JAGUAR XFR 2010 1.G Workshop Manual

Published: 11-May-2011
Interior Trim and Ornamentation - Instrument Panel Speaker Grille
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. CAUTIONS:


Protect the surrounding trim to avoid damage.
Make sure that the clips are correctly located.









3.
4. CAUTION: Make sure that the component is correctly
located on the locating dowels.


NOTE: Do not disassemble further if the component is
removed for access only.
Torque: 2 Nm

Interior Trim and Ornamentation - Headliner
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

2. Refer to: Interior Rear View Mirror (501-09 Rear View Mirrors, Removal and Installation).

3. Refer to: Overhead Console (501-12 Instrument Panel and Console, Removal and Installation).

4.
Remove both sun visors.

Refer to: Sun Visor (501-05 Interior Trim and Ornamentation, Removal and Installation).

5.
Remove both A-pillar trim panels.

Refer to: A-Pillar Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

6.
Remove both B-pillar upper trim panels.

Refer to: B-Pillar Upper Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

7.
Remove both C-pillar trim panels.

Refer to: C-Pillar Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

8.
Remove both front seats.

Refer to: Front Seat (501-10 Seating, Removal and Installation).
9. Refer to: Rear Seat Cushion (501-10 Seating, Removal and Installation).

www.JagDocs.com

13.



























Vehicles with roof opening panel

14. NOTES:


Note the different lengths of screws.


Make sure that the component is installed to the
position noted on removal.
Torque: 2 Nm

Vehicles without roof opening panel

15. NOTES:


Note the different lengths of screws.


Make sure that the component is installed to the
position noted on removal.
Torque: 2 Nm




















All vehicles

16.

17.
18.
19.



















WARNING: This step requires the aid of another
technician.
















WARNING: This step requires the aid of another
technician.
CAUTIONS:


Note the fitted position of the component prior to
removal.


Make sure that these components are installed to the
noted removal position.

Installation

20.


































21.

CAUTION: Note the fitted position of the component
prior to removal.


NOTE: Make sure that the component is installed to
the position noted on removal.






























WARNING: This step requires the aid of another
technician.

1. To install, reverse the removal procedure.

Published: 11-May-2011
Interior Trim and Ornamentation - Loadspace Scuff Plate Trim Panel
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details.


1.
2.
Installation

1. To install, reverse the removal procedure. www.JagDocs.com

Interior Trim and Ornamentation - Loadspace Trim Panel
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1.

2.

3.
Installation


Repeat the above procedure for the other side.

1. To install, reverse the removal procedure.
