NISSAN TIIDA 2007 Service Repair Manual

EC-1282
< SYMPTOM DIAGNOSIS >[K9K]
EXCESSIVE CONSUMPTION
Perform the TEST 2: INTERNAL FUEL TRANSFER PUMP CHECK. Refer to EC-1044, "BASIC INSPECTION
: Special Repair Requirement (TEST 2: Internal Fuel Transfer Pump Check)".
>> GO TO 10.
10.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 11.
11 .CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 12.
12.CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>> GO TO 13.
13.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 14.
14.CHECK INCORRECT FUEL INJECTION QUANTITY
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "
BASIC INSPECTION :
Special Repair Requirement (TEST 7: Incorrect Fuel Injection Quantity)".
>>INSPECTION END

ENGINE KNOCK
EC-1283
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ENGINE KNOCK
DescriptionINFOID:0000000001162729
CHART 16: ENGINE KNOCK
Diagnosis ProcedureINFOID:0000000001162730
1.CHECK ENGINE OIL
Check the grade of engine oil. Refer to LU-26, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace engine oil. Refer to LU-27, "
Refilling"
2.CHECK ENGINE OIL LEVEL
Is the engine oil level correct?
Ye s o r N o
Yes >> GO TO 3.
No >> Top up the oil.
3.CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Check ECM power supply and ground circuit. Refer to EC-1106, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK WIRING HARNESS
Visually check the condition of the engine wiring harness.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness or connector.
5.CHECK AIR INTAKE SYSTEM
Check air intake system. Refer to EM-269, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace air intake system.
6.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR
Check electric throttle control actuator. Refer to EC-1134, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace.
7.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace.
8.CHECK CATALYTIC CONVERTER
Is the catalytic converter clogged or deteriorated?
Is the inspection result normal?
YES >> GO TO 9.
NO >> Repair or replace.
9.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)

EC-1284
< SYMPTOM DIAGNOSIS >[K9K]
ENGINE KNOCK
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 10.
10.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 11.
11 .CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>> GO TO 12.
12.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 13.
13.CHECK INCORRECT FUEL INJECTION QUANTITY
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "
BASIC INSPECTION :
Special Repair Requirement (TEST 7: Incorrect Fuel Injection Quantity)".
>>INSPECTION END

ENGINE OVERHEATING
EC-1285
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ENGINE OVERHEATING
DescriptionINFOID:0000000001162731
CHART 17: ENGINE OVERHEATING
Diagnosis ProcedureINFOID:0000000001162732
1.CHECK COOLING SYSTEM
Check the cooling system. Refer to CO-53, "
Troubleshooting Chart".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace.
2.CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Check ECM power supply and ground circuit. Refer to EC-1106, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.CHECK WIRING HARNESS
Visually check the condition of the engine wiring harness.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Check engine coolant temperature sensor. Refer to EC-1133, "
Component Inspection".
Is the inspection result normal?
Yes >> GO TO 5.
No >> Repair or replace.
5.CHECK COOLING FAN OPERATION
Check cooling fan operation. Refer to EC-1211, "
Component Function Check".
Is the inspection result normal?
YES >>INSPECTION END
NO >> Repair or replace.

EC-1286
< SYMPTOM DIAGNOSIS >[K9K]
ENGINE SMOKES WHEN STARTED
ENGINE SMOKES WHEN STARTED
DescriptionINFOID:0000000001162733
CHART 18: ENGINE SMOKES WHEN STARTED
Diagnosis ProcedureINFOID:0000000001162734
1.CHECK ENGINE OIL
Check the grade of engine oil. Refer to LU-26, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace engine oil. Refer to LU-27, "
Refilling"
2.CHECK ENGINE OIL LEVEL
Is the engine oil level correct?
Ye s o r N o
Ye s > > G O T O 3 .
No >> Top up the oil.
3.CHECK FUEL PUMP TEMPERATURE SENSOR
Check fuel pump temperature sensor. Refer to EC-1137, "
Component Inspection".
Is the inspection result normal?
Ye s > > G O T O 4 .
No >> Repair or replace.
4.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Check engine coolant temperature sensor. Refer to EC-1133, "
Component Inspection".
Is the inspection result normal?
Ye s > > G O T O 5 .
No >> Repair or replace.
5.CHECK COOLING SYSTEM
Check the cooling system. Refer to CO-53, "
Troubleshooting Chart".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace.
6.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 7.
7.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 8.
8.CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>>INSPECTION END

ENGINE EMITS BLUE SMOKE
EC-1287
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ENGINE EMITS BLUE SMOKE
DescriptionINFOID:0000000001162735
CHART 19: ENGINE EMITS BLUE SMOKE
Diagnosis ProcedureINFOID:0000000001162736
1.CHECK ENGINE OIL
Check the grade of engine oil. Refer to LU-26, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace engine oil. Refer to LU-27, "
Refilling"
2.CHECK ENGINE OIL LEVEL
Is the engine oil level correct?
Ye s o r N o
Yes >> GO TO 3.
No >> Top up the oil.
3.CHECK FUEL
Check that the fuel reservoir is correctly filled and with the right fuel.
>> GO TO 4.
4.CHECK ENGINE COOLANT TEMPERATURE SENSOR
Check engine coolant temperature sensor. Refer to EC-1133, "
Component Inspection".
Is the inspection result normal?
Yes >> GO TO 5.
No >> Repair or replace.
5.CHECK AIR INTAKE SYSTEM
Check air intake system. Refer to EM-269, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace air intake system.
6.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR
Check electric throttle control actuator. Refer to EC-1134, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace.
7.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace.
8.CHECK TURBOCHARGER
Check that the turbocharger is working properly. Refer to EC-1195, "
Diagnosis Procedure".
Is the turbocharger correct?
Yes >> GO TO 9.
No >> Repair or replace.
9.CHECK EGR SYSTEM
Check EGR system. Refer to EC-1202, "
Diagnosis Procedure".

EC-1288
< SYMPTOM DIAGNOSIS >[K9K]
ENGINE EMITS BLUE SMOKE
Is the inspection result normal?
YES >> GO TO 10.
NO >> Repair or replace.
10.CHECK CATALYTIC CONVERTER
Is the catalytic converter clogged or deteriorated?
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace.
11 .CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 12.
12.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Perform the TEST 4: HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE). Refer to EC-
1045, "BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump (Volumetric
Control Valve) Check]".
>> GO TO 13.
13.CHECK RAIL HIGH PRESSURE CONTROL CIRCUIT
Perform the TEST 5: RAIL HIGH PRESSURE CONTROL CIRCUIT CHECK. Refer to EC-1048, "
BASIC
INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regulation Check)".
>> GO TO 14.
14.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 15.
15.CHECK INCORRECT FUEL INJECTION QUANTITY
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "
BASIC INSPECTION :
Special Repair Requirement (TEST 7: Incorrect Fuel Injection Quantity)".
>> GO TO 16.
16.CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Check ECM power supply and ground circuit. Refer to EC-1106, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 17.
NO >> Repair or replace harness or connector.
17.CHECK WIRING HARNESS
Visually check the condition of the engine wiring harness.
Is the inspection result normal?
YES >>INSPECTION END
NO >> Repair or replace harness or connector.

ENGINE SMOKES WHEN REVVED
EC-1289
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ENGINE SMOKES WHEN REVVED
DescriptionINFOID:0000000001162737
CHART 20: ENGINE SMOKES WHEN REVVED
Diagnosis ProcedureINFOID:0000000001162738
1.CHECK ENGINE OIL
Check the grade of engine oil. Refer to LU-26, "
Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Replace engine oil. Refer to LU-27, "
Refilling"
2.CHECK ENGINE OIL LEVEL
Is the engine oil level correct?
Ye s o r N o
Yes >> GO TO 3.
No >> Top up the oil.
3.CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Check ECM power supply and ground circuit. Refer to EC-1133, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness or connector.
4.CHECK WIRING HARNESS
Visually check the condition of the engine wiring harness.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness or connector.
5.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "
Component Inspection".
Is the inspection result normal?
YES >>INSPECTION END
NO >> Repair or replace.

EC-1290
< SYMPTOM DIAGNOSIS >[K9K]
ENGINE EMITS WHITE SMOKE (ESPECIALLY WHEN STARTING)
ENGINE EMITS WHITE SMOKE (ESPECIALLY WHEN STARTING)
DescriptionINFOID:0000000001162739
CHART 21: ENGINE EMITS WHITE SMOKE (ESPECIALLY WHEN STARTING)
Diagnosis ProcedureINFOID:0000000001162740
1.CHECK FUEL
Check that the fuel reservoir is correctly filled and with the right fuel.
>> GO TO 2.
2.CHECK COOLING SYSTEM
Check the cooling system. Refer to CO-53, "
Troubleshooting Chart".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace.
3.CHECK GLOW SYSTEM
Check the glow system. Refer to EC-1156, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace glow system. Refer to EM-279, "
Removal and Installation"
4.CHECK MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN
Perform the TEST 6: MAJOR LEAK IN FUEL INJECTOR/FUEL INJECTORS OPEN. Refer to EC-1052,
"BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/Fuel Injectors
Open)".
>> GO TO 5.
5.CHECK INCORRECT FUEL INJECTION QUANTITY
Perform the TEST 7: INCORRECT FUEL INJECTION QUANTITY. Refer to EC-1053, "
BASIC INSPECTION :
Special Repair Requirement (TEST 7: Incorrect Fuel Injection Quantity)".
>>INSPECTION END

EMISSION CONTROL NOT SATISFACTORY
EC-1291
< SYMPTOM DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EMISSION CONTROL NOT SATISFACTORY
DescriptionINFOID:0000000001162741
CHART 22: EMISSION CONTROL NOT SATISFACTORY
Diagnosis ProcedureINFOID:0000000001162742
1.CHECK ECM POWER SUPPLY AND GROUND CIRCUIT
Check ECM power supply and ground circuit. Refer to EC-1106, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace harness or connector.
2.CHECK WIRING HARNESS
Visually check the condition of the engine wiring harness.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness or connector.
3.CHECK AIR INTAKE SYSTEM
Check air intake system. Refer to EM-269, "
Removal and Installation".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace air intake system.
4.CHECK ELECTRIC THROTTLE CONTROL ACTUATOR
Check electric throttle control actuator. Refer to EC-1134, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace.
5.CHECK MASS AIR FLOW SENSOR
Check mass air flow sensor. Refer to EC-1125, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace.
6.CHECK TURBOCHARGER
Check that the turbocharger is working properly. Refer to EC-1195, "
Diagnosis Procedure".
Is the turbocharger correct?
Yes >> GO TO 7.
No >> Repair or replace.
7.CHECK EGR SYSTEM
Check EGR system. Refer to EC-1202, "
Diagnosis Procedure".
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace.
8.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Perform the TEST 3: HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE). Refer to EC-1044,
"BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump (Pressure Control
Valve) Check]".
>> GO TO 9.
