JAGUAR XFR 2010 1.G Workshop Manual

Air deflector retaining nuts 7 - 62 Air deflector retaining bolts 7 - 62 Engine rear undershield retaining bolts 7 - 62 Secondary bulkhead left-hand panel retaining bolts 5 - 44 Secondary bulkhead right-hand panel retaining bolts 5 - 44

Front End Body Panels - Air Deflector
Removal and Installation

Removal Published: 11-May-2011


1. WARNING: Do not work on or under a vehicle supported only by a
jack. Always support the vehicle on safety stands.
Raise and support the vehicle.




Installation
2. NOTE: Note the fitted position of the washers.
Torque: 7 Nm
1. To install, reverse the removal procedure.

Front End Body Panels - Cowl Vent Screen
Removal and Installation

Removal

CAUTION: Always protect paintwork and glass when removing exterior components.


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. For additional information, refer to: Windshield Wiper Pivot Arm (501-16 Wipers and Washers, Removal and Installation).

2.
3.

Front End Body Panels - Engine Rear Undershield
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011


1. WARNING: Make sure to support the vehicle with axle stands.

Raise and support the vehicle.




Installation

2. Torque: 7 Nm
1. To install, reverse the removal procedure. www.JagDocs.com

Front End Body Panels - Fender Splash Shield
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011


1. WARNING: Make sure to support the vehicle with axle stands.

Raise and support the vehicle.

2. Refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation).
3.
Installation

1. To install, reverse the removal procedure.

Front End Body Panels - Hood
Removal and Installation Published: 11-May-2011

Removal


1. NOTE: The hood is manufactured from aluminium. The
hood is serviced as a separate bolt-on panel.


















2. WARNING: The hood and its associated components form part of the
pedestrian protection system, it is essential that any repair or
replacement operations do not affect the safe working of the system.

For additional information relating to the pedestrian safety system
please see the following:
For additional information, refer to: Pedestrian Protection System (501-20C Pedestrian Protection System, Description and Operation).

3. For additional information relating to this repair procedure please see
the following:
For additional information, refer to: Health and Safety Precautions (100-00 General Information, Description and Operation) /
Body Repairs (501-25A Body Repairs - General Information, Description and Operation) /
Corrosion Protection (501-25B Body Repairs - Corrosion Protection, Description and Operation) /
Body and Frame (501-26 Body Repairs - Vehicle Specific Information and Tolerance Checks, Description and Operation).

Installation

1. NOTES:


If the hood hinges are deformed as a result of the pedestrian
protection system deployment, they will need to be replaced.

This step requires the aid of another technician.
Offer up the panel and loosely install the hood hinge retaining nuts.

2. Check alignment, if correct, proceed to next step, if not, rectify and
recheck before proceeding.

3. Tighten the hood hinge retaining nuts to 17 Nm and connect the struts
and secure with the clips.

4. Loosely install both hood strikers.




























5. Gently close the hood so that the strikers are aligned to the latches.

6. Check alignment, if correct, proceed to next step, if not, rectify and
recheck before proceeding.

7. Tighten the hood striker nuts to 17 Nm. www.JagDocs.com
