BODY - Seat Belt23-97
4 : Terminal to check
outer switch IL.H.1
+ : Terminal to check
outer switch (R.H.1
lQPO36119A0322lQA0317
OUTER SWITCH
(1) Disconnect the outer switch connector.
(2) Pull out the shoulder belt farther than its midpoint and checkthe continuity between the terminals.
When the belt is pulled out farther than
approx. the midpoint00
When the belt is not pulled out as far as
approx. the midpoint
NOTE
(1) The above inspection permits verification that the outer
switch turns on when the shoulder belt is properly
engaged with the slide anchor. The “midpoint” in the
above procedure refers to the center of the belt length
between the retractor and slide anchor.
(2) O-O indicates that there is continuity between the
terminals.
BUCKLE SWITCH
(1) Disconnect the buckle switch connector (L.H. only).
(2) Check the continuity between the terminals.
)I
NOTEO-O indicates that there is continuity between the terminal.
BUZZER
Check that buzzer sounds when battery voltage is applied to the
buzzer terminal.
i

23-98BODY - Seat Belt
\9-14 Nms-55 Nm
7-10 ft.lbs.25-40 ft.lbs.
Pre-removal Operation0 Removal of Front Seat
(Refer to
P.23-90.)0 Removal of Quarter Trim
(Refer to
P.23-85.)
Post-installation Operationl Installation of Quarter Trim(Refer to P.23-85.)l Installation of Front Seat(Refer to P.23-90.)
Buckle removal steps1. Seat belt switch harness
2. Buckle cover
3. Buckle
Front seat belt removal steps
4. Bolt cap
5. Slide bar
l +6. Sash guide cover
l + 7. Front seat belt
8. Cover plate
Buzzer removal stepsInstrument panel assembly
(Refer to P.23-80.)
9. BuzzerNOTE(1) Reverse the removal procedures to reinstall.
(2)
+e : Refer to “Service Points of Removal”.
(3) l + : Refer to “Service Points of Installation”
(4) m : Non-reusable parts
SERVICE POINTS OF REMOVAL6. REMOVAL OF SASH GUIDE COVER
Insert a plastic trim tool from the lower part and open the
sash guide cover.

BODY - Seat Belt23-99
19AO239
I ITest bulb 2tI
I I
INSPECTION
SEAT BELT TIMERRemove the seat belt timer from the relay box (indoor).
TIMER OPERATION CHECK(I
1 Connect the battery and the test bulb to the timer, as shown
in the illustration.
(2) Make sure that when terminal 2 is connected to the positive
(+) terminal of the battery, test bulbs 1 and 2 are lighted
for approx. 6 seconds.
(3) Make sure that even when terminal 3 is disconnect while testbulbs 1 and 2 and lighted in
(2) above, test bulb 1 remains
lighted.
BUCKLE SWITCHRefer to
P.23-97.
BUZZERRefer to
P.23-97.
SERVICE POINTS OF INSTALLATION7. INSTALLATION OF FRONT SEAT BELT
Fit the retractor retaining lug in the slot provided in the
vehicle body, and secure the retractor with the bolt by
tightening it to the specified torque.

23-100BODY - Seat Belt
35-55 Nm
25-40 ft.lbs.
Inner seat belt removalsteps319A029S
M l 1. Rear seat cushion
2. Inner seat belt
3. Bracket
Outer seat belt removal steps7. Seat belt protector
8. Retractor bracket mounting bolts
9. Outer seat belt
w H 1. Rear seat cushionNOTEl + 4. Seat belt anchor plate attaching bolts(I 1 Reverse the removal procedures to reinstall.
5. Retractor cover(2) ** : Refer to “Service Points of Removql”.
*I)6. Rear side trim(3) l + : Refer to “Service Points of Installation”.
SERVICE POINTS OF REMOVAL1. REMOVAL OF REAR SEAT CUSHION
Refer to
P.23-93.6. REMOVAL OF REAR SIDE TRIM
Refer to
P.23-85.
SERVICE POINTS OF INSTALLATION4. INSTALLATION OF SEAT BELT ANCHOR PLATE AT-
TACHING BOLTS
Install the anchor plate so that it conforms to the floor bead.1. INSTALLATION OF REAR SEAT CUSHION
Refer to
P.23-93.
