JAGUAR XFR 2010 1.G Workshop Manual

(100-00 General Information, Description and Operation) /
Body Repairs (501-25A Body Repairs - General Information, Description and Operation) /
Corrosion Protection (501-25B Body Repairs - Corrosion Protection, Description and Operation) /
Body and Frame (501-26 Body Repairs - Vehicle Specific Information and Tolerance Checks, Description and Operation).


3. NOTE: If the procedure includes removal of the rear door components,
the battery can remain connected to aid their removal and disconnected
afterwards.
Disconnect the battery ground cable.
For additional information, refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


4. NOTE: For new rear door installation, this step may be carried out
later in the removal procedure.

Disconnect the rear door wiring harness, accessed behind the grommet
on the B-pillar.


5. NOTE: For new rear door installation, this step may be carried out
later in the removal procedure.
Release the rear door check strap from the body.


6. NOTE: This step is for removing the fully trimmed rear door for access
only, for installing a new front door, continue to removal step 7.

(501-11 Glass, Frames and Mechanisms, Removal and Installation).

8. Remove the rear door latch.
For additional information, refer to: Rear Door Latch (501-14 Handles, Locks, Latches and Entry Systems, Removal and Installation).

9. Remove the rear door outer window frame mouldings.

10. Remove the rear door weatherstrips.

11. Remove the rear door wiring harness.

12. Remove the rear door impact absorbers.

13. Remove the rear door check strap.

14. Remove the rear door glass run felt.

15. Remove any miscellaneous rear door clips, grommets and blanking
covers.

16. NOTE: If new hinges are being fitted, install the
complete hinges to the B-pillar.

Remove the upper and lower rear door hinge bolts and
remove the rear door.










Installation


1. NOTE: If the rear door has been removed for access only, it can be
installed back on to its upper and lower hinge pivots and secured with
the upper and lower hinge pivot bolts.
Offer up the rear door and loosely install the rear door hinge bolts.

2. Check alignment, if correct, proceed to next step, if not, rectify and
recheck before proceeding.

3. Tighten the rear door hinge bolts to 30 Nm.

4. When correctly aligned and with the rear door hinge bolts tightened, the
new rear door can be removed at its upper and lower hinge pivot bolts
for refinishing.

Front Safety belt shoulder height adjuster retaining bolt 25 19 - Rear safety belt lower retaining bolt 40 30 - www.JagDocs.com

Interior Trim and Ornamentation - A-Pillar Trim Panel
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.


1.
2. Published: 11-May-2011














3. Torque: 6 Nm

Interior Trim and Ornamentation - B-Pillar Lower Trim Panel
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Front Scuff Plate Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

2. Refer to: Rear Scuff Plate Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).







Installation

3.

















4. CAUTION: Make sure that the clips are correctly
located.

1. To install, reverse the removal procedure.

Interior Trim and Ornamentation - B-Pillar Upper Trim Panel
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: B-Pillar Lower Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

2.
3.

5. www.JagDocs.com
