ANTENNA AMP.
Exploded ViewINFOID:0000000003838345
Removal and InstallationINFOID:0000000003838346
REMOVAL
1. Remove rear side pillar finisher. Refer to INT-39, "Removal and Installation".
2. Disconnect antenna feeder connector and clip.
3. Remove antenna amp. mounting nut, disconnect the antenna amp. connector.
4. Remove antenna amp.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1032ZZ
1. AM-FM main connector
2. Antenna amp.

AV-388
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
MULTIFUNCTION SWITCH
MULTIFUNCTION SWITCH
Exploded ViewINFOID:0000000003838347
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838348
REMOVAL
1. Remove cluster lid D. Refer to IP-11, "Exploded View".
2. Remove multifunction switch mounting screws.
3. Remove multifunction switch.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1043ZZ
1. Cluster lid D
2. Multifunction switch

AV
PRESET SWITCH
AV-389
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
PRESET SWITCH
Exploded ViewINFOID:0000000003838349
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838350
REMOVAL
1. Remove cluster lid C. Refer to IP-12, "Removal and Installation".
2. Remove preset switch mounting screws.
3. Remove preset switch.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
When installing preset switch, do not allow the print wire that connects preset switch and multifunction switch
to get caught in between AV control unit and preset switch.
1. Preset switch 2. Cluster lid C
JPNIA1044ZZ
1. Preset switch
A. Screw
B. Screw
JPNIA1045ZZ

AV-390
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
REAR CONTROL SWITCH
REAR CONTROL SWITCH
Exploded ViewINFOID:0000000003838351
REMOVAL
Refer to SE-98, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838352
REMOVAL
1. Remove rear control switch, stretching pawls of armrest assembly.
2. Disconnect rear control switch connector.
3. Remove rear control switch.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1046ZZ
1. Rear control switch
A. Clip

AV
DVD PLAYER
AV-391
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
DVD PLAYER
Exploded ViewINFOID:0000000003838353
REMOVAL
Refer to IP-11, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838354
REMOVAL
1. Remove grove box. Refer to IP-12, "Removal and Installation"
2. Remove DVD player mounting screw, disconnect the DVD player connector.
3. Remove DVD player.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1047ZZ
1. DVD player

AV-392
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
AUXILIARY INPUT JACKS
AUXILIARY INPUT JACKS
Exploded ViewINFOID:0000000003838355
REMOVAL
Refer to IP-22, "Removal and Installation".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838356
REMOVAL
1. Remove console finisher. Refer to IP-22, "Exploded View".
2. Remove auxiliary mounting screws.
3. Remove auxiliary input jacks.
INSTALLATION
Installation is the reverse order of removal.
JPNIA1048ZZ
1. Auxiliary input jacks

AV
CAMERA CONTROL UNIT
AV-393
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
CAMERA CONTROL UNIT
Exploded ViewINFOID:0000000003838365
Removal and InstallationINFOID:0000000003838366
REMOVAL
1. Remove rear wheelhouse finisher RH. Refer to INT-57, "Removal and Installation".
2. Remove camera control unit mounting screws, disconnect the camera control unit connector.
3. Remove camera control unit.
INSTALLATION
1. Installation is the reverse order of removal.
2. Perform predicted course line center position adjustment. Refer to AV-187, "
PREDICTED COURSE LINE
CENTER POSITION ADJUSTMENT : Special Repair Requirement".
JPNIA1049ZZ
1. Camera control unit

AV-394
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
REAR VIEW CAMERA
REAR VIEW CAMERA
Exploded ViewINFOID:0000000003902723
DISASSEMBLY
Removal and InstallationINFOID:0000000003902724
REMOVAL
1. Remove trunk lid finisher inner. Refer to INT-59, "Removal and Installation".
2. Remove trunk lid finisher. Refer to EXT-38, "
Removal and Installation".
3. Remove rear view camera mounting clip, disconnect the rear view camera connector.
4. Remove rear view camera.
INSTALLATION
1. Installation is the reverse order of removal.
AdjustmentINFOID:0000000003970795
Adjust the guide line position if the guide line position is shifted after installing the rear view camera.
1. Draw lines on rearward area of the vehicle passing through the
following points: 200 mm (7.87 in) from both sides of the vehicle,
and 0.5 m (1.64 ft), 1.0 m (3.28 ft) from the rear end of the
bumper.
2. Set into “Adjust offset of rear view camera” mode of Confirma-
tion / Adjustment mode.
JPNIA1050ZZ
1. Rear view camera
2. Seal
Refer to GI-4, "
Components" for symbols in the figure.
SKIB3691E

AV
REAR VIEW CAMERA
AV-395
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
C
D
E
F
G
H
I
J
K
L
MB A
O
P
3. Rotate the center dial, and then select the guiding line pattern so
that its angle is aligned with the correction line of the rear of the
vehicle.
4. Fine adjust the guiding line so that its position is aligned to the
correction line by pressing the up/down/left/right switches.
Pressing “ENTER” enable the camera control unit to memory
the adjusted guiding line position.
CAUTION:
Never operate other function such as pressing BACK while writing index data.
If Confirmation/Adjustment mode does not function in the above procedure, perform one of the
following service to adjust the index again.
 Remove battery for five min. Then reconnect battery.
 Remove camera control unit connector for five min. Then reconnect camera control unit connec-
tor.Selected pattern : 7
Up/Down adjustment range : −20 – 20
Left/Right adjustment range : −20 – 20
SKIB3689E

AV-396
< ON-VEHICLE REPAIR >[BOSE AUDIO WITHOUT NAVIGATION]
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR
Exploded ViewINFOID:0000000003838369
REMOVAL
Refer to SR-9, "Exploded View".
DISASSEMBLY
Removal and InstallationINFOID:0000000003838370
REMOVAL
1. Remove spiral cable.
2. Remove steering angle sensor mounting screws.
3. Remove steering angle sensor.
INSTALLATION
Installation is the reverse order of removal.
JSNIA0135ZZ
1. Spiral cable
2. Steering angle sensor
