Cleaning the exterior of your vehicle10-6 Vehicle care
10
E00901500347
1. Remove dirt using a sponge while sprin-kling water on the vehicle.2. Use neutral detergent on any dirt that can-not be removed easily with water.Rinse off the neutral detergent after wash-ing the vehicle.3. Dry the vehicle thoroughly using a cham-ois leather or a soft cloth.
E00901600117
The window glass can normally be cleanedusing only a sponge and water.Glass cleaner can be used to remove oil,grease, insect carcasses, etc. After washing
the glass, wipe it dry with a clean, dry, softcloth. Never use a cloth that is used for clean-ing a painted surface to clean a window. Waxfrom the painted surface could get on theglass and lower glass transparency and visi-bility.
E00901700062
Use a soft cloth and glass cleaner to removegrease, dead insects, etc., from the wiperblades. Replace the wiper blades when theyno longer wipe properly. (Refer to page11-12.)
E00902200051
Use a soft cloth to clean the inner side of thesunroof. Hard deposits should be wiped awaywith a cloth dipped in warm, neutral deter-gent solution. Wipe away the solution with asponge dipped in fresh water.
E00902100483
Clean the engine compartment at the begin-ning of autumn and end of winter. Pay partic-ular attention to flanges, crevices andperipheral parts where dust containing roadchemicals and other corrosive materialsmight collect.If salt and other chemicals are used on theroads in your area, or you live within 20 kmof the sea, clean the engine compartment atleast every three months.Never spray or splash water on the electricalcomponents in the engine compartment, asthis may cause damage.Do not bring the nearby parts, the plasticparts and so on into contact with sulphuricacid (battery electrolyte) which may crack,stain or discolour them.If they are in contact, wipe off with soft cloth,chamois or the like and an aqueous solutionof neutral detergent then immediately rinsethe affected parts with plenty of water.
Aluminium wheels*
CAUTIONzDo not use a brush or other hard implementon the wheels.Doing so could scratch the wheels.zDo not use any cleaner th
at contains an abra-
sive substance or is aci
dic or alkaline. Doing
so could cause the coating on the wheels topeel or become discoloured or stained.zDo not directly apply
hot water using a steam
cleaner or by any other means.zContact with seawater and road deicer cancause corrosion. Rinse off such substances assoon as possible.
Window glass
NOTE
zTo c l e a n t h e i n s i d e o f t h e r e a r w i n d o w,always use a soft cloth and wipe the windowglass along the demister heater element so asnot to cause damage.
Wiper blades Cleaning the sunroof*
NOTE
zThe surface treatment on the inside of theglass may be removed if hard cloth ororganic solvent (benzi
ne, kerosene, thinner,
etc.) is used.
Engine compartment
BK0203201EN.book 6 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

11
MaintenanceService precautions ......................................................................... 11-2Catalytic converter .......................................................................... 11-3Bonnet ............................................................................................. 11-3Engine oil ........................................................................................ 11-5Engine coolant/Plug-in hybrid EV system coolant ......................... 11-6Wa s h e r f l u i d . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 7Brake fluid ...................................................................................... 11-7Auxiliary battery ............................................................................. 11-8Ty r e s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 - 9Wiper blade rubber replacement ................................................... 11-12General maintenance .................................................................... 11-14Fusible links .................................................................................. 11-15Fuses ............................................................................................. 11-15Replacement of lamp bulbs .......................................................... 11-21
BK0203201EN.book 1 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Service precautions11-2 Maintenance
11
E01000102032
Adequate care of your vehicle at regularintervals serves to preserve the value andappearance as long as possible.Maintenance items as described in thisowner’s manual can be performed by theowner.We r e c o m m e n d y o u t o h a v e t h e p e r i o d i cinspection and maintenance performed by aMITSUBISHI MOTORS Authorised ServicePoint or another specialist.In the event a malfunction or a problem isdiscovered, we recommend you to have itchecked and repaired. This section containsinformation on inspection maintenance pro-cedures that you can do yourself. Follow theinstructions and cautions for each of the vari-ous procedures.Service precautions
A- Cooling fansB- Caution labelC- Radiator capD- EV cooling reserve tank cap*:Front of the vehicleWA R N I N GzBefore performing inspection or mainte-nance, be sure to disconnect the normalcharge connector from the vehicle andconfirm that the operation mode of thepower switch is set to “OFF”.
zNever touch the high-voltage parts in theengine compartment. Never remove ordisassemble the high-voltage components,cables (orange) or connectors. Also, neverdisassemble normal ch
arging cables, nor-
mal charge connector, plugs or outlet.Failure to observe this instruction couldcause an electric shock which result in aserious injury or death. These parts havelabels that indicate handling precautions.Follow the instruction on these labels.Contact a MITSUBISHI MOTORSAuthorised Service Point for any neces-sary maintenance.Refer to “High-Voltage components” onpage 2-7.zWhen checking or servicing the inside ofthe engine compartment, make sure theplug-in hybrid EV system is switched offand has had a chance to cool down.zIf it is necessary to do work in the enginecompartment with the plug-in hybrid EVsystem starting, be especially careful thatyour clothing, hair, etc., does not becomecaught by the cooling fans, drive belts, orother moving parts.zThe cooling fans can turn on automati-cally even if the plug-in hybrid EV systemis stopping. Put the operation mode of thepower switch in OFF to be safe while youwork in the engine compartment.WA R N I N G
BK0203201EN.book 2 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Catalytic converterMaintenance 11-3
11
E01000202437
The exhaust gas scavenging devices usedwith catalytic converter are extremely effi-cient for the reduction of noxious gases. Thecatalytic converter is installed in the exhaustsystem.It is important to keep the engine properlytuned to ensure proper catalyst operation andprevent possible catalyst damage.
E01000303868
1. Pull the release lever towards you tounlock the bonnet.
zMake sure that the engine and Plug-inHybrid EV system has cooled down beforeremoving the radiator cap and EV coolingsystem reserve tank cap, because hotsteam or boiling water otherwise will gushfrom the filler port and may scald you.zDo not smoke, cause sparks or allow openflames around fuel or auxiliary battery.The fumes are flammable.zBe extremely cautious when workingaround the auxiliary battery. It containspoisonous and corrosive sulphuric acid.zDo not get under your vehicle with just thebody jack supporting it. Always use auto-motive jack stands.zImproper handling of
components and
materials used in the vehicle can endangeryour personal safety. We recommend youto consult a specialist for necessary infor-mation.zThe components inside the engine roommight be very hot to the touch.To a v o i d b e i n g b u r n t , m a k e s u r e a l l c o m -ponents have sufficiently cooled beforebeginning an inspection. These compo-nents are affixed with the label indicatingprecautions for handling. Follow theinstructions on the label.WA R N I N G
1- Brake fluid reservoir (RHD)2- Engine oil level gauge3- Engine oil cap4- Brake fluid reservoir (LHD)5- Washer fluid reservoir6- EV cooling system reservoir7- Engine coolant reservoirCatalytic converter
WA R N I N GzAs with any vehicle, do not park or oper-ate this vehicle in areas where combustiblematerials such as dry grass or leaves cancome in contact with a hot exhaust since afire could occur.zPaint should not be applied to the catalyticconverter.NOTE
zUse fuel of the type recommended in “Fuelselection” on page 2.
Bonnet To o p e n
BK0203201EN.book 3 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Bonnet11-4 Maintenance
11
2. Raise the bonnet while pressing the safetylock.3. Support the bonnet by inserting the sup-port bar in its slot.
1. Unlatch the support bar and clip it in itsholder.2. Slowly lower the bonnet to a positionabout 20 cm above the closed position,then let it drop.3. Make sure the bonnet is securely lockedby softly lifting the centre of the bonnet.
NOTE
zOnly open the bonnet when the wipers are inthe parked position. In any other position,the wipers could damage the paint or bonnet.
CAUTIONzNote that the support bar may disengage thebonnet if the open bonnet is lifted by a strongwind.zAfter inserting the support bar into the slot,make sure the bar supports the bonnetsecurely from falling down on to your heador body.
To c l o s e
CAUTIONzBe careful that hands or fingers are nottrapped when closing the bonnet.zBefore driving, make sure that the bonnet issecurely locked. An
incompletely locked
bonnet can suddenly open while driving.This can be extremely dangerous.NOTE
zIf this does not close
the bonnet, release it
from a slightly higher position.zDo not press down firmly on the bonnet asdoing so could damage it.zFor vehicles equipped with the securityalarm system, if you drive with the bonnetleft open, warn
ing display is displayed on the
information screen in the multi informationdisplay.
BK0203201EN.book 4 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Engine oil
Maintenance 11-5
11
E01000404039
The engine oil used has a significant effect onthe engine’s performance, service life andstartability. Be sure to use oil of the recom-mended quality and appropriate viscosity.All engines consume a certain amount of oilduring normal operation. Therefore, it isimportant to check the oil level at regularintervals or before starting a long trip.1. Park the car on a horizontal surface.2. Switch off the engine.3. Wait a few minutes.4. Remove the dipstick and wipe it with aclean cloth.5. Reinsert the dipstick as far as it goes.
6. Remove the dipstick and read the oillevel, which should always be within therange indicated7. If the oil level is below the specified limit,remove the cap located on the cylinderhead cover and add enough oil to raise thelevel to within the specified range. Do notoverfill to avoid engine damage. Be sureto use the specified engine oil and do notmix various types of oil.8. After adding oil, close the cap securely.9. Confirm the oil level by repeating step 4to 6.
zSelect engine oil of the proper SAE vis-cosity number according to the atmos-pheric temperature.SAE 0W-20, 0W-30, 5W-30, and 5W-40engine oils can only be used if they meetACEA A3/B3, A3/B4 or A5/B5 and APISG (or higher) specifications.zUse engine oil conforming to the follow-ing classification:•API classification: “For service SG” orhigher•ILSAC certificated oil•ACEA classification:“For service A1/B1, A3/B3, A3/B4, orA5/B5”
Engine oil To c h e c k a n d r e f i l l e n g i n e o i l
FULL LOW
NOTE
zThe engine oil will dete
riorate rapidly if the
vehicle is subjected to severe conditions,requiring earlier oil replacement.Please refer to the maintenance schedule.zFor information on how to dispose of usedengine oil, refer to page 2-15.
Recommended engine oil vis-cosity
BK0203201EN.book 5 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Engine coolant/Plug-in hybrid EV system coolant11-6 Maintenance
11
E01000503105
A transparent engine coolant reserve tank (A)and EV cooling system reserve tank (B) islocated in the engine compartment.The coolant level in this tank should be keptbetween the “LOW” and “FULL” markswhen measured while the engine and theplug-in hybrid EV system are cold.
The cooling system is a closed system andnormally the loss of coolant should be veryslight. A noticeable drop in the coolant levelcould indicate leakage. If this occurs, we rec-ommend you to have the system checked assoon as possible.
If the level should drop below the “LOW”level on the reserve tank, open the lid and addcoolant.Also, if the reserve tank is completely empty,remove the radiator cap (C) or the reservetank cap (D) and add coolant until the levelreaches the filler neck.The engine coolant and the plug-in hybrid EVsystem coolant contains an ethylene glycolanti-corrosion agent. Some parts of theengine and the plug-in hybrid EV system arecast aluminium alloy, and periodic changingof the engine coolant and the plug-in hybridEV system coolant are necessary to preventcorrosion of these parts.
NOTE
zUse of additives is
not recommended since
they may reduce the effectiveness of addi-tives already included in the engine oil. Itmay result in failure of the mechanicalassembly.
Engine coolant/Plug-in hybrid EV system coolant To c h e c k t h e c o o l a n t l e v e l
*:Front of the vehicle
To a d d c o o l a n t
FULLLOW
FULLLOW
WA R N I N GzDo not open the radiator cap (C) and thereserve tank cap (D) while the engine andthe plug-in hybrid EV system are hot. Thecoolant system is under pressure and anyhot coolant escaping could cause severeburns.
Anti-freeze Use “MITSUBISHI MOTORS GENUINESUPER LONG LIFE COOLANT PRE-MIUM” or equivalent
*.
BK0203201EN.book 6 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Washer fluid
Maintenance 11-7
11
MITSUBISHI MOTORS GENUINE Coolanthas excellent protection against corrosion andrust formation of all metals including alumin-ium and can avoid blockages in the radiator,heater, cylinder head, engine block, etc.Because of the necessity of this anti-corrosionagent, the coolant must not be replaced withplain water even in summer. The requiredconcentration of anti-freeze differs dependingon the expected ambient temperature.Above -35 °C: 50 % concentration of anti-freezeBelow -35 °C: 60 % concentration of anti-freeze
If the temperatures in your area drop belowfreezing, there is the danger that the coolantin the engine, plug-in hybrid EV system orradiator could freeze and cause severe dam-age to the engine and/or radiator. Add a suffi-cient amount of anti-freeze to the coolant toprevent it from freezing.The concentration should be checked beforethe start of cold weather and anti-freezeadded to the system if necessary.
E01000700890
Open the washer fluid reservoir cap andcheck the level of washer fluid with the dip-stick.If the level is low, replenish the containerwith washer fluid.
To e n s u r e p r o p e r o p e r a t i o n o f t h e w a s h e r s a tlow temperatures, use a fluid containing ananti-freezing agent.
E01000801696
The fluid level must be between the “MAX”and “MIN” marks on the reservoir.
*: similar high quality ethylene glycol basednon-silicate, non-amine, non-nitrate andnon-borate coolant with long life hybridorganic acid technologyCAUTIONzDo not use alcohol or methanol anti-freeze orany engine coolants
mixed with alcohol or
methanol anti-freeze. The use of an improperanti-freeze can cause corrosion of the alu-minium components.zDo not use water to adjust the concentrationof coolant.zConcentrations exceeding 60 % will result ina reduction of both the anti-freeze and cool-ing performance thus adversely affecting theengine.
zDo not top up with water only.Wa t e r b y i t s e l f r e d u c e s t h e r u s t - p r o t e c t i v eand anti-freeze qualities of the coolant andhas a lower boiling point. It can also causedamage to the cooling system if it shouldfreeze. Do not use tapwater, as it can causecorrosion and rust formation.
During cold weatherWa s h e r f l u i d
CAUTION
NOTE
zThe washer fluid container serves the wind-screen, rear window and headlamps (if soequipped).
During cold weather Brake fluid To c h e c k t h e f l u i d l e v e l
EMPTY
FULL
BK0203201EN.book 7 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Auxiliary battery11-8 Maintenance
11
The fluid level is monitored by a float. Whenthe fluid level falls below the “MIN” mark,the brake fluid warning lamp lights up.The fluid level falls slightly with wear of thebrake pads, but this does not indicate anyabnormality.The fluid in the master cylinder should bechecked when doing other work under the
bonnet. The brake system should also bechecked for leaks at the same time.If the fluid level falls markedly in a shortlength of time, it indicates leaks from thebrake system.If this occurs, we recommend you to have thevehicle checked.Use brake fluid conforming to DOT3 orDOT4 from a sealed container. The brakefluid is hygroscopic. Too much moisture inthe brake fluid will adversely affect the brakesystem, reducing the performance.
E01001203284
The condition of the auxiliary battery is veryimportant for quick starting of the plug-inhybrid EV system and proper functioning ofthe vehicle’s electrical system. Regularinspection is especially important in coldweather. Be sure to have a MITSUBISHIMOTORS Authorized Service Point checkthe auxiliary battery.
LHDRHD
Fluid type
CAUTIONzTa k e c a r e i n h a n d l i n g b r a k e f l u i d a s i t i sharmful to the eyes,
may irritate your skin
and also damage to painted surfaces.zUse only the specified brake fluid.Do not mix or add different brand of brakefluid to prevent chemical reaction.Do not let any petrol
eum-based fluid touch,
mix with, or get into the brake fluid.This will damage the seals.zKeep the reservoir tank cap closed to preventthe brake fluid from deteriorating exceptmaintenance.zClean the filler cap before removing andclose the cap securely after maintenance.
Auxiliary battery
WA R N I N GzBe sure to have a MITSUBISHI MOTORSAuthorized Service Point charge the bat-tery. Do not charge the battery yourself.Flammable gases may leak and explode.CAUTIONzThere is a type of auxiliary battery is notproperly installed in the vehicle, even if thesame specification.When replacing the auxiliary battery, pleasecontact a MITSUBISHI MOTORS Author-ized Service Point.
BK0203201EN.book 8 ページ ２０１３年１１月１９日　火曜日　午前１１時５０分

Tyres
Maintenance 11-9
11
E01001300255
NOTE
zWhen the auxiliary battery is removed, thecontrolling timer for forcibly starting theengine may be reset. Since a fuel injection device may cause aclogging if the state where the engine doesnot operate continues after reset of the timer,please press the battery charge switch inorder to start the engi
ne. However, when the
drive battery is near full charge, even if thebattery charge switch is
pressed, the engine
may not start. In that case, press the batterycharge switch again after the drive batteryquantity decreases. Refer to “Battery chargeswitch” on page 7-23.zWhen the auxiliary batte
ry is removed, since
the timer control of the MITSUBISHIRemote Control is reset and the drive batterytemperature control can not be used, commu-nicate the wireless LAN device and yourvehicle again.zWhen the auxiliary battery is removed, thetimer control of the MITSUBISHI RemoteControl is reset and each function of theMITSUBISHI Remote Control can not beused. Also the drive battery can not bewarmed up.Communicate the wireless LAN device andyour vehicle again.
Ty r e s
WA R N I N GzDriving with tyres that are worn, damagedor improperly inflated can lead to a loss ofcontrol or blow out of the tyres which canresult in a collision with serious or fatalinjury.
