Towing9-20 For emergencies
9
Please contact your MITSUBISHI MOTORSAuthorised Service Point or a commercialtow truck service for assistance.Yo u r v e h i c l e m a y b e t e m p o r a r i l y t o w e d b yanother vehicle with a rope in emergency sit-uations such as running out of fuel.If your vehicle is to be towed by anothervehicle, tow your vehicle in a short distanceas much as possible and carefully in accord-ance with the instructions given in “Emer-gency towing” in this part.There may be local regulations concerningtowing in your area. It is recommended thatyou obey the regulations of the area whereyou are driving your vehicle.
If your vehicle is temporarily towed byanother vehicle with a rope in emergency sit-uations such as running out of fuel, the tow-ing distance shall be as short as possible andtow carefully in accordance with the follow-ing procedure.
CAUTIONzIf the drive-train or suspension has a prob-lem, do not tow the vehicle with only the rearwheels or front wheels placed on a dolly.
To w i n g t h e v e h i c l e b y a t o w truck
WA R N I N GzNever get under your vehicle after it hasbeen lifted by a tow truck.zNever ride in a vehicle that is being towed.
zNever tow the vehicle with front wheelsand/or rear wheels on the ground. Thismay cause damage to the electric motorsand transaxle.WA R N I N G
CAUTIONzNever tow the vehicl
e using a sling type
truck.Doing so will damage the bumper and/orbody.
Emergency towing
BK0203201EN.book 20 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Towing
For emergencies 9-21
9
1. The front towing hooks are located asshown in illustration. Secure the tow ropeto the front towing hook.
2. Start the Plug-in Hybrid EV system.If the Plug-in Hybrid EV System cannotbe started, put the operation mode of thepower switch in “ON”.
3. Put the select position in “N” (NEU-TRAL) position.4. Turn on the hazard warning lamps ifrequired by law. (Follow the local drivinglaws and regulations)5. During towing make sure that close con-tact is maintained between the drivers ofboth vehicles, and that the vehicles travelat low speed.
If your vehicle is to be towed by another vehicle
WA R N I N GzNever tow your vehicle in this methodexcept in emergency situations such asrunning out of fuel. If
the vehicle is towed
in this method when
a problem occurs in
the vehicle such as when some warninglamp illuminates, the motor, transaxle, etc.may be damagedNOTE
zUsing any part other than the designatedtowing hook could result in
damage to vehi-
cle body.
zUsing a wire rope or metal chain can resultin damage to the vehicle body. It is best touse a non-metallic rope. If you use a wirerope or metal chain, wrap it with cloth at anypoint where it touches the vehicle body.zUse care that the tow rope is kept as horizon-tal as possible. An angled tow rope can dam-age the vehicle body.zSecure the tow rope to the same side towinghook, to keep the tow rope
as straight as pos-
sible.WA R N I N GzIf the vehicle is towed with the operationmode in “ON” withou
t starting the Plug-
in Hybrid EV System, the auxiliary bat-tery may be fully discharged during tow-ing. In this case, the brake performancebecomes very poor and the steering wheelbecomes very heavy.NOTE
CAUTIONzFor vehicle equipped with the AdaptiveCruise Control system (ACC) and ForwardCollision Mitigation system (FCM), stopthese systems to prevent an unexpected acci-dent or unexpected op
eration during towing.
Refer to “Adaptive Cruise Control system(ACC)” on page 7-43 and “Forward Colli-sion Mitigation system (FCM)” on page7-55.WA R N I N GzAv o i d s u d d e n b r a k i n g ,
acceleration and
steering wheel movements; such drivingoperation could cause damage to the tow-ing hook or towing rope.People in the vicinity could be injured as aresult.zWhen going down a long slope, the brakesmay overheat, reducing effectiveness.Have your vehicle transport by a towtruck.
BK0203201EN.book 21 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Operation under adverse driving conditions9-22 For emergencies
9
Only use the rear towing hook as shown inthe illustration.Secure the tow rope to the rear towing hook.Otherwise, the instructions are the same asfor “When being towed by another vehicle”.
E00801703828
If your vehicle becomes stuck in snow, sand,or mud, it can often be moved by a rockingmotion. Rock your vehicle back and forth tofree it.Do not spin the wheels.
Constant efforts to
free a stuck vehicle can cause transaxle fail-ure.If your vehicle is still stuck after several rock-ing attempts, call for a commercial tow truckservice.
CAUTIONzThe person in the vehicle being towed mustpay attention to the brake lamps of the tow-ing vehicle and make sure the rope neverbecomes slack.zWhen the vehicle is to be towed by anothervehicle with the all wheels on the ground,make sure that the towing speed and distancegiven below are neve
r exceeded, avoiding
damage to the transaxle.To w i n g s p e e d : 3 0 k m / hTo w i n g d i s t a n c e : 3 0 k mFor the towing speed and the towing dis-tance, follow the local driving laws and regu-lations.
If your vehicle tows another vehi-cle
NOTE
zUsing any part
other than the designated
towing hook could result in damage to vehi-cle body.NOTE
zDo not tow a vehicle heavier than your ownvehicle.
Operation under adverse driving conditions If your vehicle becomes stuck in sand, mud or snow
WA R N I N GzWhen trying to rock your vehicle out of astuck position, make sure that there are nopeople nearby. The rocking motion canmake your vehicle suddenly lurch forwardor backward, and inju
re any bystanders.
BK0203201EN.book 22 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Operation under adverse driving conditions
For emergencies 9-23
9
zDo not drive on a flooded road. If youdrive on a flooded road, not only the Plug-in Hybrid EV System stops but also a fail-ure like electric leakage or short circuitmay occur.If you inevitably had to run on a floodedroad and the vehicle was exposed towater, be sure to have your vehicleinspected by a MITSUBISHI MOTORSAuthorised Service Point.zIf there is water on the brakes after driv-ing through puddles or washing the vehi-cle, resulting in temporarily ineffectivebrakes. In such cases, lightly depress thebrake pedal to see if the brakes operateproperly. If they do not, lightly depressthe pedal several times while driving inorder to dry the brake pads.zWhen driving in rain or on a road withmany puddles a layer of water may formbetween the tyres and the road surface.This reduces a tyre’s frictional resistanceon the road, resulting in loss of steeringstability and braking capability.To c o p e w i t h t h i s , o b s e r v e t h e f o l l o w i n gitems:
zWhen driving on a snow-covered or fro-zen road, it is recommended that you usesnow tyres or snow traction device (tyrechains).Refer to the “Snow tyres” and “Snowtraction device (tyre chains)” sections.zAv o i d h i g h - s p e e d o p e r a t i o n , s u d d e nacceleration, abrupt brake application andsharp cornering.zDepressing the brake pedal during travelon snowy or icy roads may cause tyreslippage and skidding. When tractionbetween the tyres and the road is reducedthe wheels may skid and the vehicle can-not readily be brought to a stop by con-ventional braking techniques. Brakingwill differ, depending upon whether youhave anti-lock brake system (ABS). Asyour vehicle is equipped with ABS, brakeby pressing the brake pedal hard, andkeeping it pressed.zAllow extra distance between your vehi-cle and the vehicle in front of you, andavoid sudden braking.
zAccumulation of ice on the braking sys-tem can cause the wheels to lock. Pullaway from a standstill slowly after con-firming safety around the vehicle.
Drive as slow as possible when driving onbumpy or rutted roads.This vehicle is intended for driving mainlyon roads with firm surface.4WD system makes possible driving on roadswithout special coverage, on flat and firmsurface. Please, remember that off-road abil-ity of your vehicle is limited. Your vehicle isnot intended for driving in heavy off-road,overcoming the rugged terrain, deep ruts, etc.
On a flooded road (a)Drive your vehicle at a slow speed.(b)Do not drive on worn tyres.
(c)Always maintain the specified tyre infla-tion pressures.
On a snow-covered or frozen road
CAUTIONzDo not press the accelerator pedal rapidly. Ifthe wheels break free of the ice, the vehiclecould suddenly start
moving and possibly
cause an accident.
On a bumpy or rutted road
CAUTIONzThe impact on tyres and/or wheels whendriving on a bumpy or rutted road can dam-age the tyre and/or wheel.
BK0203201EN.book 23 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Operation under adverse driving conditions9-24 For emergencies
9
Manufacturer of the vehicle is proceedingfrom the following assumption:taking the decision to keep driving under con-ditions mentioned above, driver takes allactions at own risk, aware of possible conse-quences.BK0203201EN.book 24 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

10
Ve h i c l e c a r eVe h i c l e c a r e p r e c a u t i o n s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 0 - 2Cleaning the interior of your vehicle ..............................................10-2Cleaning the exterior of your vehicle .............................................10-3
BK0203201EN.book 1 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Vehicle care precautions10-2 Vehicle care
10
E00900100548
In order to maintain the value of your vehicle,it is necessary to perform regular mainte-nance using the proper procedures.Always maintain your vehicle in compliancewith any environmental pollution control reg-ulations.Carefully select the materials used for wash-ing, etc., to be sure that they do not containcorrosives.If in doubt, we recommend you to consult aspecialist for the selection of these materials.
E00900200611
After cleaning the interior of your vehiclewith water, cleaner or similar, wipe and dry ina shady, well-ventilated area.
E00900301459
1. Lightly wipe these off with a soft clothsoaked in a mild soap and water solution.
2. Dip cloth in fresh water and wring it outwell. Using this cloth, wipe off the deter-gent thoroughly.
Ve h i c l e c a r e p r e c a u t i o n s
CAUTIONzCleaning products can
be dangerous. Always
follow the instructions of the cleaning prod-uct supplier.zTo a v o i d d a m a g e , n e v e r u s e t h e f o l l o w i n g t oclean your vehicle.•Petrol•Paint Thinner•Benzine•Kerosene•Turpentine•Naphtha•Lacquer Thinner•Carbon Tetrachloride•Nail Polish Remover•Acetone
Cleaning the interior of your vehicle
NOTE
zTo c l e a n t h e i n s i d e o f t h e t a i l g a t e w i n d o w,always use a soft cloth and wipe the windowglass along the demister heater element so asnot to cause damage.CAUTIONzDo not use organic substances (solvents,benzine, kerosene, alcohol, petrol, etc.) oralkaline or acidic solutions.These chemicals can cause discolouring,staining or cracking of the surface.If you use cleaners or polishing agents, makesure their ingredients
do not include the sub-
stances mentioned above.
Plastic, vinyl leather, fabric and flocked parts
NOTE
zDo not use cleaners, conditioners, and pro-tectants containing silicones or wax.Such products can cause discolouring and,when applied to the instrument panels orother parts, may cause reflections on thewindscreen and obscure vision.Also, if such products get on the switches ofthe electrical accessories, it may lead to fail-ure of these accessories.zDo not use synthetic fiber or dry cloth. Theycan cause discolouring
or damaging the sur-
face.zDo not place a deodorizer on the instrumentpanel or near lamps and instruments. Theingredients for deodoriz
er can cause discol-
ouring or cracking.
BK0203201EN.book 2 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cleaning the exterior of your vehicle
Vehicle care 10-3
10
E00900500207
1. To maintain the value of your new vehi-cle, handle the upholstery carefully andkeep the interior clean.Use a vacuum cleaner and brush to cleanthe seats. If stained, vinyl and syntheticleather should be cleaned with an appro-priate cleaner. Cloth fabrics can becleaned with either upholstery cleaner or amild soap and water solution.2. Clean the carpeting with a vacuumcleaner and remove any stains with carpetcleaner. Oil and grease can be removed bylightly dabbing with a clean colourfastcloth and stain remover.
E00900600950
1. To clean, lightly wipe the leather with asoft cloth soaked in a mild soap and watersolution.2. Dip cloth in fresh water and wring it outwell. Using this cloth, wipe off the deter-gent thoroughly.3. Apply leather protecting agent to the gen-uine leather surface.
E00900700108
If the following is left on your vehicle, it maycause corrosion, discolouration and stains,wash the vehicle as soon as possible.zSeawater, road deicing products.
zSoot and dust, iron powder from factories,chemical substance (acids, alkalis, coal-tar, etc.).zDroppings from birds, carcasses ofinsects, tree sap, etc.
E00900903547
Chemicals contained in the dirt and dustpicked up from the road surface can damagethe paint coat and body of your vehicle if leftin prolonged contact.Frequent washing and waxing is the best wayto protect your vehicle from this damage.This will also be effective in protecting itfrom environmental elements such as rain,snow, salt air, etc.Do not wash the vehicle in direct sunlight.Park the vehicle in the shade and spray it withwater to remove dust. Next, using an ampleamount of clean water and a car washingbrush or sponge, wash the vehicle from top tobottom.Use a mild car washing soap if necessary.Rinse thoroughly and wipe dry with a softcloth. After washing the vehicle, carefullyclean the joints and flanges of the doors, bon-net and other sections where dirt is likely toremain.
Upholstery Genuine leather
*
NOTE
zIf genuine leather is
wet with water or is
washed in water, wipe off water as quickly aspossible with a dry, soft cloth.If left damp, mildew may grow.zOrganic solvents such as benzine, kerosene,alcohol and petrol, acid or alkaline solventsmay discolour the genui
ne leather surface.
Be sure to use neutral detergents.zRemove dirty patche
s or oil substances
quickly as they can stain genuine leather.zThe genuine leather surface may harden andshrink if it is exposed to direct rays of thesun for long hours. When your vehicle isparked, place it in the shade as much as pos-sible.zWhen the temperature of the vehicle interiorrises in summer, vinyl products left on thegenuine leather seat may deteriorate andstick to the seat.
Cleaning the exterior of your vehicle
Was hi n g
BK0203201EN.book 3 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cleaning the exterior of your vehicle10-4 Vehicle care
10
Sea water contains salt, which generallyaccelerates corrosion of both ferrous and non-ferrous materials. Wind born spray from thesea can distribute salt for a distance of up to20 km from the shore line with prevailing on-shore winds, although the effect is generallyworse within 2 km of the shore. Salt spraycovers roads, and may be passed to your vehi-cle as dust, or as salt spray after rain. For thisreason it is important to wash all the vehicleincluding the underside (not forgetting theplug-in hybrid EV system bay and plug-inhybrid EV system bay components). See sec-tion entitled “Engine compartment” for rec-ommended cleaning practices.Ensure you request a MITSUBISHIMOTORS Authorised Service Point to con-duct the scheduled Preventative Maintenancecorrosion inspection if you live within 20 kmof the sea. Sea water spray in coastal condi-tions
WA R N I N GzDo not wash the vehicle while charging thetraction battery.Doing so could cause a fire or an electricshock.
zBefore washing the vehicle, make surethat the charging lid
and the inner lid are
completely closed.If the lid is open, the charging unit isexposed to water, resulting in a fire or anelectric shock.CAUTIONzWhen washing the under
side of your vehicle
or wheel, be careful not to injure your hands.zIf your vehicle has rain sensor wipers, placethe wiper switch lever in the “OFF” positionto deactivate the rain sensor before washingthe vehicle. Otherwise, the wipers will oper-ate in the presence of water spray on thewindscreen and may get damaged as a result.zRefrain from excessively using a car wash asits brushes may scratch the paint surface,causing it to lose its gloss. Scratches will beespecially visible on da
rker coloured vehi-
cles.zNever spray or splash
water on the electrical
components in the engine compartment.Doing so could have an adverse effect on theplug-in hybrid EV system startability.Exercise caution also when washing theunderbody; be careful not to spray water intothe engine compartment.WA R N I N G
zSome types of hot wa
ter washing equipment
apply high pressure and
heat to the vehicle.
They may cause heat distortion and damageto the vehicle resin parts and may result inflooding of the vehicle interior.Therefore;•Maintain a distance of approx. 70 cm ormore between the vehicle body and thewashing nozzle.•When washing around the door glass, holdthe nozzle at a distance of more than 70 cmand at right angles to the glass surface.
zAfter washing the vehicle, drive the vehicleslowly while lightly depressing the brakepedal several times in order to dry out thebrakes.Leaving the brakes wet could result inreduced braking performance. Also, there isa possibility that they could freeze up orbecome inoperative due
to rust, rendering the
vehicle unable to move.zUsing an automatic car wash, pay attentionto the following items, referring to the opera-tion manual or consulting a car wash opera-tor. If the following procedure is notfollowed, it could result in damage to yourvehicle.•The outside rear-view mirrors are retracted.•The antenna is removed.•The wiper arms are secured in place withtape.CAUTION
BK0203201EN.book 4 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Cleaning the exterior of your vehicle
Vehicle care 10-5
10
The salt and other chemicals spread on theroads in some areas in winter can have aharmful effect on the vehicle body. Youshould therefore wash the vehicle as often aspossible in accordance with our care-instruc-tions. It is recommended to have a preserva-tive applied and the underfloor protectionchecked before and after the cold weatherseason.After washing your vehicle, wipe off allwaterdrops from the rubber parts around thedoors to prevent the doors from freezing.
E00901000919
Wa x i n g t h e v e h i c l e w i l l h e l p p r e v e n t t h eadherence of dust and road chemicals to thepaintwork. Apply a wax solution after wash-ing the vehicle, or at least once every threemonths to assist di
splacing of water.
Do not wax your vehicle in direct sunlight.Yo u s h o u l d w a x a f t e r t h e s u r f a c e s h a v ecooled.For information on how to use wax refer tothe instruction manual of the wax.
E00901100066
The vehicle should only be polished if thepaintwork has become stained or lost its lus-tre. Do not polish parts with a mat coatingand the plastic bumpers. Doing so couldcause stains or damage the finish.
E00901300808
Use a sponge or chamois leather.If a car wax adheres on a grey or black roughsurface of the bumper, moulding or lamps,the surface becomes white. In such a case,wipe it off using lukewarm water and softcloth or chamois leather.
E00901400098
In order to prevent spots and corrosion ofchrome parts, wash with water, dry thor-oughly, and apply a special protective coat-ing. This should be done more frequently inwinter.
•If your vehicle is equi
pped with a roof rails,
consult a car wash opera
tor before using the
car washer.•If your vehicle has rain
sensor wipers, place
the wiper switch lever in the “OFF” posi-tion to deactivate the rain sensor.
During cold weather
NOTE
zTo p r e v e n t f r e e z i n g o f
the weatherstripping
on the doors, bonnet, etc., they should betreated with silicone spray.CAUTION
Wa x in g
CAUTIONzWa x e s c o n t a i n i n g h i
gh abrasive compounds
should not be used.zOn vehicles with the sunroof, be carefulwhen waxing the area around the sunroofopening, not to put any wax on the weather-strip (black rubber). If stained with wax, theweatherstrip cannot maintain a weatherproofseal with the sunroof.
Polishing
Cleaning plastic parts
CAUTIONzDo not use a scrubbing brush or other hardtools as they may damage the plastic partsurface.zDo not bring the plastic parts into contactwith petrol, light oil,
brake fluids, engine
oils, greases, paint thinners, and sulphuricacid (battery electrolyte) which may crack,stain or discolour
the plastic parts.
If they touch the plastic
parts, wipe them off
with soft cloth, chamois or the like and anaqueous solution of neutral detergent thenimmediately rinse the affected parts withwater.
Chrome parts
