NISSAN TEANA 2008 Service Manual
Manufacturer: NISSAN, Model Year: 2008, Model line: TEANA, Model: NISSAN TEANA 2008Pages: 5121, PDF Size: 69.03 MB
Page 341 of 5121
![NISSAN TEANA 2008 Service Manual AV
REAR VIEW MONITOR SYSTEM
AV-197
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PREDICTED COURSE LINE OPERATION PRINCIPLE
Detection Of Steering Rotation Direction NISSAN TEANA 2008 Service Manual AV
REAR VIEW MONITOR SYSTEM
AV-197
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PREDICTED COURSE LINE OPERATION PRINCIPLE
Detection Of Steering Rotation Direction](/img/5/57391/w960_57391-340.png)
AV
REAR VIEW MONITOR SYSTEM
AV-197
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PREDICTED COURSE LINE OPERATION PRINCIPLE
Detection Of Steering Rotation Direction
Camera control unit detects the rotation direction of steering according to the phase difference of two pairs of
pulse signals (sensor signal 1 and sensor signal 2) input from steering angle sensor.
Detection Of Steering Neutral Position
The sensor signal 3 input from steering angle sensor is generated at 1 pulse per 1 rotation of the steering
wheel. Camera control unit detects the steering neutral position from this pulse.
Correction Of Steering Neutral Position
Camera control unit corrects the steering neutral position during driving according to the vehicle speed signal
and sensor signal.
JSNIA0708GB
Page 342 of 5121
![NISSAN TEANA 2008 Service Manual AV-198
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
REAR VIEW MONITOR SYSTEM
Component Parts Location
INFOID:0000000003791258
1. Front squawker RH 2. Center speaker 3. Front squawker LH
4. Fr NISSAN TEANA 2008 Service Manual AV-198
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
REAR VIEW MONITOR SYSTEM
Component Parts Location
INFOID:0000000003791258
1. Front squawker RH 2. Center speaker 3. Front squawker LH
4. Fr](/img/5/57391/w960_57391-341.png)
AV-198
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
REAR VIEW MONITOR SYSTEM
Component Parts Location
INFOID:0000000003791258
1. Front squawker RH 2. Center speaker 3. Front squawker LH
4. Front door speaker LH 5. Rear door speaker LH 6. Rear control switch
7. Rear squawker LH 8. Woofer LH 9. BOSE amp.
10. Rear view camera 11. Woofer RH 12. Camera control unit
13. Rear squawker RH 14. Antenna amp. 15. Rear door speaker RH
16. Front door speaker RH 17. Steering angle sensor 18. Steering switch
19. AV control unit 20. Auxiliary input jacks 21. Preset switch
22. DVD player 23. Multifunction switch 24. Display unit
A. Trunk room upper RH B. Trunk room side RH C. Within rear pillar finisher RH
D. Spiral cable part E. In center console F. In grove box
JPNIA1058ZZ
Page 343 of 5121
![NISSAN TEANA 2008 Service Manual AV
REAR VIEW MONITOR SYSTEM
AV-199
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Component DescriptionINFOID:0000000003791251
Part name Description
AV CONTROL UNIT NISSAN TEANA 2008 Service Manual AV
REAR VIEW MONITOR SYSTEM
AV-199
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Component DescriptionINFOID:0000000003791251
Part name Description
AV CONTROL UNIT](/img/5/57391/w960_57391-342.png)
AV
REAR VIEW MONITOR SYSTEM
AV-199
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Component DescriptionINFOID:0000000003791251
Part name Description
AV CONTROL UNIT Image on display is transmitted to rear view monitor image by serial communi-
cation between AV control unit and display unit.
AV control unit recognizes the presence of camera system with camera con-
nection recognition signal.
DISPLAY UNIT Camera image signal is input from AV control unit.
Rear view monitor image is changed by serial communication from AV control
unit.
CAMERA CONTROL UNIT Camera image signal is input from rear view camera. Camera image signal is
output to AV control unit.
Power supply is transmitted to rear view camera.
Superimposes the guiding line and predicted course line to the camera image
that outputs to AV control unit.
Inputs the sensor signal from steering angle sensor, and then controls the pre-
dicted course line.
Camera control unit is connected via AV communication.
REAR VIEW CAMERA The image of vehicle rear view is transmitted to camera control unit.
It receives power supply from camera control unit and operates.
STEERING ANGLE SENSORSteering signal necessary for predicted course line control is transmitted to cam-
era control unit.
Page 344 of 5121
![NISSAN TEANA 2008 Service Manual AV-200
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Diagnosis DescriptionINFOID:0000000003765657
MULTIFUNCTION SWITCH AND NISSAN TEANA 2008 Service Manual AV-200
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Diagnosis DescriptionINFOID:0000000003765657
MULTIFUNCTION SWITCH AND](/img/5/57391/w960_57391-343.png)
AV-200
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Diagnosis DescriptionINFOID:0000000003765657
MULTIFUNCTION SWITCH AND PRESET SWITCH SELF-DIAGNOSIS FUNCTION
The ON/OFF operation (continuity) of each switch in the multifunction switch and preset switch can be
checked.
Self-diagnosis Mode
Press the “BACK” switch and the “UP” switch of the 4-direction
switches within 10 seconds after turning the ignition switch from
OFF to ACC and hold them for 3 seconds or more. Then the
buzzer sounds, all indicators of the preset switch illuminate, and
the self-diagnosis mode starts.
The continuity of each switch at the ON position can be checked
by pressing the switch. The buzzer sounds if the switch is normal.
NOTE:
The hazard switch and disk eject switch cannot be checked.
Finishing Self-diagnosis Mode
Self-diagnosis mode is canceled when turning the ignition switch OFF.
MULTI AV SYSTEM ON BOARD DIAGNOSIS FUNCTION
The AV control unit diagnosis function starts up with multifunction switch operation and the AV control unit
performs a diagnosis for each unit in the system during the on board diagnosis.
Perform a CONSULT-III diagnosis if the on board diagnosis does not start, e.g., the screen does not display
anything, the multifunction switch does not function, etc.
ON BOARD DIAGNOSIS
Description
The trouble diagnosis function has a self-diagnosis mode for conducting trouble diagnosis automatically and
a confirmation/adjustment mode for operating manually.
Self-diagnosis mode performs the AV control unit diagnosis and the connection diagnosis between each of
the units that make up the system, and it indicates the results to the display.
The confirmation/adjustment mode allows the technician to check, modify or adjust the vehicle signals and
set values, as well as to monitor the system error records and system communication status. The check,
modify or adjust actions generally require human intervention and judgment (the system cannot make judg-
ment automatically).
On Board Diagnosis Item
JSNIA1284GB
Mode Description
Self Diagnosis AV control unit diagnosis.
Diagnoses the connections across system components.
Page 345 of 5121
![NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-201
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is su NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-201
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is su](/img/5/57391/w960_57391-344.png)
AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-201
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
NOTE:
*:On-board self-diagnosis is not supported. Only CONSULT-III is supported.
STARTING PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “SETTING” button, turn the volume control
dial clockwise or counterclockwise for 40 clicks or more. (When
the self-diagnosis mode is started, a short beep will be heard.)
Shifting from current screen to previous screen is performed
by pressing “BACK” button.
4. The trouble diagnosis initial screen is displayed, and then the
items of “Self Diagnosis” and “Confirmation/Adjustment” can be
selected.
SELF-DIAGNOSIS MODE
1. Start the self-diagnosis function and select “Self Diagnosis”.
- Self-diagnosis subdivision screen is displayed, and the self-diagnosis mode starts.
- The bar graph visible on the center of the self-diagnosis subdivision screen indicates progress of the trou-
ble diagnosis.
Confirmation/
AdjustmentDisplay DiagnosisThe following check functions are available: color tone check by color
bar display, light and shade check by grey scale display and touch panel
calibration response check.
Vehicle SignalsDiagnosis of signals can be performed for vehicle speed, parking brake,
lights, ignition switch, and reverse.
Speaker Test The connection of a speaker can be confirmed by test tone.
Climate Control
*Not used.
Error HistoryThe system malfunction and the frequency when occurred in the past are
displayed. When the malfunctioning item is selected, the time and place
that the selected malfunction last occurred are displayed.
Camera Cont.It can perform the confirmation of a signal connection to the camera con-
trol unit, the calibration of each camera, Correct Draw Line of Camera
Image, and Fine Tuning of Birds-Eye View.
Refer to AV- 2 0 0 , "
Diagnosis Description".
Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored.
AV COMM DiagnosisThe communication condition of each unit of Multi AV system can be
monitored.
Delete Unit Connection Log Erase the connection history of unit and error history.
Initialize Settings Initializes the AV control unit memory.Mode Description
JSNIA1285GB
JSNIA0138GB
Page 346 of 5121
![NISSAN TEANA 2008 Service Manual AV-202
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
2. Diagnosis results are displayed after the self-diagnosis is com-
pleted. The unit names and the conne NISSAN TEANA 2008 Service Manual AV-202
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
2. Diagnosis results are displayed after the self-diagnosis is com-
pleted. The unit names and the conne](/img/5/57391/w960_57391-345.png)
AV-202
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
2. Diagnosis results are displayed after the self-diagnosis is com-
pleted. The unit names and the connection lines are color-coded
according to the diagnostic results.
NOTE:
Only the control unit (AV control unit) is displayed in red.
Replace AV control unit if “Self-Diagnosis did not run because of a control unit malfunction” is indicated.
The symptom is AV control unit internal error. Refer to AV-378, "
Removal and Installation".
- If multiple errors occur at the same time for a single unit, the screen switch colors are determined accord-
ing to the following order of priority: red > yellow > gray.
- The comments of the self-diagnosis results can be viewed with a
component in the diagnosis result screen.
SELF-DIAGNOSIS RESULTS
The self-diagnosis mode allows the technician to diagnose the connection in the communication line
between AV control unit and each unit and the internal operation of the AV control unit.
Because the start condition of diagnosis function is a switch operation, the on board diagnosis function can-
not be started up if any malfunction is detected in the communication circuit between AV control unit and
multifunction switch.
Check the applicable display in the following table, and then repair the malfunctioning parts.
Self-diagnosis Result Chart
Diagnosis results UnitCon-
nection
line
Normal Green Green
Connection malfunction Gray Yellow
Unit malfunction
NoteRed GreenJSNIA1286GB
JSNIA0141GB
Area with yellow connection lines DescriptionPossible malfunction location / Action
to take
NOTE:
When a control unit malfunction is detected (red in
unit display), connection malfunctions with other
connection unit may be displayed.Malfunction is detected in AV control
unit power supply and ground circuitsCheck AV control unit power supply
and ground circuits. When detecting
no malfunction in those components,
replace AV control unit.
“Self-Diagnosis did not run because of a control unit
malfunction”
JSNIA1326GB
Page 347 of 5121
![NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-203
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
When either one of the following
items is detected:
BOSE amp. malfunc NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-203
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
When either one of the following
items is detected:
BOSE amp. malfunc](/img/5/57391/w960_57391-346.png)
AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-203
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
When either one of the following
items is detected:
BOSE amp. malfunction is detected.
sound signal circuits between BOSE
amp. and each speaker is malfunc-
tioning. Replace BOSE amp.
Malfunctioning speaker circuits
When either one of the following
items is detected:
DVD player power supply and
ground circuits are malfunctioning.
AV communication circuits between
BOSE amp. and DVD player are
malfunctioning.
AV communication signal between
AV control unit and DVD player is
malfunctioning. DVD player power supply and
ground circuits
AV communication circuits between
BOSE amp. and DVD player
When either one of the following
items is detected:
BOSE amp. power supply and
ground circuits are malfunctioning.
AV communication signal between
AV control unit and BOSE amp. is
malfunctioning.BOSE amp. power supply and ground
circuits
Camera connection recognition signal
circuit is detected.Camera connection recognition signal
circuit Area with yellow connection lines DescriptionPossible malfunction location / Action
to take
JPNIA1092GB
JSNIA1327GB
JSNIA1328GB
JSNIA1329GB
Page 348 of 5121
![NISSAN TEANA 2008 Service Manual AV-204
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
CONFIRMATION/ADJUSTMENT MODE
1. Start the diagnosis function and select “Confirmation/Adjustment”. T NISSAN TEANA 2008 Service Manual AV-204
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
CONFIRMATION/ADJUSTMENT MODE
1. Start the diagnosis function and select “Confirmation/Adjustment”. T](/img/5/57391/w960_57391-347.png)
AV-204
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
CONFIRMATION/ADJUSTMENT MODE
1. Start the diagnosis function and select “Confirmation/Adjustment”. The confirmation/adjustment mode
indicates where each item can be checked or adjusted.
2. Select each switch on the “Confirmation/Adjustment Mode”
screen to display the relevant trouble diagnosis screen. Press
the “BACK” switch to return to the initial Confirmation/Adjust-
ment Mode screen.
When either one of the following
items is detected:
rear control switch power supply and
ground circuits are malfunctioning.
AV communication signal between
AV control unit and rear control
switch is malfunctioning.Rear control switch power supply and
ground circuits
With rear control switch
When either one of the following
items is detected:
malfunction is detected in AV com-
munication circuits between rear
control switch and camera control
unit.
malfunction is detected in AV com-
munication circuits between camera
control unit and BOSE amp. AV communication circuits between
rear control switch and camera con-
trol unit
AV communication circuits between
camera control unit and BOSE amp.
Without rear control switch
When either one of the following
items is detected:
malfunction is detected in AV com-
munication circuits between multi-
function switch and camera control
unit.
malfunction is detected in AV com-
munication circuits between camera
control unit and BOSE amp. AV communication circuits between
multifunction switch and camera
control unit
AV communication circuits between
camera control unit and BOSE amp.
Malfunction is detected in AV commu-
nication circuits between AV control
unit and multifunction switch.AV communication circuits between
AV control unit and multifunction
switch Area with yellow connection lines DescriptionPossible malfunction location / Action
to take
JSNIA1330GB
JSNIA1331GB
JSNIA1332GB
JSNIA0147GB
Page 349 of 5121
![NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-205
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P Display Diagnosis
The tint of the color bar indication is as per the fol NISSAN TEANA 2008 Service Manual AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-205
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P Display Diagnosis
The tint of the color bar indication is as per the fol](/img/5/57391/w960_57391-348.png)
AV
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
AV-205
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P Display Diagnosis
The tint of the color bar indication is as per the following list if RGB signal error is detected.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the system.
Sp ea ke r Tes t
JSNIA0688GB
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
JSNIA0149GB
Diagnosis item Display Vehicle status Remarks
Vehicle speedON Vehicle speed > 0 km/h (0 MPH)
Changes in indication may be delayed by approximately
1.5 seconds. This is normal. OFF Vehicle speed = 0 km/h (0 MPH)
Parking brakeON Parking brake is applied.
OFF Parking brake is released.
LightsON Light switch ON
Block the light beam from the auto light optical sensor.
OFF Light switch OFF
IgnitionON Ignition switch ON
—
OFF Ignition switch in ACC position
ReverseONShift the selector lever to “R” posi-
tion
Changes in indication may be delayed by approximately
1.5 seconds. This is normal.
OFFShift the selector lever other than
“R” position
Page 350 of 5121
![NISSAN TEANA 2008 Service Manual AV-206
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Select “SPEAKER DIAGNOSIS” to display the Speaker Diagnosis
screen. Press “START and NEXT” to ge NISSAN TEANA 2008 Service Manual AV-206
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Select “SPEAKER DIAGNOSIS” to display the Speaker Diagnosis
screen. Press “START and NEXT” to ge](/img/5/57391/w960_57391-349.png)
AV-206
< FUNCTION DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
DIAGNOSIS SYSTEM (AV CONTROL UNIT)
Select “SPEAKER DIAGNOSIS” to display the Speaker Diagnosis
screen. Press “START and NEXT” to generate a test tone in a
speaker. Press “Start” to generate a test tone in the next speaker.
Press “End” to stop the test tones.
NOTE:
The frequency of test tone emitted from each speaker is as follows.
Climate Control
On-board self-diagnosis is not supported. Only CONSULT-III is supported.
Refer to HAC-156, "
WITHOUT INTELLIGENT AIR CONDITIONER SYSTEM : CONSULT-III Function" for
details.
Camera Cont.
Refer to AV-196, "System Description".
Error History
The self-diagnosis results are judged depending on whether any error occurs from when “Self-diagnosis” is
selected until the self-diagnosis results are displayed.
However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned
ON and then no error has occurred until the self-diagnosis start. Check the “Error Record” to detect any error
that may have occurred before the self-diagnosis start because of this situation.
The error record displays the time and place of the most recent occurrence of that error. However, take note of
the following points.
Place of the error occurrence is represented by the position of the current location mark at the time an error
occurred. If current location mark has deviated from the correct position, then the place of the error occur-
rence cannot be located correctly.
The frequency of occurrence is displayed in a count up manner. The actual count up method differs depend-
ing on the error item.
Count up method A
The counter resets to 0 if an error occurs when IGN switch is turned ON. The counter increases by 1 if the
condition is normal at a next IGN ON cycle.
The counter upper limit is 39. Any counts exceeding 39 are ignored.“ The counter can be reset (no error
record display) with the “Delete log” switch or CONSULT-III.
Count up method B
The counter increases by 1 if an error occurs when IGN switch is ON. The counter will not decrease even if
the condition is normal at the next IGN ON cycle.
The counter upper limit is 50. Any counts exceeding 50 are ignored. “ The counter can be reset (no error
record display) with the “Delete log” switch or CONSULT-III.Squawker : 3 kHz
Front speaker : 300 Hz
Rear speaker : 1 kHz
JSNIA0150GB
Display type of occur-
rence frequencyError history display item
Count up method A CAN communication line, control unit (CAN), AV communication line, control unit (AV communication)
Count up method B Other than the above
