NISSAN TEANA 2008 Service Manual

AV
POWER SUPPLY AND GROUND CIRCUIT
AV-237
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
2.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the harness connector between display unit and AV control unit.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Repair harness or connector.
3.CHECK POWER SUPPLY CIRCUIT (AV CONTROL UNIT SIDE)
1. Connect the AV control unit harness connector.
2. Turn ignition switch ACC.
3. Check voltage between AV control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTED END.
NO >> Replace AV control unit.
4.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector.
3. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTED END.
NO >> Repair harness or connector.
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH : Diagnosis ProcedureINFOID:0000000003901181
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
Signal nameDisplay unit AV control unit
Continuity
Connector No. Terminal No. Connector No. Terminal No.
Ground M492
M12959
Existed
347
Signal nameDisplay unit
GroundContinuity
Connector No. Terminal No.
Inverter VCC
M492
Not existed
Signal VCC 3
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Inverter VCC
M12959
ACC 9 V
Signal VCC 47
Signal nameDisplay unit
GroundContinuity
Connector No. Terminal No.
Ground M49 1 Existed
Power source Fuse No.
Ignition switch ACC or ON 19

AV-238
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between multifunction switch harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between multifunction switch and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect multifunction switch connector.
3. Check continuity between multifunction switch harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
BOSE AMP.
BOSE AMP. : Diagnosis ProcedureINFOID:0000000003901182
1.CHECK FUSE
Check for blown fuses.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between BOSE amp. harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Check harness between BOSE amp. and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE amp. connector.
3. Check continuity between BOSE amp. harness connector and ground.
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
ACC power supply M125 3 ACC Battery voltage
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground M125 1 OFF Existed
Power source Fuse No.
Battery 32, 33
Ignition switch ACC 19
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Battery power supply B22410
OFF
Battery voltage 11
ACC power supply B225 20 ACC

AV
POWER SUPPLY AND GROUND CIRCUIT
AV-239
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Is the inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
CAMERA CONTROL UNIT
CAMERA CONTROL UNIT : Diagnosis ProcedureINFOID:0000000003901183
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUITS
Check voltage between camera control unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between camera control unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect camera control unit connector.
3. Check continuity between camera control unit harness connector and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
DVD PLAYER
DVD PLAYER : Diagnosis ProcedureINFOID:0000000003901184
1.CHECK FUSE
Check for blown fuses.
Is inspection result normal?
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground B2247
OFF Existed
12
Power source Fuse No.
Battery 31
Ignition switch ACC 19
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Battery power supply
B25132 OFF
Battery voltage
ACC power supply 30 ACC
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground B251 31 OFF Existed
Power source Fuse No.
Battery 31
Ignition switch ACC or ON 19

AV-240
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
POWER SUPPLY AND GROUND CIRCUIT
YES >> GO TO 2.
NO >> Be sure to eliminate cause of malfunction before installing new fuse.
2.CHECK POWER SUPPLY CIRCUIT
Check voltage between DVD player harness connectors and ground.
Is inspection result normal?
YES >> GO TO 3.
NO >> Check harness between DVD player and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect DVD player connectors.
3. Check continuity between DVD player harness connectors and ground.
Is inspection result normal?
YES >> INSPECTION END
NO >> Repair harness or connector.
Signal name Connector No. Terminal No. Ignition switch position Voltage (Approx.)
Battery power supply
M2542OFF
Battery voltage
ACC power supply 4 ACC
Signal name Connector No. Terminal No. Ignition switch position Continuity
Ground M254 1 OFF Existed

AV
RGB (R: RED) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
AV-241
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
RGB (R: RED) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
DescriptionINFOID:0000000003765703
Transmit the image displayed with AV control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901185
1.CHECK CONTINUITY RGB (R: RED) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (R: RED) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 17M12940 Existed
Display unit
GroundContinuity
Connector Terminal
M49 17 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 17 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2238J

AV-242
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
RGB (G: GREEN) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
RGB (G: GREEN) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY
UNIT)
DescriptionINFOID:0000000003765705
Transmit the image displayed with AV control unit or NAVI control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901186
1.CHECK CONTINUITY RGB (G: GREEN) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (G: GREEN) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 6 M129 39 Existed
Display unit
GroundContinuity
Connector Terminal
M49 6 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 6 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2236J

AV
RGB (B: BLUE) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
AV-243
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
RGB (B: BLUE) SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY UNIT)
DescriptionINFOID:0000000003765707
Transmit the image displayed with AV control unit or NAVI control unit with RGB signal to the display unit.
Diagnosis ProcedureINFOID:0000000003901187
1.CHECK CONTINUITY RGB (B: BLUE) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB (B: BLUE) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 18M12938 Existed
Display unit
GroundContinuity
Connector Terminal
M49 18 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 18 GroundStart Confirmation / Adjustment
mode, and then display color bar
by selecting “Color Spectrum Bar”
on DISPLAY DIAGNOSIS screen.
SKIB2237J

AV-244
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
RGB SYNCHRONIZING SIGNAL CIRCUIT (AV CONTROL UNIT TO DISPLAY
UNIT)
RGB SYNCHRONIZING SIGNAL CIRCUIT (AV CONTROL UNIT TO DIS-
PLAY UNIT)
DescriptionINFOID:0000000003765709
Transmit the RGB synchronizing signal to the display unit so as to synchronize the RGB image displayed with
AV control unit or NAVI control unit.
Diagnosis ProcedureINFOID:0000000003901188
1.CHECK CONTINUITY RGB SYNCHRONIZING SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 19M12941 Existed
Display unit
GroundContinuity
Connector Terminal
M49 19 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 19 Ground —
SKIB3603E

AV
RGB AREA (YS) SIGNAL CIRCUIT
AV-245
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
RGB AREA (YS) SIGNAL CIRCUIT
DescriptionINFOID:0000000003765711
Transmits the display area of RGB image displayed by AV control unit or NAVI control unit with RGB area (YS)
signal to display unit.
Diagnosis ProcedureINFOID:0000000003901189
1.CHECK CONTINUITY RGB AREA (YS) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector terminal 9 and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK RGB SYNCHRONIZING SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace display unit.
NO >> Replace AV control unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 9 M129 43 Existed
Display unit
GroundContinuity
Connector Terminal
M49 9 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 9 GroundWhen RGB image is displayed. Approx. 5 V
When AUX image is displayed.
PKIB4948J

AV-246
< COMPONENT DIAGNOSIS >[BOSE AUDIO WITHOUT NAVIGATION]
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
DescriptionINFOID:0000000003765713
In composite image (AUX image, camera image), transmit the vertical synchronizing (VP) signal and horizon-
tal synchronizing (HP) signal from display unit to AV control unit so as to synchronize the RGB images dis-
played with AV control unit such as the image quality adjusting menu, etc.
Diagnosis ProcedureINFOID:0000000003901190
1.CHECK CONTINUITY HORIZONTAL SYNCHRONIZING (HP) SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect display unit connector and AV control unit connector.
3. Check continuity between display unit harness connector and AV control unit harness connector.
4. Check continuity between display unit harness connector and ground.
Is inspection result normal?
YES >> GO TO 2.
NO >> Repair harness or connector.
2.CHECK HORIZONTAL SYNCHRONIZING (HP) SIGNAL
1. Connect display unit connector and AV control unit connector.
2. Turn ignition switch ON.
3. Check signal between display unit harness connector terminal and ground using an oscilloscope.
Is inspection result normal?
YES >> Replace AV control unit.
NO >> Replace display unit.
Display unit AV control unit
Continuity
Connector Terminal Connector Terminal
M49 8 M129 45 Existed
Display unit
GroundContinuity
Connector Terminal
M49 8 Not existed
(+)
(−) Condition Reference value Display unit
Connector Terminal
M49 8 Ground —
SKIB3601E
