Instruments6-2 Instruments and controls
6
E00500102447E00537800028
Indicates the total power of the motors andengine during driving.
Indicates the charging power generated by theregenerative brake.The more the needle reflects, the more elec-tric energy is charged.The needle of the energy usage indicator maynot enter the charge zone when the drive bat-tery is close to full charge.
E00531301044
Each time you press the rheostat illuminationbutton, there is a sound and the brightness ofthe instruments changes.
Instruments 1- Energy usage indicator
m P.6-2
2- Multi information display
m P.6-3
Information screen display list m P.6-22
3- Speedometer (km/h or mph + km/h)4- Rheostat illumination button
m P.6-2
Energy usage indicator Eco/Power zone
Charge zone Meter illumination control Eco/Power zoneCharge zone
1- Brightness level2- Rheostat illumination button
NOTE
zYo u c a n a d j u s t t o 8 d i f f e r e n t l e v e l s r e s p e c -tively for when the position lamps are illumi-nated and when they are not.zIf the vehicle is equipped with the automaticlamp control, when the lamp switch is in aposition other than the “OFF” position, themeter illumination switches automatically tothe adjusted brightness, depending on thebrightness outside the vehicle.zThe brightness level of the instruments isstored when the operation mode of the powerswitch is put in OFF.
BK0203201EN.book 2 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-3
6
E00519902119
Always stop the vehicle in a safe place beforeoperating.The following information is included on themulti information display: warnings, odome-ter, tripmeter, average fuel consumption, EVcruising range, total cruising range, EVHVdriving rate, energy flow, etc.[When the operation mode of the powerswitch is OFF]zIf you press and hold the button for about 2seconds or more when the position lamps areilluminated, the brightness level changes tothe maximum level. Pr
essing and holding the
button for about 2 sec
onds or more again
returns the brightness level to the previouslevel.
Multi information display
NOTE
1-
mark display screen
m P.6-9
2- Information screen
m P.6-5
Interrupt display screen
m P.6-8
3- Drive battery level display screen
m P.6-9
4- Odometer
m P.6-10
5- Door ajar warning display screen
m P.6-9
NOTE
zThe drive battery level display screenappears when any of the doors or the tailgateis opened during charging.
BK0203201EN.book 3 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display6-4 Instruments and controls
6
[When the operation mode of the power switch is ON]
E00520001764
Each time the multi information displayswitch is operated, the buzzer sounds and themulti information display changes betweeninformation such as warnings, tripmeter,
1- NORMAL indicator display screen
Displayed when the ECO mode switchand 4WD lock switch are OFF.
2- ECO mode indicator display screen
Displayed when the ECO mode switch isON and the 4WD lock switch is OFF.
3- ECO LOCK indicator display screen
Displayed when the ECO mode switchand 4WD lock switch are ON.
4- 4WD LOCK indicator display screen
Displayed when the ECO mode switch isOFF and the 4WD lock switch is ON.m ECO mode switch P. 6-46m 4WD lock switch P. 7-19
5- Battery charge mode display screen
m P. 7-23
6- Battery save mode display screen
m P. 7-22
7-
mark display screen
m P. 6-9
8- Forward Collision Mitigation System
(FCM) OFF display screen
* m P. 7-55
9- Lane Departure Warning (LDW) display
screen
* m P. 7-60
10- Cruise control display screen
* m P. 7-35
11- Adaptive Cruise Control System (ACC)
display screen
* m P. 7-43
12- Speed limiter display screen
* m P. 7-39
13- Drive battery level display screen
m P. 6-9
14- Odometer
m P. 6-10
15- Information screen
m P. 6-7
16- Select position indicator
m P. 7-15
17- Fuel remaining display screen
m P. 6-9
18- Outside temperature display screen
m P. 6-10
Multi information display switch
BK0203201EN.book 4 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-5
6
average fuel consumption, EV cruising range,total cruising range,
EVHV driving rate,
energy flow, etc.It is also possible to change elements such asthe language and units used on the multiinformation display by operating the multiinformation display switch.
E00520201812
Each time you lightly press the multi info
rmation display switch, the display screen switches in the following order.
Information screen (when the operation mode is OFF) *1:When there is no warning display*2:When there is a warning display
*1*2
BK0203201EN.book 5 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display6-6 Instruments and controls
6
E00520701918
When the operation mode is put in ON, the display screen switches in the following order.1-
Tripmeter
m P. 6-10
2-
Tripmeter
m P. 6-10
3- ECO score display
m P. 6-14
4- Prediction charging time
m P. 3-8
5- Service reminder
m P. 6-11
6- Redisplay of a warning display screen
m P. 6-8
Information screen (when the operatio
n mode is changed from OFF to ON)
*:When the inspection time has arrived1- Screen when the operation mode is OFF2- System check screen
m P.6-12
3- Screen when the operation mode is ON4- Service reminder
m P.6-11
*
BK0203201EN.book 6 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-7
6
E00521101788
Each time you lightly press the multi info
rmation display switch, the display screen switches in the following order.
Information screen (when the operation mode is ON) *1:When there is no warning display*2:When there is a warning display1-
Tripmeter
m P. 6-10
2-
Tripmeter
m P. 6-10
3- EV cruising range display/Total cruising range display
m P. 6-13
4- Average fuel consumption display
m P. 6-13
EVHV driving rate display
m P. 6-14
5- Energy flow display
m P. 6-14
6- ECO score display
m P.6-14
7- S-AWC (Super-All Wheel Control) operation display
m P. 7-19
8- Service reminder
m P. 6-11
9- Function setting screen
m P. 6-15
*1*2
BK0203201EN.book 7 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display6-8 Instruments and controls
6
E00522001885
When there is information to be announced,such as a system fault, the buzzer sounds andthe information screen is switched to thewarning display screen.Refer to the warning list and take the neces-sary measures. Refer to “Warning display list” on page 6-22.When the cause of the warning display iseliminated, the warning display goes outautomatically.Even if the cause of the warning display isnot eliminated, you can return to the screen
that was displayed before the warning dis-play.If you press the multi information displayswitch, the display screen switches to thescreen that was displayed before the warningdisplay and the mark (A) is displayed.
When the mark is displayed, if you lightlypress the multi information display switch afew times, the warning display screen youswitched from is redisplayed.
10- Redisplay of a warning display screen
m P. 6-8
NOTE
zWhile driving, the service reminder are not displayed even if you operate the multi in
formation display switch. Always stop the
vehicle in a safe place
before operating.zWhile driving, the function setting screen
is not displayed even if you operate
the multi information display switch.
Before operation, park the vehicle in a sa
fe place, firmly apply the parking brake,
press the electrical
parking switch, and sh
ift to “P” (PARK) position.
Refer to “Changing the functi
on settings” on page 6-15.
zWhen there is information to be announced
, such as a system fault, the buzzer s
ounds and the screen display is switched.
Refer to “Interrupt disp
lay screen” on page 6-8.
Interrupt display screen Warning display To r e t u r n t o t h e s c r e e n d i s p l a y e d b e f o r ethe warning display
NOTE
zWa r n i n g d i s p l a y s c r e e n s w i t h a “ ” o r“” mark displayed in the upper right of thescreen can be switched. If you want to switchthe display, press the multi information dis-play switch as follows.“”: Press lightly.“”: Press for about 2 seconds or more.
Redisplay of a warning display screen
BK0203201EN.book 8 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-9
6
The operation status of each system is dis-played on the information screen.Refer to the appropriate page in the warningdisplay list for further details.Refer to “Other interrupt displays” on page6-33.
E00533901028
This is displayed when you press the multiinformation display switch and return fromthe warning display screen to the previousscreen.This mark is also displayed if there is anotherwarning other than the one displayed.When the cause of the warning display iseliminated, the mark goes out automati-cally.
E00522601692
If any of the doors or the tailgate is not com-pletely closed, this displays the open door ortailgate.When the operation mode of the powerswitch is ON, if the vehicle speed exceedsapproximately 8 km/h while a door is ajar, abuzzer sounds 4 times. This notifies thedriver that a door is ajar.
E00537700027
E00522201542
This displays the amount of fuel remaining.
Other interrupt displays mark display screen
NOTE
zWhen the mark is displayed, the warningdisplay screen can be redisplayed on theinformation screen.Refer to “Information screen (when the oper-ation mode is OFF)” on page 6-5.Refer to “Information screen (when the oper-ation mode is ON)” on page 6-7.
Door ajar warning display screen
CAUTIONzBefore moving your vehicle, check that thewarning lamp is OFF.
Drive battery level display screen
Indicates the remaining power inthe drive battery.
Fuel remaining display screen F- FullE- Empty
NOTE
zIt may take se
veral seconds to stabilise the
display after refilling the tank.zIf fuel is added with the operation mode ofthe power switch is in ON, the fuel gaugemay incorrectly indicate the fuel level.zThe arrow (A) indicates that the fuel tankfiller is located on the left side of the body.
BK0203201EN.book 9 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display6-10 Instruments and controls
6
E00522401788
When the fuel is reduced to about 7 litres, theinformation screen switches to the interruptdisplay of the fuel remaining warning display,and the “ ” mark (B) on the fuel remainingdisplay flashes slowly (about once per sec-ond). After a few seconds, the informationscreen returns from the fuel remaining warn-ing display to the previous screen.When the fuel is reduced further to about 5litres, the information screen switches to thefuel remaining warning display and the “ ”mark (B) on the fuel remaining displayflashes quickly (about twice per second).
E00522101509E00527800083
The odometer indicates the distance travelled.
E00527901078
The tripmeter indicates the distance travelledbetween two points.
Fuel remaining warning display
CAUTIONzIf the warning display a
ppears, refuel as soon
as possible. If the vehicle is runs out of fuel, the enginewill not start even in
a situation need to be
generated electricity, the following condi-tions will occur.•The driving performance falls (since onlythe electrical power stored in the drive bat-tery can be used for the driving).•The heating performance cannot be availa-ble (except vehicles with electric heater).•The effectiveness of the heater is insuffi-cient (vehicles with electric heater).•The catalytic converter may be damageddue to excessive high temperature.NOTE
zOn inclines or curves, the display may beincorrect due to the movement of fuel in thetank.zBattery save or battery charge may not beactivated even if the battery save switch orthe battery charge switch is pressed, depend-ing on the remaining quantity of the drivebattery or the control condition of the sys-tem.
Outside temperature display screen
This displays the temperatureoutside the vehicle.
NOTE
zThe display setting can be changed to thepreferred units (°C or °F).Refer to “Changing the function settings” onpage 6-15.zDepending on factors such as the drivingconditions, the displayed temperature mayvary from the actual outside temperature.
Odometer Tr i p m e t e r
BK0203201EN.book 10 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Multi information display
Instruments and controls 6-11
6
To r e t u r n t h e d i s p l a y t o 0 , h o l d d o w n t h emulti information display switch for about 2seconds or more. Only the currently dis-played value will be reset.ExampleIf tripmeter is displayed, only tripmeter
will be reset.
E00522502021
Displays the approximate time until the nextperiodic inspection recommended by
MITSUBISHI MOTORS. “---” is displayedwhen the inspection time has arrived.
1. Displays the time until the next periodicinspection.2. This informs you that a periodic inspec-tion is due. We recommend you to consulta MITSUBISHI MOTORS AuthorisedService Point.At that time, when the operation mode ischanged from OFF to ON, the warningdisplay is displayed for a few seconds onthe information screen.3. After your vehicle is inspected at aMITSUBISHI MOTORS Authorised Ser-vice Point, it displays the time until thenext periodic inspection.
The “---” display can be reset while the oper-ation mode of the power switch is in OFF.
Example usage of tripmeter and tripmeter
It is possible to measure two currentlytravelled distances, from home using trip-meter and from a particular point onthe way using tripmeter .
To r e s e t t h e t r i p m e t e r
NOTE
zWhen disconnecting the auxiliary battery ter-minal, the memory of tripmeter and are cleared, and the display returns to “0”.
Service reminder
NOTE
zDepending on the vehicle specifications, thedisplayed time may differ from the next peri-odic inspection time recommended byMITSUBISHI MOTORS.In addition, the display settings for the nextperiodic inspection time can be modified.To modify the display settings, have itadjusted at a MITSUBISHI MOTORSAuthorised Service Point.For more details, consult a MITSUBISHIMOTORS Authorised Service Point.
NOTE
zThe distance is show
n in units of 100 km
(100 miles). The time is
shown in units of
months.
To r e s e t
