NISSAN TEANA 2008 Service Manual
Manufacturer: NISSAN, Model Year: 2008, Model line: TEANA, Model: NISSAN TEANA 2008Pages: 5121, PDF Size: 69.03 MB
Page 311 of 5121
![NISSAN TEANA 2008 Service Manual AV
NORMAL OPERATING CONDITION
AV-167
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003882786
BASIC OPERATIONS
RE NISSAN TEANA 2008 Service Manual AV
NORMAL OPERATING CONDITION
AV-167
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003882786
BASIC OPERATIONS
RE](/img/5/57391/w960_57391-310.png)
AV
NORMAL OPERATING CONDITION
AV-167
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000003882786
BASIC OPERATIONS
RELATED TO AUDIO
The majority of the audio malfunctions are the result of outside causes (bad CD/cassette, electromagnetic
interference, etc.). Check the symptoms below to diagnose the malfunction.
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and oper-
ation of each piece of electrical equipment, and then determine the cause.
NOTE:
CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incor-
rectly mastered by the customer on a computer.
Check if the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the red book Compact Disc
Standard and may not play.
Symptom Possible cause Possible solution
No image is displayed.The brightness is at the lowest setting. Adjust the brightness of the display.
The system in the video mode. Push
The display is turned off. Push
The screen is too dim. The move-
ment is slow.The temperature in the interior of the vehicle is low. Wait until the interior of the vehicle has
warmed up.
Some pixels in the display are dark-
er or brighter than others.This condition is an inherent characteristic of liquid
crystal displays.This is not a malfunction.
Some menu items cannot be se-
lected.Some menu items become unavailable while the ve-
hicle is driven.Park the vehicle in a safe location, and
then operate the multi AV system.
Symptom Cause and Counter measure
Cannot playCheck if the CD was inserted correctly.
Check if the CD is scratched or dirty.
Check if there is condensation inside the player, and if there is, wait until the condensation is gone
(about 1 hour) before using the player.
If there is a temperature increase error, the player will play correctly after it returns to the normal
temperature.
If there is a mixture of music CD files (CD-DA data) and MP3/WMA files on a CD, only the music
CD files (CD-DA data) will be played.
Files with extensions other than “.MP3”, “.WMA”, “.mp3”, or “.wma” cannot be played. In addition,
the character codes and number of characters for folder names and file names should be in com-
pliance with the specifications.
Check if the disc or the file is generated in an irregular format, This may occur depending on the
variation or the setting of MP3/WMA writing applications or other text editing applications.
Check if the finalization process, such as session close and disc close, is done for the disc.
Check if the CD is protected by copyright.
Poor sound quality Check if the CD is scratched or dirty.
It takes a relatively long time before
the music starts playing.If there are many folder or file levels on the MP3/WMA CD, or if it is a multisession disc, some
time may be required before the music starts playing.
Music cuts off or skipsThe writing software and hardware combination might not match, or the writing speed, writing
depth, writing width might not match the specifications. Try using the slowest writing speed.
Skipping with high bit rate files Skipping may occur with large quantities if data such as for high bit rate data.
Page 312 of 5121
![NISSAN TEANA 2008 Service Manual AV-168
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
NORMAL OPERATING CONDITION
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise f NISSAN TEANA 2008 Service Manual AV-168
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
NORMAL OPERATING CONDITION
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise f](/img/5/57391/w960_57391-311.png)
AV-168
< SYMPTOM DIAGNOSIS >[BASE AUDIO AND DISPLAY SYSTEM]
NORMAL OPERATING CONDITION
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other
sources, is not a malfunction.
NOTE:
Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking
the signal.
Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the
antenna and the waves reflected by mountains or buildings. Move immediately to the next song
when playingWhen a non-MP3/WMA file has been given an extension of “.MP3”, “.WMA”, “.mp3”, or “.wma”,
or when play is prohibited by copyright protection, the player will skip to the next song.
The songs do not play back in the
desired order.The playback order is the order in which the files were written by the software, so the files might
not play in the desired order. Symptom Cause and Counter measure
Page 313 of 5121
![NISSAN TEANA 2008 Service Manual AV
PRECAUTIONS
AV-169
< PRECAUTION >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE NISSAN TEANA 2008 Service Manual AV
PRECAUTIONS
AV-169
< PRECAUTION >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE](/img/5/57391/w960_57391-312.png)
AV
PRECAUTIONS
AV-169
< PRECAUTION >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000003960542
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the “SRS AIRBAG” and
“SEAT BELT” of this Service Manual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SRS AIRBAG”.
Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-
vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness
connectors.
Precaution for Trouble DiagnosisINFOID:0000000003882788
AV COMMUNICATION SYSTEM
Do not apply voltage of 7.0 V or higher to the measurement terminals.
Use the tester with its open terminal voltage being 7.0 V or less.
Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before
checking the circuit.
Precaution for Harness RepairINFOID:0000000003882789
AV COMMUNICATION SYSTEM
Solder the repaired parts, and wrap with tape. [Frays of twisted line
must be within 110 mm (4.33 in).]
Do not perform bypass wire connections for the repair parts. (The
spliced wire will become separated and the characteristics of
twisted line will be lost.)
PKIA0306E
PKIA0307E
Page 314 of 5121
![NISSAN TEANA 2008 Service Manual AV-170
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
AV CONTROL UNIT
ON-VEHICLE REPAIR
AV CONTROL UNIT
Exploded ViewINFOID:0000000003940154
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
NISSAN TEANA 2008 Service Manual AV-170
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
AV CONTROL UNIT
ON-VEHICLE REPAIR
AV CONTROL UNIT
Exploded ViewINFOID:0000000003940154
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY](/img/5/57391/w960_57391-313.png)
AV-170
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
AV CONTROL UNIT
ON-VEHICLE REPAIR
AV CONTROL UNIT
Exploded ViewINFOID:0000000003940154
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003940155
REMOVAL
1. Remove instrument finisher C. Refer to IP-12, "Removal and Installation".
2. Remove cluster lid D. Refer to IP-12, "
Removal and Installation".
3. Remove AV control unit with A/C amp. as a single unit from the body.
4. Remove bracket screws, and then remove AV control unit.
INSTALLATION
Installation is the reverse order of removal.
1. AV control unit 2. Bracket LH 3. A/C auto amp.
4. Bracket RH
JPNIA1034ZZ
Page 315 of 5121
![NISSAN TEANA 2008 Service Manual AV
DISPLAY UNIT
AV-171
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DISPLAY UNIT
Exploded ViewINFOID:0000000003940156
REMOVAL
Refer to IP-11, "Exploded View".
DISA NISSAN TEANA 2008 Service Manual AV
DISPLAY UNIT
AV-171
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DISPLAY UNIT
Exploded ViewINFOID:0000000003940156
REMOVAL
Refer to IP-11, "Exploded View".
DISA](/img/5/57391/w960_57391-314.png)
AV
DISPLAY UNIT
AV-171
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DISPLAY UNIT
Exploded ViewINFOID:0000000003940156
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003940157
REMOVAL
1. Remove cluster lid D. Refer to IP-12, "Removal and Installation".
2. Remove display unit mounting screws, and then disconnect the display unit connector.
3. Remove display unit.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1035ZZ
1. Display unit
Page 316 of 5121
![NISSAN TEANA 2008 Service Manual AV-172
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT DOOR SPEAKER
FRONT DOOR SPEAKER
Exploded ViewINFOID:0000000003940158
Removal and InstallationINFOID:0000000003940159
REMOVAL
1. Remove NISSAN TEANA 2008 Service Manual AV-172
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT DOOR SPEAKER
FRONT DOOR SPEAKER
Exploded ViewINFOID:0000000003940158
Removal and InstallationINFOID:0000000003940159
REMOVAL
1. Remove](/img/5/57391/w960_57391-315.png)
AV-172
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT DOOR SPEAKER
FRONT DOOR SPEAKER
Exploded ViewINFOID:0000000003940158
Removal and InstallationINFOID:0000000003940159
REMOVAL
1. Remove front door finisher. Refer to INT-30, "DRIVER SIDE : Removal and Installation" (driver side) or
INT-33, "
PASSENGER SIDE : Removal and Installation" (passenger side).
2. Remove front door speaker mounting bolts, disconnect the front door speaker connector.
3. Remove front door speaker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1036ZZ
1. Front door speaker
Page 317 of 5121
![NISSAN TEANA 2008 Service Manual AV
REAR DOOR SPEAKER
AV-173
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
REAR DOOR SPEAKER
Exploded ViewINFOID:0000000003940160
Removal and InstallationINFOID:0000 NISSAN TEANA 2008 Service Manual AV
REAR DOOR SPEAKER
AV-173
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
REAR DOOR SPEAKER
Exploded ViewINFOID:0000000003940160
Removal and InstallationINFOID:0000](/img/5/57391/w960_57391-316.png)
AV
REAR DOOR SPEAKER
AV-173
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
REAR DOOR SPEAKER
Exploded ViewINFOID:0000000003940160
Removal and InstallationINFOID:0000000003940161
REMOVAL
1. Remove rear door finisher. Refer to INT-36, "Removal and Installation".
2. Remove rear door speaker mounting bolts, disconnect the rear door speaker connector.
3. Remove rear door speaker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1037ZZ
1. Rear door speaker
Page 318 of 5121
![NISSAN TEANA 2008 Service Manual AV-174
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT SQUAWKER
FRONT SQUAWKER
Exploded ViewINFOID:0000000003940162
Removal and InstallationINFOID:0000000003940163
REMOVAL
1. Remove the spe NISSAN TEANA 2008 Service Manual AV-174
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT SQUAWKER
FRONT SQUAWKER
Exploded ViewINFOID:0000000003940162
Removal and InstallationINFOID:0000000003940163
REMOVAL
1. Remove the spe](/img/5/57391/w960_57391-317.png)
AV-174
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
FRONT SQUAWKER
FRONT SQUAWKER
Exploded ViewINFOID:0000000003940162
Removal and InstallationINFOID:0000000003940163
REMOVAL
1. Remove the speaker grille with squawker. Refer to IP-12, "Removal and Installation".
2. Remove front squawker mounting screws, lift up the front squawker and disconnect front squawker con-
nector.
3. Remove front squawker.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1038ZZ
1. Front squawker
Page 319 of 5121
![NISSAN TEANA 2008 Service Manual AV
ANTENNA AMP.
AV-175
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
ANTENNA AMP.
Exploded ViewINFOID:0000000003940164
Removal and InstallationINFOID:00000000039401 NISSAN TEANA 2008 Service Manual AV
ANTENNA AMP.
AV-175
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
ANTENNA AMP.
Exploded ViewINFOID:0000000003940164
Removal and InstallationINFOID:00000000039401](/img/5/57391/w960_57391-318.png)
AV
ANTENNA AMP.
AV-175
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
ANTENNA AMP.
Exploded ViewINFOID:0000000003940164
Removal and InstallationINFOID:0000000003940165
REMOVAL
1. Remove rear side pillar finisher. Refer to INT-39, "Removal and Installation".
2. Disconnect antenna feeder connector and clip.
3. Remove antenna amp. mounting nut, disconnect the antenna amp. connector.
4. Remove antenna amp.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1032ZZ
1. AM-FM main connector
2. Antenna amp.
Page 320 of 5121
![NISSAN TEANA 2008 Service Manual AV-176
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH
Exploded ViewINFOID:0000000003940166
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal NISSAN TEANA 2008 Service Manual AV-176
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH
Exploded ViewINFOID:0000000003940166
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal](/img/5/57391/w960_57391-319.png)
AV-176
< ON-VEHICLE REPAIR >[BASE AUDIO AND DISPLAY SYSTEM]
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH
Exploded ViewINFOID:0000000003940166
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003940167
REMOVAL
1. Remove cluster lid D. Refer to IP-12, "Removal and Installation".
2. Remove multifunction switch mounting screws.
3. Remove multifunction switch.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1052ZZ
1. Cluster lid D
2. Multifunction switch
