MITSUBISHI OUTLANDER SPORT 2014 3.G Owners Manual
Manufacturer: MITSUBISHI, Model Year: 2014, Model line: OUTLANDER SPORT, Model: MITSUBISHI OUTLANDER SPORT 2014 3.GPages: 388, PDF Size: 20.04 MB
Page 301 of 388

Sun visors8-64 For pleasant driving
8
*: “iPod,” “iPod classic,” “iPod nano,” “iPodtouch” and “iPhone” are registered trade-marks of Apple Inc. in the United States andother countries.
E00762400033
Yo u c a n p l a y m u s i c f i l e s o f t h e f o l l o w i n gspecifications that are saved in a USB mem-ory device or other device supporting massstorage class. When you connect your iPod,playable file specifications depend on theconnected iPod.
E00711202277
A vanity mirror is fitted to the back of the sunvisor.Operating the lid of the vanity mirror willautomatically turn on the mirror lamp (A).
iPhone
*
iPhone
F/W Ver.3.1.3 or later
iPhone 3G
F/W Ver.4.2.1 or later
iPhone 3GS
F/W Ver.4.3.1 or later
iPhone 4
F/W Ver.4.3.1 or later
iPhone 4S
F/W Ver.5.0.1 or later
Models other than USB memory devices and iPods
Digital audio player supporting mass storage class
NOTE
zDepending on the type of the USB memorydevice or other device connected, the con-nected device may not function properly orthe available functions may be limited. zIt is recommended to use an iPod with firm-ware updated to th
e latest version.
zYo u c a n c h a r g e y o u r i P o d b y c o n n e c t i n g i t t othe USB input terminal when the operationmode is in ON or ACC.
Model name
Condition
zDo not keep your USB memory device oriPod in your vehicle. zIt is recommended that you back up the filesin case of data damage. zDo not connect to the USB input terminalany device (hard disk, card reader, memoryreader, etc.) other than the connectabledevices specified in the previous section.The device and/or data
may be damaged. If
any of these devices
was connected by mis-
take, remove it after putting the operationmode in OFF.
File specifications Item
Condition
File format
MP3, WMA, AAC
Maximum number of levels(including the root)
Level 8
Number of folders 700Number of files 65,535
NOTE
Sun visors 1- To eliminate front glare2- To eliminate side glareVa n i t y m i r r o r
BK0203201EN.book 64 ページ 2013年11月19日 火曜日 午前11時50分
Page 302 of 388

Ashtray
For pleasant driving 8-65
8
Cards can be slipped into the holder (B) onthe back of the sunvisor.
E00711402165
To u s e t h e a s h t r a y, o p e n t h e l i d .
The moveable ashtray can be fitted at theindicated position.
CAUTION zIf the lid of vanity mirror with lamp is keptopen for prolonged periods of time, the aux-iliary battery will be discharged.
Card holder
Ashtray
CAUTION zPut out matches and cigarettes before theyare placed in the ashtray. zDon’t put papers and ot
her things that burn
into your ashtrays. If you do, cigarettes orother smoking material
s could set them on
fire, causing damage. zAlways close the ashtra
y. I f l e f t o p e n , o t h e r
cigarette butts in the ashtray may be rekin-dled.
Mounting position for move-able ashtray
BK0203201EN.book 65 ページ 2013年11月19日 火曜日 午前11時50分
Page 303 of 388

Accessory socket8-66 For pleasant driving
8
E00711602516
To u s e a p l u g - i n t y p e a c c e s s o r y, o p e n t h e l i dor remove the cap, and insert the plug in theaccessory socket.The accessory socket can be used while theoperation mode is in ON or ACC.
E00712002328
Accessory socket
CAUTION zBe sure to use a “plug-in” type accessoryoperating at 12 V and
at 120 W or less.
When using more than one socket at thesame time, make sure that the electricalaccessories are 12 V accessories and that thetotal power consumption does not exceed120 W. zLong use of the electric appliance when theready indicator is not illuminated may rundown the auxiliary battery. zWhen the accessory socket is not in use, besure to close the lid or install the cap,because the socket might become clogged byforeign material and
be short-circuited.
NOTE
zAccessory sockets in 2 locations can be usedat the same time.
Floor consoleFloor console box
Interior lamps 1- Luggage room lamp2- Room lamp (rear)3- Map & room lamps (front)4- Downlight
m P.6-40
NOTE
zIf you leave the lamps on when the readyindicator is not illuminated, you will rundown the auxiliary battery.Before you leave the vehicle, make sure thelamps are turned off.
BK0203201EN.book 66 ページ 2013年11月19日 火曜日 午前11時50分
Page 304 of 388

Interior lamps
For pleasant driving 8-67
8
E00712102404
E00712400168
Push the lens (A) to turn on the lamp. Push itagain to turn it off.
Room lamps Posi-tion of lamp switch
On/off control
1-ON ()
The lamp illuminates regardless of whether a door or the tailgate is open or closed.
FrontRear
2-DOOR (•)
The lamp illuminates when a door or the tailgate is opened. It goes off about 15 seconds after all doors and the tailgate are closed.However, the lamp goes off immediately with all doors and the tailgate closed in the follow-ing cases:•When the operation mode is put in ON.•When the central door lock function is used to lock the vehicle.•When the keyless operation key is used to lock the vehicle.•When the keyless operation function is used to lock the vehicle.
3-OFF ()
The lamp goes off regardless of whether a door or the tailgate is open or closed.
Posi-tion of lamp switch
On/off control
NOTE
zWhen the operation mode is put in OFFwhile the doors and tailgate are closed, thelamp illuminates and after about 15 secondsit goes off. zThe time until the lamp goes off can beadjusted. For details, please consult a MIT-SUBISHI MOTORS Authorised ServicePoint. On vehicles e
quipped with Mitsubishi
Multi-Communication System (MMCS),screen operations can be used to make theadjustment. Refer to the separate owner’smanual for details.
Map lamps
BK0203201EN.book 67 ページ 2013年11月19日 火曜日 午前11時50分
Page 305 of 388

Storage spaces8-68 For pleasant driving
8
E00712700709E00712902385
If any of the interior lamps are left switchedon with the operation mode in OFF, it goes
off automatically after approximately 30 min-utes.The lamps will illuminate again after theyautomatically go off if the power switch isoperated, if one of the doors or the tailgate isopened or closed, or if the keyless entry sys-tem or keyless operation system is operated.
E00713103046
E00726200268
To o p e n , p u l l t h e l e v e r ( A ) .
Luggage room lamp 1- ( )The lamp illuminates regardless of whetherthe tailgate is open or closed.2- (•)The lamp illuminates when the tailgate isopened, and goes off when the tailgate isclosed.3- ( )The lamp goes off regardless of whether thetailgate is open or closed.Lamps (room lamps, etc.) auto-cutout function
NOTE
zThe interior lamp auto-cut function can bedeactivated. The time un
til the lamps auto-
matically go off can be adjusted. For detailsand support, consult your nearest MITSUBI-SHI MOTORS Authorised Service Point.On vehicles equipped
with Mitsubishi Multi-
Communication System (MMCS), screenoperations can be used to make the adjust-ment. Refer to the se
parate owner’s manual
for details.
Storag e spaces
WA R N I N G zDo not carry fuel-filled containers orspray cans inside
your vehicle. Leaving
fuel-filled containers or spray cans in yourvehicle could cause the containers to burstor an explosion of evaporated gas.
CAUTION zNever leave lighters,
canned carbonated bev-
erage, and spectacles in the cabin when park-ing the vehicle in hot sunshine. The cabinwill become extremely hot, so lighters andother flammable items may catch fire andunopened drink cans may rupture. Also,spectacles with plastic lenses or materialscould deform or crack. zKeep the lids on storage spaces closed whiledriving the vehicle. A lid or the contents of astorage space could otherwise cause injuries.1- Luggage floor box2- Floor console box3- Glove boxGlove box
BK0203201EN.book 68 ページ 2013年11月19日 火曜日 午前11時50分
Page 306 of 388

Storage spaces
For pleasant driving 8-69
8
There is a card holder inside the glove box.
E00723302031
To o p e n t h e c o n s o l e b o x , l i f t t h e r e l e a s e l e v e r(A) and raise the lid.The floor console box can also be used as anarmrest.
E00718701795
The box for storing articles is located insidethe luggage compartment.To u s e t h e b o x , r a i s e t h e l u g g a g e f l o o r b o a r d(A).
NOTE
zWhen the lamps are ill
uminated with the
lamp switch in the “ ”, “ ”, or“AUTO” position (vehicles with automaticlamp control), the glove box lamp illumi-nates.
Card holder
Floor console box
B- Tissue holderC- Pen holderD- Tray
NOTE
zThe USB input terminal is located in thefloor console box. For de
tails, refer to “USB
input terminal” on page 8-61.
Luggage floor box
BK0203201EN.book 69 ページ 2013年11月19日 火曜日 午前11時50分
Page 307 of 388

Cup holder8-70 For pleasant driving
8
To u s e t h e l u g g a g e f l o o r b o x i n t h e r e a r s e a tside, insert your hand in the gap (B) and raisethe board (A) to the seat side.
E00714501043
The cup holder is located in front of the floorconsole.
E00716901562
In order to use the cup holder, allow the arm-rest to drop down.
WA R N I N G zDo not place any object around the“”mark, since there is the auxiliarybattery under the luggage floor box. If thebattery cover is broken, a battery fluidmay leak. If it adheres to your skin or getsin your eyes, serious injury may result.
Cup holder
CAUTION zDo not drink beverages while driving. This isdistracting and could cause an accident.
For the front seat
For the rear seat
BK0203201EN.book 70 ページ 2013年11月19日 火曜日 午前11時50分
Page 308 of 388

Bottle holder
For pleasant driving 8-71
8
E00718200360
There are bottle holders located on both sidesof front and rear doors.
E00733601085
1. Draw out the cover retracted by springand insert it in the mounting grooves (A).2. Remove the cover from the mountinggrooves, and the cover will be rolled backinto the retracted position.
There are two installation holes (B) for thecover.1. Move one of the sliders (C) toward theinside of the vehicle, and fit the tab (D)into the installation hole that is to be used.Move the opposite slider in the same fash-ion.
Bottle holder
CAUTION zDo not drink beverages while driving. This isdistracting and could
cause an accident.
zDrinks could be spilled by the vibration andjolts while driving. If the spilt drink is veryhot, you could be burnt.NOTE
zDo not store cup or drink can in the bottleholder. zTightly close the cap on drink bottles beforestoring them. zSome bottles may be too big or the wrongshape to fit in the holder.
Cargo area cover To u s e
NOTE
zDo not put luggage on the cover.
To c h a n g e p o s i t i o n
BK0203201EN.book 71 ページ 2013年11月19日 火曜日 午前11時50分
Page 309 of 388

Assist grips8-72 For pleasant driving
8
2. After changing the position, gently shakethe entire cover to make sure it is securelyretained.1. Roll the cover into the retracted position.2. Move one of the sliders (C) toward theinside of the vehicle and lift it to removethe cover.
Refit the cover by performing the removalsteps in reverse.Gently shake the entire cover after fitting it tomake sure it is securely retained.
E00732800298
The assist grips (located above the doors onthe headliner) are not designed to supportbody weight. They are intended for use onlywhile seated in the vehicle.
E00725601640
There is a coat hook on the rear seat assistgrip of the driver’s side.
NOTE
zIf the rear seatback touches the cover, movethe cover rearward.The cover could break if it supports the seat-back of the rear seat.
To r e m o v e
To r e f i t Assist grips
CAUTION zDo not use the assist grips when getting intoor out of the vehicle. The assist grips coulddetach causing you to fall.
Coat hook
WA R N I N G zDo not put a hanger or any heavy orpointed object on the
coat hook. If the cur-
tain airbag was activated, any such itemcould be propelled away with great forceand could prevent the curtain airbag frominflating correctly. Hang clothes directlyon the coat hook (without using a hanger).Make sure there are no heavy or sharpobjects in the pockets of clothes that youhang on the coat hook.
BK0203201EN.book 72 ページ 2013年11月19日 火曜日 午前11時50分
