NISSAN TEANA 2008 Service Manual

ON IS NOT DISPLAYED WHEN PRESSING REAR WINDOW DEFOGGER
SWITCH BUT IT OPERATES
DEF-61
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
ON IS NOT DISPLAYED WHEN PRESSING REAR WINDOW DEFOGGER
SWITCH BUT IT OPERATES
WITH AV CONTROL UNIT
WITH AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003806069
1.CHECK AV CONTROL FUNCTION
Check that the AV control unit is operating normally.
 Base audio: Refer to AV-45, "
Work Flow".
 BOSE audio with navigation: Refer to AV-398, "
Work Flow".
 BOSE audio without navigation: Refer to AV-185, "
Work Flow".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
WITHOUT AV CONTROL UNIT
WITHOUT AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003888342
1.CHECK A/C CONTROL FUNCTION
Check that the A/C control is operating normally.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check A/C control system. Refer to HAC-6, "
Work Flow".
2.CHECK REAR WINDOW DEFOGGER DISPLAY
Check that ON appears on the display when rear window defogger is activated.
Is the inspection result normal?
YES >> Replace A/C control (rear window defogger switch). Refer to VTL-21, "Removal and Installation".
NO >> Check rear window defogger indicator. Refer to DEF-62, "
WITHOUT AV CONTROL UNIT : Diag-
nosis Procedure".

DEF-62
< SYMPTOM DIAGNOSIS >
REAR WINDOW DEFOGGER INDICATOR DOES NOT ILLUMINATE
REAR WINDOW DEFOGGER INDICATOR DOES NOT ILLUMINATE
WITH AV CONTROL UNIT
WITH AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003806070
1.CHECK REAR WINDOW DEFOGGER OPERATION
Check rear window defogger operation.
Is the inspection result normal?
YES-1 >> Base audio: Check AV control system.Refer to AV-45, "Work Flow"
YES-2 >> BOSE audio with navigation: Check AV control system. Refer to AV-398, "Work Flow"
YES-3 >> BOSE audio without navigation: Check AV control system. Refer to AV-185, "Work Flow"
NO >> Check rear window defogger system. Refer to DEF-3, "Work Flow"
WITHOUT AV CONTROL UNIT
WITHOUT AV CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003840906
1.CHECK A/C CONTROL FUNCTION
Check that the A/C control is operating normally.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Check A/C control system. Refer to HAC-6, "
Work Flow".
2.CHECK REAR WINDOW DEFOGGER ON SIGNAL
Check rear window defogger ON signal.
Refer to DEF-25, "
Component Function Check".
Is the inspection result normal?
YES >> Replace A/C control (rear window defogger switch). Refer toVTL-21, "Removal and Installation".
NO >> Repair or replace the malfunctioning parts.

PRECAUTIONS
DEF-63
< PRECAUTION >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003940045
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
 Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.

DEF-64
< ON-VEHICLE REPAIR >
FILAMENT
ON-VEHICLE REPAIR
FILAMENT
Inspection and RepairINFOID:0000000003806072
INSPECTION
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe. Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.
3. If a filament is burned out, circuit tester registers 0 or battery
voltage.
4. To locate burned out point, move probe to left and right along fil-
ament. Test needle swings abruptly when probe passes the
point.
REPAIR
REPAIR EQUIPMENT
 Conductive silver composition (Dupont No. 4817 or an equivalent)
SEL122R
SEL263
SEL265

FILAMENT
DEF-65
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
DEF
N
O
P
 Ruler 30 cm (11.8 in) long
 Drawing pen
 Heat gun
 Alcohol
 Cloth
REPAIRING PROCEDURE
1. Wipe broken heat wire and its surrounding area clean with a
cloth dampened in alcohol.
2. Apply a small amount of conductive silver composition to tip of
drawing pen.
Shake silver composition container before use.
3. Place ruler on glass along broken line. Deposit conductive silver
composition on break with drawing pen. Slightly overlap existing
heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
4. After repair has been completed, check repaired wire for conti-
nuity. This check should be conducted 10 minutes after silver
composition is deposited.
Do not touch repaired area while test is being conducted.
5. Apply a constant stream of hot air directly to the repaired area
for approximately 20 minutes with a heat gun. A minimum dis-
tance of 3 cm (1.2 in) should be kept between repaired area and
hot air outlet.
If a heat gun is not available, let the repaired area dry for 24
hours.
PIIA0215E
SEL012D
SEL013D

DEF-66
< ON-VEHICLE REPAIR >
CONDENSER
CONDENSER
Exploded ViewINFOID:0000000003841332
Removal and InstallationINFOID:0000000003806074
REMOVAL
1. Remove the rear seat cushion and the rear seatback.
 With ventilation seat: Refer to SE-99, "
Removal and Installation".
 Without ventilation seat: Refer to SE-142, "
Removal and Installation".
2. Remove the rear kicking plate, rear wheel well garnish and the rear pillar finisher.
Refer to INT-39, "
Removal and Installation".
3. Remove bolt (A), and then remove condenser (1) from the vehi-
cle body.
INSTALLATION
Install in the reverse order of removal.
1. Condenser
JMLIA0152ZZ
JMLIA0153ZZ
