NISSAN NOTE 2016 Service Repair Manual

AV-256
< REMOVAL AND INSTALLATION >[NAVIGATION]
ANTENNA FEEDER
ANTENNA FEEDER
Feeder LayoutINFOID:0000000012433110
1. Antenna base (antenna amp. and
satellite antenna) 2. Rod Antenna
3. M351
4. M352 5. M110, M3536. M67, M350
7. M109 8. M73
ALNIA1520ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCS-1
ELECTRICAL & POWER CONTROL
C
DE
F
G H
I
J
K L
B
SECTION BCS
A
O P
N
CONTENTS
BODY CONTROL SYSTEM
WITH INTELLIGENT KEY SYSTEM
PRECAUTION ....... ........................................
5
PRECAUTIONS .............................................. .....5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
SYSTEM DESCRIPTION ..............................6
COMPONENT PARTS ................................... .....6
BODY CONTROL SYSTEM ........................................6
BODY CONTROL SYSTEM : Component Parts
Location ............................................................... ......
6
POWER CONSUMPTION CONTROL SYSTEM ... ......6
POWER CONSUMPTION CONTROL SYSTEM :
Component Parts Location ........................................
6
SYSTEM ..............................................................7
BODY CONTROL SYSTEM ........................................7
BODY CONTROL SYSTEM : System Description ......7
BODY CONTROL SYSTEM : Fail-safe ............... ......8
COMBINATION SWITCH READING SYSTEM ..... ......9
COMBINATION SWITCH READING SYSTEM :
System Description ...................................................
9
SIGNAL BUFFER SYSTEM ........................ ..............12
SIGNAL BUFFER SYSTEM : System Description ....13
POWER CONSUMPTION CONTROL SYSTEM ... ....13
POWER CONSUMPTION CONTROL SYSTEM :
System Description .................................................
13
SHIPPING MODE CONTROL SYSTEM ....................15
SHIPPING MODE CONTROL SYSTEM : System
Description .......................................................... ....
15
TRANSIT MODE CONTROL SYSTEM .....................15
TRANSIT MODE CONTROL SYSTEM : System
Description ........................................................... ....
15
DIAGNOSIS SYSTEM (BCM) ...........................17
COMMON ITEM ..................................................... ....17
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) .....................................................
17
DOOR LOCK .......................................................... ....18
DOOR LOCK : CONSULT Function (BCM -
DOOR LOCK) ..........................................................
18
REAR DEFOGGER ................................................ ....18
REAR DEFOGGER : CONSULT Function (BCM -
REAR DEFOGGER) ................................................
18
BUZZER ................................................................. ....19
BUZZER : CONSULT Function (BCM - BUZZER) ....19
INT LAMP ............................................................... ....19
INT LAMP : CONSULT Function (BCM - INT
LAMP) ......................................................................
19
HEADLAMP ........................................................... ....20
HEADLAMP : CONSULT Function (BCM - HEAD
LAMP) ......................................................................
20
WIPER .................................................................... ....21
WIPER : CONSULT Function (BCM - WIPER) .......21
FLASHER ............................................................... ....22
FLASHER : CONSULT Function (BCM - FLASH-
ER) ..........................................................................
22
AIR CONDITIONER ............................................... ....22
AIR CONDITIONER : CONSULT Function (BCM -
AIR CONDITIONER) ........................................... ....
22
INTELLIGENT KEY ................................................ ....22
INTELLIGENT KEY : CONSULT Function (BCM -
INTELLIGENT KEY) ................................................
22
COMB SW .............................................................. ....25
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-2
COMB SW : CONSULT Function (BCM - COMB
SW) .........................................................................
25
BCM ........................................................................ ...25
BCM : CONSULT Function (BCM - BCM) ..............25
IMMU ...................................................................... ...26
IMMU : CONSULT Function (BCM - IMMU) ...........26
BATTERY SAVER ................................................. ...26
BATTERY SAVER : CONSULT Function (BCM -
BATTERY SAVER) .................................................
26
THEFT ALM ........................................................... ...27
THEFT ALM : CONSULT Function (BCM -
THEFT) ...................................................................
27
RETAINED PWR .................................................... ...28
RETAINED PWR : CONSULT Function (BCM -
RETAINED PWR) ...................................................
28
SIGNAL BUFFER ................................................... ...28
SIGNAL BUFFER : CONSULT Function (BCM -
SIGNAL BUFFER) ..................................................
28
AIR PRESSURE MONITOR ................................... ...28
AIR PRESSURE MONITOR : CONSULT Function
(BCM - AIR PRESSURE MONITOR) .....................
28
PANIC ALARM ....................................................... ...29
PANIC ALARM : CONSULT Function (BCM -
PANIC ALARM) ......................................................
29
ECU DIAGNOSIS INFORMATION ..............30
BCM ................................................................ ...30
Reference Value .................................................. ...30
Fail-safe ..................................................................48
DTC Inspection Priority Chart ..............................49
DTC Index ........................................................... ...50
WIRING DIAGRAM .....................................52
BCM ................................................................ ...52
Wiring Diagram .................................................... ...52
BASIC INSPECTION ...................................58
ADDITIONAL SERVICE WHEN REPLACING
BCM ................................................................ ...
58
Description ........................................................... ...58
Work Procedure ......................................................58
CONFIGURATION (BCM) .................................59
Description ........................................................... ...59
Work Procedure ......................................................59
Configuration List ....................................................60
SHIPPING MODE CANCEL OPERATION ........61
Work Procedure ................................................... ...61
TRANSIT MODE CANCEL OPERATION ..........62
Work Procedure ................................................... ...62
DTC/CIRCUIT DIAGNOSIS ........................63
U1000 CAN COMM CIRCUIT ......................... ...63
Description ........................................................... ...63
DTC Logic ...............................................................63
Diagnosis Procedure ...............................................63
U1010 CONTROL UNIT (CAN) .........................64
DTC Logic ............................................................ ...64
Diagnosis Procedure ...............................................64
U0415 VEHICLE SPEED ...................................65
DTC Logic ...............................................................65
Diagnosis Procedure ...............................................65
B2562 LOW VOLTAGE .....................................66
DTC Logic ............................................................ ...66
Diagnosis Procedure ...............................................66
POWER SUPPLY AND GROUND CIRCUIT .....67
Diagnosis Procedure ............................................ ...67
COMBINATION SWITCH INPUT CIRCUIT .......68
Diagnosis Procedure ...............................................68
COMBINATION SWITCH OUTPUT CIRCUIT ...70
Diagnosis Procedure ...............................................70
SYMPTOM DIAGNOSIS ............................72
COMBINATION SWITCH SYSTEM SYMP-
TOMS .............................................................. ...
72
Symptom Table .................................................... ...72
NORMAL OPERATING CONDITION ................73
Description ........................................................... ...73
REMOVAL AND INSTALLATION ..............74
BCM (BODY CONTROL MODULE) ............... ...74
Removal and Installation .........................................74
COMBINATION SWITCH ............................... ...75
Removal and Installation .........................................75
WITHOUT INTELLIGENT KEY SYSTEM
PRECAUTION ........ ....................................
76
PRECAUTIONS .............................................. ...76
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .............................................................. ...
76
SYSTEM DESCRIPTION ...........................77
COMPONENT PARTS .................................... ...77
BODY CONTROL SYSTEM ......................................77
BODY CONTROL SYSTEM : Component Parts
Location ............................................................... ...
77
POWER CONSUMPTION CONTROL SYSTEM .... ...77
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
BCS-3
C
DE
F
G H
I
J
K L
B
A
O P
N
POWER CONSUMPTION CONTROL SYSTEM :
Component Parts Location ..................................
....
77
SYSTEM .............................................................78
BODY CONTROL SYSTEM ......................................78
BODY CONTROL SYSTEM : System Description ....78
BODY CONTROL SYSTEM : Fail-safe ............... ....79
COMBINATION SWITCH READING SYSTEM ..... ....79
COMBINATION SWITCH READING SYSTEM :
System Description .................................................
79
SIGNAL BUFFER .................................................. ....84
SIGNAL BUFFER : System Description ..................85
POWER CONSUMPTION CONTROL SYSTEM ... ....85
POWER CONSUMPTION CONTROL SYSTEM :
System Description .................................................
85
SHIPPING MODE CONTROL SYSTEM ....................87
SHIPPING MODE CONTROL SYSTEM : System
Description .......................................................... ....
87
TRANSIT MODE CONTROL SYSTEM .....................87
TRANSIT MODE CONTROL SYSTEM : System
Description .......................................................... ....
88
DIAGNOSIS SYSTEM (BCM) ............................89
COMMON ITEM ..................................................... ....89
COMMON ITEM : CONSULT Function (BCM -
COMMON ITEM) .....................................................
89
DOOR LOCK ......................................................... ....90
DOOR LOCK : CONSULT Function (BCM -
DOOR LOCK) .........................................................
90
REAR DEFOGGER ............................................... ....90
REAR DEFOGGER : CONSULT Function (BCM -
REAR DEFOGGER) ........................................... ....
91
BUZZER ................................................................. ....91
BUZZER : CONSULT Function (BCM - BUZZER) ....91
INT LAMP .............................................................. ....91
INT LAMP : CONSULT Function (BCM - INT
LAMP) .....................................................................
91
MULTI REMOTE ENT ............................................ ....92
MULTI REMOTE ENT : CONSULT Function
(BCM - MULTI REMOTE ENT) ...............................
92
HEADLAMP ........................................................... ....93
HEADLAMP : CONSULT Function (BCM - HEAD
LAMP) .....................................................................
93
WIPER ................................................................... ....94
WIPER : CONSULT Function (BCM - WIPER) .......94
FLASHER .............................................................. ....95
FLASHER : CONSULT Function (BCM - FLASH-
ER) ..........................................................................
95
AIR CONDITIONER ............................................... ....95
AIR CONDITIONER : CONSULT Function (BCM -
AIR CONDITIONER) ........................................... ....
95
COMB SW .............................................................. ....96
COMB SW : CONSULT Function (BCM - COMB
SW) ..........................................................................
96
BCM ....................................................................... ....96
BCM : CONSULT Function (BCM - BCM) ...............96
IMMU ...................................................................... ....96
IMMU : CONSULT Function (BCM - IMMU) ............97
BATTERY SAVER ................................................. ....97
BATTERY SAVER : CONSULT Function (BCM -
BATTERY SAVER) ..................................................
97
THEFT ALM ........................................................... ....97
THEFT ALM : CONSULT Function (BCM -
THEFT) ....................................................................
98
RETAINED PWR .................................................... ....98
RETAINED PWR : CONSULT Function (BCM -
RETAINED PWR) ....................................................
98
SIGNAL BUFFER .................................................. ....98
SIGNAL BUFFER : CONSULT Function (BCM -
SIGNAL BUFFER) ...................................................
98
AIR PRESSURE MONITOR ................................... ....99
AIR PRESSURE MONITOR : CONSULT Function
(BCM - AIR PRESSURE MONITOR) ......................
99
PANIC ALARM ...................................................... ....99
PANIC ALARM : CONSULT Function (BCM -
PANIC ALARM) .....................................................
100
ECU DIAGNOSIS INFORMATION ............101
BCM .................................................................101
Reference Value .................................................. ..101
Fail-safe .................................................................115
DTC Inspection Priority Chart .............................115
DTC Index .............................................................115
WIRING DIAGRAM ....................................117
BCM .................................................................117
Wiring Diagram .................................................... ..117
BASIC INSPECTION .................................121
ADDITIONAL SERVICE WHEN REPLACING
BCM .................................................................
121
Description ........................................................... ..121
Work Procedure .....................................................121
CONFIGURATION (BCM) ...............................123
Description .............................................................123
Work Procedure .....................................................123
Configuration List ...................................................124
SHIPPING MODE CANCEL OPERATION .....125
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-4
Work Procedure .....................................................125
TRANSIT MODE CANCEL OPERATION ........126
Work Procedure ................................................... ..126
DTC/CIRCUIT DIAGNOSIS ...................... ..127
U1000 CAN COMM ......................................... .127
Description ........................................................... ..127
DTC Logic ..............................................................127
Diagnosis Procedure .............................................127
U1010 CONTROL UNIT (CAN) .......................128
DTC Logic ............................................................ ..128
Diagnosis Procedure .............................................128
POWER SUPPLY AND GROUND CIRCUIT ...129
Diagnosis Procedure ........................................... ..129
COMBINATION SWITCH INPUT CIRCUIT .....130
Diagnosis Procedure ........................................... ..130
COMBINATION SWITCH OUTPUT CIRCUIT ..132
Diagnosis Procedure ............................................ .132
SYMPTOM DIAGNOSIS ...........................134
COMBINATION SWITCH SYSTEM SYMP-
TOMS .............................................................. ..
134
Symptom Table .................................................... .134
NORMAL OPERATING CONDITION ...............136
Description ........................................................... .136
REMOVAL AND INSTALLATION .............137
BCM (BODY CONTROL MODULE) ............... ..137
Removal and Installation .......................................137
COMBINATION SWITCH ............................... ..138
Removal and Installation .......................................138
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
PRECAUTIONSBCS-5
< PRECAUTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
PRECAUTION
PRECAUTIONS
Precaution for Supplemental
Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000012432303
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
• Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
• Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS
WARNING:
• When working near the Airbag Diagnosis Sensor Un it or other Airbag System sensors with the Igni-
tion ON or engine running, DO NOT use air or el ectric power tools or strike near the sensor(s) with a
hammer. Heavy vibration could activate the sensor( s) and deploy the air bag(s), possibly causing
serious injury.
• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the
battery and wait at least three mi nutes before performing any service.
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS-6
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
COMPONENT PARTS
SYSTEM DESCRIPTION
COMPONENT PARTS
BODY CONTROL SYSTEM
BODY CONTROL SYSTEM :
Component Parts LocationINFOID:0000000012432304
POWER CONSUMPTION CONTROL SYSTEM
POWER CONSUMPTION CONTROL SYST EM : Component Parts Location
INFOID:0000000012432305
1. BCM
A. View with instrument panel removed
AWMIA1424ZZ
1 Combination meter
Refer to MWI-58, "
METER SYSTEM
: Component Parts Location". 2 IPDM E/R
Refer to PCS-4, "
Component Parts
Location". 3BCM
Refer to BCS-6, "
BODY CONTROL
SYSTEM : Component Parts Loca-
tion".
AWMIA1437ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

BCS
SYSTEMBCS-7
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
SYSTEM
BODY CONTROL SYSTEM
BODY CONTROL SYSTEM
: System DescriptionINFOID:0000000012432306
OUTLINE
• BCM (Body Control Module) controls the various electrical components. It inputs the information required to
the control from CAN communication and the signal received from each switch and sensor.
• BCM has combination switch reading function for reading the operation status of combination switches (light,
turn signal, wiper and washer) in addition to a function fo r controlling the operation of various electrical com-
ponents. It also has the signal transmission function as the passed point of signal and the power saving con-
trol function that reduces the power c onsumption with the ignition switch OFF.
• BCM is equipped with the diagnosis function that performs the diagnosis with CONSULT and various set- tings.
BCM CONTROL FUNCTION LIST
System Reference
Combination switch reading system BCS-9, "
COMBINATION SWITCH READING SYSTEM :
System Description"
Signal buffer system
BCS-13, "SIGNAL BUFFER SYSTEM : System Description"
Power consumption control systemBCS-13, "POWER CONSUMPTION CONTROL SYSTEM :
System Description"
Shipping mode control systemBCS-15, "SHIPPING MODE CONTROL SYSTEM : System
Description"
Transit mode control systemBCS-15, "TRANSIT MODE CONTROL SYSTEM : System
Description"
Headlamp system
EXL-8, "HEADLAMP SYSTEM : System Description"
Daytime running light system (if equipped)EXL-9, "DAYTIME RUNNING LIGHT SYSTEM : System De-
scription"
Turn signal and hazard warning lamp systemEXL-10, "TURN SIGNAL AND HAZARD WARNING LAMP
SYSTEM : System Description"
Parking, license plate and tail lamps systemEXL-11, "PARKING, LICENSE PLATE AND TAIL LAMP SYS-
TEM : System Description"
Front fog lamp system
EXL-10, "FRONT FOG LAMP SYSTEM : System Descrip-
tion"
Exterior lamp battery saver system
EXL-8, "HEADLAMP SYSTEM : System Description"
Interior room lamp control systemINL-7, "INTERIOR ROOM LAMP CONTROL SYSTEM : Sys-
tem Description"
Interior room lamp battery saver systemINL-7, "INTERIOR ROOM LAMP CONTROL SYSTEM : Sys-
tem Description"
Front wiper and washer system
WW-8, "FRONT WIPER AND WASHER SYSTEM : System
Description"
Rear wiper and washer systemWW-10, "REAR WIPER AND WASHER SYSTEM : System
Description"
Rear window defogger system
DEF-6, "System Description"
Manual air conditioning systemHAC-11, "System Description"
Warning chime systemWCS-7, "WARNING CHIME SYSTEM : System Description"
Power door lock systemDLK-20, "System Description"
Nissan vehicle immobilizer system (NVIS)SEC-15, "NISSAN ANTI-THEFT SYSTEM : System Descrip-
tion"
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS-8
< SYSTEM DESCRIPTION >[WITH INTELLIGENT KEY SYSTEM]
SYSTEM
BODY CONTROL SYSTEM : Fail-safe
INFOID:0000000012432307
BCM performs fail-safe control when the following DTCs are detected.
Intelligent Key system/engine start system Door lock function
DLK-23, "
DOOR LOCK FUNCTION : System De scription"
Warning functionDLK-27, "WARNING FUNCTION : System Description"
Key reminder functionDLK-27, "KEY REMINDER FUNCTION : System Descrip-
tion"
Engine start functionSEC-12, "INTELLIGENT KEY SYSTEM/ENGINE START
FUNCTION : System Description"
Power window system
PWC-8, "System Description"
RAP (retained accessory power) systemBCS-28, "RETAINED PWR : CONSULT Function (BCM - RE-
TAINED PWR)"
TPMS (tire pressure monito
ring system) (if equipped) WT-8, "TIRE PRESSURE MONITORING SYSTEM : System
Description"
System
Reference
CONSULT DisplayFail-safe Cancellation
B2192: ID DISCORD BCM-ECM Inhibit engine cranking Erase DTC
B2193: CHAIN OF BCM-ECM Inhibit engine cranking Erase DTC
B2195: ANTI SCANNING Inhibit engine cranking Ignition switch ON → OFF
B2196: DONGLE NG Inhibit engine cranking Erase DTC
B2198: NATS ANTENNA AMP Inhibit engine cranking Erase DTC
B2557: VEHICLE SPEED —When the following CAN signal status (vehicle speed signal) becomes
consistent
• Vehicle speed signal (ABS)
• Vehicle speed signal (Meter)
B2601: SHIFT P SIGNAL —500 ms after the following signal reception status becomes consistent
• Park position switch signal
• P range signal (CAN)
B2602: SHIFT P DIAG —5 seconds after the following BCM recognition conditions are fulfilled
• Ignition switch is in the ON position
• Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
• Vehicle speed: 4 km/h (2.5 MPH) or more
B2603: SHIFT POSITION —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- Park position switch signal: P position (push selector button) or ex-
cept P position (9 – 16 V)
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- Park position switch signal: P position (release selector button) (0 – 1.5 V)
- P/N position signal: P or N positions (9 – 16 V)
B2604: SHIFT PN DIAG CAN —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
- Shift position signal (CAN): P or N position
•Status 2
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
- Shift position signal (CAN): Except P and N position
Revision: August 2015
2016 Versa Note

cardiagn.com

BCS
SYSTEMBCS-9
< SYSTEM DESCRIPTION > [WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G H
I
J
K L
B A
O P
N
COMBINATION SWITCH READING SYSTEM
COMBINATION SWITCH READING SYSTEM : System DescriptionINFOID:0000000012432308
SYSTEM DIAGRAM
OUTLINE
• BCM reads the status of the combination switch
(light, turn signal, wiper and washer) and recognizes the
status of each switch.
B2605: SHIFT PN DIAG IPDM —500 ms after any of the following BCM recognition conditions are fulfilled
•Status 1
- Ignition switch is in the ON position
- P/N position signal: Except P and N positions (0 – 1.5 V)
•Status 2
- Ignition switch is in the ON position
- P/N position signal: P or N position (9 – 16 V)
B2608: STARTER RELAY Inhibit engine cranking 500 ms after the following signal communication status becomes con-
sistent
• Starter motor re
lay control signal
• Starter relay status signal (CAN)
B260F: ECM CAN COMM Inhibit engine cranking When any of the following conditions are fulfilled
• Ignition switch changes to ACC
• Receives engine status signal (CAN)
B26F1: IGN RELAY OFF Inhibit engine cranking When the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): ON
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): ON
B26F2: IGN RELAY ON Inhibit engine crankingWhen the following conditions are fulfilled
• Ignition switch ON signal (CAN: Transmitted from BCM): OFF
• Ignition switch ON signal (CAN: Transmitted from IPDM E/R): OFF
B26F3: START CONT RLY ON Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): OFF
• Starter control relay signal (CAN: Transmitted from IPDM E/R): OFF
B26F4: START CONT RLY OFF Inhibit engine cranking When the following conditions are fulfilled
• Starter control relay signal (CAN: Transmitted from BCM): ON
• Starter control relay signal (CAN: Transmitted from IPDM E/R): ON
B26F7: BCM Inhibit engine cranking
by Intelligent Key sys-
temWhen room antenna and luggage room antenna functions normally
U0415: VDC CAN CIR2 —When vehicle speed signal (Meter) (CAN) is received normally
CONSULT Display
Fail-safe Cancellation
AWMIA1427GB
