NISSAN TIIDA 2007 Service Repair Manual

CL-16
< SERVICE INFORMATION >
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
Clutch Control SystemINFOID:0000000001375300
Clutch PedalINFOID:0000000001375301
Clutch DiscINFOID:0000000001375302
Clutch CoverINFOID:0000000001375303
Type of clutch controlHydraulic
Clearance ″A″ between clutch pedal and ASCD switch threaded
end while clutch pedal is fully released (if equipped). 0.74 - 1.96 mm (0.0291 - 0.0772 in)
Clearance ″C″ between clutch pedal and clutch interlock switch
threaded end while clutch pedal is fully depressed.0.74 - 1.96 mm (0.0291 - 0.0772 in)
Model225
Facing size (outer dia. × inner dia. × thickness) 225 mm × 160 mm × 3.2 mm (8.86 in × 6.30 in × 0.126 in)
Thickness of disc assembly with load 7.2 - 7.6 mm (0.283 - 0.299 in) with 5,394 N (550 kg, 1,213 lb)
Runout limit/diameter of the area to be measured 1.0 mm (0.039 in) / 215 mm (8.46 in) dia.
Maximum spline backlash (at outer edge of disc) 1.0 mm (0.039 in)
Wear limit of facing surface to rivet head 0.3 mm (0.012 in)
Set-load5,394 N (550 kg, 1,213 lb)
Diaphragm spring lever height 20 - 22 mm (0.79 - 0.87 in)
Uneven limit diaphragm spring toe height 0.7 mm (0.028 in) or less

CO-1
ENGINE
C
D
E
F
G
H
I
J
K
L
M
SECTION CO
A
CO
N
O
P
CONTENTS
ENGINE COOLING SYSTEM
HR16DE
FUNCTION DIAGNOSIS ...............................
4
DESCRIPTION ....................................................4
Engine Cooling System .............................................4
Engine Cooling System Schematic ...........................5
SYMPTOM DIAGNOSIS ...............................6
OVERHEATING CAUSE ANALYSIS ..................6
Troubleshooting Chart ...............................................6
PRECAUTION ...............................................8
PRECAUTIONS ...................................................8
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................
8
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .....................................
8
Precaution for Liquid Gasket .....................................8
PREPARATION ...........................................10
PREPARATION ..................................................10
Special Service Tool ...............................................10
Commercial Service Tool ........................................10
ON-VEHICLE MAINTENANCE ....................11
ENGINE COOLANT ...........................................11
Inspection ................................................................11
Changing Engine Coolant .......................................11
RADIATOR .........................................................14
Checking Radiator Cap ...........................................14
Checking Radiator ...................................................14
ON-VEHICLE REPAIR .................................16
RADIATOR .........................................................16
Component ..............................................................16
Removal and Installation .........................................16
COOLING FAN ..................................................18
Component (Models with A/C) .................................18
Component (Models without A/C) ............................18
Removal and Installation .........................................19
WATER PUMP ..................................................20
Exploded View .........................................................20
Removal and Installation .........................................20
Inspection ................................................................21
THERMOSTAT ..................................................22
Exploded View .........................................................22
Removal and Installation .........................................22
Inspection ................................................................23
WATER OUTLET ..............................................24
Exploded View .........................................................24
Removal and Installation .........................................24
Inspection ................................................................25
DISASSEMBLY AND ASSEMBLY ..............26
COOLING FAN ..................................................26
DISASSEMBLY AND ASSEMBLY ..........................26
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................
27
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
27
Periodical Maintenance Specification ......................27
Radiator ...................................................................27
Thermostat ..............................................................27
MR18DE
FUNCTION DIAGNOSIS ..............................
28
COOLING SYSTEM ..........................................28
Cooling Circuit .........................................................28

CO-2
SYMPTOM DIAGNOSIS .............................30
OVERHEATING CAUSE ANALYSIS ................30
Troubleshooting Chart ............................................30
PRECAUTION .............................................32
PRECAUTIONS .................................................32
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
32
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ..................................
32
Precaution for Liquid Gasket ..................................32
PREPARATION ...........................................34
PREPARATION .................................................34
Special Service Tool ...............................................34
Commercial Service Tool .......................................34
ON-VEHICLE MAINTENANCE ...................35
ENGINE COOLANT ...........................................35
Inspection ...............................................................35
Changing Engine Coolant .......................................35
RADIATOR ........................................................38
Checking Radiator Cap ..........................................38
Checking Radiator ..................................................38
ON-VEHICLE REPAIR ................................40
RADIATOR ........................................................40
Component .............................................................40
Removal and Installation ........................................40
COOLING FAN ..................................................42
Component (Models with A/C) ................................42
Component (Models without A/C) ...........................42
Removal and Installation ........................................43
WATER PUMP ...................................................44
Component .............................................................44
Removal and Installation ........................................44
THERMOSTAT ..................................................45
Component .............................................................45
Removal and Installation ........................................45
WATER OUTLET AND WATER CONTROL
VALVE ...............................................................
47
Component .............................................................47
Removal and Installation ........................................47
DISASSEMBLY AND ASSEMBLY .............50
COOLING FAN ..................................................50
DISASSEMBLY AND ASSEMBLY .........................50
SERVICE DATA AND SPECIFICATIONS
(SDS) ...........................................................
51
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
51
Standard and Limit ..................................................51
K9K
FUNCTION DIAGNOSIS ............................
52
DESCRIPTION ...................................................52
Engine Cooling System .........................................52
SYMPTOM DIAGNOSIS ............................53
OVERHEATING CAUSE ANALYSIS ................53
Troubleshooting Chart ............................................53
PRECAUTION ............................................55
PRECAUTIONS .................................................55
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................
55
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect ..................................
55
Precaution for Liquid Gasket ...................................55
PREPARATION ..........................................57
PREPARATION .................................................57
Special Service Tools .............................................57
Commercial Service Tools ......................................57
ON-VEHICLE MAINTENANCE ..................58
ENGINE COOLANT ...........................................58
Inspection ................................................................58
Draining ...................................................................58
Refilling ...................................................................58
Flushing ..................................................................59
RADIATOR ........................................................60
Checking Radiator Cap ...........................................60
Checking Radiator ..................................................60
ON-VEHICLE REPAIR ...............................62
RADIATOR ........................................................62
Exploded View ........................................................62
Removal and Installation .........................................62
Inspection ................................................................63
COOLING FAN ..................................................64
Exploded View ........................................................64
Removal and Installation .........................................64
Disassembly and Assembly ....................................65
Inspection ................................................................65
WATER PUMP ...................................................66
Exploded View ........................................................66
Removal and Installation .........................................66
Inspection ................................................................66

CO-3
C
D
E
F
G
H
I
J
K
L
M
COA
N
O
P
WATER OUTLET AND THERMOSTAT AS-
SEMBLY .............................................................
68
Exploded View ........................................................68
Removal and Installation .........................................68
Inspection ................................................................68
SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................
70
SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................
70
Periodical Maintenance Specification ....................70
Radiator ...................................................................70
Thermostat ..............................................................70

CO-4
< FUNCTION DIAGNOSIS >[HR16DE]
DESCRIPTION
FUNCTION DIAGNOSIS
DESCRIPTION
Engine Cooling SystemINFOID:0000000001381550
AWBIA0155ZZ
1. Cylinder head 2. Cylinder block 3. Water pump
4. Thermostat 5. Water inlet 6. Water bypass
7. Water outlet A. From radiator B. To radiator
C. From electronic throttle control actu-
ator (Northern European models)D. From heater E. To heater
F. To electronic throttle control actuator
(Northern European models)

DESCRIPTION
CO-5
< FUNCTION DIAGNOSIS >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Engine Cooling System SchematicINFOID:0000000001381551
AWBIA0130ZZ
1. Reservoir tank 2. Radiator 3. Water inlet
4. Thermostat 5. Water bypass 6. Water jacket
7. Water pump 8. Cylinder block 9. Cylinder head
10. Water outlet 11. Electronic throttle control actuator 12. Heater
A. Thermostat open B. Thermostat closed C. Constant
D. Northern European models

CO-6
< SYMPTOM DIAGNOSIS >[HR16DE]
OVERHEATING CAUSE ANALYSIS
SYMPTOM DIAGNOSIS
OVERHEATING CAUSE ANALYSIS
Troubleshooting ChartINFOID:0000000001381552
Symptom Check items
Cooling sys-
tem parts
malfunctionPoor heat transferWater pump malfunction Worn or loose drive belt
— Thermostat stuck closed —
Damaged finsDust contamination or pa-
per clogging
Physical damage
Clogged radiator cooling
tubeExcess foreign material
(rust, dirt, sand, etc.)
Reduced air flowCooling fan does not oper-
ate
Fan assembly — High resistance to fan rota-
tion
Damaged fan blades
Damaged radiator shroud — — —
Improper engine coolant
mixture ratio———
Poor engine coolant quality — Engine coolant viscosity —
Insufficient engine coolantEngine coolant leaksCooling hoseLoose clamp
Cracked hose
Water pump Poor sealing
Reservoir tank capLoose
Poor sealing
RadiatorO-ring for damage, deterio-
ration or improper fitting
Cracked radiator tank
Cracked radiator core
Reservoir tank Cracked reservoir tank
Overflowing reservoir tankExhaust gas leaks into cool-
ing systemCylinder head deterioration
Cylinder head gasket deteri-
oration

OVERHEATING CAUSE ANALYSIS
CO-7
< SYMPTOM DIAGNOSIS >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Except cool-
ing system
parts mal-
function— Overload on engineAbusive drivingHigh engine rpm under no
load
Driving in low gear for ex-
tended time
Driving at extremely high
speed
Power train system mal-
function
— Installed improper size
wheels and tires
Dragging brakes
Improper ignition timing
Blocked or restricted air
flowBlocked bumper —
— Blocked radiator grilleInstalled car brassiere
Mud contamination or paper
clogging
Blocked radiator —
Blocked condenser
Blocked air flow
Installed large fog lamp Symptom Check items

CO-8
< PRECAUTION >[HR16DE]
PRECAUTIONS
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001534589
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
 Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Precaution Necessary for Steering Wheel Rotation After Battery Disconnect
INFOID:0000000001534590
NOTE:
 This Procedure is applied only to models with Intelligent Key system and NATS (NISSAN ANTI-THEFT SYS-
TEM).
 Remove and install all control units after disconnecting both battery cables with the ignition knob in the
″LOCK″ position.
 Always use CONSULT-II to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NATS, an electrically controlled steering lock mech-
anism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery power is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables.
NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-II.
Precaution for Liquid GasketINFOID:0000000001534591
REMOVAL OF LIQUID GASKET SEALING
 After removing nuts and bolts, separate the mating surface, using Tool and remove old liquid gasket sealing.

PRECAUTIONS
CO-9
< PRECAUTION >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
CAUTION:
Be careful not to damage the mating surfaces.
 Tap Tool to insert it (1), and then slide it by tapping on the side (2)
as shown.
 In areas where Tool is difficult to use, use plastic hammer to lightly
tap the parts, to remove it.
CAUTION:
If for some unavoidable reason suitable tool such as screw-
driver is used, be careful not to damage the mating surfaces.
LIQUID GASKET APPLICATION PROCEDURE
1. Remove old liquid gasket adhering to the liquid gasket applica-
tion surface and the mating surface, using scraper.
 Remove liquid gasket completely from the groove of the liquid
gasket application surface, bolts, and bolt holes.
2. Thoroughly clean the mating surfaces and remove adhering
moisture, grease and foreign materials.
3. Attach liquid gasket tube to Tool.
Use Genuine RTV Silicone Sealant or equivalent. Refer to GI-27, "
Recommended Chemical Prod-
ucts and Sealants".
4. Apply liquid gasket without breaks to the specified location with the specified dimensions.
 If there is a groove for the liquid gasket application, apply liquid gasket to the groove.
 As for the bolt holes, normally apply liquid gasket inside the
holes. Occasionally, it should be applied outside the holes.
Make sure to read the text of service manual.
 Within five minutes of liquid gasket application, install the mat-
ing component.
 If liquid gasket protrudes, wipe it off immediately.
 Do not retighten nuts or bolts after the installation.
 After 30 minutes or more have passed from the installation, fill
engine oil and engine coolant.
CAUTION:
If there are specific instructions in this manual, observe them. Tool number : KV10111100 (J-37228)
WBIA0566E
Tool number : WS39930000 ( — )
PBIC0003E
WBIA0567E
SEM159F
