratch it with tool or fingernails. Also be careful not to
twist or stretch O-ring. If O-ring was stretched wh ile it was being attached, never insert it quickly
into fuel tube.
 Insert new O-ring straight into fu el rail. Never decenter or twist it.
JSBIA0347ZZ
JSBIA0348ZZ
JSBIA0350ZZ
JSBIA0351ZZ
Revision: 2010 May2011 QX56

EM-52
< REMOVAL AND INSTALLATION >
FUEL INJECTOR AND FUEL TUBE
 Always install the back up ring (1) in the right direction as
instructed.
3. Install fuel injector (1) to fuel rail (2) as per the following:
a. Install fuel injector holder (5) to fuel injector. CAUTION:
 Never reuse injector holder. Replace it with a new one.
 Be careful to keep fuel inject or holder from interfering
with O-ring. If interfer ence occurs, replace O-ring.
b. Insert fuel injector into fuel rail with fuel injector holder attached.  Insert it while matching it to the axial center.
 Insert so that protrusion (A) of fuel injector is aligned to cutout
(B).
c. Check that installation is complete by checking that fuel injector does not rotate or come off.
 Check that protrusions of fuel in jectors and fuel rail are aligned
with cutouts of clips after installation.
4. Insert insulator into mounting hole of fuel injector of cylinder head.
5. Install fuel rail and fuel injector assembly to cylinder head.  Tighten mounting bolts and nuts in two steps in numericalorder as shown in the figure.
6. Connect injector harness connector.
7. Install fuel feed tube (bank side) to fuel rail. CAUTION:
 When inserting fuel feed tube (b ank side) to fuel rail, press the flange part to install the tube.
 Never use O-ring with any scoring.
 Never reuse fuel feed tube (ban k side), O-ring and back up ring.
JPBIA3864ZZ
3 : O-ring (blue)
4: Backup ring
JSBIA0352ZZ
: Engine front
1st step : 10.0 N·m (1.0 kg-m, 89 in-lb)
2nd step : 20.5 N·m (2.1 kg-m, 15 ft-lb)
JSBIA0353ZZ
Revision: 2010 May2011 QX56
