Engine - V8 S/C 5.0L Petrol - Exhaust Manifold LH
Removal and Installation
Special Tool(s)
303-1444-01
Exhaust Manifold Installation Guide Pins - Threaded
303-1444-02
Exhaust Manifold Installation Guide Pins - Unthreaded Removal
NOTES:
Removal steps in this procedure may contain installation details.
Some variation in the illustrations may occur, but the essential information is always correct. Published: 11-May-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.
3. Refer to: Power Steering Pump - V8 5.0L Petrol/V8 S/C 5.0L Petrol (211-02 Power Steering, Removal and Installation).
4. Refer to: Catalytic Converter LH (309-00C Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation).
Page 972 of 3039
Installation
13.
NOTE: Do not disassemble further if the component is
removed for access only.
1. CAUTIONS:
Make sure that the mating faces are clean and free of
foreign material.
Make sure the anti-seize compound does not contact
the catalyst monitor sensor tip.
If accidentally dropped or knocked install a new
sensor.
Make sure the catalyst monitor sensor wiring harness
is not twisted more than 180 degrees and is not in contact
with either the exhaust or driveshaft.
NOTE: If the original sensor is to be installed, apply
lubricant meeting specification ESE-M12A4-A to the thread
of the sensor.
Torque: 45 Nm
2. NOTE: Install a new gasket.
Special Tool(s): 303-1444-01
Page 973 of 3039
3. NOTE: If a new cylinder head is installed use the
special tools in the illustration.
Special Tool(s): 303-1444-02
4. CAUTION: Make sure that new bolts are installed.
NOTE: Install the spacers in the noted position.
Torque: 10 Nm
5. Remove the special tool.
6. CAUTION: Make sure that new bolts are installed.
NOTE: Install the spacers in the noted position.
Torque: 10 Nm
Page 977 of 3039
Engine - V8 S/C 5.0L Petrol - Exhaust Manifold RH
Removal and Installation
Special Tool(s)
303-1444-01
Exhaust Manifold Installation Guide Pins - Threaded
303-1444-02
Exhaust Manifold Installation Guide Pins - Unthreaded Removal Published: 11-May-2011
NOTE: Some variation in the illustrations may occur, but the essential information is always correct.
All vehicles
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. NOTE: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.
3. Refer to: Catalytic Converter RH (309-00C Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation).
Right-hand drive vehicles
4.
Page 980 of 3039
Installation
12.
NOTE: Do not disassemble further if the component is
removed for access only.
All vehicles
1. Torque: 45 Nm 2. CAUTION: LH illustration shown, RH is similar.
NOTE: Install a new gasket.
Install the special tool.
Special Tool(s): 303-1444-01
Page 981 of 3039
3. CAUTION: LH illustration shown, RH is similar.
NOTE: If a new cylinder head is installed use the
special tools in the illustration.
Install the special tool.
Special Tool(s): 303-1444-02
4. CAUTIONS:
Make sure that new bolts are installed.
LH illustration shown, RH is similar.
NOTE: Install the spacers in the noted position.
Torque: 10 Nm
5. CAUTION: LH illustration shown, RH is similar.
Remove the special tool.
6. CAUTIONS:
Make sure that new bolts are installed.
LH illustration shown, RH is similar.
NOTE: Install the spacers in the noted position.
Torque: 10 Nm www.JagDocs.com
Page 986 of 3039
Engine - V8 S/C 5.0L Petrol - Oil Cooler
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 19-Nov-2013
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Cooling System Partial Draining, Filling and Bleeding - V8 S/C 5.0L Petrol (303-03C Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol, General Procedures).
4. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
5.
6. www.JagDocs.com
Page 991 of 3039
Engine - V8 S/C 5.0L Petrol - Oil Pan
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Engine Oil Level Sensor (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, Removal and Installation).
4. www.JagDocs.com
Page 992 of 3039
Installation
1. CAUTIONS:
Use only a plastic scraper when removing the sealing
material.
Use lint free cloth.
Make sure that the mating faces are clean and free of
corrosion and foreign material.
Apply RTV sealant WSE-M4G323-A6 (Loctite 5901G)
to the areas shown, and tighten the bolts within 7
minutes.
Apply a bead of sealant, 2.5 mm diameter, to the
area indicated.
2. NOTE: Tighten the bolts in the sequence shown.
Torque: 12 Nm
3. Refer to: Engine Oil Level Sensor (303-14D Electronic Engine Controls - V8 S/C 5.0L Petrol, Removal and Installation).
Page 993 of 3039
303-1442
Rear Crankshaft Seal Installer
303-1443
Rear Crankshaft Cover Alignment Tool Removal
NOTES:
Removal steps in this procedure may contain installation details.
Some variation in the illustrations may occur, but the essential information is always correct. Published: 03-Dec-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Do not work on or under a vehicle supported only by a jack. Always
support the vehicle on safety stands.
Raise and support the vehicle.
3. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).
4. Refer to: Engine (303-01D Engine - V8 S/C 5.0L Petrol, Installation).
