JAGUAR XFR 2010 1.G Workshop Manual

DTC Description Possible Cause Action U300362 Battery Voltage
Mis-match in battery
voltage, of 2 volts or more,
between remote keyless
entry module and RJB Carry out any pinpoint tests associated with this DTC using
the manufacturer approved diagnostic system

Published: 11-May-2011
Multifunction Electronic Modules - Passenger Door Module (PDM)
Diagnosis and Testing

Description and Operation

For a detailed description of the multifunction electronic control modules, refer to the relevant Description and Operation
sections in the workshop manual. REFER to: (419-10 Multifunction Electronic Modules)

Module Controlled Functions (Description and Operation), Module Controlled Functions (Description and Operation), Module Controlled Functions (Description and Operation).
Inspection and Verification


CAUTION: Diagnosis by substitution from a donor vehicle is NOT acceptable. Substitution of control modules does not
guarantee confirmation of a fault, and may also cause additional faults in the vehicle being tested and/or the donor vehicle.
1. Verify the customer concern.
2. Visually inspect for obvious signs of damage and system integrity.



3. If an obvious cause for an observed or reported concern is found, correct the cause (if possible) before proceeding to
the next step.
4. If the cause is not visually evident, check for Diagnostic Trouble Codes (DTCs) and refer to the DTC Index.

DTC Index


CAUTION: When probing connectors to take measurements in the course of the pinpoint tests, use the adaptor kit, part
number 3548-1358-00.
NOTES:


If the control module or a component is suspect and the vehicle remains under manufacturer warranty, refer to the
Warranty Policy and Procedures manual (section B1.2), or determine if any prior approval programme is in operation, prior to
the installation of a new module/component.


Generic scan tools may not read the codes listed, or may read only five digit codes. Match the five digits from the scan
tool to the first five digits of the seven digit code listed to identify the fault (the last two digits give additional information
read by the manufacturer approved diagnostic system).


When performing electrical voltage or resistance tests, always use a digital multimeter (DMM) accurate to three decimal
places, and with an up-to-date calibration certificate. When testing resistance, always take the resistance of the DMM leads
into account.


Check and rectify basic faults before beginning diagnostic routines involving pinpoint tests.


Inspect connectors for signs of water ingress, and pins for damage and/or corrosion.


If DTCs are recorded and, after performing the pinpoint tests, a fault is not present, an intermittent concern may be the
cause. Always check for loose connections and corroded terminals.

DTC Description Possible Cause Action B10EB11
Driver door double
locking motor
Driver door double locking motor
control circuit - short to ground Refer to the electrical circuit diagrams and test driver
door double locking motor control circuit for short ground Electrical

Fuse(s)
Electrical connector(s)
Wiring Harness Visual Inspection

DTC Description Possible Cause Action B10EB15
Driver door double
locking motor
Driver door double locking motor
control circuit - short to power,
open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test driver
door double locking motor control circuit for short to power or open circuit B10EC11
Passenger door
double locking
motor
Passenger door double locking
motor control circuit - short to
ground Refer to the electrical circuit diagrams and test
passenger door double locking motor control circuit for
short ground B10EC15
Passenger door
double locking
motor
Passenger door double locking
motor control circuit - short to
power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test
passenger door double locking motor control circuit for
short to power or open circuit B10ED11
Rear door driver side
double locking
motor
Rear door driver side double
locking motor control circuit -
short to ground Refer to the electrical circuit diagrams and test rear
door driver side double locking motor control circuit for
short ground B10ED15
Rear door driver side
double locking
motor
Rear door driver side double
locking motor control circuit -
short to power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test rear
door driver side double locking motor control circuit for
short power, open circuit B10EE11
Rear door passenger
side double locking
motor
Rear door passenger side double
locking motor control circuit -
short to ground Refer to the electrical circuit diagrams and test rear
door passenger side double locking motor control circuit
for short ground B10EE15
Rear door passenger
side double locking
motor
Rear door passenger side double
locking motor control circuit -
short to power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test rear
door passenger side double locking motor control circuit
for short power, open circuit B110911
Passenger door
central locking
motor
Passenger door central locking
motor control circuit - short to
ground Refer to the electrical circuit diagrams and test
passenger door central locking motor control circuit for
short ground B110915
Passenger door
central locking
motor
Passenger door central locking
motor control circuit - short to
power, open circuit Refer to the electrical circuit diagrams and test
passenger door central locking motor control circuit for
short to power, open circuit B110B11
Rear door passenger
side central locking
motor
Rear passenger door central
locking motor control circuit -
short to ground Refer to the electrical circuit diagrams and test rear
passenger door central locking motor control circuit for
short ground B110B15
Rear door passenger
side central locking
motor
Rear passenger door central
locking motor control circuit -
short to power, open circuit Refer to the electrical circuit diagrams and test rear
passenger door central locking motor control circuit for
short to power, open circuit B116311
Left Mirror Heater
Output
Left mirror heater control circuit
- short to ground Refer to the electrical circuit diagrams and test left
mirror heater control circuit for short to ground B116315
Left Mirror Heater
Output
Left mirror heater control circuit
- short to power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test left
mirror heater control circuit for short to power, open
circuit B116411
Right Mirror Heater
Output
Right mirror heater control circuit
- short to ground Refer to the electrical circuit diagrams and test right
mirror heater control circuit for short to ground B116415
Right Mirror Heater
Output
Right mirror heater control circuit
- short to power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test right
mirror heater control circuit for short to power, open
circuit B116511
Left Front Puddle
Lamp Output
Left front puddle lamp control
circuit - short to ground Refer to the electrical circuit diagrams and test left front
puddle lamp control circuit for short to ground

DTC Description Possible Cause Action B116515
Left Front Puddle
Lamp Output
Left front puddle lamp control
circuit - short to power, open
circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test left front
puddle lamp control circuit for short to power, open
circuit B116611
Right Front Puddle
Lamp Output
Right front puddle lamp control
circuit - short to ground Refer to the electrical circuit diagrams and test right
front puddle lamp control circuit for short to ground B116615
Right Front Puddle
Lamp Output
Right front puddle lamp control
circuit - short to power, open
circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test right
front puddle lamp control circuit for short to power, open
circuit B117C07
Rear Power Window
Up
Mechanical failure Check rear window mechanism for mechanical failure B117C72
Rear Power Window
Up
Actuator stuck open Suspect the rear door module. Check and install a new
module as required, refer to the new module/component
installation note at the top of the DTC Index B117C73
Rear Power Window
Up
Actuator stuck closed Suspect the rear door module. Check and install a new
module as required, refer to the new module/component
installation note at the top of the DTC Index B117C92
Rear Power Window
Up
Performance or incorrect
operation Refer to the electrical circuit diagrams and check rear
door module power and ground supplies B117D72
Rear Power Window
Down
Actuator stuck open Suspect the rear door module. Check and install a new
module as required, refer to the new module/component
installation note at the top of the DTC Index B117D73
Rear Power Window
Down
Actuator stuck closed Suspect the rear door module. Check and install a new
module as required, refer to the new module/component
installation note at the top of the DTC Index B117E07
Front Power Window
Up
Mechanical failure Check the front window mechanism for mechanical
failure B117E72
Front Power Window
Up
Actuator stuck open Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index B117E73
Front Power Window
Up
Actuator stuck closed Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index B117F72
Front Power Window
Down
Actuator stuck open Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index B117F73
Front Power Window
Down
Actuator stuck closed Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index B118929
Front Window
Position Sensor
Front window hall position
sensor - signal invalid Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system B118A29
Rear Window
Position Sensor
Rear window hall position sensor
- signal invalid Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system B11D183 LIN Bus Circuit "C"
Value of signal protection
calculation incorrect Suspect driver switchpack. Check and install a new
driver switchpack as required, refer to the new
module/component installation note at the top of the
DTC Index B11D186 LIN Bus Circuit "C" Signal invalid
Suspect driver switchpack. Check and install a new
driver switchpack as required, refer to the new
module/component installation note at the top of the
DTC Index B11D187 LIN Bus Circuit "C" Missing message
Suspect driver switchpack. Check and install a new
driver switchpack as required, refer to the new
module/component installation note at the top of the
DTC Index B11F711
Passenger Folding
Mirror Motor
Passenger folding mirror motor
control circuit - short to ground Refer to the electrical circuit diagrams and check
passenger folding mirror motor control circuit for short
to ground B11F715
Passenger Folding
Mirror Motor
Passenger folding mirror motor
control circuit - short to power,
open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and check
passenger folding mirror motor control circuit for short
to power, open circuit

DTC Description Possible Cause Action B1A9883 LIN Bus Circuit #1
Value of signal protection
calculation incorrect Refer to the electrical circuit diagrams and check LIN
circuit between DDM and rear door module for
short/open circuits B1A9886 LIN Bus Circuit #1
Signal invalid Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and check LIN
circuit between DDM and rear door module for short/open circuits B1A9887 LIN Bus Circuit #1
Missing message Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and check LIN
circuit between DDM and rear door module for short/open circuits B1C1111
Passenger
Left/Right Mirror
Motor Circuit
Passenger left/right mirror motor
control circuit - short to ground Refer to the electrical circuit diagrams and test
passenger left/right mirror motor control circuit for short
to ground B1C1115
Passenger
Left/Right Mirror
Motor Circuit
Passenger left/right mirror motor
control circuit - short to power,
open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test
passenger left/right mirror motor control circuit for short
to power, open circuit B1C1211
Passenger Up/Down
Mirror Motor Circuit
Passenger up/down mirror motor
control circuit - short to ground Refer to the electrical circuit diagrams and test
passenger up/down mirror motor control circuit for short
to ground B1C1215
Passenger Up/Down
Mirror Motor Circuit
Passenger up/down mirror motor
control circuit - short to power,
open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test
passenger up/down mirror motor control circuit for short
to power, open circuit B1C1511
Passenger Up/Down
Mirror Motor
Feedback Circuit
Passenger up/down mirror motor
feedback circuit - short to
ground Refer to the electrical circuit diagrams and test
passenger up/down mirror motor feedback circuit for
short to ground B1C1515
Passenger Up/Down
Mirror Motor
Feedback Circuit
Passenger up/down mirror motor
feedback circuit - short to power,
open circuit Refer to the electrical circuit diagrams and test
passenger up/down mirror motor feedback circuit for
short to power, open circuit B1C1611
Passenger
Left/Right Mirror
Motor Feedback
Circuit
Passenger left/right mirror motor
feedback circuit - short to ground Refer to the electrical circuit diagrams and test
passenger left/right mirror motor feedback circuit for
short to ground B1C1615
Passenger
Left/Right Mirror
Motor Feedback
Circuit
Passenger left/right mirror motor
feedback circuit - short to power,
open circuit Refer to the electrical circuit diagrams and test
passenger left/right mirror motor feedback circuit for
short to power, open circuit B1D0611 Left Turn Indicator
Left side turn indicator repeater
lamp circuit - short to ground Refer to the electrical circuit diagrams and check left
side turn indicator repeater lamp circuit for short to
ground B1D0615 Left Turn Indicator
Left side turn indicator repeater
lamp circuit - short to power,
open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and check left
side turn indicator repeater lamp circuit for short to power, open circuit B1D0711 Right Turn Indicator
Right side turn indicator
repeater lamp circuit - short to
ground Refer to the electrical circuit diagrams and check right
side turn indicator repeater lamp circuit for short to
ground B1D0715 Right Turn Indicator
Right side turn indicator
repeater lamp circuit - short to
power, open circuit Refer to the electrical circuit diagrams and check right
side turn indicator repeater lamp circuit for short to
power, open circuit C1B1411 Sensor Supply #1
Front window position hall
sensor supply circuit - short to
ground Refer to the electrical circuit diagrams and test front
window position hall sensor supply circuit for short to
ground www.JagDocs.com

DTC Description Possible Cause Action C1B1415 Sensor Supply #1
Front window position hall
sensor supply circuit - short to
power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test front
window position hall sensor supply circuit for short to power, open circuit C1B1511 Sensor Supply #2
Hall sensor supply circuit - short
to ground Refer to the electrical circuit diagrams and test window
position hall sensors supply circuit for short to ground C1B1515 Sensor Supply #2
Hall sensor supply circuit - short
to power, open circuit Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system.
Refer to the electrical circuit diagrams and test window
position hall sensors supply circuit for short to power, open circuit U001000
Medium Speed CAN
Communication Bus
Bus off Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system U014000
Lost Communication
With Body Control
Module
Missing message from CJB Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system U020800
Lost Communication
With Seat Control
Module "A"
Missing message from driver
seat module Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system U030000
Internal Control
Module Software
Incompatibility
Invalid configuration message is
received Re-configure the RJB using the manufacturer approved
diagnostic system. Clear the DTC and retest. If the DTC
remains suspect the PDM. Check and install a new
module as required, refer to the new module/component
installation note at the top of the DTC Index U200224 Switch
Signal stuck high Clear DTC and re-test. If DTC remains, suspect the
passenger side window switch. Check and install a new passenger side window switch U200424
Auxiliary Switch
Pack
Left or right rear door local
switch - signal stuck high Check for stuck rear window switch. Refer to the
electrical circuit diagrams and check left or right rear
door local switch circuit for short circuit U201011 Switch illumination
Rear window switch illumination
circuit - short to ground Refer to the electrical circuit diagrams and check rear
window switch illumination circuit for short to ground U201208
Car Configuration
Parameter(s)
Bus signal/message failures Cycle the ignition status and re-test. If DTC remains,
re-configure the RJB using the manufacturer approved diagnostic system U201324 Switch Pack
Signal stuck high Clear DTC and re-test. If DTC remains, install a new
driver door switch pack U201444
Control Module
Hardware
Data memory failure Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index U210000
Initial Configuration
Not Complete
No sub type information Re-configure the PDM using the manufacturer approved
diagnostic system U300049 Control Module
Internal electronic failure Suspect the PDM. Check and install a new PDM as
required, refer to the new module/component
installation note at the top of the DTC Index U300255
Vehicle
Identification
Number
Not configured Re-configure the PDM as new using the manufacturer
approved diagnostic system and re-test. If DTC remains
install a new module, refer to the new
module/component installation note at the top of the
DTC Index U300281
Vehicle
Identification
Number (VIN)
Vehicle/component mis-match.
Corrupt VIN data being
transmitted, module previously
installed to other vehicle Check and install correct/new module as required, refer
to the new module/component installation note at the
top of the DTC Index U300362 Battery voltage
Mis-match in battery voltage, of
2 volts or more, between PDM
and RJB Carry out any pinpoint tests associated with this DTC
using the manufacturer approved diagnostic system

Cables, General Procedures).

2. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
3.
Installation

1. To install, reverse the removal procedure.

2. If a new component has been installed, configure using Jaguar approved
diagnostic equipment.

Multifunction Electronic Modules - Driver Seat Module (DSM)
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Make the air bag supplemental restraint system (SRS) safe.

Refer to: Standard Workshop Practices (100-00 General Information, Description and Operation).

2. Refer to: Front Seat (501-10 Seating, Removal and Installation). 3.
Installation

1. To install, reverse the removal procedure.

2. If a new component has been installed, configure using Jaguar approved
diagnostic equipment.

Published: 11-May-2011
Multifunction Electronic Modules - Passenger Door Module (PDM)
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
3.
Installation

1. To install, reverse the removal procedure.

Multifunction Electronic Modules - Rear Door Module (RDM)
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Rear Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).




Installation

3. Torque: 1.5 Nm
1. To install, reverse the removal procedure. www.JagDocs.com
