JAGUAR XFR 2010 1.G Workshop Manual

1. CAUTION: Only tighten the bolts finger-tight at this stage.














2. CAUTION: Tighten the bolts in the sequence shown.
Torque:
Bolt 1 63 Nm Bolt 2 63 Nm Bolt 1 63 Nm


















3. Torque: 12 Nm www.JagDocs.com

5.
















6. Install the special tool to the front subframe.

Special Tool(s): 502-005

8. Torque:
Stage 1:80





















9. Remove the special tool.

Special Tool(s): 502-005 Nm
240°
Stage 2:

10. Remove the special tool.

Special Tool(s): 502-005
























11.

























Torque:
Stage 1: 100 Nm Stage 2: 270°













12. CAUTION:
Make sure each bolt aligns with the removal markings.

Torque: 175 Nm

13. CAUTION:
Make sure each bolt aligns with the removal markings.

Torque: 175 Nm











14.






















15.
NOTE: Repeat the step for the other side.

Torque: 175 Nm




















Torque: 43 Nm

17.

























Torque: 100 Nm














18. Torque: 45 Nm www.JagDocs.com

Torque: 5 Nm

24.




































25.





































CAUTION:
Make sure to protect the paintwork.

Special Tool(s): 303-1436 Special Tool(s): 303-021
