NISSAN TEANA 2008 Service Manual

DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
DLK-155
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
SYMPTOM DIAGNOSIS
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK
SWITCH
ALL DOOR
ALL DOOR : Diagnosis ProcedureINFOID:0000000003941945
1.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check power supply and ground circuit.
Refer to DLK-56, "
BCM (BODY CONTROL MODULE) : Diagnosis Procedure" (BCM).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch.
Refer to DLK-60, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK DOOR LOCK ACTUATOR
Check door lock actuator .
Refer to DLK-61, "
DRIVER SIDE : ComponentFunctionCheck" (driver side), DLK-62, "PASSENGER SIDE :
ComponentFunctionCheck" (passenger side), Refer to DLK-63, "REAR LH : ComponentFunctionCheck"
(rear LH), DLK-63, "REAR RH : ComponentFunctionCheck" (rear RH).
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
DRIVER SIDE
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000003941946
1.CHECK DOOR LOCK ACTUATOR
Check door lock actuator (driver side).
Refer to DLK-61, "
DRIVER SIDE : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
PASSENGER SIDE

DLK-156
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH
PASSENGER SIDE : Diagnosis Procedure
INFOID:0000000003941947
1.CHECK DOOR LOCK ACTUATOR
Check door lock actuator (passenger side).
Refer to DLK-62, "
PASSENGER SIDE : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
REAR LH
REAR LH : Diagnosis ProcedureINFOID:0000000003941948
1.CHECK DOOR LOCK ACTUATOR
Check door lock actuator (rear LH).
Refer to DLK-63, "
REAR LH : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
REAR RH
REAR RH : Diagnosis ProcedureINFOID:0000000003941949
1.CHECK DOOR LOCK ACTUATOR
Check door lock actuator (rear RH).
Refer to DLK-63, "
REAR RH : ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES NOT OPERATE
DLK-157
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
VEHICLE SPEED SENSING AUTO LOCK OPERATION DOES NOT OPER-
AT E
Diagnosis ProcedureINFOID:0000000003794988
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with door lock and unlock switch?
YES >> GO TO 2.
NO >> Go to DLK-60, "
Diagnosis Procedure".
2.CHECK VEHICLE SPEED SIGNAL
Check combination meter.
Refer to SEC-54, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

DLK-158
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH INTELLIGENT KEY
DOOR DOES NOT LOCK/UNLOCK WITH INTELLIGENT KEY
DescriptionINFOID:0000000003794992
NOTE:
 Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
 Intelligent Key is removed from key slot.
 All doors are closed.
Diagnosis ProcedureINFOID:0000000003794993
1.CHECK POWER DOOR LOCK OPERATION
Check power door lock operation.
Does door lock/unlock with door lock and unlock switch?
YES >> GO TO 2.
NO >> Go to DLK-60, "
Diagnosis Procedure".
2.CHECK REMOTE KEYLESS ENTRY RECEIVER
Check remote keyless entry receiver.
Refer to DLK-67, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CHECK INTELLIGENT KEY
Check Intelligent Key.
Refer to DLK-84, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK KEY SLOT
Check key slot.
Refer to DLK-86, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

HAZARD AND HORN REMINDER DOES NOT OPERATE
DLK-159
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
HAZARD AND HORN REMINDER DOES NOT OPERATE
DescriptionINFOID:0000000003795000
NOTE:
 Before performing the diagnosis following procedure, check “Work Flow”. Refer to DLK-7, "
Work Flow".
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATION CONDITIONS)
 Ignition switch is in the OFF or LOCK position.
 Intelligent Key is removed from key slot.
Diagnosis ProcedureINFOID:0000000003795001
1.CHECK “HAZARD ANSWER BACK” SETTING IN “WORK SUPPORT”
Check “HAZARD ANSWER BACK” setting in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “HAZARD ANSWER BACK” setting in “WORK SUPPORT”.
2.CHECK “HORN WITH KEYLESS LOCK” SETTING IN “WORK SUPPORT”.
Check “HORN WITH KEYLESS LOCK” setting in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “HORN WITH KEYLESS LOCK” setting in “WORK SUPPORT”.
3.CHECK HAZARD WARNING LAMP
Check hazard warning lamp.
Refer to DLK-96, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK HORN
Check horn.
Refer to DLK-91, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

DLK-160
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
AUTO DOOR LOCK OPERATION DOES NOT OPERATE
AUTO DOOR LOCK OPERATION DOES NOT OPERATE
DescriptionINFOID:0000000003795002
NOTE:
 Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
Diagnosis ProcedureINFOID:0000000003795003
1.CHECK “AUTO LOCK SET” SETTING IN “WORK SUPPORT”
Check “AUTO LOCK SET” setting in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Set “AUTO LOCK SET” setting in “WORK SUPPORT”.
2.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-161
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000003795004
NOTE:
 Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
 Intelligent Key is removed from key slot.
 Ignition switch is in OFF position.
 No Intelligent Keys are inside the vehicle.
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000003795005
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent Key button?
YES >> GO TO 2.
NO >> Go to DLK-158, "
Description".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
Check “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
3.CHECK DOOR REQUEST SWITCH
Check door request switch (driver side).
Refer to DLK-72, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna (driver side).
Refer to DLK-80, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check Intermittent Incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
PASSENGER SIDE
PASSENGER SIDE : DescriptionINFOID:0000000003795006
NOTE:
 Before performing the diagnosis in the following procedure, check “Work Flow”. Refer to DLK-7, "
Work
Flow".

DLK-162
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
 Intelligent Key is removed from key slot.
 Ignition switch is in the OFF position.
 No Intelligent Keys are inside the vehicle.
PASSENGER SIDE : Diagnosis ProcedureINFOID:0000000003795007
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent key button?
YES >> GO TO 2.
NO >> Go to DLK-158, "
Description".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
Check “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
3.CHECK DOOR REQUEST SWITCH
Check door request switch (passenger side).
Refer to DLK-72, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna (passenger side).
Refer to DLK-80, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check Intermittent Incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
TRUNK
TRUNK : DescriptionINFOID:0000000003908231
NOTE:
 Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-7, "
Work Flow".
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
 Door lock function is normal.
 Vehicle speed is less than 5 km/h (3MPH).
 All doors are unlocked.

DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DLK-163
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK : Diagnosis ProcedureINFOID:0000000003907977
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent key button?
YES >> GO TO 2.
NO >> Go to DLK-67, "
Description".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
Check “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
Refer to DLK-43, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “LOCK/UNLOCK BY I-KEY” in “WORK SUPPORT”.
3.CHECK TRUNK LID OPENER REQUEST SWITCH
Check trunk lid opener request switch.
Refer to DLK-74, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna (trunk room).
Refer to DLK-80, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check Intermittent Incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.

DLK-164
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER SWITCH
TRUNK LID DOES NOT OPEN WITH TRUNK LID OPENER SWITCH
DescriptionINFOID:0000000003843873
NOTE:
 Before performing the diagnosis in the following table, check “Work Flow”. Refer to DLK-7, "
Work Flow".
 Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
 Door lock function is normal.
 Vehicle speed is less than 5 km/h (3 MPH).
 All doors are unlocked.
Diagnosis ProcedureINFOID:0000000003843874
1.CHECK TRUNK LID OPENER SWITCH
Check trunk lid opener switch.
Refer to DLK-70, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace the malfunctioning parts.
2.CHECK TRUNK LID OPENER ACTUATOR
Check trunk lid opener actuator.
Refer to DLK-65, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace the malfunctioning parts.
3.CONFIRM THE OPERATION
Confirm the operation again.
Is the result normal?
YES >> Check intermittent incident. Refer to GI-35, "Intermittent Incident".
NO >> GO TO 1.
