INFINITI QX56 2009 Factory Service Manual

THIRD SEATSE-59
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
7. Remove the seat hinge rear bolt (A) and seat belt buckle bolt (B) from the seat assembly.
CAUTION:
Discard the seat belt buckle bolt and use a new bolt for
installation.
8. Disconnect the seat harness.
9. Remove the seat assembly.
INSTALLATION
Installation is in the reverse order of removal.
Power seat cross beamINFOID:0000000003775480
REMOVAL
1. Remove the lower seat mount bolts.
2. Fold the seat cushion up.
3. Remove the harness connectors from the seat control unit.
4. Press the front release tab and remove the seat crontrol unit.
LIIA2325E
ALIIA0096GB
ALIIA0097ZZ
ALIIA0098ZZ
Revision: December 20092009 QX56

SE-60
< ON-VEHICLE REPAIR >
THIRD SEAT
5. Remove the two screws from the power seat motor coverassembly.
6. Disconnect the wiring harness from the power seat motor cover clips (A).
7. Remove the power seat motor cover.
8. Release the power motor cross-beam clip and open the hinged strap.
9. Remove the power motor cross-beam screws.
ALIIA0099ZZ
ALIIA0100ZZ
ALIIA0101ZZ
ALIIA0103ZZ
Revision: December 20092009 QX56

THIRD SEATSE-61
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
10. Remove the power motor cross-beam. NOTE:
The cable and conduit will be removed with the cross-beam.
11. Remove the cable and conduit from the cross-beam retainers.
Installation
1. Install the cable into the drive motor and slide the conduit on the motor ferrule.
•⇐ : Vehicle front
2. Install the cable (A) into the RH seat motor. •⇐ : Vehicle front
3. Install the power motor cross-beam right side screws
ALIIA0102ZZ
ALIIA0104ZZ
ALIIA0105ZZ
ALIIA0103ZZ
Revision: December 20092009 QX56

SE-62
< ON-VEHICLE REPAIR >
THIRD SEAT
4. Starting at the right side, snap the cable and conduit into thepower seat cross-beam retainers.
5. Snap the hinged strap retainer around the motor assembly.
6. Replace the power seat motor cover.
7. Install the seat harness to the power seat motor cover clips (A).
8. Install the seat control unit and connect the seat control unit har- ness connectors.
ALIIA0106ZZ
ALIIA0107ZZ
ALIIA0099ZZ
ALIIA0100ZZ
ALIIA0097ZZ
Revision: December 20092009 QX56

THIRD SEATSE-63
< ON-VEHICLE REPAIR >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
9. Install the lower seat mount bolts.
RH Side SeatINFOID:0000000003775481
REMOVAL
1. Remove the storage bin. Refer to INT-19, "Removal and Installation".
2. Remove the lower base trim covers.
3. Remove front link nuts (A) and RH hinge front bolt (B).
4. Remove push pin (2) and release elastic band (3) from seat frame (1).
•⇐ : Vehicle front
5. Partially lift seatback upright, then remove seat belt buckle (2) from between hinge cover (1) and seat cushion side facing (3).
•⇐ : Vehicle front
6. Retract the seat into the cargo floor position.
ALIIA0096GB
LIIA2326E
LHIA0105E
LHIA0106E
Revision: December 20092009 QX56

SE-64
< ON-VEHICLE REPAIR >
THIRD SEAT
7. Remove the rear bolts from the seat assembly.
8. Disconnect the seat harness.
9. Remove the seat assembly.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2327E
Revision: December 20092009 QX56

FRONT SEATSE-65
< DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
DISASSEMBLY AND ASSEMBLY
FRONT SEAT
Exploded ViewINFOID:0000000003775482
Driver Seat
LIIA1578E
Revision: December 20092009 QX56

SE-66
< DISASSEMBLY AND ASSEMBLY >
FRONT SEAT
1. Headrest2. Headrest holder with multi-position
lock 3. Seatback assembly
4. Lumbar switch bezel 5. Power seat switch escutcheon 6. Recliner switch knob
7. Slide switch knob 8. Driver power seat frame assembly 9. Inner leg cover
10. Driver seat wiring harness 11. Bolt cover 12. Seat cushion outer finisher
13. Outer pedestal finisher 14. Seat cushion front finisher15. Seat cushion inner finisher
16. Seat cushion frame 17. Seat cushion heating element 18. Seat cushion pad
19. Seat cushion trim cover 20. Armrest assembly21. Headrest holder
22. Seat slide/ recline switch 23. Power lumbar switch
Revision: December 20092009 QX56

FRONT SEATSE-67
< DISASSEMBLY AND ASSEMBLY >
C
DE
F
G H
I
K L
M A
B
SE
N
O P
Passenger Seat
WIIA0476E
1. Headrest 2. Headrest holder with multi-position
lock 3. Seatback board
4. Armrest assembly 5. Lumbar switch bezel6. Fold flat link bar
7. Outboard reclining arm outer cover 8. Outboard reclining arm inner cover 9. Inboard reclining arm inner cover
10. Latch cover 11. Inner leg cover12. Outboard reclining arm inner cover
13. Seat cushion inner cover 14. Passenger seat wiring harness 15. Inner front leg cover
16. Power seat frame assembly 17. NVH assembly 18. Seat cushion front finisher
Revision: December 20092009 QX56

SE-68
< DISASSEMBLY AND ASSEMBLY >
FRONT SEAT
Disassembly and Assembly
INFOID:0000000003775483
SEATBACK TRIM AND PAD
WARNING:
Removal of front side air bag module should only be done to allow deployment of front side air bag
module prior to disposal of seatback assembly.
NOTE:
Only complete seatback assemblies can be replaced on vehicles equipped with side air bags.
Be sure to set the front/rear cushion lifter to the top position.
Driver Seat
1. Remove the headrest.
2. Unhook the j-channel.
3. From inside of the seatback, squeeze the headrest holder tabs at the base of the stay pipe and pull up to remove.
NOTE:
Before installing the headrest holder, check its orientation (front/
rear and right/left).
Passenger Seat
1. Remove the headrest.
2. Remove the seatback board from the back of the seatback.
19. Outer pedestal finisher 20. Seat cushion outer finisher21. Seat cushion assembly
22. Power seat switch escutcheon 23. Slide switch knob 24. Recliner switch knob
25. Seatback assembly 26. Headrest holder27. Seat slide/ recline switch
28. Power lumbar switch
LIIA1580E
LRS023
PIIA0163E
