Page 2261 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - Loadspace Trim Panel LH Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

Page 2262 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - Loadspace Trim Panel RH Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

Page 2263 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Interior Trim and Ornamentation - Luggage Compartment Lid Trim Panel Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation de

Page 2264 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - Parcel Shelf Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. Refer to

Page 2265 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2266 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2267 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. NOTE: The procedure must be carried out on both sides of the seat. Torque: 6 Nm 8.

Page 2268 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. 10. NOTE: On installation, use a suitable tool to make sure that the parcel shelf is located underneath the rea

Page 2269 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 11. 12. 13. NOTE: Do not disassemble further if the component is removed for access only. www.JagDocs.com

Page 2270 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
