NISSAN TEANA 2008 Service Manual

BRC-110
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1143 STEERING ANGLE SENSOR
C1143 STEERING ANGLE SENSOR
DescriptionINFOID:0000000003766958
The steering angle sensor detects the rotation amount, angular velocity and direction of the steering wheel,
and transmits the data to the ABS actuator and electric unit (control unit) via CAN communication.
DTC LogicINFOID:0000000003766959
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1143” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-110, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766960
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Disconnect steering angle sensor connector.
4. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK STEERING ANGLE SENSOR HARNESS
1. Turn the ignition switch ON.
CAUTION:
Never start the engine.
2. Check the voltage between steering angle sensor harness connector and ground.
3. Turn the ignition switch OFF.
4. Check the continuity between steering angle sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
DTC Display item Malfunction detected condition Possible cause
C1143 ST ANG SEN CIRCUIT Steering angle sensor is malfunctioning. Harness or connector
 Steering angle sensor
 ABS actuator and electric unit
(control unit)
Steering angle sensor
—Voltage
Connector Terminal
M30 4 Ground Battery voltage
Steering angle sensor
— Continuity
Connector Terminal
M30 1 Ground Existed

C1143 STEERING ANGLE SENSOR
BRC-111
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
3.CHECK DATA MONITOR
1. Connect steering angle sensor connector and ABS actuator and electric unit (control unit) connector.
2. Check steering angle sensor signal. Refer to BRC-111, "
Component Inspection".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Replace steering angle sensor and adjust neutral position of steering angle sensor.
Component InspectionINFOID:0000000003766961
1.CHECK DATA MONITOR
Select “STR ANGLE SIG” in “DATA MONITOR” and check steering angle sensor signal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-110, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000003766962
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the steering
angle sensor or the ABS actuator and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF
STEERING ANGLE SENSOR NEUTRAL POSITION : Description".
>> END
Steering condition STR ANGLE SIG (DATA MONITOR)
Driving straight±2.5°
Turn 90° to right Approx. +90°
Turn 90° to left Approx. −90°

BRC-112
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1144 STEERING ANGLE SENSOR
C1144 STEERING ANGLE SENSOR
DTC LogicINFOID:0000000003766963
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Select “ST ANG SEN ADJUSTMENT” in “WORK SUPPORT”, and perform adjust the neutral position of
steering angle sensor.
3. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1144” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-112, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766964
1.CHECK STEERING ANGLE SENSOR
Check steering angle sensor. Refer to BRC-110, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Special Repair RequirementINFOID:0000000003767347
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the steering
angle sensor or the ABS actuator and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF
STEERING ANGLE SENSOR NEUTRAL POSITION : Description".
>> END
DTC Display item Malfunction detected condition Possible cause
C1144 ST ANG SEN SIGNAL Neutral position of steering angle sensor is not finished. Harness or connector
 Steering angle sensor
 ABS actuator and electric unit
(control unit)

C1145, C1146 YAW RATE/SIDE G SENSOR
BRC-113
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
C1145, C1146 YAW RATE/SIDE G SENSOR
DescriptionINFOID:0000000003766966
The yaw rate/side G sensor detects the yaw rate/side G affecting the vehicle, and transmits the data to the
ABS actuator and electric unit (control unit) as an analog voltage signal.
DTC LogicINFOID:0000000003766967
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1145” or “C1146” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-113, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766968
CAUTION:
 Sudden turns (such as spin turns, acceleration turns), drifting, etc., when VDC function is off (VDC
OFF switch “ON”) may cause yaw rate/side G sensor system to indicate a malfunction. However, this
is not a malfunction, if normal operation can be resumed after restarting engine. Then erase memory
of self-diagnosis.
 If vehicle is on turn-table at entrance to parking garage, or on other moving surface, VDC OFF indica-
tor lamp may illuminate and CONSULT-III self-diagnosis may indicate yaw rate sensor system mal-
function. However, in this case there is no malfunction in yaw rate sensor system. Take vehicle off of
turn-table or other moving surface, and start the engine. Results will return to normal.
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Disconnect yaw rate/side G sensor connector.
4. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK YAW RATE/SIDE G SENSOR POWER SUPPLY CIRCUIT
1. Turn the ignition switch ON.
CAUTION:
Never start the engine.
2. Check the voltage between yaw rate/side G sensor harness connector and ground.
3. Turn the ignition switch OFF.
4. Check the voltage between yaw rate/side G sensor harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1145 YAW RATE SENSORYaw rate sensor is malfunctioning, or the yaw rate sensor
signal line is open or shorted. Harness or connector
 ABS actuator and electric unit
(control unit)
 Yaw rate/side G sensor C1146 SIDE G-SEN CIRCUITSide G sensor is malfunctioning, or circuit of side G sen-
sor is open or shorted.
Yaw rate/side G sensor
—Voltage
Connector Terminal
M72 4 Ground Battery voltage

BRC-114
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1145, C1146 YAW RATE/SIDE G SENSOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK YAW RATE/SIDE G SENSOR GROUND CIRCUIT
Check the continuity between yaw rate/side G sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace damaged parts.
4.CHECK YAW RATE/SIDE G SENSOR HARNESS
Check the continuity between yaw rate/side G sensor harness connector and ABS actuator and electric unit
(control unit) harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace damaged parts. Refer to BRC-150, "
Precautions for Harness Repair".
5.CHECK DATA MONITOR
1. Connect yaw rate/side G sensor connector and ABS actuator and electric unit (control unit) connector.
2. Check yaw rate/side G sensor signal. Refer to BRC-114, "
Component Inspection".
Is the inspection result normal?
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Replace yaw rate/side G sensor.
Component InspectionINFOID:0000000003766969
1.CHECK DATA MONITOR
Select “YAW RATE SEN”, “SIDE G-SENSOR” in “DATA MONITOR” and check yaw rate/side G sensor signal.
Yaw rate sensor
Yaw rate/side G sensor
—Voltage
Connector Terminal
M72 4 Ground Approx. 0 V
Yaw rate/side G sensor
— Continuity
Connector Terminal
M72 1 Ground Existed
ABS actuator and electric unit
(control unit)Yaw rate/side G sensor
Continuity
Connector Terminal Connector Terminal
E3614
M722
Existed
25 3
Vehicle conditionYAW RATE SEN
(DATA MONITOR)
Vehicle stopped Approx. 0 d/s
Vehicle turning right Negative value
Vehicle turning left Positive value

C1145, C1146 YAW RATE/SIDE G SENSOR
BRC-115
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Side G sensor
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-113, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000003767348
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
Vehicle conditionSIDE G-SENSOR
(DATA MONITOR)
Vehicle stopped
Approx. 0 m/s
2
Vehicle turning right Negative value
Vehicle turning left Positive value

BRC-116
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1155 BRAKE FLUID LEVEL SWITCH
C1155 BRAKE FLUID LEVEL SWITCH
DescriptionINFOID:0000000003766981
The brake fluid level switch converts the brake fluid level to an electric signal and transmits it to the ABS actu-
ator and electric unit (control unit).
DTC LogicINFOID:0000000003766982
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1155” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-116, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003766983
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect brake fluid level switch connector.
3. Disconnect combination meter connector.
4. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK BRAKE FLUID LEVEL SWITCH
Check brake fluid level switch. Refer to BRC-117, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Brake fluid level switch is malfunction. Replace reservoir tank.
3.CHECK BRAKE FLUID LEVEL SWITCH CIRCUIT
1. Check the continuity between brake fluid level switch harness connector and combination meter harness
connector.
2. Check the continuity between brake fluid level switch harness connector and ground.
3. Check the continuity between combination meter harness connector and ground.
DTC Display item Malfunction detected condition Possible cause
C1155 BR FLUID LEVEL LOWBrake fluid level is low or communication line between
the ABS actuator and electric unit (control unit) and brake
fluid level switch is open or shorted. Harness or connector
 Brake fluid level switch
 Combination meter
Combination meter Brake fluid level switch
Continuity
Connector Terminal Connector Terminal
M34 27 E37 1 Existed
Brake fluid level switch
— Continuity
Connector Terminal
E37 2 Ground Existed

C1155 BRAKE FLUID LEVEL SWITCH
BRC-117
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
Is the inspection result normal?
YES >> Replace combination meter.
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003766984
1.CHECK BRAKE FLUID LEVEL SWITCH
1. Turn the ignition switch OFF.
2. Disconnect brake fluid level switch connector.
3. Check the continuity between brake fluid level switch connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace reservoir tank. Refer to BR-25, "
Exploded View".
Special Repair RequirementINFOID:0000000003767349
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
Combination meter
—Continuity
Connector Terminal
M34 27 Ground Not existed
Brake fluid level switch
Condition Continuity
Te r m i n a l
1 − 2When brake fluid is full in the reservoir tank. Not existed
When brake fluid is empty in the reservoir
tank.Existed

BRC-118
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C1164, C1165 CV SYSTEM
C1164, C1165 CV SYSTEM
DescriptionINFOID:0000000003767321
The cut valve shuts off the normal brake fluid path from the master cylinder, when VDC/TCS is activated.
DTC LogicINFOID:0000000003767322
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.DTC REPRODUCTION PROCEDURE
1. Turn the ignition switch ON.
2. Perform ABS actuator and electric unit (control unit) self-diagnosis.
Is DTC
“C1164” or “C1165” detected?
YES >> Proceed to diagnosis procedure. Refer to BRC-118, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000003767323
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect ABS actuator and electric unit (control unit) connector.
3. Check terminal for deformation, disconnection, looseness, etc.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace damaged parts.
2.CHECK SOLENOID, VDC SWITCH-OVER VALVE AND ACTUATOR RELAY POWER SUPPLY CIRCUIT
Check the voltage between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace damaged parts.
3.CHECK SOLENOID, VDC SWITCH-OVER VALVE AND ACTUATOR RELAY GROUND CIRCUIT
Check the continuity between ABS actuator and electric unit (control unit) harness connector and ground.
Is the inspection result normal?
DTC Display item Malfunction detected condition Possible cause
C1164 CV 1VDC switch-over solenoid valve (CV1) on the primary
side is open circuit or shorted, or the control line is open
or shorted to the power supply or the ground. Harness or connector
 ABS actuator and electric unit
(control unit)
C1165 CV 2VDC switch-over solenoid valve (CV2) on the secondary
side is open circuit or shorted, or the control line is open
or shorted to the power supply or the ground.
ABS actuator and electric unit (control unit)
—Voltage
Connector Terminal
E36 3 Ground Battery voltage
ABS actuator and electric unit (control unit)
— Continuity
Connector Terminal
E361
Ground Existed
4

C1164, C1165 CV SYSTEM
BRC-119
< COMPONENT DIAGNOSIS >[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
YES >> Replace ABS actuator and electric unit (control unit).
NO >> Repair or replace damaged parts.
Component InspectionINFOID:0000000003767324
1.CHECK ACTIVE TEST
1. Select each test menu item on ”ACTIVE TEST“.
2. On the display, touch “Up”, “ACT UP”, and “ACT KEEP”, and check that the system operates as shown in
the table below.
*: On for 1 to 2 seconds after the touch, and then Off.
NOTE:
A brief moment of On/Off condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Proceed to diagnosis procedure. Refer to BRC-118, "
Diagnosis Procedure".
Special Repair RequirementINFOID:0000000003767360
1.ADJUSTMENT OF STEERING ANGLE SENSOR NEUTRAL POSITION
Always perform the neutral position adjustment for the steering angle sensor, when replacing the ABS actua-
tor and electric unit (control unit). Refer to BRC-66, "
ADJUSTMENT OF STEERING ANGLE SENSOR NEU-
TRAL POSITION : Description".
>> END
Test item Display itemDisplay (Note)
Up ACT UP ACT KEEP
FR RH ABS SOLENOID
(ACT)FR RH IN SOL Off Off Off
FR RH OUT SOL Off Off Off
USV[FR-RL] Off On On
HSV[FR-RL] Off On* Off
FR LH ABS SOLENOID
(ACT)FR LH IN SOL Off Off Off
FR LH OUT SOL Off Off Off
USV[FL-RR] Off On On
HSV[FL-RR] Off On* Off
RR RH ABS SOLENOID
(ACT)RR RH IN SOL Off Off Off
RR RH OUT SOL Off Off Off
USV[FL-RR] Off On On
HSV[FL-RR] Off On* Off
RR LH ABS SOLENOID
(ACT)RR LH IN SOL Off Off Off
RR LH OUT SOL Off Off Off
USV[FR-RL] Off On On
HSV[FR-RL] Off On* Off
