ENGINE MANAGEMENT SYSTEM - SIEMENS
18-3-16 REPAIRS
Sensor - throttle position (TP) - NAS -
from 03MY
$% 19.22.49
Remove
1.Ensure ignition is switched off.
2.Remove 2 nuts and release throttle pedal and
TP sensor assembly from studs.
3.Disconnect multiplug from TP sensor.
4.Remove throttle pedal and TP sensor
assembly.
Refit
1.Position throttle pedal and TP sensor assembly
and connect multiplug.
2.Fit throttle pedal and TP sensor assembly to
studs and tighten nuts to 25 Nm (18 lbf.ft).
Page 322 of 1007
FUEL DELIVERY SYSTEM - PETROL
ADJUSTMENTS 19-2-1
FUEL DELIVERY SYST EM - PE TROL ADJUST ME NTS
Throttle cable - check and adjust - KV6
$% 19.20.05
Check
1.Remove engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Before adjusting cable, ensure that cable is
correctly routed and located.
Adjust
1.Release cable adjusting nut from abutment
bracket.2.Hold throttle cam in fully closed position.
3.Rotate adjusting nut until all slack is taken out
of inner cable and nut is in contact with rear
face of abutment bracket. Ensure throttle does
not open.
4.Fit throttle cable adjusting nut in abutment
bracket.
5.Operate throttle pedal and ensure that full
throttle pedal movement is available.
6.Fit engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
Page 323 of 1007
FUEL DELIVERY SYSTEM - PETROL
19-2-2 ADJUSTMENTS
Throttle cable - check and adjust - K1.8
$% 19.20.05
Check
1.Before adjusting cable, ensure that cable is
correctly routed and located.
Adjust
1.Release cable adjusting nut from abutment
bracket.
2.Hold throttle cam in fully closed position.
3.Rotate adjusting nut until all slack is taken out
of inner cable and nut is in contact with rear
face of abutment bracket. Ensure throttle does
not open.
4.Fit throttle cable adjusting nut in abutment
bracket.
5.Operate throttle pedal and ensure that full
throttle pedal movement is available.
Fuel system - depressurise - KV6 - Non
NAS
$% 19.50.02
Check
1.Remove acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Position absorbent cloth around fuel feed pipe
connection to collect spillage.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.
3.Pull back cover from hose connector and
carefully release connector.
WARNING: Depressurise the system before
disconnecting any components. Fuel
pressure will be present in the system even
if the ignition has been switched off for
some time.
4.Secure connector once pressure has been
relieved.
5.Fit acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
Page 324 of 1007
FUEL DELIVERY SYSTEM - PETROL
ADJUSTMENTS 19-2-3
Fuel system - depressurise - KV6 - NAS
$% 19.50.02
Check
1.Remove acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2. Up to 03MY: Remove nut and bolt securing coil
and position coil aside.
3.Remove schraeder valve cap.
4.Position absorbent cloth around fuel feed pipe
connection to collect spillage.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.5.Connect adapter LRT-19-006 to schraeder
valve.
6.Position opposite end of adapter LRT-19-006
into container, turn tap to release pressure.
7.Remove adapter LRT-19-006 from schraeder
valve.
8.Fit cap to schraeder valve.
9. Up to 03MY: Fit and tighten nut and bolt
securing coil.
10.Fit acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
Page 325 of 1007
FUEL DELIVERY SYSTEM - PETROL
19-2-4 ADJUSTMENTS
Fuel system - depressurise - K1.8
$% 19.50.02
Check
1.Position absorbent cloth around fuel feed pipe
connection to collect spillage.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.
2.Disconnect fuel feed hose from fuel rail.
3.Connect feed hose to fuel rail once pressure
has relieved.
Fuel system - pressure test - KV6 - Non
NAS
$% 19.50.13
Check
1.Remove engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Position absorbent cloth around fuel feed pipe
connection to collect spillage.
WARNING: Fuel vapour is highly flammable
and in confined spaces is also explosive
and toxic. Always have a fire extinguisher
containing foam, CO
2, gas or powder close
at hand when handling or draining fuel.
3.Disconnect fuel inlet hose from fuel rail pipe.
4.Connect adaptor LRT-19-013, to pressure
gauge LRT-19-004 .
5.Position pressure gauge LRT-19-004, connect
to fuel inlet hose and to fuel rail pipe, securing
pressure gauge hose to fuel rail pipe with clip.
6.Start engine. Pressure at idle = 3.4 bar. If
pressure below 3.4 bar suspect the following in
order: fuel hoses, filter, regulator and pump.
7.Stop engine.
8.Release clip and disconnect LRT-19-004
pressure gauge from fuel inlet hose and fuel rail
pipe.
9.Disconnect adaptor LRT-19-013 from LRT-19-
004 pressure gauge.
10.Connect fuel inlet hose to fuel rail pipe.
11.Fit engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
M19 3247A
LRT-19 - 013
LRT -19- 004
Page 326 of 1007
FUEL DELIVERY SYSTEM - PETROL
ADJUSTMENTS 19-2-5
Fuel system - pressure test - KV6 - NAS
$% 19.50.13
Remove
1.Remove acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Position absorbent cloth beneath fuel rail.
WARNING: Fuel vapour is highly flammable
and in confined spaces is also explosive
and toxic. Always have a fire extinguisher
containing foam, CO
2, gas or powder close
at hand when handling or draining fuel.
3. Up to 03MY: Remove nut and bolt securing coil
and position coil aside.
4.Connect adaptor LRT-19-006, to pressure
gauge LRT-19-004 .
5.Remove schraeder valve cap.
6.Connect pressure gauge to fuel rail schraeder
valve.
7.Start engine. Pressure at idle = 3.4 bar. If
pressure is below 3.4 bar, suspect the following
in order: fuel hoses, filter, regulator and pump.
Refit
1.Stop engine.
2.Disconnect pressure gauge LRT-19-006 and
adapter LRT-19-004 from fuel rail.
3. Up to 03MY: Fit and tighten nut and bolt
securing coil.
4.Fit acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
Fuel system - pressure test - K1.8
$% 19.50.13
Check
1.Disconnect battery earth lead.
2.Position absorbent cloth beneath fuel pipe to
catch spillage.
WARNING: The spilling of fuel is
unavoidable during this operation. Ensure
that all necessary precautions are taken to
prevent fire and explosion.
3.Disconnect fuel pipe from inlet manifold.
4.Connect LRT-19-004A to manifold and fuel
pipe.
Note:: LRT-19-004X can be used as an
alternative.
5.Connect battery earth lead.
6.Start engine. Pressure at idle = 3.6 bar ± 0.2
bar.
7.Stop engine. If pressure is out of tolerance
suspect the following in order: fuel hoses, filter
and pump.
8.Remove plug, reconnect vacuum hose and
secure hose with clip.
9.Disconnect battery earth lead.
10.Disconnect LRT-19-004A from fuel pipe and
inlet manifold.
11.Connect fuel pipe to manifold.
12.Connect battery earth lead.
LRT - 19 -004A
M19 3675
Page 327 of 1007
FUEL DELIVERY SYSTEM - PETROL
19-2-6 ADJUSTMENTS
Fuel tank - drain
$% 19.55.02
Drain
1.Disconnect both battery leads, negative lead
first.
2.Remove fuel pump assembly.
+ FUEL DELIVERY SYSTEM -
PETROL, REPAIRS, Pump - fuel.
3.Using a fuel recovery appliance, drain the fuel
from the tank into a sealed container. Follow
the manufacturer's instructions for the
connection and safe use of the appliance.
WARNING: Fuel vapour is highly flammable
and in confined spaces is also explosive
and toxic. Always have a fire extinguisher
containing foam, CO
2, gas or powder close
at hand when handling or draining fuel.
Refill
1.Fit fuel pump assembly.
+ FUEL DELIVERY SYSTEM -
PETROL, REPAIRS, Pump - fuel.
2.Connect battery leads, earth lead last.
Page 328 of 1007
FUEL DELIVERY SYSTEM - PETROL
REPAIRS 19-2-7
REPAIRS
Air cleaner - K1.8
$% 19.10.01
Remove
1.Release air intake duct from air cleaner.
2.Remove clip and disconnect air intake hose
from throttle housing.3.Remove 2 bolts securing air cleaner to battery
tray.
4.Remove air cleaner assembly.
Refit
1.Position air cleaner assembly.
NOTE: Ensure bottom of air cleaner is located
on peg.
2.Fit bolts and tighten to 9 Nm (7 lbf.ft).
3.Connect air intake hose to throttle housing and
secure with clip.
4.Connect air intake duct to air cleaner.
Page 329 of 1007
FUEL DELIVERY SYSTEM - PETROL
19-2-8 REPAIRS
Element - air cleaner - K1.8
$% 19.10.10
Remove
1.Release 4 clips securing air cleaner top casing.
2.Release casing and position aside.
3.Remove air cleaner element.
Refit
1.Clean inside of air cleaner.
2.Fit air cleaner element.
3.Position casing and secure with clips.
Element - air cleaner - KV6
$% 19.10.10
Remove
1.Remove acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Remove 2 screws securing air cleaner element
cartridge to acoustic cover.
3.Release cartridge from acoustic cover and
remove air cleaner element from cartridge.
Refit
1.Clean air cleaner element cartridge.
2.Fit new air cleaner element in cartridge.
3.Position cartridge to acoustic cover, fit and
tighten screws.
4.Fit engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
M19 3328
M19 3195
M19 3196
Page 330 of 1007
FUEL DELIVERY SYSTEM - PETROL
REPAIRS 19-2-9
Element - air cleaner - KV6 - NAS
$% 19.10.10
Remove
1.Remove acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
2.Remove 2 screws securing heat shield to
acoustic cover, remove heat shield.
3.Remove 2 screws securing air cleaner element
cartridge to acoustic cover.
4.Remove cartridge from acoustic cover and
remove element.Refit
1.Clean cover and cartridge.
2.Fit element, fit cartridge to cover and secure
with screws.
3.Fit heat shield and secure with screws.
4.Fit engine acoustic cover.
+ ENGINE - K SERIES KV6, REPAIRS,
Cover - engine acoustic.
M19 3195
M19 3196
