INFINITI QX56 2011 Factory Service Manual

P0733 3GR INCORRECT RATIOTM-123
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from “OUT OF
CONDITION” to “TESTING”.
CAUTION:
When “TESTING” is not indicated on CONSULT-III for a long time, check “Self Diagnostic Results”
in “TRANSMISSION”. When a DTC other than “P0733” is detected, check the DTC. Refer to TM-78,
"DTC Index".
With GST
1. Drive vehicle and maintain the following conditions for 2 seconds or more.
2. Check DTC.
Is
“OUT OF CONDITION”, “STOP VEHICLE” or “COMPLETED RESULT NG” displayed? / Is “P0733”
detected?
YES-1 (OUT OF CONDITION) >>Perform “Step 3” again.
YES-2 (STOP VEHICLE)>>GO TO 4.
YES-3 (COMPLETED RESULT NG)>>Go to TM-123, "
Diagnosis Procedure".
YES-4 (“P0733” is detected)>>Go to TM-123, "
Diagnosis Procedure".
NO >> GO TO 4.
4.CHECK SYMPTOM (PART 2)
1. Stop vehicle.
2. Drive vehicle in “D” position allowing it to shift from 1GR to 7GR and check shift timing and shift shock.
>> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226829
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-122,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
GEAR : 3rd
ACCELE POSI : 0.7/8 or more
VEHICLE SPEED : 10 km/h (7 MPH) or more
Selector lever : “M” position
Gear position : 3rd
Accelerator pedal opening : 0.7/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56

TM-124
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0734 4GR INCORRECT RATIO
P0734 4GR INCORRECT RATIO
DescriptionINFOID:0000000006226830
This malfunction is detected when the A/T does not shift
into 4GR position as instructed by TCM. This is not
only caused by electrical malfunction (circuits open or s horted) but by mechanical malfunction such as control
valve sticking, improper solenoid valve operation, etc.
DTC LogicINFOID:0000000006226831
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
“ TM-125, "
Diagnosis Procedure"” must be performed before star ting “DTC CONFIRMATION PROCE-
DURE”.
 Never perform “DTC CONFIRMATION PROCEDURE” before completing the repair, which may cause secondary malfunction.
 Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK ATF TEMPERATURE
With CONSULT-III
1. Start the engine.
2. Select “ATF TEMP 1” in “Data Monitor” in “TRANSMISSION”.
3. Check ATF temperature is in the following range.
With GST
1. Start the engine.
2. Drive vehicle for approximately 5 minutes in urban areas.
Is ATF temperature within specified range?
YES >> GO TO 3.
NO >> Drive vehicle to warm ATF or stop engine to cool ATF.
3.CHECK SYMPTOM (PART 1)
With CONSULT-III
1. Select “4TH GR FNCTN P0734” in “DTC & SRT confirmation” in “TRANSMISSION”.
2. Drive vehicle with manual mode and maintain the following conditions.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0734 Gear 4 Incorrect Ratio The gear ratio is:
 1.496 or more
 1.328 or less Input clutch solenoid valve
 Direct clutch solenoid valve
 High and low reverse clutch
solenoid valve
 Front brake solenoid valve
 Low brake solenoid valve
 2346 brake solenoid valve
 Anti-interlock solenoid valve
 Each clutch and brake
 Output speed sensor
 Input speed sensor 1, 2
 Hydraulic co ntrol circuit
ATF TEMP 1 : 20 °C (68 °F) – 140 °C (284 °F)
Revision: 2010 May2011 QX56

P0734 4GR INCORRECT RATIOTM-125
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from “OUT OF
CONDITION” to “TESTING”.
CAUTION:
When “TESTING” is not indicated on CONSULT-III for a long time, check “Self Diagnostic Results”
in “TRANSMISSION”. When a DTC other than “P0734” is detected, check the DTC. Refer to TM-78,
"DTC Index".
With GST
1. Drive vehicle and maintain the following conditions for 2 seconds or more.
2. Check DTC.
Is
“OUT OF CONDITION”, “STOP VEHICLE” or “COMPLETED RESULT NG” displayed? / Is “P0734”
detected?
YES-1 (OUT OF CONDITION) >>Perform “Step 3” again.
YES-2 (STOP VEHICLE)>>GO TO 4.
YES-3 (COMPLETED RESULT NG)>>Go to TM-125, "
Diagnosis Procedure".
YES-4 (“P0734” is detected)>>Go to TM-125, "
Diagnosis Procedure".
NO >> GO TO 4.
4.CHECK SYMPTOM (PART 2)
1. Stop vehicle.
2. Drive vehicle in “D” position allowing it to shift from 1GR to 7GR and check shift timing and shift shock.
>> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226832
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-124,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the transmission case and control valve & TCM. Refer to TM-211, "Exploded View".
NO >> Repair or replace damaged parts.
GEAR : 4th
ACCELE POSI : 0.7/8 or more
VEHICLE SPEED : 10 km/h (7 MPH) or more
Selector lever : “M” position
Gear position : 4th
Accelerator pedal opening : 0.7/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56

TM-126
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0735 5GR INCORRECT RATIO
P0735 5GR INCORRECT RATIO
DescriptionINFOID:0000000006226833
This malfunction is detected when the A/T does not shift
into 5GR position as instructed by TCM. This is not
only caused by electrical malfunction (circuits open or s horted) but by mechanical malfunction such as control
valve sticking, improper solenoid valve operation, etc.
DTC LogicINFOID:0000000006226834
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
“ TM-127, "
Diagnosis Procedure"” must be performed before star ting “DTC CONFIRMATION PROCE-
DURE”.
 Never perform “DTC CONFIRMATION PROCEDURE” before completing the repair, which may cause secondary malfunction.
 Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK ATF TEMPERATURE
With CONSULT-III
1. Start the engine.
2. Select “ATF TEMP 1” in “Data Monitor” in “TRANSMISSION”.
3. Check ATF temperature is in the following range.
With GST
1. Start the engine.
2. Drive vehicle for approximately 5 minutes in urban areas.
Is ATF temperature within specified range?
YES >> GO TO 3.
NO >> Drive vehicle to warm ATF or stop engine to cool ATF.
3.CHECK SYMPTOM (PART 1)
With CONSULT-III
1. Select “5TH GR FNCTN P0735” in “DTC & SRT confirmation” in “TRANSMISSION”.
2. Drive vehicle with manual mode and maintain the following conditions.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0735 Gear 5 Incorrect Circuit The gear ratio is:
 1.060 or more
 0.940 or less Input clutch solenoid valve
 Direct clutch solenoid valve
 High and low reverse clutch
solenoid valve
 Front brake solenoid valve
 Low brake solenoid valve
 2346 brake solenoid valve
 Anti-interlock solenoid valve
 Each clutch and brake
 Output speed sensor
 Input speed sensor 1, 2
 Hydraulic co ntrol circuit
ATF TEMP 1 : 20 °C (68 °F) – 140 °C (284 °F)
Revision: 2010 May2011 QX56

P0735 5GR INCORRECT RATIOTM-127
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
3. Keep the current driving status for 2 seconds or more if CONSULT-III screen changes from “OUT OF
CONDITION” to “TESTING”.
CAUTION:
When “TESTING” is not indicated on CONSULT-III for a long time, check “Self Diagnostic Results”
in “TRANSMISSION”. When a DTC other than “P0735” is detected, check the DTC. Refer to TM-78,
"DTC Index".
With GST
1. Drive vehicle and maintain the following conditions for 2 seconds or more.
2. Check DTC.
Is
“OUT OF CONDITION”, “STOP VEHICLE” or “COMPLETED RESULT NG” displayed? / Is “P0735”
detected?
YES-1 (OUT OF CONDITION) >>Perform “Step 3” again.
YES-2 (STOP VEHICLE)>>GO TO 4.
YES-3 (COMPLETED RESULT NG)>>Go to TM-127, "
Diagnosis Procedure".
YES-4 (“P0735” is detected)>>Go to TM-127, "
Diagnosis Procedure".
NO >> GO TO 4.
4.CHECK SYMPTOM (PART 2)
1. Stop vehicle.
2. Drive vehicle in “D” position allowing it to shift from 1GR to 7GR and check shift timing and shift shock.
>> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226835
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-126,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
GEAR : 5th
ACCELE POSI : 0.7/8 or more
VEHICLE SPEED : 10 km/h (7 MPH) or more
Selector lever : “M” position
Gear position : 5th
Accelerator pedal opening : 0.7/8 or more
Vehicle speed : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56

TM-128
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0740 TORQUE CONVERTER
P0740 TORQUE CONVERTER
DTC LogicINFOID:0000000006226836
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “MANU MODE SW”, “GEA R” and “VEHICLE SPEED” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 30 seconds or more.
NOTE:
Driving the vehicle uphill (increased engine load) will help maintain the driving conditions required for this
test.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”. With GST
Follow the procedure “With CONSULT-III”.
Is
“P0740” detected?
YES >> Go to TM-128, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226837
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0740 Torque Converter Clutch Cir-
cuit/Open The torque converter clutch so-
lenoid valve monitor value is 0.4
A or less when the torque con-
verter clutch solenoid valve
command value is more than
0.75 A. Harness or connectors
(Solenoid valve circuit is
open or shorted.)
 Torque converter clutch sole- noid valve
MANU MODE SW : ON
GEAR : 2nd
VEHICLE SPEED : 40 km/h (25 MPH) or more
Revision: 2010 May2011 QX56

P0744 TORQUE CONVERTERTM-129
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0744 TORQUE CONVERTER
DescriptionINFOID:0000000006226838
This malfunction is detected when the A/T does not lock-up. This is not only caused by electrical malfunction
(circuits open or shorted) but also by mechanical malfunc tion such as control valve sticking, improper solenoid
valve operation, etc.
DTC LogicINFOID:0000000006226839
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “MANU MODE SW”, “GEAR” and “VEHICLE SPEED” in “Data Monitor” in “TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 10 seconds or more. NOTE:
Driving the vehicle uphill (increased engine load) will hel p maintain the driving conditions required for this
test.
4. Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0744” detected?
YES >> Go to TM-129, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226840
1.DETECT MALFUNCTIONING ITEM
Disassemble the A/T assembly to check component parts. Refer to TM-226, "
Disassembly".
NOTE:
Check the component parts, referring to “Possibl e cause” in “DTC DETECTION LOGIC”. Refer to TM-129,
"DTC Logic".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0744 Torque Converter Clutch Circuit
Intermittent The lock-up is not performed in
spite of within the lock-up area.  Harness or connectors
 Torque converter clutch sole-
noid valve
 Torque converter
 Input speed sensor 1, 2
 Hydraulic control circuit
MANU MODE SW : ON
GEAR : 2nd
VEHICLE SPEED : 40 km/h (25 MPH) or more
Revision: 2010 May2011 QX56

TM-130
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0744 TORQUE CONVERTER
NO >> Repair or replace damaged parts.
Revision: 2010 May2011 QX56

P0745 PRESSURE CONTROL SOLENOID ATM-131
< DTC/CIRCUIT DIAGNOSIS > [7AT: RE7R01B]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
P0745 PRESSURE CONTROL SOLENOID A
DTC LogicINFOID:0000000006226841
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Wait for 5 seconds or more at idle speed in “N” position.
3. Perform “Self Diagnostic Resu lts” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0745” detected?
YES >> Go to TM-131, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226842
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0745 Pressure Control Solenoid A The line pressure solenoid
valve monitor value is 0.4 A or
less when the line pressure so-
lenoid valve command value is
more than 0.75 A. Harness or connectors
(Solenoid valve circuit is
open or shorted.)
 Line pressure solenoid valve
Revision: 2010 May2011 QX56

TM-132
< DTC/CIRCUIT DIAGNOSIS >[7AT: RE7R01B]
P0750 SHIFT SOLENOID A
P0750 SHIFT SOLENOID A
DTC LogicINFOID:0000000006226843
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
CAUTION:
Always drive vehicle at a safe speed.
1.PRECONDITIONING
If “DTC CONFIRMATION PROCEDURE” is previously c onducted, always turn ignition switch OFF and wait at
least 10 seconds before performing the next test.
>> GO TO 2.
2.CHECK DTC DETECTION
With CONSULT-III
1. Start the engine.
2. Select “BATTERY VOLT”, “MANU MODE SW”, “G EAR” and “VHCL/S SE-A/T” in “Data Monitor” in
“TRANSMISSION”.
3. Drive vehicle and maintain the following conditions for 5 seconds or more.
4. Perform “Self Diagnostic Results” in “TRANSMISSION”.
With GST
Follow the procedure “With CONSULT-III”.
Is
“P0750” detected?
YES >> Go to TM-132, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000006226844
1.CHECK INTERMITTENT INCIDENT
Refer to GI-40, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace the control valve & TCM. Refer to TM-182, "Exploded View".
NO >> Repair or replace damaged parts.
DTC Trouble diagnosis name DTC is detected if... Possible cause
P0750 Shift Solenoid A  The anti-interlock solenoid
valve monitor value is ON
when the anti-interlock sole-
noid valve command value is
OFF.
 The anti-interlock solenoid valve monitor value is OFF
when the anti-interlock sole-
noid valve command value is
ON.  Harness or connectors
(Solenoid valve circuit is
open or shorted.)
 Anti-interlock solenoid valve
BATTERY VOLT : 9 V or more
MANU MODE SW : ON
GEAR : 1st
VHCL/S SE-A/T : 10 km/h (7 MPH) or more
Revision: 2010 May2011 QX56
