JAGUAR XFR 2010 1.G Workshop Manual

2. Remove the special tool.

Special Tool(s): 303-1442 www.JagDocs.com

4. NOTE: Tighten the bolts in the indicated sequence.
Special Tool(s): JLR-303-1622 Torque: 11 Nm

Torque: 11 Nm


















6. Refer to: Flexplate (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

Engine - V8 S/C 5.0L Petrol - Cylinder Head LH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 18-May-2012

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.

3. Refer to: Camshaft LH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

4. Refer to: Exhaust Manifold LH (303-01C Engine - V8 5.0L Petrol, Removal and Installation).

5.
6.

7.
















8.
9.
10. CAUTION: Discard the seal.


NOTE: Engine shown removed for clarity.



















































NOTE: Clamp the hose to minimize coolant loss.

11.























12.
13. NOTE: Clamp the hose to minimize coolant loss.


















































CAUTION: Discard the seals. www.JagDocs.com

17.
18. CAUTIONS:


If a new cylinder head has been installed then new
tappets must be installed.


If the cylinder head is being removed without a new
component being installed, the tappets must be installed in
their original positions.


NOTE: Left-hand shown, right-hand similar.

Installation 19.


1. CAUTION: An acceptable flatness of the cylinder head is
0.1mm.

Check cylinder head face for distortion, across the center
and from corner to corner.













2. WARNING: Make sure care is taken when handling the
cylinder head gasket.

CAUTIONS:


The head gasket must be installed over the cylinder
block dowels.


Make sure that the mating faces are clean and free of
foreign material.


NOTE: Install a new cylinder head gasket.

3. CAUTION: Make sure that new cylinder head bolts are
installed.


NOTE: Tighten the bolts in the indicated sequence.
Torque: 20 Nm


























4. NOTE: Tighten the bolts in the indicated sequence.
Torque: 35 Nm
