INFINITI QX56 2011 Factory Service Manual

BRM-36
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
View A: Before installing outer sill
View B: Before installing outer sill and front pillar brace
1. Urethane foam
Unit: mm (in): Vehicle front
Replacement parts z Outer sill (LH) zOuter sill rein forcement (LH) zFront fender bracket assembly (LH)
JSKIA1832GB
Revision: 2010 May2011 QX56

REPLACEMENT OPERATIONSBRM-37
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
1. Body sealing
Unit: mm (in) : Vehicle front
JSKIA1833GB
Revision: 2010 May2011 QX56

BRM-38
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
View K: Before installing outer sill and lower center pillar brace
View M: Before installing outer sill, lower center pillar brace, and outer sill reinforcement
View O: Before installing outer sill
1. Urethane foam 2. Body sealing
Unit: mm (in)
: Vehicle front
JSKIA1834GB
Revision: 2010 May2011 QX56

REPLACEMENT OPERATIONSBRM-39
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
Rear FenderINFOID:0000000006248503
1. Urethane foam 2. Body sealing
Unit: mm (in) : Vehicle front
: Weld the parts onto the back of the component part.
Replacement parts z Rear fender (LH)
JSKIA1835GB
Revision: 2010 May2011 QX56

BRM-40
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
1. Adhesive
Unit: mm (in): Vehicle front
Refer to GI-4, "
Components" for symbols in the figure.
JSKIA1836GB
Revision: 2010 May2011 QX56

REPLACEMENT OPERATIONSBRM-41
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
View M: Before installing rear fender
Unit: mm (in) : Vehicle front
JSKIA1837GB
Revision: 2010 May2011 QX56

BRM-42
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
Rear Fender Extension
INFOID:0000000006248504
Rear Panel and Rear End CrossmemberINFOID:0000000006248505
Remove the rear side member (reusable) and the rear end cross bracket (reusable) for easier installation.
Unit: mm (in)
Replacement parts
z Rear fender extension (LH)
JSKIA1838GB
Revision: 2010 May2011 QX56

REPLACEMENT OPERATIONSBRM-43
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
o. Left side p. Right side : Vehicle front
: Welding method, the number of welding points, and the tightening torque apply to both side of the vehicle.
Refer to GI-4, "
Components" for symbols in the figure.
Replacement parts z Rear crossmember zUpper rear end crossmember as-
sembly
JSKIA1920GB
Revision: 2010 May2011 QX56

BRM-44
< REMOVAL AND INSTALLATION >
REPLACEMENT OPERATIONS
: Vehicle front.
: Weld the parts onto the back of the component part.
: Welding method, the number of welding points, and the tightening torque apply to both side of the vehicle.
Refer to GI-4, "
Components" for symbols in the figure.
JSKIA1840GB
Revision: 2010 May2011 QX56

REPLACEMENT OPERATIONSBRM-45
< REMOVAL AND INSTALLATION >
C
DE
F
G H
I
J
L
M A
B
BRM
N
O P
Rear Floor RearINFOID:0000000006248506
Work after rear panel and rear end crossmember are removed.
1. Rear side member 2. Rear end cross bracket
Unit: mm (in) : Vehicle front
: Welding method, the number of welding points, and the tightening torque apply to both side of the vehicle.
JSKIA1921GB
Revision: 2010 May2011 QX56
