2. Remove the rear window glass. Refer to. GW-25, "Removal and Installation".
1. Laser welds 2. Spot welds
ALKIA2539ZZ
1. Air or electric drill 2. 8 (0.31in) spot weld removal drill bit
ALKIA2540ZZ
Revision: November 20132014 Altima NAM

BRM-44
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
NOTE:
Only drill through the first layer of metal (the roof outer panel).
3. Drill out spot welds using a 8 mm (0.31in) spot weld removing bit on the windshield and rear window glass flanges.
NOTE:
Only grind through the first layer or metal (the roof outer panel)
4. Using an angle head grinder or cutting wheel to grind through the first layer only on the laser welded areas (roof panel sides) to release the weld.
1. Air or electric angle head grinder 2. Cutting wheel
ALKIA2541ZZ
Revision: November 20132014 Altima NAM

REPLACEMENT OPERATIONSBRM-45
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
BRM
N
O P
5. Remove roof panel (1).
PREPARATION
1. Grind all mating surfaces around the roof flanges.
2. Test panel for proper alignment and fit.
ALKIA2543ZZ
1. Weld through primer
Front
ALKIA2542ZZ
Revision: November 20132014 Altima NAM

BRM-46
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
3. Remove panel.
4. Compare to the removed panel, then drill 8mm (0.31in) holes in the same location on the new service roof
panel.
5. Use 3M weld through primer to prime the front and rear window flanges
INSTALLATION
1. Check the dimensions and fit.
2. Use clamping pliers to retain the roof panel to the front and rear window flanges.
3. Plug weld as necessary.
4. Use panel bonding adhesive in place of the laser welds along the roof side flanges.
5. Dress welds as necessary to allow proper glass fit.
6. Refer to NISSAN approved panel refinishing.
7. Install the headlining. Refer to INT-30, "Removal and Installation"
.
8. Install rear window glass. Refer to GW-25, "Removal and Installation"
.
9. Install windshield glass. Refer to GW-12, "Removal and Installation"
.
Outer SillINFOID:0000000009464980
OUTER SILL - EARLY PRODUCTION MODELS
Early Production Models
Work after the front pillar reinforcement, center pillar reinforcement, and rear fender have been removed.
1. Panel bonding area 2. Plug welds A. Clamping pliers
Front
ALKIA2544ZZ
Manufacturing Plant Smyrna: built before 10/25/2012
Canton: built before 11/07/2012
Revision: November 20132014 Altima NAM

REPLACEMENT OPERATIONSBRM-47
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
BRM
N
O P
Early Production Models
OUTER SILL - LATE PRODUCTION MODELS
AWKIA2234ZZ
Change parts
z Outer sill reinforcement
Front
Revision: November 20132014 Altima NAM

BRM-48
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
Late Production Models
Work after the front pillar reinforcement, center pillar reinforcement, and rear fender have been removed.
Late Production Models
Manufacturing Plant Smyrna: built on 10/25/2012 or later
Canton: built on 11/07/2012 or later
AWKIA2457ZZ
Revision: November 20132014 Altima NAM

REPLACEMENT OPERATIONSBRM-49
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
BRM
N
O P
Rear FenderINFOID:0000000009464981
Change parts
z Outer sill reinforcement
Front
ALKIA2565ZZ
Change parts A Recommended cut zone
Revision: November 20132014 Altima NAM

BRM-50
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
Rear Panel
INFOID:0000000009464982
Change parts z Rear panel assembly Front
ALKIA2548ZZ
Revision: November 20132014 Altima NAM

REPLACEMENT OPERATIONSBRM-51
< REMOVAL AND INSTALLATION >
C
D E
F
G H
I
J
L
M A
B
BRM
N
O P
Rear Floor RearINFOID:0000000009464983
• Work after rear panel assembly has been removed.
Change parts z Rear floor rear Front
ALKIA2547ZZ
Revision: November 20132014 Altima NAM

BRM-52
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
Rear Side Member Extension
INFOID:0000000009464984
• Work after rear panel assembly and rear floor rear have been removed.
Change parts z Rear side member extension Front
ALKIA2577ZZ
Revision: November 20132014 Altima NAM
