Page 1201 of 1632
Fig. 27: Starting System Wiring Diagram (Tacoma -2.4L)
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 46 © 2005 Mitchell Repair Information Company, LLC.
Page 1202 of 1632
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 47 © 2005 Mitchell Repair Information Company, LLC.
Page 1203 of 1632
Fig. 28: Starting System Wiring Diagram (Tacoma -2.7L & 3.4L)
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 48 © 2005 Mitchell Repair Information Company, LLC.
Page 1204 of 1632
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 49 © 2005 Mitchell Repair Information Company, LLC.
Page 1205 of 1632
Fig. 29: Starting System Wiring Diagram (2000 Tundra)
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 50 © 2005 Mitchell Repair Information Company, LLC.
Page 1206 of 1632
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 51 © 2005 Mitchell Repair Information Company, LLC.
Page 1207 of 1632
Fig. 30: Starting System Wiring Diagram (4Runner)
1999 Toyota RAV4
1999-2000 STARTING & CHARGING SYSTEMS Starters
Microsoft
Sunday, November 22, 2009 10:19:19 AMPage 52 © 2005 Mitchell Repair Information Company, LLC.
Page 1208 of 1632

1999-2000 STEERING
Steering Columns - Standard
DESCRIPTION & OPERATION
Steering column is a collapsible 2-piece design. Columns use shear pins to absorb collision impact. Steering
shaft is connected directly to steering gear with either a flexible coupling or "U" joint. Some models have an air
bag integral with the steering wheel pad.
SERVICE PRECAUTIONS
Observe the following precautions when servicing Supplemental Restraint System (SRS):
Disable SRS before servicing any SRS or steering column component. Failure to do this could result in
accidental air bag deployment and possible personal injury. See DISABLING & ACTIVATING AIR
BAG SYSTEM .
Remove air bag sensor assembly/center air bag sensor and front air bag sensors if repairing the vehicle
requires impacting (shocking) the vehicle.
Replace dropped, cracked, dented or otherwise damaged components.
DO NOT expose front air bag sensors, air bag sensor assembly/center air bag sensor or steering wheel
pad (air bag module) directly to heat or flame.
Information labels are attached to air bag components. Follow all notices on labels.
After work on SRS is completed, check air bag warning light to ensure system is functioning properly.
See appropriate AIR BAG RESTRAINT SYSTEMS article in ACCESSORIES & EQUIPMENT.
Always wear safety glasses when servicing or handling an air bag.
When placing a live air bag on a bench or other surface, always face air bag and trim cover upward, away
from surface. This will reduce motion of module if it is accidentally deployed.
Carry a live air bag module with trim cover (air bag) pointed away from your body to minimize injury in
case of accidental deployment.
If SRS is not fully functional for any reason, vehicle should not be driven until system is repaired and
becomes operational. DO NOT remove bulbs, modules, sensors or other components or in any way
disable system from operating normally. If SRS is not functional, park vehicle until it is repaired and
functions properl
y. NOTE: For models with tilt wheel steering columns, see appropriate STEERING
COLUMNS - TILT WHEEL article.
WARNING:To avoid injury from accidental air bag deployment, read and carefully
follow all SERVICE PRECAUTIONS. Deactivate air bag system before
performing any repairs. See DISABLING & ACTIVATING AIR BAG
SYSTEM .
1999 Toyota RAV4
1999-2000 STEERING Steering Columns - Standard
1999 Toyota RAV4
1999-2000 STEERING Steering Columns - Standard
Microsoft
Sunday, November 22, 2009 10:34:51 AMPage 1 © 2005 Mitchell Repair Information Company, LLC.
Microsoft
Sunday, November 22, 2009 10:34:55 AMPage 1 © 2005 Mitchell Repair Information Company, LLC.
Page 1209 of 1632

DISABLING & ACTIVATING AIR BAG SYSTEM
DISABLING SYSTEM
Turn ignition switch to LOCK position. Disconnect and shield negative battery cable. Wait at least 90 seconds
before working on system. Remove steering wheel pad (air bag module). See STEERING WHEEL & AIR
BAG under REMOVAL & INSTALLATION.
ACTIVATING SYSTEM
Install steering wheel pad. Reconnect negative battery cable. Perform system operation check. See appropriate
AIR BAG RESTRAINT SYSTEMS article in ACCESSORIES & EQUIPMENT.
ADJUSTMENTS
SPIRAL CABLE
On vehicles equipped with air bag system, spiral cable must be correctly adjusted to ensure proper air bag
operation. Ensure front wheels are in straight-ahead position. Turn spiral cable (located on combination switch)
counterclockwise by hand until it becomes difficult to turn. Turn spiral cable clockwise about 2.5 turns and
ensure marks ali
gn. See Fig. 1 . WARNING:Back-up power supply maintains SRS voltage for about 90 seconds after
battery is disconnected. After disabling SRS, wait at least 90 seconds
before servicing SRS to prevent accidental air bag deployment and
possible personal injury.
1999 Toyota RAV4
1999-2000 STEERING Steering Columns - Standard
Microsoft
Sunday, November 22, 2009 10:34:51 AMPage 2 © 2005 Mitchell Repair Information Company, LLC.
Page 1210 of 1632
Fig. 1: Adjusting Air Bag Spiral Cable (Typical)
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
REMOVAL & INSTALLATION
STEERING WHEEL & AIR BAG
Removal
1. Ensure front wheels are in straight-ahead position. Turn ignition switch to LOCK position. Disconnect
WARNING:Failure to follow air bag service precautions may result in air bag
deployment and personal injury. See SERVICE PRECAUTIONS
. After
component replacement, perform a system operational check to ensure
proper system operation. See appropriate AIR BAG RESTRAINT
SYSTEMS article in ACCESSORIES & EQUIPMENT.
NOTE: See DISABLING & ACTIVATING AIR BAG SYSTEM
.
1999 Toyota RAV4
1999-2000 STEERING Steering Columns - Standard
Microsoft
Sunday, November 22, 2009 10:34:51 AMPage 3 © 2005 Mitchell Repair Information Company, LLC.
