AIR BREATHER HOSE
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000012431188
REMOVAL
1. Remove air duct (inlet). Refer to
EM-26, "Exploded View".
2. Remove air breather hose from transaxle assembly.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Check that air breather hose is not collapsed or bl ocked due to folding or bending when installed.
• Be sure to insert air breather hose (1) fully until it reaches the base of the transaxle tube (A).
JSDIA1978ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

G SENSORTM-241
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
G SENSOR
Exploded ViewINFOID:0000000012431189
Removal and InstallationINFOID:0000000012431190
CAUTION:
• Do not drop or strike G sensor, because it may be damaged by impact.
• Do not use a power tool.
REMOVAL
1. Disconnect the battery negative terminal. Refer to PG-70, "Exploded View".
2. Remove center console assembly. Refer to IP-18, "
Removal and Installation".
3. Disconnect the harness connector from G sensor.
4. Remove G sensor.
INSTALLATION
Installation is in the reverse order of removal.
AdjustmentINFOID:0000000012431191
ADJUSTMENT AFTER INSTALLATION
Perform “G SENSOR CALIBRATION”. Refer to TM-130, "Description".
1. G sensor Front
JSDIA1922GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-242
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OIL PAN, CONTROL VALVE
OIL PAN, CONTROL VALVE
Exploded ViewINFOID:0000000012431192
Removal and InstallationINFOID:0000000012431193
REMOVAL
1. Disconnect battery negative terminal.
1. Transaxle assembly
2. O-ring 3. Control valve
4. Manual plate 5. Washer 6. O-ring
7. Strainer 8. Oil pan gasket9. Magnet
10. Oil pan 11. Drain plug gasket 12. Drain plug
13. Overflow tube : Apply petroleum jelly
: Always replace after every disassembly.
: Apply CVT fluid
: N·m (kg-m, ft-lb)
: N·m (kg-m, in-lb)
JSDIA6707GB
Revision: August 2015 2016 Versa Note

cardiagn.com

OIL PAN, CONTROL VALVETM-243
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
2. Disconnect the CVT unit harness connector.
3. Remove the drain plug and overflow tube, and then drain the CVT fluid. CAUTION:
Use caution when looking into the drain hole as there is the risk of fluid entering the eye.
4. Remove the drain plug gasket from the drain plug.
5. Remove the oil pan mounting bolts ( ), and then remove the oil pan and oil pan gasket.
6. Remove the magnets from the oil pan.
7. Remove the strainer bolts , and then remove the strainer from the control valve.
8. Remove the nut and washer , and then remove manual plate .
CAUTION:
To remove nut, fix manual plat e with flat-blade screwdriver
(B).
9. Press the CVT unit harness connector into the transaxle case. CAUTION:
Never damage the CVT unit harness connector.
NOTE:
Clean around the CVT unit harness connector to prevent foreign
materials from entering into the transaxle case.
10. Remove the control valve bolts , and then remove the control valve from the transaxle case.
CAUTION:
• Never drop the control valve and manual valve.
:Vehicle front
JSDIA1874ZZ
JSDIA6594ZZ
JSDIA6595ZZ
JSDIA6598ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-244
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OIL PAN, CONTROL VALVE
• To remove bolt of the oil temperature sensor bracket and
the control valve, fix bracket with flat-blade screw-
driver.
11. Remove the O-ring to the CVT unit harness connector.
INSTALLATION
1. Install the O-ring to the CVT unit harness connector. CAUTION:
• Never reuse O-ring.
• Apply CVT fluid to the O-ring
• Never pinch the harness , between the control valve and
the CVT unit harness connector bracket .
• Never twist the harness.
• Never slack the harness.
2. Install the control valve, and than tighten control valve bolts to the specitoed torque.
CAUTION:
• Never pinch the harness be tween the control valve and
the transaxle case.
• Never drop the control valve and manual valve.
3. Install the manual plate and washer , and then tighten nut to the specitied torque.
CAUTION:
To tighten nut, fix manual plat e with flat-blade screwdriver.
JSDIA6596ZZ
JSDIA6599ZZ
JSDIA6598ZZ
JSDIA6597ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

OIL PAN, CONTROL VALVETM-245
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
4. Install the strainer , and then tighten the strainer bolts to the specitied torque.
5. Install oil pan (with oil pan gasket) to transaxle case and tempo- rarily tighten oil pan bolts ( ).
CAUTION:
Never reuse oil pan gasket.
6. Tighten the oil pan bolts to specification in the order shown.
7. Tighten the overflow tube to the specitied torque. CAUTION:
If it is not tightened to the specified torque, the tube may be
damaged.
8. Connect the CVT unit harness connector.
9. Connect battery negative terminal.
10. Fill with CVT fluid from overflow tube to the specified level. Refer to TM-228, "
Replacement".
11. Install the drain plug and drain plug gasket to oil pan. CAUTION:
Never reuse drain plug gasket.
Inspection and AdjustmentINFOID:0000000012431194
INSPECTION AFTER REMOVAL
Check oil pan for foreign material.
• If a large amount of worn material is found, clutch plate may be worn.
• If iron powder is found, bearings, gears, or clutch plates may be worn.
• If aluminum powder is found, bushing may be worn, or ch ips or burrs of aluminum casting parts may enter.
Check points where wear is found in all cases.
ADJUSTMENT AFTER INSTALLATION
Erase the CVT fluid deterioration data.
INSPECTION AFTER INSTALLATION
• When replacing control valve, perform "ADDITION AL SERVICE WHEN REPLACING CONTROL VALVE OR
TRANSAXLE ASSEMBLY". Refer to TM-127, "
Work Procedure".
• Check the CVT fluid level, condition and leakage.
JSDIA6594ZZ
: Vehicle front
JSDIA1874ZZ
: Vehicle front
JSDIA1884ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-246
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
PRIMARY SPEED SENSOR
PRIMARY SPEED SENSOR
Exploded ViewINFOID:0000000012431195
Removal and InstallationINFOID:0000000012431196
REMOVAL
1. Partially remove fender protector (LH). Refer to
TM-246, "Exploded View".
2. Disconnect the harness connector from primary speed sensor.
3. Remove the primary speed sensor.
4. Remove the O-ring from the primary speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431197
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. O-ring 3. Primary speed sensor
Front : Genuine NISSAN CVT Fluid NS-3
JSDIA1880GB
Revision: August 2015 2016 Versa Note

cardiagn.com

SECONDARY SPEED SENSORTM-247
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SECONDARY SPEED SENSOR
Exploded ViewINFOID:0000000012431198
Removal and InstallationINFOID:0000000012431199
REMOVAL
1. Remove battery tray. Refer to PG-71, "Removal and Installation (Battery Tray)".
2. Remove IPDM/ER. Refer to PCS-30, "
Removal and Installation".
3. Disconnect the harness connector from secondary speed sensor.
4. Remove the secondary speed sensor.
5. Remove the O-ring from the secondary speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431200
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. O-ring3. Secondary speed sensor
Front : Genuine NISSAN CVT Fluid NS-3
JSDIA1881GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-248
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OUTPUT SPEED SENSOR
OUTPUT SPEED SENSOR
Exploded ViewINFOID:0000000012431201
Removal and InstallationINFOID:0000000012431202
REMOVAL
1. Disconnect the harness connector from output speed sensor.
NOTE:
Lift up the vehicle and perform the work from rear of the transaxle assembly.
2. Remove the output speed sensor.
3. Remove the O-ring from the output speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431203
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Check the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. Output speed sensor 3. O-ring
Front Genuine NISSAN CVT Fluid NS-3
JSDIA1882GB
Revision: August 2015 2016 Versa Note

cardiagn.com

DIFFERENTIAL SIDE OIL SEALTM-249
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DIFFERENTIAL SIDE OIL SEAL
Exploded ViewINFOID:0000000012431204
Removal and InstallationINFOID:0000000012431205
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
REMOVAL
1. Remove the front drive shaft from the transaxle assembly. Refer to FAX-19, "Removal and Installation"
2. Remove the differential side oil seal using suitable tool.
CAUTION:
When removing the differential side oil seal, be careful not to scratch the oil seal mating surfaces
of the transaxle case and converter housing.
INSTALLATION
CAUTION:
When inserting the drive shaf t, be sure to use Tool.
1. Measure height (A) of seal lip. Calculate protrusion (C) of seal
lip according to measured height (A) of seal lip and reference
value (B) of side oil seal insertion.
CAUTION:
• Do not reuse differential side oil seal.
• Put a mark on the measurement area and measure height of seal lip at four points diagonally
using suitable tool.
NOTICE:
1. Transaxle assembly 2. Differential side oil seal (left side) 3. Differential side oil seal (right side)
Front Genuine NISSAN CVT Fluid NS-3
JSDIA1888ZZ
Tool number : KV38107900 ( — )
(1) : Differential side oil seal
(2) : Converter housing or transaxle case
Lip protrusion (C): C=A–B
Differential side oil seal insertion
reference value (B) : 1.8 mm (0.071 in)
JSDIA4816ZZ
