COMPONENT DIAGNOSIS
DOOR MIRROR
Wiring Diagram — Position Adjustment (LHD) —INFOID:0000000001702329
AWLWA0014GB

MIR-4
< COMPONENT DIAGNOSIS >
DOOR MIRROR
Wiring Diagram — Position Adjustment (RHD) —
INFOID:0000000001728321
AWLWA0015GB

DOOR MIRROR
MIR-5
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
MIR
N
O
P
Wiring Diagram — Power Fold System (LHD) —INFOID:0000000001728322
AWLWA0016GB

MIR-6
< COMPONENT DIAGNOSIS >
DOOR MIRROR
Wiring Diagram — Power Fold System (RHD) —
INFOID:0000000001728323
AWLWA0017GB

DOOR MIRROR
MIR-7
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
K
MA
B
MIR
N
O
P
REMOVAL AND INSTALLATION
DOOR MIRROR
Removal and InstallationINFOID:0000000001716808
CAUTION:
Be careful not to damage the mirror body.
REMOVAL
1. Remove the front door finisher. Refer to INT-13, "Removal and Installation".
2. Disconnect the harness connector of door mirror.
3. Using a suitable tool remove door mirror base cover.
CAUTION:
 Do not reuse the disassembled door mirror base cover.
 Be careful not to damage the door panel with a tool.
4. Remove the door mirror bolts, and remove the door mirror
assembly.
CAUTION:
Do not use force to remove the door mirror assembly by
force because it is attached by clip.
INSTALLATION
Installation is in the reverse order of removal.
PIIB2638J
1. Door mirror base cover 2. Door mirror
PIIB2679E
PIIB6288E

MIR-8
< REMOVAL AND INSTALLATION >
DOOR MIRROR
Disassembly and Assembly
INFOID:0000000001716809
DISASSEMBLY
1. Pull out all the terminals from the connector.
NOTE:
Before pulling out the terminal, note the connector terminal arrangement.
2. Turn the mirror glass surface upward.
3. Apply a protective tape A to the housing.
4. Insert a suitable tool B into the concave gap between mirror
holder (1) and power unit (2). Push up tabs (3) (2 locations) on
mirror holder to disengage lower part of mirror holder, and
remove mirror body assembly.
NOTE:
When pushing up the tabs, do not forcefully push up only 1 con-
cave position but try to push up 2 concave positions.
5. Remove the mirror body (1) from the mirror housing assembly
(2).
ASSEMBLY
1. Warm the lower tabs with a dryer or equivalent.
NOTE:
Warm the lower tabs sufficiently before installing the mirror body. The tabs may be broken if it is cold. Be
especially careful in the winter.
2. Engage upper tabs of mirror body (1) with power unit (2). Then,
press lower part of mirror glass down until the lower part snaps
to allow engagement of lower tabs.
NOTE:
After installation, visually check that the lower tabs are securely
engaged when viewed from the bottom of mirror surface.
3. Insert the harness terminals into the connector.
NOTE:
Make sure to insert the harness terminals into the correct con-
nector. Do not confuse the locations.
PIIB6317E
PIIB6096E
PIIB6316E

INSIDE MIRROR
MIR-9
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
K
MA
B
MIR
N
O
P
INSIDE MIRROR
Removal and InstallationINFOID:0000000001716810
REMOVAL
Slide the inside mirror upward, and then remove inside mirror (1)
from the mirror base (2).
CAUTION:
 Do not use excessive force to remove the inside mirror
because it is inserted tightly into the mirror base.
 Do not reuse the inside mirror disassembled from mirror
base.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
Be sure to insert the inside mirror to the mirror base until the pawl is engaged to the mirror base.
