MITSUBISHI LANCER EVOLUTION X 2008 Workshop Manual

GENERAL INFORMATION
INTERIOR52A-2
GENERAL INFORMATIONM2520000101013
Functionality, interior comfort, and safety have been
emphasized, giving interior design for elegance and
relaxation space. Various measures have been taken
to protect the environment and recycle resources.
FEATURES
Quality improvement
1. Two-tone interior
2. Full interior trim
Usability improvement
1. Armrest (floor console, rear seat, front door trim, rear door trim)
2. Cup holder (floor console, rear seat armrest)
3. Bottle holder (front door trim)
Convenient storage
1. Glove box
2. Seatback pocket (driver’s seat)
3. Card holder (glove box)
4. Tissue paper holder (floor console)
5. Floor console box
6. Door pocket (front door trim, rear door trim)
Safety improvement
1. Front and rear collision protection seat mecha-
nism (front seat)
2. ISO-FIX lower anchor (rear seat outside)
3. Upper tether anchor (rear shelf)
4. ELR 3-point seat belt (driver’s seat)
5. ELR/ALR 3-point seat belt (front passenger, rear)
6. Seat belt retractor with a driver's side preten-
sioner and force limiter
7. Seat belt retractor with a passenger’s side pre-
tensioner and force limiter
8. Headliner energy absorption rib out curtain air bag>
Consideration for the optimum driving position
1. Seat height adjustment (driver’s seat)
2. Head restraint with height adjustment (front, rear)
3. Seat slide adjustment (front)
Measures for resource recycling
1. Aggressively use PP materials that are easy to recycle and easy to stamp material symbols on
the plastic (resin) parts.
2. Reduction of chemical material (formaldehyde*,
organic solvent)
NOTE: *: Clear and colourless, toxic, irritating odour

INSTRUMENT PANEL AND FLOOR CONSOLE
INTERIOR52A-3
INSTRUMENT PANEL AND FLOOR CONSOLEM2520001000793
The instrument panel and the floor console have the
following features.
•The instrument panel is two-toned.
•The division unit of each part has been enlarged,
also the gap and level difference between the
instrument panel has been minimized to achieve
the delicate quality.
AC609712
Glove box
Card holder
Cup holder Console box Console box
Type B Type C
Tr a y
Armrest
Center tray
Glove box
Tissue paper
holderOrnament panel

INSTRUMENT PANEL AND FLOOR CONSOLE
INTERIOR52A-4
•The decorated panel creating uniformity from the
instrument panel to the door trim has been
adopted.
•The holder in which two cards can be stored has
been installed in the glove box.
•The glove box with damper function has been
installed.
•The center tray for storing small items has been
installed in front of the selector or shift lever cen
-
ter panel.
•The cup holder which can hold two 20-oz bottles
has been equipped. The cup holder can store two
CDs in the upright position and pen-size long
items horizontally.
•Under the arm rest of type B, a large box that can
store 6 CDs has been equipped. (9 CDs for type
C)
•A tray that can store cigarettes and lighters has
been equipped. switch>
•The synthetic cloth is used for the arm rest lid to
enhance luxury and soft feelings.

SEAT
INTERIOR52A-5
SEAT
FRONT SEATM2520004000996
The front seats offer the following advantages.•The cross frame has been installed below the
seat cushion to reduce a risk of injury by restrain
-
ing the forward travel of the passenger. (Waist
position travel reduction frame structure)
AC609378


AB

Head restraint
vertical adjustment Head restraint
vertical adjustment
Reclining adjustment Reclining adjustment
Seatback pocket
Heated seat
switch
Height adjustment
(Driver's side)
Sliding adjustment Sliding adjustment
Seat heater
Height adjustment
(Driver's side)

SEAT
INTERIOR52A-6
•The seat frame and head restraint have been
installed to the proper positions to minimize the
severity of whiplash injury at rear-end collision at
a low speed. (Whiplash injury reduction seat
structure)
•The overall height mechanism raises and lowers
the seat cushion together with the seatback, thus
the driver's posture is always kept at the best
position, resulting in the improved riding comfort.
•The pump-type height lever has been adopted for
easier operation with a light force by the vertical
adjustment system. Also, the height adjustment
amount has been increased for more optimum
driving position.
•The variable hardness pad has been adopted for
the sporty-look seat with increased bucket
amount of side bolster in order to establish the
sporty shape with support function , and
the standard shape which is basic and for actual
use and comfortable driving.
•Heated seats are available for the driver's and
passenger's seats.
•The genuine leather for the seat has been
upgraded to enhance the texture and luxury feel
-
ing.
SPECIFICATIONS FOR HEATED SEAT
ItemSpecifications
ENERGY CONSUMPTION WHIGH61 ± 6.1
LOW16 ± 1.6
THERMOSTAT °CON → OFF40 ± 4
OFF → ON30 ± 5

SEAT
INTERIOR52A-7
REAR SEATM2520007000605
A low-back bench seat is used for rear seat. The rear
seat offer the following advantages:
•The center armrest has a cup holder.
•An upper tether anchor has been installed on the
rear shelf trim, and an ISO-FIX lower anchor has
been installed on the body side.
AC609174
Cup holderHead restraint
vertical adjustrment
Head restraint
vertical adjustrment
Rear seatback
forward folding
AB

SEAT BELT
INTERIOR52A-8
SEAT BELTM2520010000683
FRONT SEAT BELT
•An ELR three-point seat belt (driver's side) and
three-point seat belt with ELR/ALR changeover
mechanism (passenger's side) is used.
•One-touch push button style adjustable seat belt
anchor and retractable buckle provide the most
suitable belt fitting.
•The seat belt retractor with the force limiter for
the driver’s seat and the front passenger’s seat
increase safety.
•A seat belt warning light is installed to the driver’s
and passenger’s seat.
REAR SEAT BELT
•3-point seat belt with Automatic Locking Retrac-
tor (ALR)/ELR changeover mechanism
(LH/RH/Center) is used for the rear seat.
AC608590
Seat belt warning lamp
Seat belt warning lamp


ELR three-point
seat belt
One-touch push button style
adjustable seat belt
shoulder anchor
ELR/automatic locking
retractor (ALR) switching
three-point seat belt
Seat belt retractor
with a pre-tensioner
and force limiter ELR/automatic locking retractor
(ALR) switching three-point seat belt
Seat belt
retractor
AB

SEAT BELT
INTERIOR52A-9
SEAT BELT RETRACTOR WITH FORCE LIMITER
.The driver’s/front passenger’s seat belt retractor has been
equipped with a force limiter. The force limiter is a device which
operates when a predetermined force is applied, and limits the
force.
.
OPERATION
1. If a collision energy is transmi tted to the seat belt, the ELR
mechanism will operate to lock the seat belt.
2. If the energy increases to a predetermined value, the torsion bar will be distorted. As the spindle rotates together with the
torsion bar, the seat belt w ebbing is pulled out, reducing the
impact to the occupants.
AC100083
TORSION BAR
SPINDLE
BELT
AB

TRIMS
INTERIOR52A-10
TRIMS
INTERIOR TRIMSM2520012000559
•The interiors are fully covered by trims.
•The energy absorption rib molding located in the
back side of the front pillar trim and the rear pillar
trim protect head from side impacts and the resin
materials for the trims are unbreakable materials.
•Use of nonflammable materials for the trims has
increased safety as outstanding interiors. Also,
material codes are indicated to deal with recy
-
cling easily.
AC608126
Energy absorption ribFront pillar trim
(back side)
Front pillar trim
Cowl side trim Center pillar trim upper
Rear pillar trim
Front scuff plate Center pillar trim lower
Rear scuff plate
Trunk side trimRear end trim
AB
Rear shelf trim Trunk lid trim

TRIMS
INTERIOR52A-11
DOOR TRIMM2520012300594
•The decorated panel has been adopted for the
front door trim.
•The bottle holder for bottles with shapes that are
difficult to keep upright has been adopted for the
front door pocket.
•The front door pocket with a large capacity has
been adopted for items such as A4-size map.
Also, the rear door pocket has been added.
•The shock absorbing arm rest has been adopted
which reduces the mid section injuries to passen
-
gers by collapsing upon side impact.
•The arm rest which is formed with cloth has been
adopted to create a continuous flow with the
ornament section.
AC608432


Door pocketDoor pocket
Armrest
Bottle holder
Armrest
Ornament panel
AB
