Malfunction Indicator Light
B: ACTIVATION OF MALFUNCTION
INDICATOR LIGHT
1) When the ignition switch is turned to ON (engine
off), the malfunction indicator light in the combina-
tion meter illuminates.
NOTE:
If the malfunction indicator light does not illuminate,
perform the diagnosis of malfunction indicator light
circuit or the combination meter circuit. EN(H4DOTC)-52, MALFUNCTION INDICATOR
LIGHT DOES NOT COME ON, Malfunction Indica-
tor Light.>
2) After starting the engine, the malfunction indica-
tor light goes out.If it does not, either the engine or
the emission control system is malfunctioning.3) If the diagnosis system detects a misfire which
could damage the catalyst, the malfunction indica-
tor light will blink at a cycle of 1 Hz.
4) When the ignition switch is turned to ON (engine
off) or to “START” with the test mode connector
connected, the malfunction indicator light blinks at
a cycle of 3 Hz.
(A) Malfunction indicator light
(1) No faulty
(2) Trouble occurs
(3) ON
(4) OFF
(5) Ignition switch ON
(6) Engine start
EN-00335(A)
EN-01679
(1)
(2)
(5)
(6)(3)
(4)
(3)
(4)
(1) ON
(2) OFF
(3) Ignition switch ON
(4) Engine start
(5) Misfire start
(6) 1 second
(1) ON
(2) OFF
(3) Ignition switch ON
(4) 1 second
EN-01680
(2) (1)
(3)
(4)
(5)(6)
EN-01681
(2)(1)
(4)
(3)

EN(H4DOTC)-52
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
C: MALFUNCTION INDICATOR LIGHT DOES NOT COME ON
DIAGNOSIS:
The malfunction indicator light circuit is open or shorted.
TROUBLE SYMPTOM:
When the ignition switch is turned to ON (engine OFF), malfunction indicator light does not operate.
WIRING DIAGRAM:
EN-02309
BATTERYIGNITION
SWITCH
SBF-4SBF-1
B72
B72
B38
B134
ECM
i3
E
14
RHD
RHD
A17
B37
i12 A :
i10 B :
i12i10B134
i3
i2
LHD
LHD
5
COMBINATION
METER
3412
123 456
789 121310 11 14
*
16
B38
i3
B37No.14
*LHD : 17
RHD : 13
B9
A1
34
12 8910 11
12 13 14 15 16 17 18 19 20 21 22 23 24567219
32
1234 5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
25
12345678910111213141516171819202122232425262728293056 7
82 1
94 310
24 22 23 25 11 12 13 14 15
26 27
2816 17
18 19 20 21
33 34 29
32 30 31
A:

EN(H4DOTC)-53
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
Step Check Yes No
1 CHECK OUTPUT SIGNAL FROM ECM.
1) Turn the ignition switch to ON.
2) Measure the voltage between ECM con-
nector and chassis ground.
Connector & terminal
(B134) No. 17 (+) — Chassis ground (
−):Is the voltage less than 1 V? Go to step 4.Go to step 2.
2 CHECK POOR CONTACT.Does the malfunction indicator
light come on when shaking or
pulling the ECM connector and
harness?Repair the poor
contact in ECM
connector.Go to step 3.
3 CHECK ECM CONNECTOR.Is the ECM connector correctly
connected?Replace the ECM.
FU(H4DOTC)-50,
Engine Control
Module (ECM).>Repair the con-
nection of ECM
connector.
4 CHECK HARNESS BETWEEN COMBINA-
TION METER AND ECM CONNECTOR.
1) Turn the ignition switch to OFF.
2) Remove the combination meter. IDI-10, Combination Meter Assembly.>
3) Disconnect the connector from ECM and
combination meter.
4) Measure the resistance of harness
between ECM and combination meter connec-
tor.
Connector & terminal
(B134) No. 17 — (i12) No. 1:Is the resistance less than 1
Ω?Go to step 5.Repair the har-
ness and connec-
tor.
NOTE:
In this case repair
the following:
 Open circuit in
harness between
ECM and combi-
nation meter con-
nector
 Poor contact in
coupling connector
5 CHECK POOR CONTACT.
Check poor contact in combination meter con-
nector.Is there poor contact in combi-
nation meter connector?Repair poor con-
tact in combination
meter connector.Go to step 6.
6 CHECK HARNESS BETWEEN COMBINA-
TION METER AND IGNITION SWITCH CON-
NECTOR.
1) Turn the ignition switch to ON.
2) Measure the voltage between combination
meter connector and chassis ground.
Connector & terminal
(i10) No. 9 (+) — Chassis ground (
−):Is the voltage more than 10 V? Replace the board
of combination
meter. 10, Combination
Meter Assembly.>Check the follow-
ing and repair if
necessary.
N
OTE:
 Blown out of
fuse (No. 14)
 Open or short
circuit in harness
between fuse (No.
14) and battery
terminal
 Poor contact in
ignition switch con-
nector

EN(H4DOTC)-54
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
D: MALFUNCTION INDICATOR LIGHT DOES NOT GO OFF
DIAGNOSIS:
The malfunction indicator light circuit is shorted.
TROUBLE SYMPTOM:
Although malfunction indicator light comes on when the engine runs, DTC is not shown on the Subaru Select
Monitor or OBD-II general scan tool display.
WIRING DIAGRAM:
Step Check Yes No
1 CHECK HARNESS BETWEEN COMBINA-
TION METER AND ECM CONNECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM.
3) Turn the ignition switch to ON.Does malfunction indicator
light illuminate?Repair short circuit
in harness
between combina-
tion meter and
ECM connector.Replace the ECM.
FU(H4DOTC)-50,
Engine Control
Module (ECM).>
EN-02309
BATTERYIGNITION
SWITCH
SBF-4SBF-1
B72
B72
B38
B134
ECM
i3
E
14
RHD
RHD
A17
B37
i12 A :
i10 B :
i12i10B134
i3
i2
LHD
LHD
5
COMBINATION
METER
3412
123 456
789 121310 11 14
*
16
B38
i3
B37No.14
*LHD : 17
RHD : 13
B9
A1
34
12 8910 11
12 13 14 15 16 17 18 19 20 21 22 23 24567219
32
1234 5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
25
12345678910111213141516171819202122232425262728293056 7
82 1
94 310
24 22 23 25 11 12 13 14 15
26 27
2816 17
18 19 20 21
33 34 29
32 30 31
A:

EN(H4DOTC)-55
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
E: MALFUNCTION INDICATOR LIGHT DOES NOT BLINK AT A CYCLE OF 3 Hz
DIAGNOSIS:
 The malfunction indicator light circuit is open or shorted.
 Test mode connector circuit is in open.
TROUBLE SYMPTOM:
When in inspection mode, malfunction indicator light does not blink at a cycle of 3 Hz.
WIRING DIAGRAM:
EN-02310
BATTERYIGNITION
SWITCH
SBF-4SBF-1
B72
B36B75B76E3F2
E2
B134
B137ECM
i3
EE
14
1611
A17
D15
i12 A :
i10 B :
B125B100B126
A :LHD : 17
RHD : 13
*
D :
RHD
LHDLHD
RHD
9
B9
A1
:LHD
:RHD COMBINATION
METER
*
i2
B37
RHD
RHD
i3
B38
LHD
LHD
16
No.14
F60
B21
5
B72
B21
B75
B134
B76i12
i10
B137
i3: RHD
F60: LHD
34
12
123 456
789 121310 11 14
123
4
56
78
9
1011 12
1314 15 16
1
21
21
21
2
B37
56 7
82 1
94 310
24 22 23 25 11 12 13 14 15
26 27
2816 17
18 19 20 21
33 34 29
32 30 31
567
82 1
94 310
22 23 11 12 13 14 15
24 25
2616 17
18 19 20 21
27 28 29 30 31
123456789101112131415161718192021222324252627282930219
32
1234
5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
2534
12 8910 11
12 13 14 15 16 17 18 19 20 21 22 23 24567
A :
B :
1234 5678910 11 12 13 14 15 16 17 18 19 20
F2

EN(H4DOTC)-56
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
Step Check Yes No
1 CHECK STATUS OF MALFUNCTION INDI-
CATOR LIGHT.
1) Turn the ignition switch to OFF.
2) Disconnect the test mode connectors
3) Turn the ignition switch to ON.(engine OFF)Does malfunction indicator
light illuminate?Go to step 2.Repair the mal-
function indictor
light circuit. to EN(H4DOTC)-
52, MALFUNC-
TION INDICA-
TOR LIGHT
DOES NOT
COME ON, Mal-
function Indicator
Light.>
2 CHECK HARNESS BETWEEN COMBINA-
TION METER AND ECM CONNECTOR.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM.
3) Turn the ignition switch to ON.Does malfunction indicator
light illuminate?Repair ground
short circuit in har-
ness between
combination meter
and ECM connec-
tor.Go to step 3.
3 CHECK HARNESS BETWEEN TEST MODE
CONNECTOR AND CHASSIS GROUND.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM.
3) Measure the resistance of harness
between test mode connector and chassis
ground.
Connector & terminal
(B76) No. 1 — Chassis ground:Is the resistance less than 1
Ω?Go to step 4.Repair the har-
ness and connec-
tor.
N
OTE:
In this case repair
the following:
 Open circuit in
harness between
test mode connec-
tor and chassis
ground
4 CHECK POOR CONTACT.
Check poor contact in ECM connector.Is there poor contact in ECM
connector?Repair the poor
contact in ECM
connector.Go to step 5.
5 CHECK HARNESS BETWEEN ECM AND
TEST MODE CONNECTOR.
1) Connect the test mode connector.
2) Measure the resistance of harness
between ECM and chassis ground.
Connector & terminal
(B137) No. 15 — Chassis ground:Is the resistance less than 1
Ω?Go to step 6.Repair open circuit
in harness
between ECM and
test mode connec-
tor.
6 CHECK POOR CONTACT.
Check poor contact in ECM connector.Is there poor contact in ECM
connector?Repair the poor
contact in ECM
connector.Replace the ECM.
FU(H4DOTC)-50,
Engine Control
Module (ECM).>

EN(H4DOTC)-57
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
F: MALFUNCTION INDICATOR LIGHT REMAINS BLINKING AT A CYCLE OF 3
Hz
DIAGNOSIS:
Test mode connector circuit is shorted.
TROUBLE SYMPTOM:
Malfunction indicator light blinks at a cycle of 3 Hz when the ignition switch is turned to ON.
WIRING DIAGRAM:
EN-02310
BATTERYIGNITION
SWITCH
SBF-4SBF-1
B72
B36B75B76E3F2
E2
B134
B137ECM
i3
EE
14
1611
A17
D15
i12 A :
i10 B :
B125B100B126
A :LHD : 17
RHD : 13
*
D :
RHD
LHDLHD
RHD
9
B9
A1
:LHD
:RHD COMBINATION
METER
*
i2
B37
RHD
RHD
i3
B38
LHD
LHD
16
No.14
F60
B21
5
B72
B21
B75
B134
B76i12
i10
B137
i3: RHD
F60: LHD
34
12
123 456
789 121310 11 14
123
4
56
78
9
1011 12
1314 15 16
1
21
21
21
2
B37
56 7
82 1
94 310
24 22 23 25 11 12 13 14 15
26 27
2816 17
18 19 20 21
33 34 29
32 30 31
567
82 1
94 310
22 23 11 12 13 14 15
24 25
2616 17
18 19 20 21
27 28 29 30 31
123456789101112131415161718192021222324252627282930219
32
1234
5610 11 12 13 14 15716
23 3019 20
22 26 27 28 29817
24 3118
2534
12 8910 11
12 13 14 15 16 17 18 19 20 21 22 23 24567
A :
B :
1234 5678910 11 12 13 14 15 16 17 18 19 20
F2

EN(H4DOTC)-58
ENGINE (DIAGNOSTIC)
Malfunction Indicator Light
Step Check Yes No
1 CHECK TEST MODE CONNECTOR.
1) Disconnect the test mode connectors
2) Turn the ignition switch to ON.Does the malfunction indicator
light blink?Go to step 2.System is in good
order.
N
OTE:
Malfunction indica-
tor light blinks at a
cycle of 3 Hz when
test mode connec-
tor is connected.
2 CHECK HARNESS BETWEEN ECM CON-
NECTOR AND ENGINE GROUND TERMI-
NAL.
1) Turn the ignition switch to OFF.
2) Disconnect the connector from ECM.
3) Measure the resistance of harness
between ECM connector and chassis ground.
Connector & terminal
(B137) No. 15 — Chassis ground:Is the resistance less than 5
Ω?Repair the short
circuit in harness
between ECM and
test mode connec-
tor.Replace the ECM.
FU(H4DOTC)-50,
Engine Control
Module (ECM).>

EN(H4DOTC)-59
ENGINE (DIAGNOSTIC)
Diagnostics for Engine Starting Failure
17.Diagnostics for Engine Starting Failure
A: PROCEDURE
1. Inspection of starter motor circuit. Failure.>
↓
2. Inspection of ECM power supply and ground line. OF ENGINE CONTROL MODULE (ECM), Diagnostics for Engine Starting Failure.>
↓
3. Inspection of ignition control system. ing Failure.>
↓
4. Inspection of fuel pump circuit.
↓
5. Inspection of fuel injector circuit. ure.>

EN(H4DOTC)-60
ENGINE (DIAGNOSTIC)
Diagnostics for Engine Starting Failure
B: STARTER MOTOR CIRCUIT
CAUTION:
After repair or replacement of faulty parts, conduct Clear Memory Mode ERATION, Clear Memory Mode.> and Inspection Mode .
WIRING DIAGRAM:
EN-02311
BATTERY
INHIBITOR SWITCH
IGNITION
SWITCH
STARTER
MOTOR
SBF-4SBF-1
B72
B72
B14
B137
ECM
EE
1
3
D8
3412
B137
T3B12MT
AT
AT
MT
1112712
PR
N
D3
21
T7
B12
123
8
9
10
4
11
1256
7
T7
123
8910411 1256
7567
82 1
94 310
22 23 11 12 13 14 15
24 25
2616 17
18 19 20 21
27 28 29 30 31
