JAGUAR XFR 2010 1.G Workshop Manual

18.























19.
20. NOTE: Clamp the hose to minimize coolant loss.

























CAUTION: Install a new seal.
Torque: 12 Nm www.JagDocs.com

Torque: 25 Nm













23.
Refer to: Exhaust Manifold (303-01A, Removal and Installation).

24. Refer to: Camshaft RH (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

25. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).

26. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Engine - V8 S/C 5.0L Petrol - Engine Mount LH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

All vehicles Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Air Conditioning (A/C) Compressor - V8 5.0L Petrol/V8 S/C 5.0L Petrol (412-03 Air Conditioning, Removal and Installation).

4. CAUTION: Support the engine on a jack. The angle may need to be
adjusted during this procedure.
Support the engine with the lifting equipment.

Left-hand drive vehicles

5.














6. NOTE: Note the fitted position.
Torque: 35 Nm Right-hand side shown, left-hand side similar.

Support and release the power steering rack.


















Torque: 63 Nm Remove and discard the nut.
















Torque: 48 Nm Raise the engine.

Installation
10.

NOTE: Do not disassemble further if the component is
removed for access only.
Torque: 48 Nm Remove and discard the nut.

1. To install, reverse the removal procedure.

Engine - V8 S/C 5.0L Petrol - Engine Mount RH
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

All vehicles Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation).

All vehicles

4. CAUTION: Support the engine on a jack. The angle may need to be
adjusted during this procedure.

Support the engine with the lifting equipment.

Right-hand drive vehicles

5. www.JagDocs.com

6.
7.
All vehicles

8.
NOTE: Note the fitted position.

Torque: 35 Nm













Torque: 100 Nm



















Torque: 63 Nm

Installation 9.



















10. Torque: 48 Nm


















NOTE: Do not disassemble further if the component is
removed for access only.
Torque: 48 Nm
1. To install, reverse the removal procedure.

Engine - V8 S/C 5.0L Petrol - Exhaust Manifold LH
Removal and Installation

Special Tool(s)


303-1444-01
Exhaust Manifold Installation Guide Pins - Threaded

303-1444-02
Exhaust Manifold Installation Guide Pins - Unthreaded Removal

NOTES:


Removal steps in this procedure may contain installation details.


Some variation in the illustrations may occur, but the essential information is always correct. Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

3. Refer to: Power Steering Pump - V8 5.0L Petrol/V8 S/C 5.0L Petrol (211-02 Power Steering, Removal and Installation).

4. Refer to: Catalytic Converter LH (309-00C Exhaust System - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation).

5.
6. CAUTION: Discard the bolt.

NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.












7.
8.
