INFINITI QX56 2011 Factory Service Manual

EXT-36
< REMOVAL AND INSTALLATION >
SILL MOLDING
SILL MOLDING
Exploded ViewINFOID:0000000006367621
Removal and InstallationINFOID:0000000006367622
REMOVAL
1. Fully open front and rear door.
2. Disengage sill molding (1) fixing clips with a remover tool (A),and then remove sill molding.
CAUTION:
 Disengage the clips slowly and carefully.
 Never pull the sill molding strongly.
INSTALLATION
Note the following items, and then install in the reverse order of removal.
CAUTION:
 When installing, check visually th e sill molding and the clips, then replace them with new parts if
they have been damaged.
 When installing the sill molding, check that blind clips are secure ly fitted in panel holes on body, and
then press them in.
1. Sill molding 2. Double-sided tape
[t: 1.2 mm (0.047) in]
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA5380ZZ
: Clip
JMKIA2029ZZ
Revision: 2010 May2011 QX56

DOOR SASH COVEREXT-37
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
DOOR SASH COVER
Exploded ViewINFOID:0000000006367623
Removal and InstallationINFOID:0000000006367624
FRONT DOOR SASH COVER
Removal
1. Remove front door sash cover fixing clips.
1. Front door sash cover 2. Rear door sash cover 3. Double sided tape [1.2 mm (0.047) in]
4. Double sided tape [2.0 mm (0.079) in] 5. Double sided tape
[1.6 mm (0.063) in] 6. EPT seal
[1.6 mm (0.063) in]
: Clip
: Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA5312ZZ
Revision: 2010 May2011 QX56

EXT-38
< REMOVAL AND INSTALLATION >
DOOR SASH COVER
2. Insert a remover tool (A) between front door sash cover (1) anddoor panel, cut double-sided tape using a cutter (B) while lifting
front door sash cover, and remove front door sash cover.
CAUTION:
 Use a remover tool which is made of a material that doesnot damage door panel.
 Never lift front door sash cover with excessive force.
Installation
Note the following items, and then install in the reverse order of removal.
CAUTION:
 When installing, slid e and install front door sash cover (2)
from door rear side, so that front door outside molding (1) is
not deformed.
 Replace double-sided tape on back of front door sash cover with a new double-sided adhesive tape
if front door sash cover is reused.
 Replace EPT sealer of front door sash cover with a new EPT sealer if front door sash cover is
reused.
 Remove double-sided adhesive ta pe remaining on body and back of front door sash cover using
double-sided adhesive tape remover wh en removing front door sash molding.
 Install after cleaning adhesive parts of doo r side and back of front door sash cover.
 To secure contact, do not wash vehicle within 24 hours after installation.
REAR DOOR SASH COVER
Removal
1. Remove rear door sash cover fixing clips.
2. Insert a remover tool (A) between rear door sash cover (1) and
door panel, cut double-sided tape using a cutter (B) while lifting
rear door sash cover, and remove rear door sash cover.
CAUTION:
 Never use an item as a remover tool that could damagedoor panel.
 Never lift rear door sash cover with excessive force.
Installation
Note the following items, and install in the reverse order of removal.
CAUTION:
JMKIA2034ZZ
JMKIA5005ZZ
JMKIA2034ZZ
Revision: 2010 May2011 QX56

DOOR SASH COVEREXT-39
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
 When installing, slide and inst all rear door sash cover (2) from
door front, so that rear door outside molding (1) is not
deformed.
 Replace double-sided adhesive tape on back of r ear door sash cover with a new double-sided adhe-
sive tape if rear door sash cover is reused.
 Replace EPT sealer of rear door sash cover with a new EPT sealer if rear door sash cover is reused.
 Remove double-sided adhesive tape remaining on bo dy and back of rear door sash cover using dou-
ble-sided adhesive tape remover when removing rear door sash cover.
 Install after cleaning adhesive parts of d oor side and back of rear door sash cover.
 To secure contact, do not wash vehicle within 24 hours after installation.
JMKIA5007ZZ
Revision: 2010 May2011 QX56

EXT-40
< REMOVAL AND INSTALLATION >
FRONT PILLAR FINISHER
FRONT PILLAR FINISHER
Exploded ViewINFOID:0000000006367625
Removal and InstallationINFOID:0000000006367626
REMOVAL
1. Remove roof drip molding. Refer to EXT-43, "Removal and Installation".
2. Remove front pillar finisher fixing screw.
3. Disengage clips with remover tool, and then remove front pillar finisher.
INSTALLATION
Note the following items, and then install in the reverse order of removal.
CAUTION:
 Visually check the clips for deformation and dama ge during installation. Replace with new ones if
necessary.
 When installing front pillar finisher, check that cl ips are securely fitted in body panel holes, and
press them it.
1. Front pillar finisher 2. Grommet 3. Grommet
4. EPT sealer [t: 12.0 mm (0.472 in)]
: Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA5311ZZ
Revision: 2010 May2011 QX56

REAR SPOILEREXT-41
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
REAR SPOILER
Exploded ViewINFOID:0000000006367627
Removal and InstallationINFOID:0000000006367628
REMOVAL
1. Remove back door trim. Refer to INT-39, "Removal and Installation".
2. Remove rear spoiler mounting nuts.
3. Cut rear spoiler fixing double-sided tape with cutter knife.
4. Disengage rear spoiler fixing clips with remover tool (A), and then remove rear spoiler.
CAUTION:
Apply a protective tape (B) on body panel and rear spoiler
to protect the painted surface from damage.
1. Rear spoiler assembly 2. Grommet 3. High-mounted stop lamp
4. High-mounted stop lamp cover 5. Washer nozzle 6. EPT sealer [t: 5.0 mm (0.197 in)]
7. Double-sided tape
[t: 1.6 mm (0.063 in)] 8. EPT sealer [t: 4.0 mm (0.157 in)]
: Clip
: Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JMKIA5322ZZ
: Clip
JMKIA5383ZZ
Revision: 2010 May2011 QX56

EXT-42
< REMOVAL AND INSTALLATION >
REAR SPOILER
5. Remove following parts after removing rear spoiler. High-mounted stop lamp
Grommets
 Washer nozzle
INSTALLATION
Note the following items, and then install in the reverse order of removal.
CAUTION:
 Be careful no to damage the back door.
 Always replace double-sided tape with a new one, if rear spoiler is reused.
 Remove double-sided tape remain ing on back door panel and back of rear spoiler with a double-
sided tape remover, after removing rear spoiler.
 When installing, visually check the rear spoiler and the clips, then replace them with new parts if
they are damaged.
 When installing rear spoiler, check that clips an d bolts are securely fitted in back door panel holes,
and then press them in.
 Never wash the vehicle within 24 hours af ter installing so as to keep adhesive.
Revision: 2010 May2011 QX56

DRIP MOLDINGEXT-43
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
DRIP MOLDING
Exploded ViewINFOID:0000000006367629
Removal and InstallationINFOID:0000000006367630
REMOVAL
Remove drip molding fixing clips from rear end to front end using
remover tool (A).
CAUTION:
Apply protective tape (B) on body panel to protect the painted
damage from damage.
INSTALLATION
Note the following items, and then install in the reverse order of removal.
CAUTION:
When installing, check visually the drip molding and clips, then replace them with new parts if they are
damaged.
1. Drip molding clip 2. Drip molding
JMKIA5314ZZ
: Clip
JMKIA5474ZZ
Revision: 2010 May2011 QX56

EXT-44
< REMOVAL AND INSTALLATION >
BACK DOOR FINISHER
BACK DOOR FINISHER
Exploded ViewINFOID:0000000006367631
Removal and InstallationINFOID:0000000006367632
REMOVAL
Back Door Finisher Center Upper
1. Remove back door trim. Refer to INT-39, "Removal and Installation".
2. Disconnect rear view camera and back door opener switch harness connectors.
3. Remove back door finisher center upper mounting nuts.
4. Disengage fixing clips, and then remove back door finisher center upper.
5. Remove following parts after removing back door finisher center upper mounting nuts.  Rear view camera
 Back door opener switch
 License lamp
Back Door Finisher Center Lower
1. Remove back door trim. Refer to INT-39, "Removal and Installation".
2. Remove back door finisher center lower mounting nuts.
3. Disengage fixing clips, and then remove back door finisher center lower.
INSTALLATION
Install in the reverse order of removal.
1. Grommet 2. Back door finisher center lower 3. Rear view camera
4. Back door opener request switch 5. Back door finisher center upper
JMKIA5466ZZ
Revision: 2010 May2011 QX56

SIDE STEPEXT-45
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
EXT
N
O P
SIDE STEP
Exploded ViewINFOID:0000000006367633
Removal and InstallationINFOID:0000000006367634
REMOVAL
1. Remove side step mounting bolts, and then remove side step.
2. Remove side step bracket mounting bolts, and then remove side step brackets.
INSTALLATION
Install in the reverse order of removal.
1. Side step bracket 2. Side step
JMKIA5467ZZ
Revision: 2010 May2011 QX56
