INDEX FOR DTC
Revision: 2006 January2006 M35/M45
P0456 0456 EVAP VERY SML LEAKEC-466
P0460 0460 FUEL LEV SEN SLOSHEC-475
P0461 0461 FUEL LEVEL SENSOREC-477
P0462 0462 FUEL LEVL SEN/CIRCEC-479
P0463 0463 FUEL LEVL SEN/CIRCEC-479
P0500 0500
VEH SPEED SEN/CIRC*5EC-481
P0506 0506 ISC SYSTEMEC-483
P0507 0507 ISC SYSTEMEC-485
P0550 0550 PW ST P SEN/CIRCEC-487
P0603 0603 ECM BACK UP/CIRCUITEC-492
P0605 0605 ECMEC-496
P0643 0643 SENSOR POWER/CIRCEC-499
P0700 0700 TCMAT- 11 2
P0705 0705 PNP SW/CIRCAT- 11 3
P0710 0710 ATF TEMP SEN/CIRCAT-135
P0717 0717 TURBINE SENSORAT- 11 7
P0720 0720
VEH SPD SEN/CIR AT*5AT- 11 9
P0725 0725 ENGINE SPEED SIGAT-124
P0740 0740 TCC SOLENOID/CIRCAT-126
P0744 0744 A/T TCC S/V FNCTNAT-128
P0745 0745 L/PRESS SOL/CIRCAT-130
P0850 0850 P-N POS SW/CIRCUITEC-504
P1148 1148 CLOSED LOOP-B1EC-509
P1168 1168 CLOSED LOOP-B2EC-509
P1211 1211 TCS C/U FUNCTNEC-510
P1212 1212 TCS/CIRCEC-511
P1217 1217 ENG OVER TEMPEC-512
P1220 1220 FPCM/CIRCUITEC-525
P1225 1225 CTP LEARNINGEC-533
P1226 1226 CTP LEARNINGEC-535
P1550 1550 BAT CURRENT SENSOREC-537
P1551 1551 BAT CURRENT SENSOREC-543
P1552 1552 BAT CURRENT SENSOREC-543
P1553 1553 BAT CURRENT SENSOREC-549
P1554 1554 BAT CURRENT SENSOREC-555
P1564 1564 ASCD SWEC-561 (Models with ICC)
EC-568
(Models with ASCD)
P1568 1568
ICC COMMAND VALUE*
6EC-575
P1572 1572 ASCD BRAKE SWEC-576 (Models with ICC)
EC-585
(Models with ASCD)
P1574 1574 ASCD VHL SPD SENEC-593
(Models with ICC)
EC-595
(Models with ASCD)
P1610 - P1615 1610 - 1615 NATS MALFUNCTIONEC-53
DTC*1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC
EC-19
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 January2006 M35/M45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur at the same time, the MIL illuminates.
*6: Models with ICC.P1705 1705 TP SEN/CIRC A/TAT-132
P1715 1715 IN PULY SPEEDEC-597
P1730 1730 A/T INTERLOCKAT-142
P1752 1752 I/C SOLENOID/CIRCAT-147
P1754 1754 I/C SOLENOID FNCTNAT-149
P1757 1757 FR/B SOLENOID/CIRCAT-151
P1759 1759 FR/B SOLENOID FNCTAT-153
P1762 1762 D/C SOLENOID/CIRCAT-155
P1764 1764 D/C SOLENOID FNCTNAT-157
P1767 1767 HLR/C SOL/CIRCAT-159
P1769 1769 HLR/C SOL FNCTNAT-161
P1772 1772 LC/B SOLENOID/CIRCAT-163
P1774 1774 LC/B SOLENOID FNCTAT-165
P1805 1805 BRAKE SW/CIRCUITEC-598
P2100 2100 ETC MOT PWREC-607
P2101 2101 ETC FUNCTION/CIRCEC-613
P2103 2103 ETC MOT PWREC-607
P 2 11 8 2 11 8 E T C M O TEC-619
P 2 11 9 2 11 9 E T C A C T REC-624
P2122 2122 APP SEN 1/CIRCEC-626
P2123 2123 APP SEN 1/CIRCEC-626
P2127 2127 APP SEN 2/CIRCEC-633
P2128 2128 APP SEN 2/CIRCEC-633
P2135 2135 TP SENSOREC-640
P2138 2138 APP SENSOREC-647
P2A00 2A00 A/F SENSOR1 (B1)EC-655
P2A03 2A03 A/F SENSOR1 (B2)EC-655
DTC*1
Items
(CONSULT-II screen terms)Reference page
CONSULT-II
GST*
2ECM*3

EC-20
[VQ35DE]
INDEX FOR DTC
Revision: 2006 January2006 M35/M45
Alphabetical IndexNBS004RV
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-173, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
If DTC U1010 is displayed with other DTC, first perform the trouble diagnosis for DTC U1010. Refer
to EC-176, "
DTC U1010 CAN COMMUNICATION" .
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3
A/F SEN1 HTR (B1) P0031 0031EC-182
A/F SEN1 HTR (B1) P0032 0032EC-182
A/F SEN1 HTR (B2) P0051 0051EC-182
A/F SEN1 HTR (B2) P0052 0052EC-182
A/F SENSOR1 (B1) P0130 0130EC-246
A/F SENSOR1 (B1) P0131 0131EC-256
A/F SENSOR1 (B1) P0132 0132EC-265
A/F SENSOR1 (B1) P0133 0133EC-274
A/F SENSOR1 (B1) P2A00 2A00EC-655
A/F SENSOR1 (B2) P0150 0150EC-246
A/F SENSOR1 (B2) P0151 0151EC-256
A/F SENSOR1 (B2) P0152 0152EC-265
A/F SENSOR1 (B2) P0153 0153EC-274
A/F SENSOR1 (B2) P2A03 2A03EC-655
A/T INTERLOCK P1730 1730AT-142
A/T TCC S/V FNCTN P0744 0744AT-128
APP SENSOR P2138 2138EC-647
APP SEN 1/CIRC P2122 2122EC-626
APP SEN 1/CIRC P2123 2123EC-626
APP SEN 2/CIRC P2127 2127EC-633
APP SEN 2/CIRC P2128 2128EC-633
ASCD BRAKE SW P1572 1572EC-576 (Models with ICC)
EC-585
(Models with ASCD)
ASCD SW P1564 1564EC-561
(Models with ICC)
EC-568
(Models with ASCD)
ASCD VHL SPD SEN P1574 1574EC-593
(Models with ICC)
EC-595
(Models with ASCD)
ATF TEMP SEN/CIRC P0710 0710AT-135
BAT CURRENT SENSOR P1550 1550EC-537
BAT CURRENT SENSOR P1551 1551EC-543
BAT CURRENT SENSOR P1552 1552EC-543
BAT CURRENT SENSOR P1553 1553EC-549
BAT CURRENT SENSOR P1554 1554EC-555
BRAKE SW/CIRCUIT P1805 1805EC-598
CAN COMM CIRCUIT U1000
1000*4EC-173
CAN COMM CIRCUIT U1001
1001*4EC-173
CKP SEN/CIRCUIT P0335 0335EC-376
CLOSED LOOP-B1 P1148 1148EC-509

INDEX FOR DTC
EC-21
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 January2006 M35/M45CLOSED LOOP-B2 P1168 1168EC-509
CMP SEN/CIRC-B1 P0340 0340EC-383
CMP SEN/CIRC-B2 P0345 0345EC-383
CONTROL UNIT(CAN)
U1010*41010EC-176
CTP LEARNING P1225 1225EC-533
CTP LEARNING P1226 1226EC-535
CYL 1 MISFIRE P0301 0301EC-361
CYL 2 MISFIRE P0302 0302EC-361
CYL 3 MISFIRE P0303 0303EC-361
CYL 4 MISFIRE P0304 0304EC-361
CYL 5 MISFIRE P0305 0305EC-361
CYL 6 MISFIRE P0306 0306EC-361
D/C SOLENOID/CIRC P1762 1762AT-155
D/C SOLENOID FNCTN P1764 1764AT-157
ECM P0605 0605EC-496
ECM BACK UP/CIRCUIT P0603 0603EC-492
ECT SEN/CIRC P0117 0117EC-226
ECT SEN/CIRC P0118 0118EC-226
ECT SENSOR P0125 0125EC-238
ENG OVER TEMP P1217 1217EC-512
ENGINE SPEED SIG P0725 0725AT-124
ETC ACTR P2119 2119EC-624
ETC FUNCTION/CIRC P2101 2101EC-613
ETC MOT P2118 2118EC-619
ETC MOT PWR P2100 2100EC-607
ETC MOT PWR P2103 2103EC-607
EVAP GROSS LEAK P0455 0455EC-458
EVAP PURG FLOW/MON P0441 0441EC-398
EVAP SMALL LEAK P0442 0442EC-403
EVAP SYS PRES SEN P0451 0451EC-440
EVAP SYS PRES SEN P0452 0452EC-443
EVAP SYS PRES SEN P0453 0453EC-450
EVAP VERY SML LEAK P0456 0456EC-466
FPCM/CIRCUIT P1220 1220EC-525
FR/B SOLENOID/CIRC P1757 1757AT-151
FR/B SOLENOID FNCT P1759 1759AT-153
FTT SEN/CIRCUIT P0182 0182EC-349
FTT SEN/CIRCUIT P0183 0183EC-349
FTT SENSOR P0181 0181EC-343
FUEL LEVEL SENSOR P0461 0461EC-477
FUEL LEVL SEN/CIRC P0462 0462EC-479
FUEL LEVL SEN/CIRC P0463 0463EC-479
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

EC-22
[VQ35DE]
INDEX FOR DTC
Revision: 2006 January2006 M35/M45
FUEL LEV SEN SLOSH P0460 0460EC-475
FUEL SYS-LEAN-B1 P0171 0171EC-321
FUEL SYS-LEAN-B2 P0174 0174EC-321
FUEL SYS-RICH-B1 P0172 0172EC-332
FUEL SYS-RICH-B2 P0175 0175EC-332
HLR/C SOL/CIRC P1767 1767AT-159
HLR/C SOL FNCTN P1769 1769AT-161
HO2S2 HTR (B1) P0037 0037EC-189
HO2S2 HTR (B1) P0038 0038EC-189
HO2S2 HTR (B2) P0057 0057EC-189
HO2S2 HTR (B2) P0058 0058EC-189
HO2S2 (B1) P0137 0137EC-286
HO2S2 (B1) P0138 0138EC-297
HO2S2 (B1) P0139 0139EC-310
HO2S2 (B2) P0157 0157EC-286
HO2S2 (B2) P0158 0158EC-297
HO2S2 (B2) P0159 0159EC-310
I/C SOLENOID/CIRC P1752 1752AT-147
I/C SOLENOID FNCTN P1754 1754AT-149
IAT SEN/CIRCUIT P0112 0112EC-221
IAT SEN/CIRCUIT P0113 0113EC-221
IAT SENSOR P0127 0127EC-241
ICC COMMAND VALUE*6P1568 1568EC-575
INT/V TIM CONT-B1 P0011 0011EC-178
INT/V TIM CONT-B2 P0021 0021EC-178
INT/V TIM V/CIR-B1 P0075 0075EC-197
INT/V TIM V/CIR-B2 P0081 0081EC-197
IN PULY SPEED P1715 1715EC-597
ISC SYSTEM P0506 0506EC-483
ISC SYSTEM P0507 0507EC-485
KNOCK SEN/CIRC-B1 P0327 0327EC-371
KNOCK SEN/CIRC-B1 P0328 0328EC-371
L/PRESS SOL/CIRC P0745 0745AT-130
LC/B SOLENOID/CIRC P1772 1772AT-163
LC/B SOLENOID FNCT P1774 1774AT-165
MAF SEN/CIRCUIT P0101 0101EC-205
MAF SEN/CIRCUIT P0102 0102EC-214
MAF SEN/CIRCUIT P0103 0103EC-214
MULTI CYL MISFIRE P0300 0300EC-361
NATS MALFUNCTION P1610 - P1615 1610 - 1615EC-53
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000 — Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

INDEX FOR DTC
EC-23
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 January2006 M35/M45
*1: 1st trip DTC No. is the same as DTC No.
*2: This number is prescribed by SAE J2012.
*3: In Diagnostic Test Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-II.
*5: When the fail-safe operations for both self-diagnoses occur at the same time, the MIL illuminates.
*6: Models with ICC.P-N POS SW/CIRCUIT P0850 0850EC-504
PNP SW/CIRC P0705 0705AT- 11 3
PURG VOLUME CONT/V P0443 0443EC-412
PURG VOLUME CONT/V P0444 0444EC-420
PURG VOLUME CONT/V P0445 0445EC-420
PW ST P SEN/CIRC P0550 0550EC-487
SENSOR POWER/CIRC P0643 0643EC-499
TCC SOLENOID/CIRC P0740 0740AT-126
TCM P0700 0700AT- 11 2
TCS/CIRC P1212 1212EC-511
TCS C/U FUNCTN P1211 1211EC-510
THERMSTAT FNCTN P0128 0128EC-244
TP SENSOR P2135 2135EC-640
TP SEN 1/CIRC P0222 0222EC-354
TP SEN 1/CIRC P0223 0223EC-354
TP SEN 2/CIRC P0122 0122EC-231
TP SEN 2/CIRC P0123 0123EC-231
TP SEN/CIRC A/T P1705 1705AT-132
TURBINE SENSOR P0717 0717AT- 11 7
TW CATALYST SYS-B1 P0420 0420EC-392
TW CATALYST SYS-B2 P0430 0430EC-392
VEH SPD SEN/CIR AT*5P0720 0720AT- 11 9
VEH SPEED SEN/CIRC*5P0500 0500EC-481
VENT CONTROL VALVE P0447 0447EC-427
VENT CONTROL VALVE P0448 0448EC-434
Items
(CONSULT-II screen terms)DTC*
1
Reference page
CONSULT-II
GST*
2ECM*3

EC-24
[VQ35DE]
PRECAUTIONS
Revision: 2006 January2006 M35/M45
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
NBS004RW
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NING :
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Procedures without Cowl Top CoverNBS004RX
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
On Board Diagnostic (OBD) System of Engine and A/TNBS004RY
The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the
driver of a malfunction causing emission deterioration.
CAUTION:
Be sure to turn the ignition switch OFF and disconnect the negative battery cable before any
repair or inspection work. The open/short circuit of related switches, sensors, solenoid valves,
etc. will cause the MIL to light up.
Be sure to connect and lock the connectors securely after work. A loose (unlocked) connector will
cause the MIL to light up due to the open circuit. (Be sure the connector is free from water, grease,
dirt, bent terminals, etc.)
Certain systems and components, especially those related to OBD, may use a new style slide-
locking type harness connector. For description and how to disconnect, refer to PG-102, "
HAR-
NESS CONNECTOR" .
Be sure to route and secure the harnesses properly after work. The interference of the harness
with a bracket, etc. may cause the MIL to light up due to the short circuit.
Be sure to connect rubber tubes properly after work. A misconnected or disconnected rubber tube
may cause the MIL to light up due to the malfunction of the EVAP system or fuel injection system,
etc.
Be sure to erase the unnecessary malfunction information (repairs completed) from the ECM and
TCM (Transmission control module) before returning the vehicle to the customer.
PIIB3706J

PRECAUTIONS
EC-25
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 January2006 M35/M45
PrecautionNBS004RZ
Always use a 12 volt battery as power source.
Do not attempt to disconnect battery cables while engine is
running.
Before connecting or disconnecting the ECM harness con-
nector, turn ignition switch OFF and disconnect negative
battery cable. Failure to do so may damage the ECM
because battery voltage is applied to ECM even if ignition
switch is turned OFF.
Before removing parts, turn ignition switch OFF and then
disconnect battery ground cable.
Do not disassemble ECM.
If a battery cable is disconnected, the memory will return to
the ECM value.
The ECM will now start to self-control at its initial value.
Engine operation can vary slightly when the terminal is dis-
connected. However, this is not an indication of a malfunc-
tion. Do not replace parts because of a slight variation.
If the battery is disconnected, the following emission-
related diagnostic information will be lost within 24 hours.
–Diagnostic trouble codes
–1st trip diagnostic trouble codes
–Freeze frame data
–1st trip freeze frame data
–System readiness test (SRT) codes
–Te s t v a l u e s
When connecting ECM harness connector, fasten (B) it
securely with a lever (2) as far as it will go as shown in the
figure.
–ECM (1)
–Loosen (A)
When connecting or disconnecting pin connectors into or
from ECM, take care not to damage pin terminals (bend or
break).
Make sure that there are not any bends or breaks on ECM
pin terminal, when connecting pin connectors.
Securely connect ECM harness connectors.
A poor connection can cause an extremely high (surge)
voltage to develop in coil and condenser, thus resulting in
damage to ICs.
Keep engine control system harness at least 10 cm (4 in)
away from adjacent harness, to prevent engine control sys-
tem malfunctions due to receiving external noise, degraded
operation of ICs, etc.
Keep engine control system parts and harness dry.
SEF289H
PBIB1164E
PBIB2714E
PBIB0090E

EC-26
[VQ35DE]
PRECAUTIONS
Revision: 2006 January2006 M35/M45
Before replacing ECM, perform ECM Terminals and Refer-
ence Value inspection and make sure ECM functions prop-
erly. Refer to EC-124, "
ECM Harness Connector Terminal
Layout" .
Handle mass air flow sensor carefully to avoid damage.
Do not clean mass air flow sensor with any type of deter-
gent.
Do not disassemble electric throttle control actuator.
Even a slight leak in the air intake system can cause seri-
ous incidents.
Do not shock or jar the camshaft position sensor (PHASE),
crankshaft position sensor (POS).
After performing each TROUBLE DIAGNOSIS, perform DTC
Confirmation Procedure or Overall Function Check.
The DTC should not be displayed in the DTC Confirmation
Procedure if the repair is completed. The Overall Function
Check should be a good result if the repair is completed.
When measuring ECM signals with a circuit tester, never
allow the two tester probes to contact.
Accidental contact of probes will cause a short circuit and
damage the ECM power transistor.
Do not use ECM ground terminals when measuring input/
output voltage. Doing so may result in damage to the ECM's
transistor. Use a ground other than ECM terminals, such as
the ground.
MEF040D
SEF217U
SEF348N

PRECAUTIONS
EC-27
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 January2006 M35/M45
B1 indicates the bank 1, B2 indicates the bank 2 as shown
in the figure.
Do not operate fuel pump when there is no fuel in lines.
–Fuel level sensor unit and fuel pump (1)
–Fuel pressure regulator (2)
–Fuel tank temperature sensor (3)
Tighten fuel hose clamps to the specified torque.
Do not depress accelerator pedal when starting.
Immediately after starting, do not rev up engine unneces-
sarily.
Do not rev up engine just prior to shutdown.
When installing C.B. ham radio or a mobile phone, be sure
to observe the following as it may adversely affect elec-
tronic control systems depending on installation location.
–Keep the antenna as far as possible from the electronic
control units.
–Keep the antenna feeder line more than 20 cm (8 in) away
from the harness of electronic controls.
Do not let them run parallel for a long distance.
–Adjust the antenna and feeder line so that the standing-
wave radio can be kept smaller.
–Be sure to ground the radio to vehicle body.
SEC893C
PBIB2707E
SEF709Y
SEF708Y
