EXL-22
< FUNCTION DIAGNOSIS >[XENON TYPE]
PARKING, LICENSE PLATE AND TAIL LAMPS SYSTEM
Component Parts Location
INFOID:0000000003773541
Component DescriptionINFOID:0000000003773542
1. Parking lamp 2. Combination switch 3. Tail lamp
4. License plate lamp 5. IPDM E/R 6. BCM
7. Tail lamp indicator lamp
A. Engine room (LH) B. Behind the combination meter C. On the combination meter
JPLIA1123ZZ
Part Description
BCM Detects each switch condition by the combination switch reading function.
Judges the ON/OFF status of the parking, license plate and tail lamps according to
the vehicle condition.
- Requests the tail lamp relay ON to IPDM E/R (with CAN communication).
- Requests the tail lamp indicator lamp ON to the combination meter (with CAN com-
munication).
IPDM E/RControls the integrated relay and supplies voltage to the load according to the request
from BCM (with CAN communication).
Combination switch
(Lighting & turn signal switch)Refer to BCS-8, "
System Diagram".
Combination meter
(Tail lamp indicator lamp)Turns the tail lamp indicator lamp ON according to the request from BCM (with CAN
communication).
Page 2052 of 5121
![NISSAN TEANA 2008 Service Manual REAR FOG LAMP SYSTEM
EXL-23
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR FOG LAMP SYSTEM
System DiagramINFOID:0000000003811061
System DescriptionINFOID:0000000003811062
OUT NISSAN TEANA 2008 Service Manual REAR FOG LAMP SYSTEM
EXL-23
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR FOG LAMP SYSTEM
System DiagramINFOID:0000000003811061
System DescriptionINFOID:0000000003811062
OUT](/img/5/57391/w960_57391-2051.png)
REAR FOG LAMP SYSTEM
EXL-23
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR FOG LAMP SYSTEM
System DiagramINFOID:0000000003811061
System DescriptionINFOID:0000000003811062
OUTLINE
Rear fog lamp is controlled with the combination switch reading function and the rear fog lamp control function
of BCM.
REAR FOG LAMP OPERATION
BCM detects the condition of the combination switch by the combination switch reading function.
BCM supplies voltage to rear fog lamp according to the rear fog lamp ON condition.
Rear fog lamp ON condition- Rear fog lamp switch signal is input with front fog lamp ON and rear fog lamp OFF
Rear fog lamp switch ON with any of following condition.- Lighting switch 2ND
- Lighting switch 1ST, and front fog lamp switch ON
BCM transmits the rear fog lamp status signal to the combination meter with CAN communication.
Combination meter turns the rear fog lamp indicator lamp ON according to the rear fog lamp status signal.
JPLIA0179GB
Page 2053 of 5121
![NISSAN TEANA 2008 Service Manual EXL-24
< FUNCTION DIAGNOSIS >[XENON TYPE]
REAR FOG LAMP SYSTEM
Component Parts Location
INFOID:0000000003811063
Component DescriptionINFOID:0000000003811064
1. Combination switch 2. Rear fog lamp 3. B NISSAN TEANA 2008 Service Manual EXL-24
< FUNCTION DIAGNOSIS >[XENON TYPE]
REAR FOG LAMP SYSTEM
Component Parts Location
INFOID:0000000003811063
Component DescriptionINFOID:0000000003811064
1. Combination switch 2. Rear fog lamp 3. B](/img/5/57391/w960_57391-2052.png)
EXL-24
< FUNCTION DIAGNOSIS >[XENON TYPE]
REAR FOG LAMP SYSTEM
Component Parts Location
INFOID:0000000003811063
Component DescriptionINFOID:0000000003811064
1. Combination switch 2. Rear fog lamp 3. BCM
4. Rear fog lamp indicator lamp
A. Behind the combination meter B. On the combination meter
JPLIA1125ZZ
Part Description
BCM Detects each switch condition by the combination switch reading function.
Judges that the rear fog lamp is turned ON according to the vehicle status
- Supplies voltage to the rear fog lamp
- Requests the rear fog lamp indicator lamp ON to the combination meter (with CAN
communication).
Combination switch
(Lighting & turn signal switch)Refer to BCS-8, "
System Diagram".
Combination meter
(Rear fog lamp indicator lamp)Turns the rear fog lamp indicator lamp ON according to the request from BCM (with CAN
communication).
Page 2054 of 5121
![NISSAN TEANA 2008 Service Manual EXTERIOR LAMP BATTERY SAVER SYSTEM
EXL-25
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
EXTERIOR LAMP BATTERY SAVER SYSTEM
System DiagramINFOID:0000000003773543
System Descriptio NISSAN TEANA 2008 Service Manual EXTERIOR LAMP BATTERY SAVER SYSTEM
EXL-25
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
EXTERIOR LAMP BATTERY SAVER SYSTEM
System DiagramINFOID:0000000003773543
System Descriptio](/img/5/57391/w960_57391-2053.png)
EXTERIOR LAMP BATTERY SAVER SYSTEM
EXL-25
< FUNCTION DIAGNOSIS >[XENON TYPE]
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
EXTERIOR LAMP BATTERY SAVER SYSTEM
System DiagramINFOID:0000000003773543
System DescriptionINFOID:0000000003773544
OUTLINE
Exterior lamp battery saver system is controlled by each function of BCM and IPDM E/R.
Control by BCM- Combination switch reading function
- Headlamp control function
- Exterior lamp battery saver function
Control by IPDM E/R- Relay control function
BCM turns the exterior lamp* OFF after a period of time to prevent the battery from over-discharge when the
ignition switch is turned OFF with the exterior lamp ON.
*: Headlamp (LO/HI), parking lamp, tail lamp, license plate lamp, front fog lamp and rear fog lamp.
EXTERIOR LAMP BATTERY SAVER ACTIVATION
BCM activates the timer and turns the exterior lamp OFF 5 minutes after the ignition switch is turned from ON
→ OFF with the exterior lamps ON.
NOTE:
Headlamp control function turns the exterior lamps ON normally when the ignition switch is turned ACC or
the engine started (both before and after the exterior lamp battery saver is turned OFF).
The timer starts at the time that the lighting switch is turned from OFF → 1ST or 2ND with the exterior lamp
OFF.
JPLIA1084GB
Page 2055 of 5121
![NISSAN TEANA 2008 Service Manual EXL-26
< FUNCTION DIAGNOSIS >[XENON TYPE]
EXTERIOR LAMP BATTERY SAVER SYSTEM
Component Parts Location
INFOID:0000000003773545
Component DescriptionINFOID:0000000003773546
1. Combination switch 2. IPDM NISSAN TEANA 2008 Service Manual EXL-26
< FUNCTION DIAGNOSIS >[XENON TYPE]
EXTERIOR LAMP BATTERY SAVER SYSTEM
Component Parts Location
INFOID:0000000003773545
Component DescriptionINFOID:0000000003773546
1. Combination switch 2. IPDM](/img/5/57391/w960_57391-2054.png)
EXL-26
< FUNCTION DIAGNOSIS >[XENON TYPE]
EXTERIOR LAMP BATTERY SAVER SYSTEM
Component Parts Location
INFOID:0000000003773545
Component DescriptionINFOID:0000000003773546
1. Combination switch 2. IPDM E/R 3. BCM
