NISSAN NOTE 2016 Service Repair Manual

TM-220
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
SHIFT POSITION INDICATOR CIRCUIT
SHIFT POSITION INDICATOR CIRCUIT
Component Parts Fu
nction InspectionINFOID:0000000012431167
1.CHECK SHIFT POSITION INDICATOR
1. Start the engine.
2. Shift selector lever.
3. Check that the selector lever position and the shift position indicator on the combination meter are identi-
cal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to TM-220, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012431168
1.CHECK TCM INPUT/OUTPUT SIGNAL
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “RANGE”.
4. Shift selector lever.
5. Check that selector lever position, “RANGE” on CONSULT screen, and shift position indicator display on
combination meter are identical.
Is the check result normal?
YES >> INSPECTION END
NO-1 (“RANGE” is changed but is not displayed on shift position indicator.>>Check “Self Diagnostic Result” in “TRANSMISSION”.
NO-2 (“RANGE” and shift position indicator are differ ent.)>>Check “Self Diagnostic Result” in “TRANSMIS-
SION”.
NO-3 (Specific“RANGE” is not displayed on shift position indicator.)>>Check “Self Diagnostic Result” in
“METER/M&A”.
Revision: August 2015 2016 Versa Note

cardiagn.com

SHIFT LOCK SYSTEMTM-221
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM
Component Function CheckINFOID:0000000012431169
1.CHECK SHIFT LOCK OPERATIO N (BRAKE PEDAL RELEASED)
1. Ignition switch ON.
2. Attempt to shift selector lever to any position other than “P” position with brake pedal released.
Can the selector lever be shifted?
YES >> Go to TM-221, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK SHIFT LOCK OPERATIO N (BRAKE PEDAL APPLIED)
Attempt to shift the selector lever to any pos ition other than “P” position with brake pedal applied.
Can the selector lever be shifted?
YES >> Inspection End.
NO >> Go to TM-221, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012431170
1.CHECK STOP LAMP SWITCH
1. Ignition switch ON.
2. Check voltage between stop lamp switch connector E13 terminal 4 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK GROUND CIRCUIT
1. Ignition switch OFF.
2. Disconnect CVT shift selector connector.
3. Check continuity between CVT shift selector connector M38 terminal 6 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace ground circuit.
3.CHECK STOP LAMP SWITCH POWER CIRCUIT
Check voltage between stop lamp switch connector E13 terminal 3 and ground.
Is the inspection result normal?
YES >> Replace stop lamp switch.
NO >> Repair or replace power circuit.
Stop lamp switch Ground Brake pedal Voltage
Connector Terminal
E13 4Ground Applied
Battery voltage
Released 0V
CVT shift selector
GroundContinuity
Connector Terminal
M38 6Ground Yes
Stop lamp switch
GroundVoltage
Connector Terminal
E13 3GroundBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-222
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
SHIFT LOCK SYSTEM
4.CHECK CVT SHIFT SELECTOR POWER CIRCUIT
Check voltage between CVT shift selector connector M38 terminal 5 and ground.
Is the inspection result normal?
YES >> Replace CVT shift selector. Refer to TM-231, "Removal and Installation".
NO >> Repair or replace power circuit.
CVT shift selector GroundBrake pedal Voltage
Connector Terminal
M38 5Ground AppliedBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-223
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SYMPTOM DIAGNOSIS
CVT CONTROL SYSTEM
Symptom TableINFOID:0000000012431171
The diagnosis item number indicates the order of check. Start checking in the order from 1.
Symptom diagnosis chart 1-1
SymptomCheck under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure soleno
id valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Driving is
not possi-
ble. The engine speed increases in
“D”, “L”, or “R” position, but the
vehicle cannot start.
11111 11 12 1 1 1 2
Engine stall occurs in “D”, “L”,
or “R” position and the vehicle
does not start. 11 11 1111 1 1 2
Acceleration at start is not suf-
ficient in “D”, “L”, or “R” posi-
tion. 1 2 1 1112211 2 1 1 1
The engine speed increases
suddenly in “D”, “L”, or “R” po-
sition during driving. 11
211 1 1
Engine brake is suddenly ap-
plied in “D” or “R” position dur-
ing driving. 11
11 11
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-224
< SYMPTOM DIAGNOSIS >[CVT: RE0F11A]
CVT CONTROL SYSTEM
Shifting is
not possi-
ble. The engine races when the
auxiliary gearbox is shifted
from 1GR ⇔
2GR. 21
1 11
Engine braking is not effective
in “L” position. 111 11 1 21 1 1
Shifting does not occur with
OD OFF. 111111 11
Engine stall occurs immediate-
ly before stop at deceleration in
“D” or “L” position. 11
During driving in “D” position,
slippage occurs in lockup or
lockup is not possible. 1 1111211 1
1
Symptom
Check under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure solenoid valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Revision: August 2015
2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-225
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Symptom diagnosis chart 1-2
Symptom Replace the transaxle assembly.
Oil pres-
sure con- trol Power transmission
Valve body, control valve
Oil pump
Torque converter
Pulley, steel belt
Low brake
High clutch
Reverse brake
Bearings
Counter gear
Planetary gear
Reduction gear
Final gear, differential gear
Parking mechanism
TM-259
Driving is
not possi- ble. The engine speed increases in
“D”, “L”, or “R” position, but the
vehicle cannot start.
11 11
(In “D” or “L”) 1
(In “R”) 1111
Engine stall occurs in “D”, “L”,
or “R” position and the vehicle
does not start. 1
111111
Acceleration at start is not suf-
ficient in “D”, “L”, or “R” posi-
tion. 111
(In “D” or “L”) 1
(In “R”)
The engine speed increases
suddenly in “D”, “L”, or “R” po-
sition during driving. 11 11
(In “D” or “L”) 1
(In “D” or “L”) 1
(In “R”)
Engine brake is suddenly ap-
plied in “D” or “R” position dur-
ing driving. 1
1
(In “D” or
“L”) 1
(In “D” or
“L”) 1
(In “R”)
Shifting is
not possi- ble. The engine races when the
auxiliary gearbox is shifted
from 1GR ⇔
2GR. 11 2 1 1
Engine braking is not effective
in “L” position. 1212 1 1
Shifting does not occur with
OD OFF.
Engine stall occurs immedi-
ately before stop at decelera-
tion in “D” or “L” position. 11
During driving in “D” position,
slippage occurs in lockup or
lockup is not possible. 11
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-226
< SYMPTOM DIAGNOSIS >[CVT: RE0F11A]
CVT CONTROL SYSTEM
Symptom diagnosis chart 2-1
SymptomCheck under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure soleno
id valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Shock vi-
bration
Noise Shock at start is large in “D”,
“L”, or “R” position.
12
11
Shock is large when the aux-
iliary gearbox is shifted from
1GR → 2GR. 212
22 11
Shock in lockup is large dur-
ing driving in “D ” or “L” posi-
tion. 11
Shock is large when the lever
is shifted from “N” → “D” and
“N” → “R” positions. 1 12111 11111
Shock is large when the lever
is shifted from “D” → “L” posi-
tion.
Vibration occurs in “D”, “L”, or
“R” position during driving. 1111 12 111
Noise occurs during driving. 1
Noise occurs in idling. 1 1
Other Starter operates in “D”, “L”, or
“R” position.
11
1
Starter does not operate in
“P” or “N” position. 11
1
Engine stall occurs in “D”, “L”,
or “R” position during stop. 111 1
Engine stall occurs in “P” or
“N” position during stop. 111 1
Parking lock does not oper-
ate in “P” position. 11
Parking lock cannot be can-
celled when the selector le-
ver is shifted from “P” position
to other position. 11
Revision: August 2015
2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-227
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Symptom diagnosis chart 2-2
Symptom Replace the transaxle assembly.
Oil pres-
sure con- trol Power transmission
Valve body, control valve
Oil pump
Torque converter
Pulley, steel belt
Low brake
High clutch
Reverse brake
Bearings
Counter gear
Planetary gear
Reduction gear
Final gear, differential gear
Parking mechanism
TM-259
Shock vi-
bration
Noise Shock at start is large in “D”,
“L”, or “R” position.
111
(In “D” or “L”) 1
(In “R”) 2222
Shock is large when the auxil-
iary gearbox is shifted from
1GR → 2GR. 11
1
Shock in lockup is large dur-
ing driving in “D” or “L” posi-
tion. 11
Shock is large when the lever
is shifted from “N” → “D” and
“N” → “R” positions. 11
(“N” →
“D”) 1
(“N” →
“D”)
Shock is large when the lever
is shifted from “D” → “L” posi-
tion. 11
1
Vibration occurs in “D”, “L”, or
“R” position during driving. 11111
(In “D” or “L”) 1
(In “D” or “L”) 1
(In “R”) 11111
Noise occurs during driving. 1 1 1 11111
Noise occurs in idling. 1 1 1 1 1 1
Other Starter operates in “D”, “L”, or
“R” position.
Starter does not operate in “P”
or “N” position.
Engine stall occurs
in “D”, “L”,
or “R” position during stop. 11
Engine stall occurs in “P” or
“N” position during stop.
Parking lock does not operate
in “P” position. 1
Parking lock cannot be can-
celled when the selector lever
is shifted from “P” position to
other position. 1
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-228
< PERIODIC MAINTENANCE >[CVT: RE0F11A]
CVT FLUID
PERIODIC MAINTENANCE
CVT FLUID
InspectionINFOID:0000000012431172
FLUID LEAKAGE
• Check transaxle surrounding area (oil seal and plug etc.)for fluid
leakage.
• If anything is found, repair or replace damaged parts and adjust
CVT fluid level. Refer to TM-229, "
Adjustment".
ReplacementINFOID:0000000012431173
CAUTION:
• Use only Genuine NISSAN CVT Fluid NS-3. Using transmission fluid other than Genuine NISSAN
CVT Fluid NS-3 will damage the CVT, which is not covered by the (NISSAN new vehicle limited) war-
ranty.
• Always use shop paper. Never use shop cloth.
• Replace a drain plug gasket with new ones at the final stage of the operation when installing.
• Use caution when looking into the drain hole as th ere is a risk of dripping fluid entering the eye.
• After replacement, always perform CVT fluid leakage check.
1. Select “Data Monitor” in “T RANSMISSION” using CONSULT.
2. Select “FLUID TEMP” and confirm t hat the CVT fluid temperature is 40°C (104° F) or less.
3. Check that the selector lever is in the “P ” position, then completely engage the parking brake.
4. Lift up the vehicle.
5. Remove the drain plug and overflow tube and drain the CVT fluid from the oil pan. TM-242, "
Removal and
Installation".
6. Install the charging pipe set (KV311039S0) (A) into the drain hole.
CAUTION:
Tighten the charging pipe by hand.
7. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
8. Fill approximately 3 liter (2-5/8 lmp qt) of the CVT fluid.
9. Remove the ATF changer hose and charging pipe, then install the drain plug.
NOTE:
Perform this work quickly because CVT fluid leaks.
10. Lift down the vehicle.
11. Start the engine.
12. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “L”, and shift it to the “P” position.
NOTE:
SMA146B
CVT fluid : Refer to TM-265, "General Specification".
Fluid capacity : Refer to TM-265, "
General Specification".
JSDIA1876ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

CVT FLUIDTM-229
< PERIODIC MAINTENANCE > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Hold the lever at each position for 5 seconds.
13. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35°C (95°F) to 45 °C (113 °F).
14. Stop the engine.
15. Lift up the vehicle.
16. Remove the drain plug, and then drain CVT fluid from oil pan.
17. Repeat steps 6 to 16 (one time).
18. Install the overflow tube. Refer to TM-242, "
Removal and Installation".
CAUTION:
Be sure to tighten to the specified torque. If it is not tightened to the specified torque, the tube may
be damaged.
19. Install the charging pipe set (KV311039S0) (A) into the drain hole.
CAUTION:
Tighten the charging pipe by hand.
20. Install the ATF changer hose (B) to the charging pipe. CAUTION:
Press the ATF changer hose all the way onto the charging
pipe until it stops.
21. Fill approximately 3 liter (2-5 /8 lmp qt) of the CVT fluid.
22. Remove the ATF changer hose and charging pipe, then install the drain plug.
NOTE:
Perform this work quickly because CVT fluid leaks.
23. Lift down the vehicle.
24. Start the engine.
25. While depressing the brake pedal, shift the selector leve r to the entire position from “P” to “L”, and shift it
to the “P” position.
NOTE:
Hold the lever at each position for 5 seconds.
26. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35°C (95°F) to 45 °C (113 °F).
27. Lift up the vehicle.
28. Remove the drain plug and confirm that the CV T fluid is drained from the overflow tube.
CAUTION:
Perform this work with the vehicle idling.
NOTE:
If the CVT fluid is not drained, refer to “Adjustment” and refill with the CVT fluid.
29. When the flow of CVT fluid slows to a drip, tighten the drain plug to the specified torque. TM-242,
"Removal and Installation".
CAUTION:
Never reuse drain plug gasket.
30. Lift down the vehicle.
31. Select “Work Support” in “T RANSMISSION” using CONSULT.
32. Select “CONFORM CVTF DETERIORTN”.
33. Select “Erase”.
34. Stop the engine.
AdjustmentINFOID:0000000012431174
CAUTION:
• Use only Genuine NISSAN CVT Fluid NS-3. Using transmission fluid other than Genuine NISSAN CVT Fluid NS-3 will damage the CVT, which is not covered by the (NISSAN new vehicle limited) war-
ranty.
JSDIA1876ZZ
CVT fluid : Refer to TM-265, "General Specification".
Fluid capacity : Refer to TM-265, "
General Specification".
Revision: August 2015 2016 Versa Note

cardiagn.com
